Vista VDC1604 User manual

Please read this manual carefully before connecting your Dome Controller and operating it for the first time.
Be sure to read carefully and follow the PRODUCT S FETY instructions on page 6.
Keep the manual in a safe place for future reference.
VDC1604
INSTRUCTION MANUAL
Vista Dome Controller English

Page 2
VDC1604 VISTA DOME CONTROLLER Installation and Operating Instru tions
IMPORTANT
The first few pages of these instructions contain important information on safety and product
conformity. Please read, and ensure that you understand this information before continuing.

Page 3
Installation and Operating Instru tions VDC1604 VISTA DOME CONTROLLER
CONTENTS
Produ t safety .................................................................................................................................................................... 6
Radio Frequen y Devi es .................................................................................................................................................. 6
Unpacking ........................................................................................................................................................................... 6
Product Description ............................................................................................................................................................. 7
Overview .............................................................................................................................................................................. 7
Installation ........................................................................................................................................................................... 8
Mounting the unit ............................................................................................................................................................ 8
Installing the keyboard...................................................................................................................................................
Network Access Point Connections ............................................................................................................................ 10
Baxnet Notes ................................................................................................................................................................ 11
Setting the Keyboard ID ............................................................................................................................................... 11
Setting the keyboard baudrate..................................................................................................................................... 11
Connections ...................................................................................................................................................................... 12
Video Inputs ................................................................................................................................................................. 12
Video Outputs .............................................................................................................................................................. 12
Dome Telemetry .......................................................................................................................................................... 12
Alarm Inputs ................................................................................................................................................................. 12
Alarm Outputs .............................................................................................................................................................. 12
Keyboard Key Descriptions ............................................................................................................................................... 13
PROGRAMMING
Programming .................................................................................................................................................................... 16
Entering the Menu System ........................................................................................................................................... 16
Password Entry ............................................................................................................................................................ 16
Menu Navigation .......................................................................................................................................................... 16
Exiting the Menu System.............................................................................................................................................. 17
Programming the Time and Date ..................................................................................................................................... 17
Editing Text Items .............................................................................................................................................................. 18
Camera Setup Menu ......................................................................................................................................................... 18
Sequences and Views Menu ............................................................................................................................................ 1
PROGRAM VIEW MENU .............................................................................................................................................. 1
PROGRAM SEQUENCE MENU ................................................................................................................................... 1
TIMED FUNCTIONS MENU ......................................................................................................................................... 20
Alarm Handling Menu ........................................................................................................................................................ 21
ALARM MODE MENU ................................................................................................................................................... 21
ALARM RESPONSE MENU ......................................................................................................................................... 21
INPUT SETTINGS MENU ............................................................................................................................................. 22
OUTPUT SETTINGS MENU ......................................................................................................................................... 22
ALARM WINDOW SETUP MENU ................................................................................................................................. 22
ALARM LOG MENU ...................................................................................................................................................... 23
Control Access Menus ...................................................................................................................................................... 23
Keyboard - Monitor ....................................................................................................................................................... 23
Keyboard - Camera ..................................................................................................................................................... 23
Keyboard - PTZ ............................................................................................................................................................ 23
Control Access Menus ...................................................................................................................................................... 23
KEYBOARD TO MONITOR ACCESS MENU ............................................................................................................... 23
KEYBOARD TO CAMERA ACCESS MENU ................................................................................................................. 24
KEYBOARD TO PTZ ACCESS MENU .......................................................................................................................... 24
Display Setup Menu .......................................................................................................................................................... 24
System Setup Menu .......................................................................................................................................................... 25

Page 4
VDC1604 VISTA DOME CONTROLLER Installation and Operating Instru tions
CONTENTS
OPERATION
Selecting a Monitor ............................................................................................................................................................ 28
Recovery from Power Loss ......................................................................................................................................... 28
Selecting a Camera .......................................................................................................................................................... 28
Selecting Telemetry Control .............................................................................................................................................. 28
Auto Iris ........................................................................................................................................................................ 28
Auto Focus ................................................................................................................................................................... 28
Monitor Displays ................................................................................................................................................................ 28
Accessing the Dome Camera Menu................................................................................................................................. 2
Storing a Preset ................................................................................................................................................................. 2
Recalling a Preset ............................................................................................................................................................. 2
Learn Program Mode ........................................................................................................................................................ 2
Recalling a Learn Function ............................................................................................................................................... 30
Colour/ Mono Select .......................................................................................................................................................... 30
Program Tour ..................................................................................................................................................................... 30
Entering Program Mode .............................................................................................................................................. 30
Recall Tour ........................................................................................................................................................................ 31
Defining a View .................................................................................................................................................................. 32
Recalling a View ................................................................................................................................................................ 32
Defining a Programmed Sequence .................................................................................................................................. 32
Recalling a Programmed sequence ................................................................................................................................ 33
Defining a Timed Function ................................................................................................................................................ 34
Defining an Alarm Response ............................................................................................................................................ 35
Alarms ............................................................................................................................................................................... 36
Specifications .................................................................................................................................................................... 37
Appendix A - Password Recovery ...................................................................................................................................... 38
Appendix B - RS485 Cable Preparation ........................................................................................................................... 3

