Vision MARK-1 User manual

USER GUIDE

Overview.........................................................4
Getting Started with the Vision MARK-1.....7
1. Charge the Device................................7
2. Turn ON the Device..............................7
3. Unlocking the Screen...........................8
4. Connect to Wi-Fi....................................9
5. Sign in to the Organization
Portal with Insitucloud Account........11
6. Install a Materials App.......................12
7. Ready to Make Measurements.........13
Getting to Know Your Device......................14
1. Status Bar and Navigation Bar.........14
2. Basic Gestures....................................15
3. Turn OFF or RESTART the Device.....15
4. Plugging in an Insight Module..........15
Using Apps.....................................................16
1. Finding Apps.......................................16
2. Switch Between Recently Used
Apps.....................................................17
3. Close Apps..........................................17
4. Adding an App to the Home
Screen..................................................19
5. Move or Remove Home Screen
Apps.....................................................20
Change Your Settings...................................21
1. Quick Settings.....................................21
2. Change the Brightness......................22
3. Battery.................................................22
4. Change the Volume............................24
5. Additional Settings.............................24
Safety Precautions.......................................25
Regulatory Notices.......................................28
Contents

4
The Vision MARK-1 performs rapid
materials assessments on location
and during materials use which
allows for better control, helps
to prevent materials defects,
and improves overall quality in a
manufacturing process.
Note: In order to make materials measurement on the
device, the Vision MARK-1 needs a specic Insight module
and materials probe that correspond to the
materials being measured.
Overview

5
The Vision MARK-1 performs rapid
materials assessments on location
and during materials use which
allows for better control, helps
to prevent materials defects,
and improves overall quality in a
manufacturing process.
Note: In order to make materials measurement on the
device, the Vision MARK-1 needs a specic Insight module
and materials probe that correspond to the
materials being measured.
Front
Charging
Port
LED Status
Indicator
(RYG)
Power
Button
Volume
Control
Insight
Port

6
Back
Humidity
Sensor
Lanyard
Straps

7
1. Charge the Device
Before using the Vision MARK-1, plug in the
power cord and fully charge it.
2. Turn ON the Device
To turn ON the Vision MARK-1, press and hold
the power button for a few seconds and you
will see the Insituware logo appear on the
screen.
Getting Started with the
Vision MARK-1

8
3. Unlock the Screen
To unlock the screen, swipe your nger up
from the bottom of the screen.
To lock the screen, press the power button
once.

9
4. Connect to Wi-Fi
From the Home screen tap the Settings app.
Tap Network & Internet.

10
Toggle the button to turn Wi-Fi on, then
select a listed network.
Enter the network password (if applicable) to
nish connecting to Wi-Fi.

11
5. Sign in to the Organization Portal
with Insitucloud Account
From the Home screen, tap the Organization
Portal app.
Log in with your Insitucloud credentials.
Note: If you do not already have an Insitucloud account,
tap the Sign Up tab in the Organization Portal app or go
to portal.insituware.com to create an account.

12
6. Install a Materials app
In the Organization Portal app, under
Applications select the Materials app you
would like to install and tap Install.
Once logged in, select your Organization.
Note: If there is an app update, it will say Update instead
of Install.

13
6. Install a Materials app
In the Organization Portal app, under
Applications select the Materials app you
would like to install and tap Install.
Once logged in, select your Organization.7. Ready to Make Measurements
Now you are ready to make measurements
with the Vision MARK-1!
Note: For more information on using Materials apps,
Insights, and probes with the Vision MARK-1, visit
support.insituware.com.

14
Getting to Know Your
Device
Status Bar
Navigation Bar
Back Home Overview
Time Wi-Fi Battery Life

15
Basic Gestures
Tap to select or open something on your
device like a button or an app.
Tap and hold to move apps around or
occasionally access other options (think of this
as “right-clicking”).
Swipe to scroll up and down, left and right, or
any other direction on the screen.
Turn OFF or RESTART the Device
To turn OFF or RESTART the Vision MARK-1,
press and hold the power button on the side
until the options to Power O and Restart
appear on the screen.
Plugging in an Insight Module
Use the guides on the side of the Insight
module to slide it into the Vision MARK-1
device and connect it in place.
You will know it is connected when you can
feel and hear the Insight module click into
place.

16
Using Apps
Finding Apps
To search for apps, swipe up on the screen to
access All Apps.
Use the search bar to type in the name of the
app you are looking for, or search through the
apps below.

17
Finding Apps
To search for apps, swipe up on the screen to
access All Apps.
Use the search bar to type in the name of the
app you are looking for, or search through the
apps below.
Switch Between Recently Used Apps
Tap the Overview button ( ) on the
Navigation Bar to show all open apps.
Swipe left or right to go to the app you want
and tap it.
Close Apps
Close one app: While viewing open apps,
swipe up on the app you want to close.

18
Close all apps: While viewing open apps,
swipe right until you see Clear All.
Tap Clear All to close all open apps.

19
Close all apps: While viewing open apps,
swipe right until you see Clear All.
Tap Clear All to close all open apps.
Adding an App to the Home Screen
Find the app you want to add to the Home
screen.
Tap and hold the app (don’t release yet), and
start dragging across the screen where you
will be taken to a special view of the Home
screen.
Continue to hold the app while you decide
where to put it.
Release the app once you’ve chosen a spot,
and it will be added to your Home screen.

20
Move or Remove Home Screen Apps
On the Home screen, tap and hold the app
you want to move or remove.
To move it, drag and drop the icon to a new
location.
To remove it, drag the icon to the Remove
option.
To uninstall it from the device, drag the icon
to the Uninstall option.
Note: This won’t delete the app from your device. It will only
remove the shortcut from the Home screen.
