SonoSite iLook User manual

iLook®
USER GUIDE

iLook
USER GUIDE

ii
SonoSite, Inc.
21919 30th Drive SE
Bothell, WA 98021
USA
T: 1-888-482-9449 or 1-425-951-1200
F: 1-425-951-1201
SonoSite Ltd
Alexander House
40A Wilbury Way
Hitchin
Herts SG4 0AP
UK
T: [phone]
F: [phone]
“iLook” is a trademark of SonoSite, Inc.
Kensington is a registered trademark of Kensington Technology Group.
Non-SonoSite product names may be trademarks or registered trademarks of their respective owners.
SonoSite products may be covered by one or more of the following U.S. patents: 4454884, 4462408, 4469106, 4474184, 4475376,
4515017, 4534357, 4542653, 4543960, 4552607, 4561807, 4566035, 4567895, 4581636, 4591355, 4603702, 4607642, 4644795, 4670339,
4773140, 4817618, 4883059, 4887306, 5016641, 5050610, 5095910, 5099847, 5123415, 5158088, 5197477, 5207225, 5215094, 5226420,
5226422, 5233994, 5255682, 5275167, 5287753, 5305756, 5353354, 5365929, 5381795, 5386830, 5390674, 5402793, 5,423,220, 5438994,
5450851, 5456257, 5471989, 5471990, 5474073, 5476097, 5479930, 5482045, 5482047, 5485842, 5492134, 5517994, 5529070, 5546946,
5555887, 5603323, 5606972, 5617863, 5634465, 5634466, 5636631, 5645066, 5648942, 5669385, 5706819, 5715823, 5718229, 5720291,
5722412, 5752517, 5762067, 5782769, 5800356, 5817024, 5833613, 5846200, 5860924, 5893363, 5916168, 5951478, 6036643, 6102863,
6104126, 6113547, 6117085, 6142946, 6203498 B1, 6371918, 6135961, 6364839, 6383139, 6416475, 6447451, 6471651, 6569101, 6575908,
6604630, 6648826, 6835177, 6817982, 6730035, 6962566, D0280762, D0285484, D0286325, D0300241, D0306343, D0328095,
D0369307, D0379231, D456509, D461895, 6817982, D509900. Other patents pending.
P02651-04 01/2007
Copyright 2007 by SonoSite, Inc.
All rights reserved.
Caution: Federal (United States) law restricts this device to sale by or on the order of a physician.

iii
Contents
Chapter 1: Introduction
About the User Guide ...............................................................................1
Conventions Used in This User Guide ..................................................2
Symbols and Terms Used in This User Guide ......................................2
Customer Comments ................................................................................2
About the System ......................................................................................2
System Battery ...........................................................................................4
Software Licensing ....................................................................................6
Attaching the Handle Pad .......................................................................6
Chapter 2: Getting Started
Healthy Scanning Guidelines ..................................................................7
Position the System ...........................................................................8
Position Yourself ................................................................................9
Go Lightly ...........................................................................................9
Take Breaks .........................................................................................9
Exercise .............................................................................................10
System Controls .......................................................................................10
Screen Layout and Icons ........................................................................11
General Operation ...................................................................................13
Directional Controller .....................................................................13
Touch Screen ....................................................................................14
On-Screen Keyboard .......................................................................14
System Set-up ..........................................................................................16
Chapter 3: The Exam
Prepare for the Exam ..............................................................................21
Patient Information .................................................................................22
Exam Types and Imaging Modes .........................................................22
2D Image ..................................................................................................23
Color Power Doppler (CPD) or Directional Color Power
Doppler (DCPD) Image ..........................................................................25
Frozen Image ...........................................................................................26
Distance Measurement ...........................................................................27
Volume Calculation ................................................................................28
Image Storage ..........................................................................................29
After the Exam .........................................................................................31

