Instructions for Use
TO30/4.3-100-V-B
Telecentric measurement lens
Instructions for Use
TO30/4.3-100-V-B
Telecentric measurement lens
999.995.924.10-en-2.2
© Vision & Control GmbH 2019

Impress
Publisher / Manufacturer Vision & Control GmbH
Mittelbergstraße 16
98527 Suhl, Germany
Telephone: [phone]
Telefax: [phone]
www.vision-control.com
Name of the document 999.995.924.10-en-2.2
Date of first issue 22.10.2018
Date modified 2019-09-26
Copyright © Vision & Control GmbH 2019
Copyright
It is forbidden to pass this document on to third parties, reproduce and
communicate its contents in as far as this has not been expressly authorized.
Offenders will be liable for damages.
All rights are reserved with respect to patent, utility sample and design patent
registrations, as well as for rights of use within the scope of copyright.
vicotar®, vicolux®, pictor®, vicosys® and vcwin® are registered trademarks of
Vision & Control GmbH.
The products and brand names of other manufacturers or suppliers are
mentioned for information only.
2 -- © Vision & Control GmbH 2019

Validity
These instructions for use are valid for the following device:
Device Order no.
TO30/4.3-100-V-B 2-05-547
Product Identification
Designation Description
TO Telecentric measurement lens
30 Maximum object field diameter in mm
4.3 Maximum image sensor diagonal in mm
100 Working distance in mm
V Variable aperture
B Spectral range: 450 nm - 660 nm (visible light)
optimized at 450 nm - 490 nm (B - blue light)
© Vision & Control GmbH 2019 -- 3

TO30/4.3-100-V-B
Table of Contents
TABLE OF CONTENTS
1 Information about the Instructions of Use..................................................6
1.1 Intended Use................................................................................................ 6
1.2 Improper Use................................................................................................7
1.3 Qualified Personnel...................................................................................... 7
1.4 Warranty and Liability...................................................................................8
2 Safety.............................................................................................................. 9
2.1 Presentation of Safety Instructions.............................................................. 9
2.2 Safe Handling of the Device...................................................................... 10
3 Scope of Delivery and Accessories.......................................................... 11
3.1 Scope of Delivery....................................................................................... 11
3.2 Accessories.................................................................................................11
4 Device Description...................................................................................... 14
4.1 Device Views.............................................................................................. 14
4.2 Operating Elements....................................................................................14
4.3 Notices on the device.................................................................................15
5 Technical Data............................................................................................. 16
5.1 General Parameters................................................................................... 16
5.2 Optical Parameters.....................................................................................18
5.2.1 Resolution...........................................................................................18
5.2.2 Depth of field...................................................................................... 19
5.2.3 Absolute Distortion............................................................................. 19
5.2.4 Telecentricity....................................................................................... 19
5.3 Optical characteristics (design data).......................................................... 20
5.3.1 MTF depending on the Spatial Frequency.........................................21
5.3.2 MTF depending on the Object Field...................................................23
5.3.3 Lateral Chromatic Aberration............................................................. 25
5.3.4 Longitudinal Chromatic Aberration..................................................... 25
5.3.5 Distortion.............................................................................................26
5.3.6 Vignetting............................................................................................26
5.4 Conditions for Operation, Storage and Transport...................................... 27
5.5 Technical Drawings.....................................................................................28
6 Commissioning............................................................................................ 29
6.1 Unpacking................................................................................................... 29
4 999.995.924.10-en-2.2 © Vision & Control GmbH 2019

