Graham Field LUMEX TENDERCLOUD AQTC8035 Installation instructions

AQTC8035-INS-LAB-RevB11 1
AQTC8035 TENDERCLOUD® STATIC AIR MATTRESS OVERLAY:
INSTALLATION & OPERATION INSTRUCTIONS
PLEASE SAVE THESE INSTRUCTIONS FOR FUTURE USE
Info: The most current version of these instructions can be found online at www.grahamfield.com
WARNING:Thisproductisforsinglepatientuse.
WARNING:Important!Readandunderstandtheseinstructionsbeforeinstallingorusingthe
LumexTendercloudStaticAirMattressOverlay.Theseinstructionscontaininformationthat
willaidyouinachievingmaximumtherapeuticresults.Ifyoudonotunderstandanypartof
thesewarnings,cautionsorinstructions,contactahealthcareprofessionalfordirectioninthe
useofthisproduct.Iftheoverlayisnotproperlyinstalled,personalinjuryanddamagetothe
overlaycouldresult.
WARNING:Ifcomponentsaredamagedormissing,contactyourdealerimmediately.DONOT
usesubstituteparts.UseonlyLumexreplacementparts.Theuseof non-Lumexreplacement
partscouldcausepersonalinjury,propertydamage,andvoidthewarranty.
WARNING:Thisproducthasamaximumweightcapacityof300lb.
WARNING:GFHealthProducts,Inc.assumesnoresponsibilityforanydamageorinjurycaused
byimproperassemblyoruseofthisproduct.
ATTENTION:EMERGENCYDEFLATIONPROCEDURE
 MattressmustbedeatedbeforestartingCPR.Forquickdeation,completelyunscrewlarge
redvalvebyturningcounter-clockwise.
PROCEDIMIENTOPARADESINFLARENEMERGENCIA
 ElcolchóndebedeestardesinadoantesdeempezarRCP(ResucitaciónCardiopulmonar).
Paradesinarrápidamente,ajustecompletamentelaválvularojagrandevolteándolahaciasu
izquierda.
INTENDEDUSEOFTHISDEVICE
The intended use of the Tendercloud Static Air Mattress Overlay is as a support and pressure reduction
surface.
INSTALLATION
Ination
1. From the foot end of the bed, unroll the overlay on top of regular mattress with valve on the left side.
Smooth out and place each of the four corner straps around the standard hospital mattress.
2. Exclusive 2-part valve system:
a. Unscrew top black cap.
b. Tighten bottom red valve (it is essential that the bottom red valve be closed rmly).
3. Insert air-lling device into top of the red valve and inate for 60 seconds if using an electric pump.
4. Replace black top cap and tighten rmly after ination.
5. Make up bed as usual with sheets, leaving overlay valve exposed (incontinence pads may be used).
6. Patient may now be placed on overlay.
OPERATION
HandCheck
1. With patient in place (lying down), gently insert your hand palm up under overlay directly beneath the
patient’s buttocks.
2. Always keep the back of your hand at against the hospital mattress. If the patient’s weight is directly
resting on the palm of your hand, overlay will need to be inated for an additional 30 seconds. If you can-
not feel the patient, overlay is working efciently and additional ination is not required.

AQTC8035-INS-LAB-RevB11 2
www.grahamfield.com
GF Health Products, Inc. is not responsible for typographical errors. Packaging, warranties, products and specications are subject to change without notice.
Graham-Field, Lumex and Tendercloud are registered trademarks of GF Health Products, Inc.
© 2011 GF Health Products, Inc. • 2935 Northeast Parkway • Atlanta, GA 30360 • tel [phone]
CAUTION:Periodicallycheckpatient’sskinforrednessordeterioration.Consultphysician
shouldanyoccur.
CAUTION:Performregularhandchecks.Markthefollowingcalendarwithan“X”throughthe
datewhenHandCheckisperformed.
IMPORTANT:
Perform regular hand checks.
Mark the following calendar with an “X” through the date
when Hand Check is performed.
Date Tendercloud went into service: _________________
MONTH
___________ ___________ ___________
1 2 3 4 5 6 7
8 9 10 11 12 13 14
15 16 17 18 19 20 21
22 23 24 25 26 27 28
29 30 31
1 2 3 4 5 6 7
8 9 10 11 12 13 14
15 16 17 18 19 20 21
22 23 24 25 26 27 28
29 30 31
1 2 3 4 5 6 7
8 9 10 11 12 13 14
15 16 17 18 19 20 21
22 23 24 25 26 27 28
29 30 31
MAINTENANCE
Cleaning
Wipe the overlay with a clean, damp cloth and mild detergent. The overlay may also be cleaned using a 10%
solution of sodium hypochlorite (bleach) diluted in water. Air dry overlay thoroughly without direct expo-
sure to sunlight before use.
s NOTICE:DONOTcleanwithphenolicproducts.
LIMITEDWARRANTY
GF Health Products, Inc. offers a 90-day limited warranty against manufacturer's defects on the Lumex
AQTC8035 Tendercloud Static Air Mattress Overlay. If a product is deemed to be under warranty, GF Health
Products, Inc. shall provide, at its option, (1) replacement of any defective part or product or (2) a credit of
the original selling price made to GF Health Products, Inc.'s initial customer. The warranty does not include
any labor charges incurred in replacement part(s) installation or any associated freight or shipping charges
to GF Health Products, Inc.
The warranties contained herein contain all the representations and warranties with respect to the subject
matter of this document, and supersede all prior negotiations, agreements and understandings with respect
thereto. The recipient of this document hereby acknowledges and represents that it has not relied on any
representation, assertion, guarantee, warranty, collateral contract or other assurance, except those set out
in this document.