iv
Chapter 4: Accessories
Docking Station ....................................................................................... 33
Stand ......................................................................................................... 34
Connectivity ............................................................................................ 36
Battery ...................................................................................................... 37
Auxiliary Power Cable ........................................................................... 38
Kensington®Security Cable .................................................................. 39
Printer ....................................................................................................... 40
SiteLink Image Manager Software ....................................................... 40
IrfanView Software ................................................................................ 40
Chapter 5: Safety
Ergonomic Safety .................................................................................... 41
Electrical Safety ....................................................................................... 41
Equipment Protection ............................................................................ 43
Battery Safety .......................................................................................... 43
Biological Safety ...................................................................................... 44
The ALARA Principle ............................................................................ 45
Applying ALARA ........................................................................... 45
Direct Controls ................................................................................ 46
Indirect Controls ............................................................................. 46
Receiver Controls ............................................................................ 46
Output Display ....................................................................................... 46
Related Guidance Documents ....................................................... 46
Acoustic Output Measurement ............................................................ 47
In Situ, Derated, and Water Value Intensities ............................. 47
Tissue Models and Equipment Survey ........................................ 48
Intended Uses .......................................................................................... 49
About the Acoustic Output Table ........................................................ 50
Acoustic Output Tables .................................................................. 52
Global Maximum Derated ISPTA and MI Values ..................... 52
Acoustic Measurement Precision and Uncertainty .................... 53
Labeling Symbols ................................................................................... 53
Chapter 6: Troubleshooting and Maintenance
Troubleshooting ...................................................................................... 57
Maintenance ............................................................................................ 58
Recommended Disinfectant .................................................................. 59
Safety ........................................................................................................ 59
Cleaning and Disinfecting the Ultrasound System ........................... 60
Cleaning and Disinfecting Transducers .............................................. 61
Sterilizable Transducers ........................................................................ 62
Cleaning and Disinfecting Transducer Cables ................................... 63
Cleaning and Disinfecting the Docking Station and Stand .............. 64
Cleaning and Disinfecting the Battery ................................................ 65

v
Chapter 7: Specifications
System Dimensions .................................................................................73
Display Dimensions ................................................................................73
Transducers ..............................................................................................73
Imaging Modes ........................................................................................73
Applications .............................................................................................73
Measurement ...........................................................................................74
2D .......................................................................................................74
Image Storage ..........................................................................................74
Accessories ...............................................................................................74
Hardware, Software, and Documentation ...................................74
Cables ................................................................................................74
Peripherals ...............................................................................................75
Medical Grade ..................................................................................75
Non-Medical Grade .........................................................................75
Temperature, Pressure, and Humidity Limits ....................................75
Operating Limits: System/Docking Station/Stand ...................75
Shipping/Storage Limits: System/Docking Station
without Battery ................................................................................75
Operating Limits: Battery ...............................................................75
Shipping/Storage Limits: Battery .................................................75
Electrical ...................................................................................................76
Battery .......................................................................................................76
Electromechanical Safety Standards ....................................................76
EMC Standards Classification ...............................................................76
Airborne Equipment Standards ............................................................76
Chapter 8: References
Display Size ..............................................................................................77
Caliper Placement ...................................................................................77
2D Measurements ...................................................................................77
Volume Measurement ............................................................................78
Acquisition Error .....................................................................................78
Terminology and Measurement Publications .....................................79
Reference ..................................................................................................79
Chapter 9: Glossary
Keys ...........................................................................................................81
Terms ........................................................................................................81
Index ....................................................................................................87