TO30/4.3-100-V-B
Table of Contents
6.2 Mounting..................................................................................................... 29
6.2.1 Mounting at the clamping area...........................................................30
6.2.2 Mounting of filters...............................................................................30
6.2.3 Mounting at the camera..................................................................... 30
6.3 Configuration...............................................................................................31
6.3.1 Setting the working distance.............................................................. 31
6.3.2 Adjusting the aperture........................................................................ 32
7 Operation...................................................................................................... 33
8 Maintenance and Service........................................................................... 34
8.1 Maintenance............................................................................................... 34
8.2 Service........................................................................................................ 36
9 Disposal........................................................................................................ 37
Table of Figures
Image 1: Device view.................................................................................... 14
Image 2: Type plate.......................................................................................15
Image 3: Illustrative sketch of optical characteristics.................................... 20
Image 4: MTF - spatial frequency dependent (470 nm, F8)..........................21
Image 5: MTF - spatial frequency dependent (470 nm, F11)........................ 21
Image 6: MTF - spatial frequency dependent (470 nm, F14)........................22
Image 7: MTF - object field dependent (470 nm, F8)................................... 23
Image 8: MTF - object field dependent (470 nm, F11)..................................23
Image 9: MTF - object field dependent (470 nm, F14)................................. 24
Image 10: Lateral chromatic aberration - wavelength dependent................... 25
Image 11: Longitudinal chromatic aberration - wavelength dependent........... 25
Image 12: Distortion - wavelength dependent.................................................26
Image 13: Vignetting........................................................................................26
Image 14: Technical Drawings........................................................................ 28
Image 15: Assembly regions........................................................................... 29
Image 16: Illustrative sketch - working distance............................................. 31
Image 17: Adjusting the aperture.................................................................... 32
© Vision & Control GmbH 2019 999.995.924.10-en-2.2 5

TO30/4.3-100-V-B
Information about the Instructions of Use
1 INFORMATION ABOUT THE INSTRUCTIONS OF
USE
This document contains technical information, important instructions for correct
installation, commissioning and use, as well as product information which were
up-to-date at the time of going to press.
Using this document makes it easier for you to familiarise yourself with the
device and avoid malfunctions caused by improper operation.
The instructions of use and the local regulations and rules must be followed.
To ensure a save and proper application, please read the instructions of use
carefully and keep them for future reference.
1.1 Intended Use
The device is intended exclusively for use as an imaging element for industrial
image processing.
The device is intended for use in a confined environment.
The device may only be used if it is in technically faultless condition and only
for its intended purpose, and only in accordance with the specifications in this
instructions of use by authorised operative personnel, who are aware of the
safety rules and hazards.
If the device is planned to be used for any other purpose or in a different
environment, the express authorisation of the manufacturer must be obtained
in advance. Any modifications or adaptations required may only be made by
the manufacturer.
6 999.995.924.10-en-2.2 © Vision & Control GmbH 2019

TO30/4.3-100-V-B
Information about the Instructions of Use
1.2 Improper Use
All unintended use and all device-related activities not described in these
instructions of use is to be deemed as unauthorised misuse outside the legal
limits of indemnity of the manufacturer.
Reasonably foreseeable misuse is:
•Non-compliance with the instructions for use,
•Faulty operation,
•Operating by personnel not qualified or instructed,
•Operating the device if it is not in a proper technical condition,
•Operating the device in ambient conditions differing from the corresponding
specifications in the instructions of use,
•Using spare parts which are not original parts from the manufacturer,
•Using incompatible accessory components,
•Improper maintenance and repair works,
•Unauthorised modifications to the device.
1.3 Qualified Personnel
The device may only be assembled, commissioned, operated, maintained,
installed, set up, cleaned, repaired and transported by qualified skilled
personnel.
A qualified person is deemed to be someone who has been trained and
instructed for his/her activities with the device, and who has proven his/her
capability to the purchaser. The operating personnel must be authorised by the
purchaser for those activities at the device.
For the installation and operation of the device, the skilled personnel must
know and comply with the applicable guidelines and standards for handling the
device.
© Vision & Control GmbH 2019 999.995.924.10-en-2.2 7

TO30/4.3-100-V-B
Information about the Instructions of Use
1.4 Warranty and Liability
The contents of this document have been checked carefully and correspond to
current legislation and best practise at the time of going to press.
However, the manufacturer shall not be liable for any damage arising from the
use of this edition of the manual, and rejects any warranty derived therefrom.
Within the bounds of the legal requirements, the manufacturer shall only
be responsible for the technical safety characteristics of the device if the
maintenance, repairs and modifications to the device are performed by himself
or by authorised skilled personnel in accordance with his instructions.
Loss of warranty
The manufacturer shall accept no liability or warranty in the event of improper
use, opening of the device or incorrect maintenance.
8 999.995.924.10-en-2.2 © Vision & Control GmbH 2019

TO30/4.3-100-V-B
Safety
2 SAFETY
2.1 Presentation of Safety Instructions
Each safety instruction is introduced by a key word and colour highlighted.
The key word indicates the degree of danger. The danger and its cause are
described, and then the measures to prevent conceivable consequences of the
danger. These measures must be taken.
DANGER
Indicates an imminent danger with high risk, resulting in severe injuries or
death if not avoided.
WARNING
Indicates a hazardous situation with medium risk, possibly resulting in severe
injuries or death if not avoided.
CAUTION
Indicates a hazardous situation with low risk, resulting in minor or medium
injuries if not avoided.
NOTICE
Indicates a situation that may result in property damage.
© Vision & Control GmbH 2019 999.995.924.10-en-2.2 9

