Vision CS-1600P User manual

CS-1600P PAIR 60W ACTIVE CEILING
LOUDSPEAKERS
Home
>
Techaudio
> CS-1600P Pair 60w Active Ceiling Loudspeakers
Snapshot
> Integrated 2 x 30 watt RMS) digital amplifier
> 1 x wired input / 1 x Bluetooth input / 1 x line-level output
> IR remote included
Details

The CS-1600P are based on Vision’s passive ceiling loudspeakers but have a powerful 60 watt
amplifier built in to eliminate the need for an e ternal amplifier. They are suited to meeting rooms
and classrooms where a discrete audio solution is required.
Bluetooth 4.0
Connect directly from your phone or laptop wirelessly. When Bluetooth is activated either by turning
them on or selecting “Bluetooth” on the remote control, the loudspeakers will search for Bluetooth
devices for ten minutes and automatically switch from the cabled input when a device connects.
When the bluetooth device is disconnected the loudspeakers automatically switch back to the
line-level input. (NB: implementation of Bluetooth drivers on Windows computers is variable so
they don’t always work)
Remote Control
A full range of options are presented on the IR remote control, including bass and treble
adjustment.

Master/Slave
Like Vision’s other powered loudspeakers these are packaged and sold as a pair. The amplifier is
housed in the “master” loudspeaker which has the connection panel, and there is a speaker output
which connects to the passive “slave” loudspeaker.
igital
The CS-1600P uses a class- digital amplifier chip which uses no power at rest unlike analogue
amplifiers, and consumes very little power when in use. They are assembled on
semi-automated production lines to ensure consistency and reliability.
Audio Output
If you require two pairs for the room an audio output allows you to pass the audio signal on to a
second pair of CS-1600P. In fact you can daisy-chain as many pairs as you need using this
line-level audio output.

RS-232
To assist with integration into a fully controlled audio-visual environment these loudspeakers can be
controlled with RS-232 (serial) codes.
emory
When power is connected the CS-1600P automatically turns on and remembers the previous input
and volume setting. Restoring power brings the loudspeakers back to life automatically.
etal Backcan
To satisfy strict fire safety regulations in some countries the CS-1600P have a sheet-metal
back-can which enhances Electro- agnetic Compatibility (E C) and reduces heat transfer.
2-Way Drivers
These loudspeakers feature a two-way woofer and tweeter design which sounds great in
presentation or teaching environments.
Auto-Standby
If the amplifier senses no input it will automatically go into standby mode. As soon as you press play
on your source device it will automatically switch on again.
Manual
Specifications

PRODUCT DIMENSIONS: 260 x 180 mm / 10.2″ x 7.1″ (diameter x eig t
for eac speaker)
PACKAGED DIMENSIONS: 592 x 315 x 229 mm / 23.3″ x 12.4″ x 9.0″
CUTOUT SIZE: 222mm / 8.74″
PRODUCT WEIGHT: 4.9 kg / 10.8 lb (per pair)
PACKAGED WEIGHT: 7.2 kg /15.9 lb (per pair)
CONSTRUCTION MATERIAL: Plastic (ABS) + S eet metal backcan
COLOUR: W ite
TECHNICAL DETAILS:
Amplifier Output: 2 x 30 watts (RMS)
Woofer: 4″
Tweeter: 1.5″ Silk
Output Impedance: 8 o ms
Sensitivity: 89 dB (1w/1m)

Frequency response: 80 Hz-20 kHz
Power Consumption: ≤ 70 w
MAST R LOUDSP AK R INPUTS:
Input 1: Phoenix connector
Serial Connector: 9-pin D-sub connector (male)
MAST R LOUDSP AK R OUTPUTS:
Speaker Output: Phoenix connector
Speaker Output (on master): Phoenix connector
SLAV LOUDSP AK R INPUTS:
Speaker input (on slave): Phoenix connector
ACC SSORI S INCLUD D:
1 x Speaker Cable 5 m (16.4′) long
1 x Remote Control (Battery included: CR2025 3V Li-Mn)
1 x Female Minijack to Phoenix connector cable
1 x Female 2-Phono to Phoenix connector cable
POW R SUPPLY: 100-240v 50/60Hz AC xternal Power Supply – 24 volt / 2.5 amp.
Laptop-style transformer. Includes 4 x 0.5m figure-8 power cables: UK/ U/US/AU. DC tail length:
4m.
Transformer dimensions: 120 x 56 x 36mm / 4.72″ x 2.2″ x 1.42″
WARRANTY 2-year return to base

FCC STATEMENT :
This device complies with Part 15 of the FCC Rules. Operation is subject to the following
two conditions:
1) This device may not cause harmful interference, and
2) This device must accept any interference received, including interference that may
cause undesired operation.
Warning: Changes or modifications not expressly approved by the party responsible for
compliance could void the user's authority to operate the equipment.
NOTE: This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates uses and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the
user is encouraged to try to correct the interference by one or more of the following
measures:
 Reorient or relocate the receiving antenna.
 Increase the separation between the equipment and receiver.
 Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
 Consult the dealer or an experienced radio/TV technician for help.
RF warning statement:
The device has been evaluated to meet general RF exposure requirement. The device
can be used in portable exposure condition without restriction.