vi

Chapter 1: Introduction 1
Introduction
Chapter 1: Introduction
Read this information before using the iLook®personal imaging tool. The information in this guide
applies to the ultrasound system, transducer, accessories, and peripherals.
About the User Guide
This user guide is a reference for using the iLook system. It is designed for a reader familiar with
ultrasound techniques; it does not provide training in sonography or clinical practices. Before using
the system, you must have ultrasound training.
The user guide covers the preparation, use, and maintenance of the iLook system, transducer, and
accessories. Refer to the manufacturers’ instructions for specific information about peripherals.
The user guide includes a table of contents and an index to help you find the information that you
need. The user guide is divided into the following chapters:
Chapter 1 “Introduction” Contains general information about the user guide and the
system. Customer assistance information is included here.
Chapter 2 “Getting Started” Contains information on healthy scanning practices, basic
operation, and changing system settings.
Chapter 3 “The Exam” Contains detailed information about preparing for the
exam, adjusting imaging modes, performing a distance
measurement, manipulating a frozen image, and saving
and reviewing images.
Chapter 4 “Accessories” Contains information about using the accessories and
peripherals.
Chapter 5 “Safety” Contains information required by various regulatory
agencies, including information about ALARA (as low as
reasonably achievable), the output display standard,
acoustic power and intensity tables, and other safety
information.
Chapter 6 “Troubleshooting
and Maintenance”
Contains information to help you correct problems with
system operation. Also contains information about proper
care of the system, transducer, and accessories.
Chapter 7 “Specifications” Contains system and accessory specifications and agency
approvals. Specifications for recommended peripherals are
in the manufacturers’ instructions.
Chapter 8 “References” Contains information about measurement accuracy and the
sources from which the system measurements and
calculations are derived.

2Chapter 1: Introduction
Introduction
Conventions Used in This User Guide
These conventions are used in this user guide:
•A Warning describes precautions necessary to prevent injury or loss of life.
•A Caution describes precautions necessary to protect the products.
•Operating instructions are introduced with a statement in bold-face type that ends with a colon.
For example: To read this user guide:
•When the steps in the operating instructions must be performed in a specific order, the steps are
numbered.
•Bulleted lists present information in list format, but they do not imply a sequence.
•The left side of the system is to your left as you face the system. The system handle is on the left
side of the system, and the battery compartment is at the bottom left of the system.
Symbols and Terms Used in This User Guide
Symbols and terms used on the system, are explained in “Screen Layout and Icons” on page 11,
Chapter 9, “Glossary” and/or Chapter 5, “Safety.”
Customer Comments
Questions and comments are encouraged. SonoSite is interested in your feedback regarding the
system and the user guide. Please call SonoSite at 1-888-482-9449. If you are outside the USA, call
the nearest SonoSite representative. You can also send electronic mail (e-mail) to SonoSite at the
following address:
[email protected]
About the System
The iLook system is a portable, software-controlled, ultrasound system with all-digital architecture.
It is used to acquire and display real-time, 2D, color power Doppler (CPD), directional color power
Doppler (DCPD), and Tissue Harmonic Imaging ultrasound images. The system includes cine
review, a distance measurement, a volume calculation, image storage, and image review. Currently,
the system supports the C15/4-2 MHz 15-mm microcurved array broadband transducer and an
L25/10-5 MHz 25-mm linear transducer.
The system accessories include an AC power supply, an extra battery, an auxiliary power cable,
handle pads, a stand, and a docking station for charging batteries and downloading images to a
personal computer using SiteLink image manager software.
Optional peripherals include a medical grade black and white printer and a Kensington Security
Cable. Manufacturer’s instructions accompany each peripheral. Instructions for the use of
peripherals with the system are covered in Chapter 4, “Accessories.”
Chapter 9 “Glossary” Contains definitions of ultrasound system terms and
features.

Chapter 1: Introduction 3
Introduction
The software that runs the system uses graphic display elements similar to those used in many
personal computers. System terms are explained in Chapter 9, “Glossary.” On-screen symbols are
explained in “Screen Layout and Icons” on page 11.
The following figure illustrates the iLook system.
Figure 1 The iLook System
Transducer clip
Transducer
Handle pad
Battery
I/O connector
Stylus
Table 1: The iLook System
Item Description
Battery Two batteries are provided. Fully depleted batteries require approximately
two hours to charge to 90% capacity and three hours to charge to 100%
capacity.
Handle Pad Small and large handle pads are provided.
Transducer Clip
(C15 only)
Provides a storage area for the C15 transducer during exams or when
transporting the system.
Transducer The transducer is permanently attached to the system.
Stylus Used to tap on-screen menus, caliper placement, and data entry.
I/O Connector Used to connect system to docking station and auxiliary power.