TO30/4.3-100-V-B
Safety
2.2 Safe Handling of the Device
Read the following applicable safety instructions carefully and completely.
Follow the instructions for your own safety, the safety of other people, and to
avoid damage to the device and the connected technical equipment. Hazards
going beyond the general safety instructions are referred to separately at the
relevant points in this manual.
CAUTION
Eye damage
•Do not look directly through the lens.
CAUTION
Cutting injuries caused by glass breakage
The lenses of the objective are made of glass.
•Protect the objective against impact and do not drop it.
•In case of glass breakage do not touch any breakage edges.
•In case of glass breakage use cut-resistant protective gloves.
•Dispose of glass breakage using appropriate waste
containers.
10 999.995.924.10-en-2.2 © Vision & Control GmbH 2019

TO30/4.3-100-V-B
Scope of Delivery and Accessories
3 SCOPE OF DELIVERY AND ACCESSORIES
3.1 Scope of Delivery
Designation Quantity
Device TO30/4.3-100-V-B 1 x
Covering cap 2 x
Hex-wrench, width across flats AF = 1.5 mm 1 x
Instructions for Use TO30/4.3-100-V-B 1 x
3.2 Accessories
The following accessories are available for the lens.
Lens holder
Designation Description Order no.
Lens Holder d28 Holder for telecentric lenses and lightings
with clamping diameter d = 28 mm, for vibra-
tion-free attachment
2-90-138
Deflection mirrow
Designation Description Order no.
Deflection mirrow
90-42
90° deflection, attachment for telecentric
lenses and lightings with front diameter 42 mm
2-25-114
© Vision & Control GmbH 2019 999.995.924.10-en-2.2 11

TO30/4.3-100-V-B
Scope of Delivery and Accessories
Beam Splitter Unit
Designation Description Order no.
STE30x30-VIS1 Beam splitter unit - merges the optical axis of
the lens or camera with the axis oft the lighting
1-18-050
Adapter
STE30x30
TZO42
Adapter for attaching the STE30x30 to
telecentric lenses and lights with front
diameter 42 mm
1-18-025
CS to C-mount adapter / Extension rings
Designation Description Order no.
CS to C-mount
adapter 5.0 mm
for connecting C-mount lenses with CS-mount
cameras, length: 5 mm
2-90-414
Extension tube
set C-mount
consist of extension rings with each 0.5 mm,
1 mm, 5 mm, 10 mm, 20 mm and 40 mm
2-90-410
Extension ring
0.5 mm
26 x 31 x 0.5 reduces the minimum object
distance (MOD)
2-90-415
Extension ring
1.0 mm
26 x 31 x 1.0 reduces the minimum object
distance (MOD)
2-90-416
12 999.995.924.10-en-2.2 © Vision & Control GmbH 2019

TO30/4.3-100-V-B
Scope of Delivery and Accessories
Filter for filter thread object-side
Designation Description Order no.
ND filter 0.6
M39x0.5
Optical density 0.6 - 25% transmission, f-stop
reduction 2
2-91-150
ND filter 1.2
M39x0.5
Optical density 1.2 - 6.3% transmission, f-stop
reduction 4
2-91-160
ND filter 3.0
M39x0.5
Optical density 3.0 - 0.1% transmission, f-stop
reduction 10
2-91-170
UV blocking filter
M39x0.5
Long-pass filter with edge length λ = 350 nm
(UV absorbing filter), usable as protective
glass
2-91-120
IR filter M26x0.5 Long-pass filter with edge length λ = 830 nm
(daylight absorbing filter)
2-91-133
Pole filter
M39x0.5
Linear polarizing filter in the range of
λ = 420 nm to λ = 780 nm
2-91-140
Colour filter red
M39x0.5
Long-pass filter with edge length λ = 630 nm
(red filter)
2-91-261
© Vision & Control GmbH 2019 999.995.924.10-en-2.2 13