Page 5
Installation and Operating Instru tions VDC1604 VISTA DOME CONTROLLER

Page 6
VDC1604 VISTA DOME CONTROLLER Installation and Operating Instru tions
PRODUCT SAFETY
WARNINGS
Installation and servi ing is only to be arried out by suitably qualified and experien ed personnel to lo al or national
wiring standards.
Good engineering pra ti e must be arried out at all times and all servi ing and repairs arried out indoors.
The VDC1604 must only be powered with the lass 2 isolated power supply provided.
Do not ex eed the voltage and temperature limits given in the spe ifi ation.
The Vista VDC1604 is designed for use in general purpose CCTV applications and has no other purpose.
PRODUCT CERTIFICATIONS
Ele tri al Safety
British Standard BSEN60 50:2000 Safety of information technology equipment, including electrical business equipment.
Radio Frequen y Emissions
British standard BSEN50081-1:1 2 Electromagnetic compatibility - Generic emission standard
Part 1. Residential, commercial and light industry
Immunity
British Standard BSEN 50130-4:1 6 Alarm Systems Part 4 Electromagnetic compatibility
Product family standard: Immunity requirements for components of fire, intruder and social alarm systems
EU CONFORMANCE STATEMENT
A Declaration of Conformity in accordance with the above EU standards has been made and is on file at Norbain SD
Limited, Wokingham, Berkshire RG41 5TS.
The manufacturer declares, that the product supplied with this document is complaint with the provisions of the EMC
Directive 8 /336 EEC, the Low Voltage Directive LVD 73/23 EEC the CE Marking Directive 3/68 EEC and all associated
amendments.
UNPACKING
Keep your packaging for use if your VDC1604 is stored for a time or needs to be returned for whatever reason. The
packaging should contain:-
 VDC1604 Vista Dome Controller 16 x 4 Switching Matrix
 PSU and IEC Cable
 Two mounting brackets for 1  rack use
 These Instructions
Check the product code on the serial number label. If you have an incorrect item or it is damaged then inform your supplier
and the carriers immediately. If the equipment is incorrect or damaged, do not attempt to use it.
IMPORTANT
In the event of power interruption, the VDC1604 will lose current camera and monitor selections and revert to its default
settings upon reconnection of the supply.
All monitor and camera pairings must be re-entered if required. Sequences and views will also need to be re-entered.
Timed functions, when active, will recall sequences/views/cameras within a short period dependent upon the resume
timer settings.
If this recovery action is not sufficient for the application, it is recommended that the unit and its associated equipment is
supplied from a secure and uninterruptible power supply.
See also Sele ting a Monitor (page 26) and Defining a Timed Fun tion (page 30).

Page 7
Installation and Operating Instru tions VDC1604 VISTA DOME CONTROLLER
PRODUCT DESCRIPTION
Thank you for choosing the VDC1604 Vista Dome Controller. The VDC1604 is a small switching matrix designed to
control Domes and remote controlled cameras that respond to any one of the following RS485 twisted-pair telemetry
protocols: Vista PowerDome, Pelco D, Ultrak and VCL (note that dependant on the dome type, not all features may be
supported).
The system is capable of switching 16 video inputs to four video outputs and is controlled by a separate keyboard. Up to
four keyboards may be connected via BaxNet RS485 data bus.
Features
 16 Video Inputs (self-terminating, loop through)
 Four Video Outputs
 Twisted pair telemetry support for Dome cameras (for Baxall (Norbain), Pelco, Ultrak and VCL products)
 Four auxiliaries
 Up to 255 camera presets dependant on dome type (128 on the Vista PowerDome)
 Programmable camera view sequence (8 continuous and 8 one-shot sequences)
 Alarm output relay
OVERVIEW
Shown below are the front and rear panels of the unit showing the locations of the indicators and connectors.
Note: Only use the power supply provided with your VDC1604. Other power supplies may cause damage.
1
3
21 5 9 13371115261014481216
CONTROL OUTPUT KEYBOARD
12V DC
4
Loop-through Video inputs (1-16)Video Outputs (1-4) Alarms Power
Ke
y
board connector
Control Connector
Power LED
VDC1604
Fig.1 - Front and rear panels

