Vitek VTC-HOCRBD4F User manual

VITEK
FEATURES:
• 1/2.9” Sony Progressive Scan CMOS
• 2.1MegaPixel with Full 1080p/720p HD-SDI Output (SMPTE292M)
• 25 IR LEDs with 70’ Range
• Built in fixed 3.7mm Megapixel lens
• Heavy Duty Vandal & IP67 Weather Resistance rating
• 16:9 Video Format
• 100% Pure Digital Transmission of video data
• Up to 700’ HD Transmission Range (depending on
cable characteristics and integrity)
• 12VDC Operation
VTC-HOCRBD4F
2.1MP HD-SDI Compact Indoor/Outdoor
WDR True Day/Night Ball Camera

22
Detailed Specifications
Sensor
Resolution
S/N
Video Output
IR Illuminators
IR Color Temp.
IR Range
Dynamic Intensity IR LEDs
Lens
Minimum Illumination
Day/Night
Electronic shutter speed
White Balance
Brightness
DNR
WDR
HD Transmission Range
Weather Resistance Rating
Operating Conditions
Input Voltage
Power Consumption (12VDC)
Dimensions
1/2.9” Sony CMOS
2.1 MegaPixel (1080p / 720p)
More than 52 dB (AGC Off)
1x HD-SDI (BNC)
25 IR LEDs
850nm
70’
YES
3.7mm Fixed
1 Lux at F1.2 / 0.1 Lux (B/W) / 0 Lux at IR On
Auto
Auto
Auto
Auto
3D-DNR
YES
Up to 700’ (Depending on cable characteristics and integrity)
IP-67
14°-122°F (-10°-50°C) < 80% RH
12VDC
190mA / 360mA (IR OFF/ON)
3.06” x 3.67” (H x Dia.)
Sony® and PELCO® are the registered trademarks of their independently owned and operated companies. These products have not been licensed
or endorsed by the manufacturers of Sony® and PELCO® products.

3
3.06”
3.67”
3.67”
3.67”
2.04”
HDMI
HD-SDI DVR

4
VT-HDOC Series
On Cue Series 4, 8, & 16 Channel HD-SDI Video Recorders
• 4, 8, or 16 Channel HD-SDI Inputs (Universal) with Full1080p, 720P, 960H & D1 Camera Support
• Simple plug and play, point-to-point connection from camera to DVR
• Pentaplex Operation (Multi-Channel Live-View, Playback, Recording, Backup, Network)
• VT-HDOC16: 480fps Live Display, Recording & Playback at 720p/1080p
• VT-HDOC8: 240fps Live Display, Recording & Playback at 720p/1080p
• VT-HDOC4: 120fps Live Display, Recording & Playback at 720p/1080p
• HDMI, VGA, and BNC Spot Output / Alarm In & Out / 4 Channel Audio In
• VT-HDOC 4 & 8 offer 2 Internal SATA2/SATA3 HDD Slots supporting up to 8TB (2 x 4TB HDD) using
Advanced HDD Format (VT-HDOC16 Offers 5x SATA Slots for up to 20TB Internal Storage)
• External SATA Port (eSATA) supporting up to 5x External HDDs
• Remote Viewing via CVS Software, Web Browser, and Mobile Phones (iOS/Android)
• Viewing multiple Recorders with included CVS Software
• Adjustable Motion Detection Grid
• Thumbnail / Panorama Search
OTHER PRODUCTS FROM VITEK
On Cue HD-SDI Video Recorders

5

6
LIMITED LIABILITY WARRANTY
VITEK products carry a three (3) year limited warranty. VITEK warrants to the purchaser that
products manufactured by VITEK are free of any rightful claim of infringement or the like, and
when used in the manner intended, will be free of defects in materials and workmanship for
a period of three (3) years, or as otherwise stated above, from the date of purchase by the
end user. This warranty is nontransferable and extends only to the original buyer or end user
customer of a VITEK Authorized Reseller.
The product must have been used only for its intended purpose, and not been subjected to
damage by misuse, willful or accidental damage, caused by excessive voltage or lightning.
The product must not have been tampered with in any way or the guarantee will be
considered null and void.
This guarantee does not affect your statutory rights.
Contact your local VITEK Reseller should servicing become necessary.
VITEK makes no warranty or guarantee whatsoever with respect to products sold or
purchased through unauthorized sales channels. Warranty support is available only if product
is purchased through a VITEK Authorized Reseller.
Version 1.4 (3700-8537F)
June 2014