TO30/4.3-100-V-B
Device Description
4 DEVICE DESCRIPTION
4.1 Device Views
3
2
5
4
1
Image 1: Device view
1Filter thread M39x0.5 4C-mount camera connection
2Type plate 5Contact edge camera
3Aperture setting ring
4.2 Operating Elements
The device provides a rotatable aperture setting ring with fixation for adjusting
the aperture.
14 999.995.924.10-en-2.2 © Vision & Control GmbH 2019

TO30/4.3-100-V-B
Device Description
4.3 Notices on the device
Type plate
Type: TO30/4.3-100-V-B
SN.: XXXXXXXX
Type: TO30/4.3-100-V-B
SN.: XXXXXXXX
2
3
1
Image 2: Type plate
1Position on the lens
2Device designation
3Serial number
© Vision & Control GmbH 2019 999.995.924.10-en-2.2 15

TO30/4.3-100-V-B
Technical Data
5 TECHNICAL DATA
5.1 General Parameters
Parameter Value
Housing material Aluminium, black anodised
Optical material Glass
Housing dimensions Length: 92 mm (without connection thread)
Diameter: 42 mm (aperture ring 30.5 mm)
Clamping diameter: 28 mm
Filter thread object-side M39 x 0.5
Lens mount C-mount
Flange focal distance 17.526 mm
Aperture Variable F8 - F22
Maximum object field diagonal 30 mm
Maximum image field diagonal 4.3 mm
Maximum sensor size 1/4"
Weight 133 g
16 999.995.924.10-en-2.2 © Vision & Control GmbH 2019

TO30/4.3-100-V-B
Technical Data
Optimal sensor size
ADVICE
The illustrated image sensor serves as an overview. Other image sensors
with image field diagonals up to 4.3 mm are also possible.
4.05 mm
1/4"
3.4 mm
2.2 mm
Object fields at different sensor formats
Sensor Object field
Type Size Diagonal Size
1/4" 3.4 mm x 2.2 mm 4.05 mm 23.2 mm x 15.0 mm
© Vision & Control GmbH 2019 999.995.924.10-en-2.2 17

TO30/4.3-100-V-B
Technical Data
5.2 Optical Parameters
Parameter Value
Spectral range 450 nm - 660 nm (visible light)
optimized at 450 nm - 490 nm (blue light)
Effective F-number F8 - F22
Object-sided numerical aperture 0.009 - 0.003
Image-sided numerical aperture 0.062 - 0.023
Image scale 0.146
Working distance 100 ± 2 mm
Image length 209.0 mm
5.2.1 Resolution
MTF at 50 LP/mm, Wavelength: 470 nm - 490 nm, entire image area
Aperture Value
F8 > 60 %
F10 > 59 %
F11 > 59 %
F14 > 55 %
F16 > 50 %
F22 > 36 %
18 999.995.924.10-en-2.2 © Vision & Control GmbH 2019

TO30/4.3-100-V-B
Technical Data
5.2.2 Depth of field
MTF = 20 % at 20 LP/mm - Wavelength: 470 nm
Aperture Total Range further from
the lens
Range nearer to the
lens
F8 32.0 mm 16.0 mm 16.0 mm
F10 41.0 mm 22.0 mm 19.0 mm
F11 47.0 mm 24.0 mm 22.0 mm
F14 64.0 mm 32.0 mm 32.0 mm
F16 73.0 mm 38.0 mm 35.0 mm
F22 97.0 mm 55.0 mm 42.0 mm
5.2.3 Absolute Distortion
Image field diagonal Wavelength Distortion
4.3 mm (1/4") Blue: 450 nm
Blue: 470 nm
Blue: 490 nm
< 0.74 %
< 0.78 %
< 0.82 %
5.2.4 Telecentricity
Parameter Value
Telecentricity type Object-sided
Object-side telecentricity angle φ < 0.05 °
Image resizing at 1 mm object depth < 1.75 μm
Image resizing at 2 mm object depth < 3.50 μm
© Vision & Control GmbH 2019 999.995.924.10-en-2.2 19

TO30/4.3-100-V-B
Technical Data
5.3 Optical characteristics (design data)
2/3"
1
3
5
2
6
4
Image 3: Illustrative sketch of optical characteristics
1Image plane 4Image field
2Image centre (axis points) 5Line grid tangential (T)
3Image sensor 6Line grid sagittal (S)
ADVICE
The following design data was determined with the optics design software
Zemax.
The values refer to the image space.
20 999.995.924.10-en-2.2 © Vision & Control GmbH 2019