Page 8
VDC1604 VISTA DOME CONTROLLER Installation and Operating Instru tions
OVERVIEW
Fig. 2 - Typi al onfiguration
INSTALLATION
Mounting the unit
The VDC1604 is designed to be used as a free standing or rack mounted unit using the mounting brackets supplied.
When choosing a suitable location for the unit, please ensure:
 An electrical output socket (capable of supplying 240V AC 50Hz at 500mA) is located within a suitable distance for the
included Class 2 power supply.
 The power supply cord cannot become pinched or trapped under a heavy object. The power cord should be routed so
that it is not likely to be walked on.
 The unit is protected from the accidental ingress of foreign objects or liquid spills. The unit must not be used near
water e.g. near a swimming pool, or any other area that is classified as a wet or damp location.

Page 9
Installation and Operating Instru tions VDC1604 VISTA DOME CONTROLLER
INSTALLATION
When fixing the VDC1604 into a 1  rack, the two mounting brackets must be fixed to the unit. Remove the plastic plugs
from the fixing holes (two on each side of the unit) and fix the mounting brackets with the supplied M5 screws as shown
in figure 3 below.
Fig. 3 - 19 ra k fixing
Installing the keyboard
The VDC1604 functions are controlled by an external NPX/RKB/J3De desktop keyboard.
Fig. 4 - Single keyboard onne tion
A single keyboard may be connected as shown in figure 4. Power is supplied to the keyboard by the keyboard connector
on the VDC1604. Note that the connection length A-B must not exceed 10m otherwise the keyboard will not receive
sufficient power. More than one keyboard may be connected (with a maximum of four keyboards) as shown in figure 5.
Fig. 5 - Multiple keyboard onne tions

Page 10
VDC1604 VISTA DOME CONTROLLER Installation and Operating Instru tions
INSTALLATION
This connection toplology is know as Daisy-chain. The following rules must be observed:
1. A maximum of four keyboards can be connected.
2. The distance from A to F must not exceed 1200m (including the stub lengths).
3. Keyboards 1, 2, 3 and 4 will each require a separate PSU even if the total length of the RS485 network is less than 10m.
4. Cables A-B, C-E and D-F are screened/shielded Cat5, and are available from Vista in lengths of 1m up to 10m.
The standard baud rate for the VDC1604 is 600 bps which, together with line impedances, will restrict the cabling
distances for the keyboard. Approved RS485 cable should be used for the data connections between the NAPs. In theory,
cabling distance can be up to 1.2 km. In practice however, the type of cable chosen, its routing, etc. will have an effect on
the maximum length that can be used.
The keyboard has built in network termination and/or biasing. For most small to medium sized installations, it should not
be necessary to change the switches from their default settings. Only for large installations should your network require
biasing and/or terminating. The switches are shown below. The default setting for switches 1, 2 and 3 is OFF. Switch 4 is
not used.
BAXKMI Network A ess Point Conne tions
The interconnection of Network Access Points is shown in Figure 6.
Fig. 6 - BAXKMI Network A ess Point Inter onne tions
4
OFF U
P
ON
3
21
*Default setting
Network setting Swit h 1 Swit h 2
Biased ON ON
Not Biased* OFF* OFF*
Network setting Swit h 3
Terminated ON
Not Terminated* OFF*
*Default setting

