Vision ZG 8101 IN User manual

Operation
1. Opening the garage door to change angle of detector will send the status of
"ON"(Basic Set,Value:0xFF) to any associated nodes, and the LED will flash once.
2. Closing the garage door to change angle of detector will send the status of
"OFF"(Basic Set,Value:0x00) to any associated nodes, and the LED will flash once.
3. Normal operation, the LED will not light.
4. The ZG8101 detector equipped with tamper switch. If the cover of detector is
removed, the garage detector will send an alarm report (type:0x07, level:0xFF) to
the Z-Wave™ Interface Controller, and the LED will go solid. Before replacing the
cover, the detector is under “Awake”mode.
Federal Communications Commission Statement
This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency energy and, if not installed
and used in accordance with the instruction, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the
user is encouraged to try and correct the interferene by one of the following measures:
Reorient or relocate the receiving antenna,
Increase the separation between the equipment and receiver,
Connect the equipment into and outlet on a circuit different from that to which the receiver
is connected.
Consult the dealer or an experienced radio/TV technician for help.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following
two conditions: (1) this device may not cause harmful interference, and (2) this device
must accept any interference received, including interference that may cause undersired
operation.
FCC Caution:Any changes or modifications not expressly approved by the party
responsible for compliance could void the user’s authority to operate this equipment.
Limited Warranty
Vision Guarantees that every wireless garage door detector is free from physical defects
in material and workmanship under normal use for one year from the date of purchase. If
the product proves defective during this one-year warranty period, Vision will replace it
free of charge. Vision does not issue any refunds. This warranty is extended to the
original end user purchase only and is not transferable. This warranty does not apply to :
(1) damage to units caused by accident, dropping or abuse in handling, or any negligent
use; (2) units which have been subject to unauthorized repair, taken apart, or otherwise
modified; (3) units not used in accordance with instruction; (4) damages exceeding the
cost of the product; (5) transit damage, initial installation costs, removal cost, or
reinstallation cost.
For information on addional devices, plesae visit us at www.visionsecurity.com.tw
ZG 8101
V1
1020717
6B1Z-81001
-3-
Installation & Operation Manual
ZG 8101 IN
ZG 8101 EU
ZG 8101 RU
ZG 8101 US
ZG 8101 JP
ZG 8101 BR
Wireless Garage Door Detector

Introduction
Thanks for choosing the Vision’s wireless garage door detector of the home security
device. This sensor is a Z-Wave™enabled device (interoperable, two-way RF mesh
networking technology) and is fully compatible with any Z-Wave™enabled network. Every
mains powered Z-Wave enabled device acts as a signal repeater and multiple devices
result in more possible transmission routes which helps eliminate “RF dead-sports”
Z-Wave™enabled devices displaying the Z-Wave™logo can also be used with it
regardless of the manufacturer, and ours can also be used in other manufacturer’s
Z-Wave™enabled networks. This detector monitors garage door and send Z-Wave™
signal when angel is changed.
Product Description and Specification
*** For indoor use only***
Specification:
Package Content:
Protocol: Z-Wave™(ZM3102N)
Frequency Range:
865.22MHz (ZG8101IN)
868.42MHz (ZG8101EU)
869.00MHz (ZG8101RU)
908.42MHz (ZG8101US)
920.00MHz (ZG8101JP)
921.42MHz (ZG8101BR)
Operating Range: Up to 100 feet line of sight
Operating Temp.: -15°C~ 60°C (5°F ~140°F)
Battery: Panasonic CR123A * 1PC
1pc
1pc
1pc
3pcs
1pc
1pc
ZG 8101 detector
Bracket Holder
Adhesive tape for detector
Screw for bracket
CR123A Lithium Battery
Installation & Operation manual
Installation
Notice: If you are installing the entire Z-Wave™ system for the first time, please refer to
the installation guide of Z-Wave™ Interface Controller before installing ZG8101.
1. Install Battery: Use care when installing the battery. Press the locking tab on the top
detector cover, and then gently pull up the cover. Observe the correct polarity before
insert the battery.
2. After insert the battery, the LED will start to flash slowly, which means the sensor has
not yet been “inclusion”.
3. For “Inclusion”in (adding to) a network: Put the Z-Wave™Interface Controller into
-1-
“inclusion”mode, and following its instruction to add the ZG8101 to your controller. To
get in the “inclusion”mode, the distance between sensor and controller is suggested
to be in one meter. Press the program switch of ZG8101 for 1 second at least.
The LED on the ZG8101 should go solid, if not, please try again.
For “Exclusion” from (removing from) a network: Put the Z-Wave™ Interface
Controller into “exclusion” mode, and following its instruction to delete the ZG8101
from your controller. Press the program switch of ZG8101 for 1 second at least to be
excluded.
For “Association”: removing the cover of the ZG8101 to get into the “Awake” mode,
then put the Z-Wave™ Interface Controller into “Association”, and following its
instruction to associate the ZG8101 with other device. Close the cover back after
“association” done, afterward the ZG8101 will get into “Sleep” mode for power saving.
Support one association group (5 nodes).
”Awake” mode: it is to leave the “Sleep” mode by removing the cover of ZG8101, to
allow the Z-Wave™ Interface Controller to do “Inclusion”, “Exclusion”, “Association”
and to reply and receive the commands from controller.
6. Slide back the rear cover and screw fastening with the front cover, the LED should go off.
7. Using the adhesive tape or fixing screws to fix the bracket holder with garage detector.
For better operation, please install detector on top portion of garage door.
8. External Switch: If your garage door needs external switch for fully monitoring. You
could use an external switch to connect with the ZG8101 for extending detection. The
ZG8101 has 2 normally closed contact terminals. These can be used for additional
external switch wired contacts. The external switch will send an alarm report
(type:0x07,level:0xFF) by opening the garage door.
-2-
