VisuScience QuikVue VFR-100 User manual

User Guide
QuikVue® Filter Kit
Model: VFR-100/VFY-100
Please be sure to read this guide carefully before using the instrument and keep it handy for
ready reference.

Thanks for purchasing QuikVue® Filter Kit designed by Shanghai VisuScience
Meditech Co., Ltd.
QuikVue® Filter Kit has been designed to work with QuikVue® smartphone eye
imaging adaptor. The kit includes two filter clips as below:
MeiboFilter™: It is a red filter used to examine meibomian glands.
FluoFliter™:It is a yellow filter used to examine fluorescein images.
Specification
Color
Red Filter x 1, Yellow Filter x 1
Material
High transmittance glass
Weight
6g
Packing List
Red Filter x 1 Yellow Filter x 1
Installation Guide
1. Clip the QuikVue® smartphone eye imaging adaptor onto the smartphone
for use.
2. Clip the MeiboFilter ™ or FluoFliter ™ onto QuikVue® smartphone eye
imaging adaptor and make sure the illumination LED is not covered by the filter
as demonstrated below:
3. When use MeiboFilter™, please turn on the black/white camera mode on
user’s smartphone to examine meibomian glands.
Note: the black/white camera mode is available in some models of smartphone
only.

Following example shows the user guide on iPhone
A. Enter the camera mode and press the icon on right upper corner as below
and then select the “NOIR” mode.
B. Clip QuikVue® smartphone eye imaging adaptor onto the iPhone make sure
QuikVue® lens is in align with iPhone camera lens. Then clip MeiboFilter™
onto QuikVue® adaptor.
C. After capturing the picture, please download an app named Snapseed.
D. Open Snapseed app and import meibomian image and select following each
mode “pop” or “accentuate” to check the enhanced effect. Export the
enhanced image for future record.

Cleaning Guide
Please clean the plastic part with the wet cloth.
Please clean the lens of filter with dry superfine micro fiber cloth.
Service
If you meet any problem during operation of QuikVue® Filter Kit, please do not
disassemble the product by yourself. Please contact the distributor who
provided you with the product, or contact Shanghai VisuScience Meditech Co.,
Ltd. for help.

Shanghai VisuScience Meditech Co., Ltd.
Address: No. 344 Sanlin Road, Pudong New Area, Shanghai, China
Tel/Fax: [phone] Email: [email protected]
Website: www.visuscience.com
© 2020 VisuScience. All rights reserved.
V202009