Page 11
Installation and Operating Instru tions VDC1604 VISTA DOME CONTROLLER
INSTALLATION
Baxnet Notes
1. A maximum of 16 devices may be connected to a BaxNet network. This includes VDC1604s Triplex Columbus and
keyboard combinations.
2. Baxnet RS485 addresses from 1 to 4 are reserved for VDC1604s or Triplex Columbus.
3. VDC1604 address IDs are between 1 and 16.
Setting the Keyboard ID
Each NPX/RKB/J3De keyboard on the Baxnet requires a unique RS485 address. Addresses 1 to 4 are restricted to
VDC1604 or Triplex Columbus units. We recommend that you use addresses 2 to 32. Keyboards with lower addresses
have control priority over keyboards with higher addresses.
1. Disconnect the power from the keyboard.
2. Reconnect the power.
3. Within 5 seconds of reconnecting the power, press the and
Esc
keys simultaneously.
4. The LCD display on the keyboard should display:
Special Config
5. Within 5 seconds, press the key
6. The LCD should change to:
Change KB Id
7. Within 5 seconds enter the new ID number (1 to 4) and press the enter key.
8. The LCD should now display:
Change KBD Id
New SELFUNT = 00
n
where n is the new keyboard ID.
Setting the keyboard baudrate
The default Baxnet baud rate for the keyboard and the VDC1604 and Triplex Columbus is 600. This can be changed on
the keyboard and VDC1604, but not on the Triplex Columbus. To change the baud rate on the keyboard, follow the steps
below.
1. Disconnect the power from the keyboard.
2. Reconnect the power.
3. Within 5 seconds of reconnecting the power, press the and
Esc
keys simultaneously.
4. The LCD display on the keyboard should display:
Special Config
5. Within 5 seconds, press the key.
6. The LCD display should show:
1-9600 2=19200
7. Press 1 for 600 or 2 for 1 200.
8. Press the enter key.
To change the baud rate on the VDC1604 see System Settings on page 25.

Page 12
VDC1604 VISTA DOME CONTROLLER Installation and Operating Instru tions
CONNECTIONS
Video Inputs
Video inputs are 75 ohm 1V peak-to-peak composite to PAL/CCIR standard. For each video input on the VDC1604, there
are two BNC connectors. One is for the camera input and the other is a looped-through output. Connect up to 16 video
inputs to the top row of BNC sockets. Connect any outputs that you wish to loop-through to the lower BNC socket in each
pair.
If you connect to both sockets, the VDC1604 automatically re-configures itself, removing the built in 75 ohm termination.
If you use the loop through facility, please ensure the connected equipment (e.g. monitor or VCR), provides a 75 ohm
termination at the end of the line.
Video Outputs
Video outputs are 75 ohm 1V peak-to-peak composite to PAL/CCIR standard. Any video input can be switched to any video
output. Your monitor should be set to 75 ohm.
Dome Telemetry
The VDC1604 has provision for the connection of dome cameras using any one of the following RS485 twisted-pair
telemetry protocols: Vista PowerDome, Pelco D, Ultrak and VLC. Please note that depending on the dome type, not all
functions of the dome may be available. Other standards will be available in future releases of the product. The telemetry
connections are shown schematically in Figure 7. Refer to the dome instruction manual for more information. Cable
preparation details are provided in Appendix B.
Fig. 7 - Dome Telemetry Conne tions
Alarm Inputs
The VDC1604 has provision for up to 16 alarm inputs. Input can be from a volt-free normally open or normally closed
contact and is software programmable. The alarm connections are via the 25-way D-type connector whose pin assignments
are shown in Figure 8.
1
2
13
25
11
14
7
8
Gnd
Gnd
3
4
13
14
9
10
5
6
Alarm Ground
(pin 9 or 22)
Normally
O
pen
Example showin
g
Alarm input 1 connections
Normally
C
losed
Alarm Ground
(pin 9 or 22)
Alarm Input
(pin 1) Alarm Input (pin 1)
15
16
11
12
Fig. 8 - Alarm input onne tions
Alarm Outputs
The VDC1604 has one pair of volt-free alarm contacts, (Alarm OP1), that is independently software programmable as
either normally open or normally closed. The contact is capable of switching up to 30V at 500mA (non-inductive).
Connections are shown in Figure .
13
25
11
14
Alarm
O
P1 Normally Open Normally Closed
Alarm Output 1
(pin 10)
Alarm Output 1
(p
in 11
)
Fig. 9 - Alarm output onne tions
1
3
21 5 9 133711152610144 8 12 16
CONTROL OUTPUT KEYBOARD
12V DC
4
Network -
Network + Ground
VIDE
O
TELEMETRY