4Chapter 1: Introduction
Introduction
System Battery
The iLook ultrasound system comes with two rechargeable lithium ion batteries. Each battery
comprises three lithium ion cells plus electronics, a temperature sensor, and the battery contacts. A
fully charged battery will last for 20 minutes or more depending on usage. Additionally, the display
brightness affects battery life. To conserve battery life, adjust brightness to a lower setting. See
“Brightness” on page 16.
To conserve battery life, the system has an automatic shut off feature. When powered on and no
buttons have been pressed for 5 minutes, the system will automatically turn off. If desired, this
feature can be disabled. See “Auto Shut Off” on page 16.
To ensure the battery remains fully charged, place the system in the docking station or stand when
not in use.
Note: For optimal battery life, store the batteries between -20°C (-4°F) and +25°C (77°F).
Figure 2 Battery Installation
To install the battery:
1Insert the battery (ridge side up) into the battery compartment.
2Slide the latch up to secure the battery in place.
Note: If the battery is being installed for the first time, it will need to be charged.

Chapter 1: Introduction 5
Introduction
To remove the battery:
1Turn the system off.
2Place your hand underneath the battery. Slide the battery latch down and pull the battery out
of the compartment.
Note: When the battery charge is depleted or the battery is replaced, the system retains brightness,
contrast, auto shut off, language, video format, date/time, and patient information.
To check battery charge:
1Disconnect AC power or remove the system from the dock or stand.
2Ensure the system is powered on.
3Check the battery charge icon in the lower right corner of the screen:
To charge the battery in the system:
Insert the system in the docking station or stand for iLook. See “To charge the system battery:” on
page 37.
Or
Connect the auxiliary power cable and power supply. See “To connect the auxiliary power cable:”
on page 38.
Note: When charging, the battery charge icon in the lower right corner of the screen will repeatedly fill.
When fully charged, all three charge bars will remain on.
Warning: To avoid damage to the battery or personal injury, place your hand under the
battery compartment to prevent the battery from falling out.
(flashing)
Fully charged 2/3* 1/3* Nearly empty
* Approximate remaining battery capacity.
Caution: To avoid damaging the system or battery, charge batteries only when the ambient
temperature is between 10° and 40°C (50° and 104°F).

6Chapter 1: Introduction
Introduction
Software Licensing
The system is shipped with a valid license number. For further questions, contact technical support.
USA/Canada Customers: 1-877-657-8118
International Customers: Contact your local representative or [phone].
Attaching the Handle Pad
The size of the handle opening can be customized to provide maximum support and comfort. Three
options are available: no pad, the small handle pad, or the large handle pad. The small handle pad
is installed and is suitable for most hand sizes. SonoSite recommends using the large handle pad if
your hands are small or using no pad if your hands are large. Select the option that provides the best
support and comfort for your hand size.
To remove or change the handle pad:
1Verify system is turned off.
2Lay the system on a flat surface with the display side down.
3Using a #2 Phillips screwdriver, remove the screws from the handle pad.
4Pull the handle pad out.
5Insert the new pad and securely fasten.

