VISIO DL-10 QW 5A User manual

DMX Down Light
DL-10 QW 5A
User Manual

1C
CONTENT
1. Safety Instructions ...................................................................................... 2
2. Features...................................................................................................... 3
3. Technical Specifications.............................................................................. 3
4. How To Control The Fixture ........................................................................ 3
5. Installations................................................................................................. 4
6. Lumen Output............................................................................................. 6
7. Troubleshooting .......................................................................................... 8
8. Cleaning And Maintenance......................................................................... 8

2C
1. Safety Instructions
WARNING
yPlease keep this User Guide for future consultation. If you sell the fixture to
another user, be sure that they also receive this instruction booklet.
Cautions：
yAll fixtures are intact from the manufacturer, please operate follow up the
user manual, artificial fault are not under guarantee repair.
yUnpack and check carefully there is no transportation damage before using
the fixture.
yDo install and operate by qualified technician.
yBefore operating, ensure that the voltage and frequency of power supply
match the power requirements of the fixture.
yIt’s important to ground with yellow/green conductor to earth in order to
avoid electric shock.
yMaximum ambient temperature is 40℃. Don’t operate it where the
temperature is higher than this.
yDon’t connect the device to any dimmer pack.
yMake sure there are no flammable materials close to the fixture while
operating, as it is fire hazard.
yLook over power wires carefully, replace immediately if there is any
damage.
yAvoid any inflammable liquids, water or metal objects entering the fixture.
Once it happens, cut off the mains power immediately.
yDo not operate in dirty and dusty environment, also cleaning fixtures
regularly.
yDo not allow children to operate the fixture.
yDo not touch any wire during operation as there might be a hazard of
electric shock.
yIn the event of serious operating problem, stop using the fixture
immediately.
yDo not open the fixture as there are no user serviceable parts inside. Never
try to repair the fixture by yourself. Repairs carried out by unskilled people
can lead to damage or malfunction. Please contact the nearest authorized
technical assistance center.
yDisconnect the mains power if the fixture is not used for a long time.
Please read the instructions carefully which
includes important information about the
installation, operation and maintenance.

3C
yDo use original packing materials once transport it again.
yDo not look directly at the LED light beam while the fixture is on.
2. Features
zHigh brightness with good efficiency and reliability.
zNo image stacking.
zExcellent color mixing with powerful light output.
zDie-cast aluminum housing with elegant design.
3. Technical Specifications
zInput Voltage: DC24V
zPower Consumption: 14W
zLED: 1X10W CREE Quad-color LED
zDimension: φ135X110.6mm
zInstallation hole dimension: φ125mm
zBeam Angle: 10°, 20°
zWeight: 0.78Kgs
4. How To Control The Fixture
Please set up DMX address & Channel Mode of the fixture by VD-T (sold
separately). VD-T is a specially designed handy setup tool for all Visio integral
fixtures and controllers. By connecting VD-T to any unit via XLR, you can
easily setup DMX Address, Channel Modes, White Balance, Manual Colors,
and Fade Speed functions. If you use VD-T to control the fixture, you can
follow User Manual of VD-T. After you set the address by VD-T, then you can
control the fixture by DMX controller, the DMX 512 configuration is as follows:
Important: Please set up DMX address & Channel Mode of the fixture one by
one before you install the units to ceiling or the desired location.
1
3
5
110.6

4C
5. Installations
5.1 Before install the fixture, please ensure the power is off.
5.1.1 Choose the appropriate location and secure the fixture’s Armature to the
location, then connect power cable and signal line, finally place the aluminum
body into it.

5C
Signal Lin
e
Power Cable
5.1.2 Connect the unit’s power cable and DMX signal cable to the main cables
parallelly as indicated in 5.3 Connection Diagram. There are two wires (red
and black) for power cable, red cable is positive, black cable is grounding.
Three colors red, white and black for signal line, red line is (+), white line is (-)
and black line is grounding.
5.1.3 Connect wires to the mains power cable or signal cables through wiring
terminal per code instruction.
5.2 Change Beam Angle
If you want to change beam angle of fixture, you can change lens of the fixture
refer to the photo below:
Completed by qualified technician only

6C
5.3 Connection Diagram
6. Lumen Output
Lumens：326.159lm
Beam Angle: 10°

7C
Lumens：263.372lm
Beam Angle: 20°

8C
7. Troubleshooting
If the fixture does not work, no light, please check the connection of power
cable and signal line, also measure the mains voltage on the main connector.
8. Cleaning And Maintenance
The cleaning must be carried out periodically to optimize light output. Cleaning
frequency depends on the environment in which the fixture operates: moist,
smoky or particularly dirty surrounding can cause greater accumulation of dirt
on the fixture.
yClean with lint-free cloth using normal glass cleaning liquid.
yAlways dry the parts carefully.
yClean the surface at least every 30 days.

9C

10C