Page 13
Installation and Operating Instru tions VDC1604 VISTA DOME CONTROLLER
KEYBOARD KEY DESCRIPTIONS
13
2
5
8
0
46
79
Fn
M
Esc
T
E
N
T
E
R
AUX
AF AI
1
2
4
5
6
7
8
9
11
12 13
14
15 16 17 18
19
20 21 22 23 24
25
26
27 28 29
30
31
32
33
35
36
34
37 39
38 40
10
P
41
42 44
43
3
Fig. 10 - NPX/RKB/J3De Keyboard overview
KEY DESCRIPTION
1
Esc
Used in menu functions. Cancels the current menu level and returns to the previous level (where supported).
2
M
Selects Menu mode for Triplex Columbus and VDC 1604. Must be held for at least 2 seconds.
3Toggles the multiple picture display on a multiplexer.
4Runs a programmed sequences.
5Shift key - allows multiple use of keys.
6Electronically freezes the picture on a multiplexer.
7Printer. (Not yet implemented).
8Allows you to select which remote unit to communicate with.
Fn
Used in conjunction with other keys to modify their actions.
10 LCD - Displays operations being performed by the system.
11
1
Numerical keys (0- ).
12 Enables a specific monitor to be selected.
13 Enables a specific camera to be selected.
14 Clears the alarm displayed the the selected monitor.
15 Focus on a distant object for cameras with controllable lenses.
Focus on a near object for cameras with controllable lenses.
16 Close the iris for cameras with controllable irises.
Open the iris for cameras with controllable irises.
17 Zoom in for cameras with controllable zoom lens.
Zoom out for cameras with controllable zoom lens.
18 Electronically zooms the display on the monitor when used in conjunction with Columbus.
1
T
Allows telemetry control (Triplex Columbus specific key).

Page 14
VDC1604 VISTA DOME CONTROLLER Installation and Operating Instru tions
KEY DESCRIPTION
20 Reverse play.
21 Pause play.
22 Search key - used to search Columbus.
23 Fast Review.
24 Fast Forward.
25 Joystick - P/T control or Triplex Columbus playback.
26 Enter key.
27 Record.
28 Stop play / Live mode.
2 Play forward.
30 Toggles camera power relay on/off for a selected camera (Aux 1).
31 Toggles lights on/off for a selected camera (Aux 5).
32 Starts Autopan for selected camera.
33 Selects wash for selected camera (Aux 2).
34 Applies certain selected functions globally. (Not yet implemented).
35
AUX
Auxiliary 4.
36 Selects wipe for selected camera (Aux 6).
37 Enables a specific preset to be selected and displayed on the currently selected monitor.
38 Recall a Learn Tour.
3 Recall a Preset Tour.
40 Flips the on screen picture 180O on supported domes.
41 Toggles between Colour / Mono video on supported domes and cameras.
42
AF
Enable Auto focus.
43 Dome menu access, hold for 2 seconds.
44 AI Enable Auto iris.
NPX/KBD/J3De keyboards are provided with a joystick to control cameras fitted with pan/tilt heads. Where on screen
programming is required, the joystick is used to input text, navigate through menus, etc. Important Note: During power-
up, the keyboard performs a joystick calibration function. Do not move the joystick during this period until the keyboard
has been properly initialised.

Page 15
Installation and Operating Instru tions VDC1604 VISTA DOME CONTROLLER
THE MENU SYSTEM AND PROGRAMMING

Page 16
VDC1604 VISTA DOME CONTROLLER Installation and Operating Instru tions
Main Menu
4Camera Setup
Seq/View functi ns
Alarm handling
C ntr l access
Time and date
Display set up
System settings
Exit menus
Installer Main Menu
PROGRAMMING
The VDC1604 menu system allows you to customise the system to meet your specific requirements. There are two
levels of menu, Installer and User. When the operator enters the Installer password, the Installer menu system is
accessible. Conversely, when the User password is entered, the User menu system is accessible. The User menu has
fewer options than the Installer menu but they operate in exactly the same way.
User menu
4Time and date
Pr gram View
Pr gram Sequence
Display setup
Alarm event l g
Exit menus
User Main Menu
Passw rd: * * * *
Password entry s reen
Part N : Pr Matrix
Unit ID: 9
BaxNet: 19200
S ftware Versi n: B.18 PAL
OS versi n: 2.03
Software version s reen
ENTERING THE MENU SYSTEM
The menu system is entered by pressing the Menu
M
key for at least 2 seconds.
Note that a valid monitor (1 to 3) must be selected before menu access can be
gained. A screen showing the software version will be displayed. Press the
enter key. The menu access screen will now be displayed prompting for a
password.
Password Entry
Enter the password using the numerical keys, then press the enter key. The
password entered will depend on whether you wish to enter the User menu or
the Installer menu.
Note
The fa tory set default password for the Installer menu is 7, 8, 9, 0. The
default User menu password is 1, 2, 3, 4. It is strongly advised that you
hange these passwords as soon as possible in order to maintain system
se urity. Passwords may be hanged in the System settings Menu.
Once the password has been correctly entered, the Installer or User Main
Menu screen will be displayed.
Note: If a password is lost, a re overy system is available. See Appendix A.
MENU NAVIGATION
The joystick is used to navigate the menu system. A field that can be edited is
shown in reverse video. In general, a menu item is selected and edited as
follows:
1. Use Joysti k Up/Down movements to move up or down between fields
and/or menu items. The selected field is indicated by a cursor symbol4.
2. Press the Enter key (or Joystick right) to enter edit mode for the selected
menu item or field. The cursor will change from 4 to + to indicate that you
are in edit mode.
3. Then use either:
the Joysti k Up/Down movement to select items from picklists, or
the Numeri al keys to input numerical data
the Joysti k Left to escape to the previous menu
the Joysti k Right to perform an enter command
4. Press the Enter key (or joystick right) to exit edit mode. The cursor will
change from + to 4.