Chapter 2: Getting Started 7
Getting Started
Chapter 2: Getting Started
This chapter contains information on healthy scanning practices, basic operation, and changing
system settings.
Healthy Scanning Guidelines
These guidelines are intended to assist you in the comfortable and effective use of your hand carried
ultrasound system.
Warning: Use of an ultrasound system may be linked to musculoskeletal disordersa,b,c.
Use of an ultrasound system is defined as the physical interaction between the
operator, the ultrasound system, and transducer.
When using an ultrasound system, as with many similar physical activities, you
may experience occasional discomfort in your hands, fingers, arms, shoulders,
eyes, back, or other parts of your body. However, if you experience symptoms such
as constant or recurring discomfort, pain, throbbing, aching, tingling, numbness,
burning sensation, or stiffness, do not ignore these warning signs. Promptly see a
qualified health professional. Symptoms such as these can be linked with
musculoskeletal disorders (MSDs). MSDs can be painful and may result in
potentially disabling injuries to the nerves, muscles, tendons, or other parts of the
body. Examples of MSDs include carpal tunnel syndrome and tendonitis.
While researchers are not able to definitively answer many questions about MSDs,
there is a general agreement that certain factors are associated with their
occurrence including: preexisting medical and physical conditions, overall health,
equipment and body position while doing work, frequency of work, duration of
work, and other physical activities that may facilitate the onset of MSDsd. This
chapter provides guidelines that may help you work more comfortably and may
reduce your risk of MSDse,f.
a. Magnavita, N., Bevilacqua, L., Mirk, P., Fileni, A., and Castellino, N., 1999. Work-related musculoskeletal
complaints in sonologists. Occupational Environmental Medicine 41:11, 981-988.
b. Craig, M., 1985. Sonography: an occupational hazard? Journal of Diagnostic Medical Sonography 3,121-125.
c. Smith, C.S., Wolf, G.W., Xie, G. Y., and Smith, M. D., 1997. Muscoskeletal pain in cardiac ultrasonographers:
Results of a random survey. Journal of American Society of Echocardiography May, 357-362.
d. Wihlidal, L.M. and Kumar, S., 1997. An injury profile of practicing diagnostic medical sonographers in
Alberta. International Journal of Industrial Ergonomics 19, 205-216.
e. Habes, D.J. and Baron, S., 1999. Health Hazard Report 99-0093-2749 University of Medicine and Dentistry of
New Jersey.
f. Vanderpool, H.E., Friis, E.A., Smith, B.S., and Harms, K.L., 1993. Prevalence of carpal tunnel syndrome and
other work-related muscoskeletal problems in cardiac sonographers. Journal of Medicine 35:6, 605-610.

8Chapter 2: Getting Started
Getting Started
Position the System
To promote comfortable shoulder, arm and hand postures, consider the following:
•Use a stand to support the weight of the ultrasound system.
•If a stand is not available, use the patient bed, other furniture in the patient room, or your
leg/knee to support the weight of the ultrasound system. Do not operate the ultrasound system
without support, except for short term use.
Figure 1 Healthy Scanning Positions
•Use the ultrasound system handle pad appropriate for your hand size. Two handle pad sizes
are provided which allow for the handle opening size to be customized.
To minimize eye strain, consider the following:
•When the exam/procedure allows, position the system within reach.
•Adjust the angle of the system/display to minimize glare from overhead or outside lighting.
To minimize neck strain, consider the following:
•If using a stand, adjust the stand height such that the display is at or slightly below eye level.
Warning: Under prolonged use, the back of the enclosure can reach temperatures that
exceed EN60601-1 limits for patient contact, therefore, only the operator shall
handle the system. This does not include the transducer face. The ultrasound
system is labeled: SHORT TERM USE. (Short term use is based on a use model of
4-10 exams per day at 5 minutes per exam.)
Power off the system when not in use.

