USER MANUAL
VS LED Grow Light

Product
VS1000 LED 100W
VS1500 LED 150W
VS2000 LED 200W
VS3000 LED 300W
VS4000 LED 400W
VS1000E LED 100W
Model
VS1000
VS1500
VS2000
VS3000
VS4000
VS1000E
SKU
LED-100NJ
LED-150
LED-300
LED-400J
VS1000E
LED-200J
PRODUCTS INCLUDED IN THIS MANUAL:

Safety Information
Product Contents
Key Features
1
2
4
Specificaitons
Application
Installation
5
7
8
Warranty Information 11
CONTENTS

Please read the following information carefully before using. Failure to observe these
safety instructions may result in serious injury and will release VIVOSUN of all liability
and void all product warranties.
SAFETY INFORMATION
Handling: Set up the light in an operating environment that allows for adequate air circulation.
Never allow objects to obstruct or enter the ventilation openings. Avoid looking directly at the
lights, when they are turned on. Use shielding and grow room glasses to protect your eyes.
For Indoor use Only: DO NOT devices in this kit outdoors or in any hazardous location such as
near flammable, explosive, corrosive chemicals, or in wet environments. Appropriate tempera-
ture range: -20 °C to 40 °C (-4 °F to 104 °F).
Power Cord: Your AC cord has a three-wire grounding plug (a plug that has a grounding pin).
This plug fits only a grounded AC outlet. If you're unable to insert the plug into an outlet because
the outlet isn't grounded, contact a licensed electrician to replace the outlet with a properly
grounded one.
Repairs: If there is something wrong with your light, please contact us. Opening the light to
inspect or repair in accordance with VIVOSUN's instructions and express permission will not
affect your existing warranty. However, if you disassemble the light or install add-ons inside
without express permission from VIVOSUN, you may damage the light and void warranty.
Cleaning: DO NOT use water or any detergent to clean this product.
1

2
PRODUCT CONTENTS
VS1000/VS1500/VS2000/VS3000/VS4000
LED Grow Light
x 1pc
Rope Hanger
x 2pcs
Grow Room Glasses
x 1pc
RJ11 3-Way
Cable Splitter
x 1pc
Power Cord
x 1pc
RJ11 Network Cable
x 2pcs

3
PRODUCT CONTENTS
VS1000E
LED Grow Light
x 1pc
Rope Hanger
x 2pcs
Wire Ropes
x 2pcs

4
KEY FEATURES
SAMSUNG LED DIODES
Powered by Samsung
high-efficiency diodes for
horticulture at perfect spectrum.
HIGH EFFICACY
High-quality diodes and
power supply mean high
PPE, up to 2.7 umol/J.
FULL SPECTRUM &FR
380-780nm of full spectrum
coverage with 450nm,
660nm and 730nm rich for
photosynthesis.
MULTIPLE LIGHTS
CONTROL
1 light can control up to 20
lights with RJ11 serial
connection.
DIMMING CONTROL
0-100%light dimming for
different growing stages
(except VS1000E).
CERTIFICATION
ETL, CE, FCC certifica-
tions and waterproof of
IP65.

5
SPECIFICATIONS
LED Source
Spectrum
Input Voltage
Frequency
Input Power
Power Factor
Dimensions(L)
Dimensions(W)
Dimensions(H)
Weight
Dimming
Lifetime
Certifications
Warranty
VS1000 VS1500 VS4000VS2000 VS3000 VS1000E
11.8"/30cm 14.2"/36cm 23.5"/60cm23.5"/60cm 19.7"/50cm 11.8"/30cm
11.8"/30cm 14.2"/36cm 23.5"/60cm11.8"/30cm 19.7"/50cm 10.2"/26cm
2.36"/6cm 2.95"/7.5cm 3.23"/8.2cm2.95"/7.5cm 3.23"/8.2cm 1.69"/4.3cm
3.22 lbs.
/1.46kg
5.42 lbs.
/2.46kg
9.03 lbs.
/4.1kg
10.93 lbs.
/4.96kg
17.46 lbs.
/7.92kg
2.98 lbs.
/1.35kg
100W 150W 400W200W 300W 100W
Samsung LM301D
Full spectrum: 380 –780nm;rich 660nm and 730nm
120-277V
L90>50,000 hours
ETL, CE, FCC, and IP65 waterproofing
5-Year Standard Warranty
50-60Hz
>0.9
Samsung
LM281B+ pro
25%/50%/75%/100%/OFF/EXT N/A

6
SPECIFICATIONS
SPECTRUM
Wave length (nm)
380
0.0
0.2
0.4
0.6
0.8
1.0
1.2
480 580 680 780

7
Set the LED power on high and place the light further away from your plants to cover a wider
area, or set the LED at a lower power and place the light closer to your plants for less coverage
but a more eco-friendly solution.
APPLICATION
SUGGESTED HANGING DISTANCE &SUGGESTED LIGHTING TIME
Stage
Germination
Seeding
Veg
Flower
Distance
Inch (In.) Centimeter (cm.)
24-30 61-76
61-76
18-24
24-30
12-18
46-61
30-46
Time
18 Hours ON
16 Hours ON
18 Hours ON
12 Hours ON
Note: This suggestion is for reference only, and can be freely adjusted according to the
actual situation.

8
INSTALLATION
INSTALLATION OPTIONS (VS1000/VS1500/VS2000/VS3000/VS4000)
1. Pass the rope hangers through the LED's hooks, and then fix the other end of rope hangers to
the ceiling.
2.Remove the hooks from the LEDs, then fit them onto the ceiling bracket before installing them
back onto the LED.

INSTALLATION
INSTALLATION OPTIONS (VS1000E)
1. Pass the rope hangers through the LED's hooks, and then fix the other end of rope hangers to
the ceiling.
9

10
Choose a light as the master Light (A) and use the RJ11 cables and cable splitter to connect other
lights (B, C) as the controlled Lights as showed above. Turn the dimming knob to the "EXT" on
the controlled light (B, C) and they will be controlled by the master light (A). A master light can
control up to 20 lights.
Note: Ensure all the controlled lights turned to "EXT" and work normally. If connected to a timer,
ensure the total power of all the lights (including the master light and controlled lights) conform
the rated power of the timer.
VS1000E does not support multiple light connections.
INSTALLATION
CONNECTING MULTIPLE LIGHTS
Main Control Light
Controlled Light
Controlled Light

WARRANTY INFORMATION
1. We offer a 5-year warranty against manufacturing defects for all of our products from the date
of purchase. If you need warranty assistance, please contact us as soon as possible.
2. The warranty does not cover damage due to high moisture levels, water damage, power
surges, improper hanging/mounting, improper use, dust build-up, or users' unauthorized
modifications.
3. In the USA, if any light ceases working within 30 days of use, you can choose:
(A) Exchange: We will email you a pre-paid return label. Please ship the light back to our USA
warranty center and a replacement will be sent to you free of charge as soon as we receive the
defective product.
(B) Refund: We will email you a pre-paid return label. Please ship the product to our USA
warranty center and we will issue a refund as soon as the light has been received. Refund
periods may depend on the processing time of your bank or institution-usually, a refund takes
about 5 business days to be processed.
4. Our company reserves all rights to the final explanation of this warranty structure. If you have
any questions about our warranty policy, please contact us.