Page 17
Installation and Operating Instru tions VDC1604 VISTA DOME CONTROLLER
PROGRAMMING
EXITING THE MENU SYSTEM
Each submenu has a Previous menu field. To exit a submenu, either select
this item and press enter to return to the previous menu level, or press the
Escape
Esc
key. This will eventually bring you back to the Main Menu. Here, use
the joystick to select Exit menus and press enter. The Save and Exit menu will
be displayed.
In this menu, there are three choices:
Save hanges and exit - selecting this will save any changes you have made
and then exit the menu system.
Dis ard hanges and exit - selecting this will discard any changes you have
made and exit the menu system.
* Restore fa tory defaults - this menu item will reset all of the default factory
settings.
* Clear log - this command will clear the contents of the alarm log.
Can el and return to menu - selecting this will close the Save and Exit screen
and return you to the main menu.
Alternatively, the menu system may be exited at any time and from any place by
pressing the Escape key. When used, this method will not save any menu
hanges that have been made within the menu system.
Note that in order to preserve configuration integrity, each data entry screen
within the menu system should be exited by selecting Previous menu or by the
valid selection of a new menu.
* These menu items are only available to the installer.
PROGRAMMING THE TIME AND DATE
Your VDC1604 has a battery-backed clock that will retain the correct time, date and all other programmed data in the event
of power loss to the unit. The Time and Date menu is accessed from the main
menu.
Programming the Date
1. Select the date format field and use the joystick to select from the
picklist MM/DD/YY, DD/MM/YY or YY/MM/DD. Default is DD/MM/YY. Press
enter.
2. Select the Set field and use the number keys to enter the day (DD) in a
two digit form i.e. 01, 31, etc. Advance to the next field (MM) using the
joystick and enter the month in two digit form. Advance to the next field (YY)
and enter the year. Note the date must be entered in DD/MM/YY format.
3. Select the Set day field and use the joystick to choose the correct
day from the pick list.
4. Select Set lo k to make the selected time active.
Programming the Time
1. Select the Time format field and use the up/down joystick to select 24 hour
or 12 hour from the picklist . Press enter. Note that in 12 hour format, a.m.
times are displayed 09.54 and p.m. times are displayed 09:54.
2. Select the Set time field. The hours field will be selected. Use the number
keys to enter the desired hour in a two digit format, i.e. 02, 13, etc. Advance
the cursor to the minutes field using the joystick and press enter. Use the
number keys to input the minutes. Press enter. Note that the time in this
field is always entered in 24 hour format regardless of how the time will
actually be shown by the on-screen display system.
Note
To activate the time and date information you have entered, select Set lo k
and press the enter key. To abandon any changes, select Prev and press the
enter key.
Save and exit
4Save changes and exit
Discard changes and exit
Rest re fact ry defaults
Clear l g
Cancel and return t menu
Time and Date
Date f rmat 4 DD/MM/YY
Time f rmat 24 h ur
Daylight save N ne
Set DD 01 MM 12 YY 99
Set time 24hr cl ck hh:mm
Set day MON
Prev Set cl ck
Daylight Savi g
The Daylight Saving time functi n is
achieved using the Daylight Save field.
On the day bef re DST, select Adva ce
r Retard. The time will then be
advanced r retarded as appr priate,
by ne h ur at the next ccurence f
2.00 a.m. f r advance and 2.00 a.m. f r
retard.
The DST Daylight Save field will then
reset itself t No e.