Chapter 2: Getting Started 9
Getting Started
Position Yourself
To support your back, consider the following:
•Use a chair that has support for your lower back.
•Use a chair that adjusts to your work surface height and promotes a natural body posture.
•Use a chair that allows for quick height adjustments.
•Always sit or stand in an upright manner. Avoid bending or stooping.
To minimize reaching and twisting, consider the following:
•Use an adjustable bed to adjust the height of the patient.
•Position the patient as close to you as possible.
•Face forward. Avoid twisting your head or body.
•Move your entire body front to back and position your scanning arm next to or slightly in front
of you.
•Stand for difficult exams to minimize reaching.
To promote comfortable shoulder and arm postures for your scanning arm, consider
the following:
•Keep your elbow close to your side.
•Relax your shoulders in a level position.
•Support your arm using a support cushion or pillow, or rest it on the bed.
To minimize neck bending and twisting, consider the following:
•Position the ultrasound system/display directly in front of you.
•Provide an auxiliary monitor for patient viewing.
Go Lightly
To promote comfortable hand, wrist, and finger postures for your scanning arm,
consider the following:
•Hold the transducer lightly in your fingers.
•Minimize the pressure applied on the patient.
•Keep your wrist in a straight position.
Take Breaks
Minimizing scanning time and taking breaks can be very effective in allowing your body to recover
from physical activity, which can help you avoid any MSDs. Some ultrasound tasks may require
longer or more frequent breaks. One way of taking a break is to stop and relax. However, simply
changing tasks can help some muscle groups relax while others remain or become active.

10 Chapter 2: Getting Started
Getting Started
To vary your daily activities, consider the following:
•Plan your work so there are breaks in between ultrasound exams.
•When scanning, use both system input devices, the touch screen and the directional controller.
•Work efficiently when performing an ultrasound exam by using the software and hardware
features correctly. Learn more about these features in Chapter 3 of this guide.
•Keep moving. Avoid sustaining the same posture by varying your head, neck, body, arm, and
leg positions.
Exercise
Targeted exercises can strengthen muscle groups, which may help you avoid MSDs. Contact a
qualified health professional to determine stretches and exercises that are right for you.
System Controls
Figure 2 System Controls
Patient
Touch screen
Menu
Directional
controller
Freeze
Save
Power
Table 1: System Controls
System
Control Icon Description
Power Press and hold for 1 beep to turn power on. Press and hold for
2beepstoturnpoweroff.
Menu Press to turn the on-screen menu on. Press again to turn the
on-screen menu off.

Chapter 2: Getting Started 11
Getting Started
Screen Layout and Icons
The following figure shows the screen layout and system icons.
Figure 3 Screen Layout and Icons
Freeze Press to freeze an image. Measurements can be made on a frozen
image. Press freeze again to unfreeze the image.
Save Press to save an image to the internal memory. Storage capacity is
up to 74 images.
Patient Press to access Patient Information, Exam Type, Image Review, and
System Set-up. Press again to return to imaging.
Directional
Controller
Use to navigate on-screen menus, adjust caliper position, and enter
data. Use the right, left, up, or down arrows to highlight menu items.
Press the center to select.
Touch
Screen
Use stylus to tap on-screen menu options, position calipers, and
enter data. The touch screen is not active during live imaging.
Table 1: System Controls (Continued)
System
Control Icon Description
DatePatient name/ID
Depth
System status
Time
Measurement
On-screen
menu
Depth markers
Skin line
Calculation

12 Chapter 2: Getting Started
Getting Started
Table 2: Screen Layout and Icons
Screen Area Icon/Information Description
Patient Name/ID Displays current patient name and identification.
Date Displays date.
Measurement Displays measurement in centimeters when image is
frozen and calipers are displayed.
Caliper A cursor used to measure distance on a frozen image.
On-screen menu Context sensitive menu that displays menu options
depending on the current mode of the system.
Time Displays time.
Exam type Displays exam type.
Transducer Displays the type of transducer (C15 or L25)
permanently attached to the system.
Harmonic icon
(C15 only)
Displayed when tissue harmonic imaging is on.
Freeze image
icon
Displayed when the image is frozen.
Image storage
icon
Displays the number of images saved in the system.
The system stores up to 74 images.
Battery charge
icon
Displays the level of the battery charge. The more bars
you see, the greater the charge. When the battery
becomes very low, no bars are displayed and the icon
flashes.
AC power icon Displayed if the system is plugged into AC power.
Depth Numeric value showing current depth in centimeters
from skin line to current depth.
Depth markers Indicates depth markers.