Page 18
VDC1604 VISTA DOME CONTROLLER Installation and Operating Instru tions
EDITING TEXT ITEMS
Some menus such as the Camera Setup menu and the View definition menu allow you to enter descriptive textual titles.
All titles are edited in the same manner. Once a title field has been selected with the joystick, pressing enter will invoke
the Text Edit s reen. Here, letters are selected one at a time using the joystick and enter key until the desired title has
been created.
When the Text edit screen is opened, the first character of the currently selected
title will flash. Below the current title field are pick lines containing alphabetical
characters. A pick line is selected using up/down joystick movements. Individual
characters are selected using left/right joystick movements. To enter the
selected character into the title, press the enter key. The title character will be
replaced by the letter selected in the pick line. When a title character has been
entered, the cursor will automatically move to the next character in the title field.
Numerals, where required in the title field, are entered directly using the number
keys of the keyboard. A space is entered by selecting the character between the
* and Ä characters. When the desired title has been entered, use the up/down
joystick to select either:
Keep hanges - this will save the title and return you to the menu from which
the Text edit screen was spawned.
Can el - this will cancel any edited changes and return you to the menu from
which the Text edit screen was spawned.
CAMERA SETUP MENU
The Camera Setup Menu is accessible from the Main Menu. It allows you to set up various parameters such as video loss
action, titles, etc. on a camera by camera basis. Use the joystick up/down to move through the menu and its fields.
Camera number
This allows you to select the video input to be edited. Video inputs number 1 to
16 and correspond to cameras 1 to 16. Use the number keys to enter the video
input.
Sour e type
Allows you to specify the type of camera that is connected to the selected video
input. This pick list has the following choices:
Fixed - static camera
PTZ - dome or pan/tilt camera
NONE - no video source connected to the input. Choose this option where you
do not want to get erroneous video-loss alarms.
Video loss
This allows you to choose whether the video loss alarm for the selected video
input is active. The pick list has the following choices:
On - Video loss is recorded in the alarm log and displayed on the system
banner.
Off - Video loss is ignored.
Title line
This menu item allows you to control the vertical position of the cameras on-
screen title. The display is divided into 11 lines with line 0 being at the top and
line 10 at the bottom. The camera title can occupy lines 0, 1 or 2. Use the
number keys to enter a line number between 0 and 2.
Title text
Selecting this option and pressing enter invokes the Text Edit Screen (see
EDITING TEXT ITEMS page 16) allowing you to specify a camera title of up to 22
characters. This is the title which will appear when the video input is selected.
Set amera address
Select this option to set up the Ultrak KDZ dome camera for operation on the
dome network.
Camera Setup
Camera number 4 01
S urce type NONE
Vide l ss On
Title line 01
Title text
Fr nt d r
Set camera address
Previ us menu
Text edit screen
Camera Title
Keep changes
Cancel
ABCDEFGHIJKLM NOPQRSTUVWXYZ
abcdefghijklmn pqrstuvwxyz
:/+* ÄÖÜÅå.

Page 19
Installation and Operating Instru tions VDC1604 VISTA DOME CONTROLLER
SET CAMERA ADDRESS MENU (ULTRAK KDZ DOME ONLY)
Set amera address
This option allows the Ultrak KDZ series dome to be programmed for operation
on the RS485 dome network.
Serial No.
Note the domes serial number and enter it into this field. Note that the letter A
of the serial number is entered as 0 e.g. a serial number of A1234567 is
entered as 01234567.
Camera No.
This number corresponds directly with the address the dome will take on the
RS485 network. Note that duplicated camera numbers will cause multiple
domes to be controlled.
Sed to amera
Select this option to send the programmed settings to the KDZ dome. This
option is required every time information is entered.
Note: Conne ting the Ultrak KDZ dome only
Connect the KDZ dome to the VD1604 dome network port on the reverse of the
unit (page 8). Power up the dome, then the VDC1604. Refer to the above for
information on setting the serial number and RS485 network address.
SEQUENCES AND VIEWS MENU
This menu is called from the Main menu and allows you to define camera sequences and views (a preset and camera
combination). The menu has three sub menus, Program View, Program Sequen e and Timed fun tions.
PROGRAM VIEW MENU
This menu allows you to set up any one of up to 64 views which can be defined
for any of the cameras connected to the system. Use the joystick up/down to
move through the menu and its fields.
View
This is the number uniquely defining the view. Use the number keys to enter a
number (1 to 64).
Name line
This menu item allows you to control the vertical position of the on-screen
caption for the view. The display is divided into 11 lines with line 0 being at the
top and line 10 at the bottom. The name can occupy lines 7, 8 or . Use the
number keys to enter a line number between 7 and .
Title field
Selecting the title field and pressing enter invokes the Text Edit Screen (see
EDITING TEXT ITEMS page 16) allowing you to specify a view title of up to 22
characters which will appear when this view is selected.
Camera
Use this field to select the desired camera. Enter the camera number (1 to 16)
using the number keys.
Preset
This field allows you to select the preset position that is invoked when the view
is selected. Enter the preset number (1 to ) using the number keys.
PROGRAM SEQUENCE MENU
This menu allows you to select a sequence of views or cameras that can be
displayed on any monitor. Up to eight sequences can be defined. The sequence
can comprise 16 views and/or cameras.
View sequen e
This field is the number of the sequence currently being defined. Use the
number keys to enter a number (1 to 8).
Pr gram Sequence
View sequence 41
V r C: Number Dwell
Previ us menu
7C01 03
8C01 09
9C01 10
10 C01 03
11 C01 03
12 C01 05
14C01 03
2C02 09
3V03 10
4C04 03
5V05 03
6C06 03
13 C01 03
14 C01 09
15 C01 10
16 C01 03
Sequences and Views
4Pr gram View
Pr gram Sequence
Timed functi ns
Previ us menu
Pr gram View
View 401
Name line 07
View title
Fr nt d r
Camera 02
Preset 16
Previ us menu
Set camera address
Serial N : ????????
Camera N :
Send t camera
Main menu

Page 20
VDC1604 VISTA DOME CONTROLLER Installation and Operating Instru tions
SEQUENCES AND VIEWS MENU
V or C
This field allows you to determine whether the step consists of a Camera (C) or
a View (V). Use the joystick to select V or C from the picklist.
This field is the number of the camera or view to be recalled at the current step.
Use the number keys to enter a number. Note that entering 00 will end the
view sequen e at that step.
Dwell
This field allows you to assign a dwell time in seconds for each camera or view
in the sequence. Use the number keys to enter a time in seconds between 3
and . Default dwell time is 3 seconds.
TIMED FUNCTIONS MENU
This menu allows you to set up Cameras, Views or View Sequences, on the
four monitor outputs, which are invoked at user-defined times of the day or
week. Up to eight of these timed functions can be defined.
Fun tion
This field allows you to select one of the eight timed functions for editing. Use
the number keys to select which timed function you want to edit.
On
This field determines the day on which the selected timed function will initiate.
Note that the time frame itself may overlap into the next day. The pick list
comprises:
MON, TUE, WED, THU, FRI, SAT, SUN, WEND (weekend), WDAY (Mon - Fri), EDAY
(every day), NONE (timed functions off).
at
This field allows you to enter the time for the function to commence. Use the
number keys to enter the desired value in Hours and Minutes. Times must be
entered in 24 hour format.
till
This field allows you to enter the end time for the function hours and minutes.
Use the number keys to enter the desired value in Hours and Minutes.
The sequences/views etc. running under timed function will remain in force
after the timed function is completed until manual intervention or another timed
function commences.
Monitor
Shows which view or sequence will be displayed by each of the four monitors
for the currently selected timed function This field cannot be edited.
View/Seq
This field consists of a pick list that allows you to select, for each monitor,
whether the timed function is a VIEW, Seq (Sequence) CAM (camera) or NONE.
Selecting NONE will not change the current image on the selected monitor
when the Timed function initiates. Note that changing the View/Seq field will
automatically set the corresponding No. field to 00. You must enter the required
No. after the View/Seq field has been changed.
No.
This field allows you to specify the number of the View or Sequence. Use the
number keys to enter a number for the View or Sequence.
Restart in
When a timed function is running, there may be instances of menu events or
operator input via the keyboard. This field allows you to specify a time period
after which the timed function will resume. Use the number keys to enter the
desired time period in seconds (10 to 60 in 10 second increments). The default
setting for this field is 0 seconds. This effectively disables the resume function.
Note that manual selection of a sequence on a monitor will override the Restart
in function on that monitor only. Other monitors will use the function as normal.
Two or more timed functions should not be programmed to overlap. If this does
occur, the timed function running will continue to completion at which point the
second timed function will start.
Timed functi ns
Functi n 4 1
On MON at 11:00
till 13:00
M nit r View/Seq N .
1VIEW 12
2Seq 08
3NONE 00
4NONE 00
Restart in 010s
Previ us menu
Pr gram Sequence
View sequence 41
V r C: Number Dwell
Previ us menu
7C01 03
8C01 09
9C01 10
10 C01 03
11 C01 03
12 C01 05
14C01 03
2C02 09
3V03 10
4C04 03
5V05 03
6C06 03
13 C01 03
14 C01 09
15 C01 10
16 C01 03
