SPYKER 30 Troubleshooting guide

MODEL 299
Mulch Spreader
©2005 Spyker Spreaders – Urbana, IN U.S.A. 05-99-0064
P.O. Box 7 • 140 Mill Street • Urbana, IN 46990 USA
1-800-972-6130 • Fax [phone]
"ACCUWAY'' Spread Pattern Equalizer
ENSURES spreading dead center of the
spreader. (Indicated with "22" in model number)
Gears are unconditionally guaranteed
ENSURES trouble free operation.
Dial-A-Matic spread rate control
ENSURES spreading at exact spread
rates.
Optional BORDER PATROL spread pattern
cut-off prevents spreading on drive-ways,
flower beds, etc.
Extension hoppers available for all round
hopper spreaders. Adds 20 lbs. to
capacity.
Shipped Set-Up. Saves time and labor
ENSURES proper assembly.(except #64)
Stainless steel frames ensurelonger
spreader life, easier maintenance and
present a quality image.
High grade plastic non-corroding wheels
with nylon bearings, no lubrication
required, ENSURES trouble free
maintenance.
FEATURES &
BENEFITS
MODEL 298
Mulch Spreader
70 SERIES
90 SERIES
20 SERIES
179 SERIES
spread with confidence
Spreading Chart
Operation Guide
Service Manual
Parts List
spread with confidence
It’s the spread that counts
It’s the spread that counts
For Models:
30, 34, 54, 64
P.O. Box 7
140 Mill Street
Urbana, IN
46990 USA
1-800-972-6130
Fax: [phone]
Model 64 pictured

For Models 34 and 54 proceed to step number nine.
Drive bolt
hole
1. Caution: Tighten nuts only after complete
handle assembly has been made. Use caution
not to crush the tubing.
2. Position the axle/spinner assembly (Part #22 for
Models 54 & 64) (Part #47 for Model 34 Only)
in the frame (26), exactly as shown.
Frame and axle/spinner assembly must be
positioned exactly as shown for clockwise
rotation.
3. Slide the axle bushings
(23) over the axle and
into the frame.
Bushing flanges must
be on the outside of
the frame as shown.
Arms on the flanges
preferably toward the
ground when spreader
is assembled.
2
Did You Know?
Assembly Instructions
Tools you will need:
Flat head Screwdriver
7/16” & 3/8” wrenches
Hammer
Parts you will use:
• Hopper assembly
• Axle/gears/spinner assembly
• Drive pin for installation in
axle to engage drive wheel.
• Frame
•(2) support braces
• (2) wheels
• (2) axle bearings
• (2) wheel retainer caps
• (2) handle grips
• Rotary agitator - for use - only if required
and necessary - do not install initially
• Top “T” handle section
• Center handle section
• Lower ground prop section
• Rate control wire with lever
• (4) 1 1/2” long bolts
• (6) 1 1/4” long bolts
• (10) 1/4” nuts
•(1) Felt washer
•(1) Cable clip
•(2) 3/8” nuts
• (2) 1 1/8” nuts
For Quick and Easy Assembly - First Read Entire Procedure
Then Follow Carefully The Step by Step Instructions
1

4
7. Now install hopper to
frame. Slide the spinner
shaft (12) through the
bearing hole in the
bottom of the hopper.
8. Install front center bolt
& nuts (2-4) along
with the front grab
handle (52) (loosely)
first. Then install side
bolts, and
tighten all
bolts securely.
10 . Connect T-handle to
center section using
(1) 11 /
4
” bolt and nut.
9. Install the handle
grips (33) on han-
dle. For easier
installation, grips
may be lubricated
with water only.
*model 34 only
Note: Center sections is being
obsoleted. Your spreader may
not contain one.
Troubleshooting
Model 34 tire shown
Spreader Assembly
4. After installing
axle in frame.
Install 1 drive pin
(18) into axle for
drive wheel.
5. Install the wheels. Be
sure slotted hub side
is next to the frame.
(The drive pin will
engage the drive wheel.)
Note: model 54 has a black
plastic hopper.
3
6. CAUTION -- at this
point make certain
assembly is correct.
Then install wheel
retainers (25) by taping
firmly with a hammer
(Once installed,
removal is nearly
impossible.)
White Nylon Washer
45
45 45

15 .Check for proper alignment. Tighten ALL nuts
and bolts at this time.
16 . Attach lever control
assembly (34) to the
right hand side of
T-handle (30) using
(2) 3/8” x (11 /
8
”) bolt
and nut.
Tighten securely.
17 . Rate gate adjustment
procedure
New Linkage Adjustment Procedure
1. Set regulator dial to 1.
2. Set lever completely to offposition.
3. Attach cable clamp to ground prop
with
11 /
4
” bolt and nut and finger
tighten.
4. Route cable through clamp, then
through swivel and then tighten the
cable clamp bolt just enough to allow
the cable to slide back and forth easily.
5. Adjust sheath on cable so there is a
1/8" inch of control wire that is visible
between the sheath and the edge of
the rate gate linkage.
6
6. Tighten the cable clamp bolt to
secure the sheath.
7. Tighten the screw on the swivel
to anchor the wire, making sure
that the rate gate linkage is
pushed up against the dial.
8. Trim excess wire behind swivel
connector when finished
(if necessary).
Read Before Using
Read Before Using
Spreader Assembly
11 . Connect ground prop
to center section
using (1) 11 /
4
” bolt
and nut. The flattened
side of the ground
prop should be on the
opposite side as the
T-handle labels.
12 . Now use the 11 /
2
” bolt
and install support
braces (27) loosely to
handle assembly
14 . Secure the braces
(27) loosely to the
frame with a 11 /
2”
bolt and nut.
Braces must be on
the inside of the
frame.
13 . Position the spreader
as shown. Join the
handle loosely to the
crossbar, using the
11 /
2
” bolt.
5

30
35-36
2-4
2-4
2-4
2-4
2-4
51
2-4
3-4
3-4
3-4
3-4
3-4
3-4
2-4
4
42
2-4
2-4
33
31
6
8
37
37
9
10
7
7
5
34
27
23
26
27
32
13
28
28
11
49 - for model 34
12 - for models 54 & 64
16
15
16
17
18
19
15
14
25
25
21
21
21
21
29
20
20
23
38
52
17 for Models 54 & 64
Rate Gate
Assembly
41
Note: direction
of curve in
agitator wire
8
Extension Hopper
Notes:
1. A Calibrator is also available to do it yourself.
2. The rate gate is closed by pushing the control lever away from you.
The rate gate is opened by pulling the control lever toward you.
3. Either wheel can be used as the drive wheel.
* Standard fasteners available at most hardware departments.
Parts shipped open account to qualified accounts. All others, cash with order
or parts will be shipped C.O.D. at prevailing prices at time of shipment.
Exploded View
Read Before Using
Rate Dial Adjustment
Dial Setting Information
The RATE DIAL has 9 numbers with 10 stops
between each number, for accurate control of
the spreading rate.
The dial is set with only a turn. It will
automatically lock into the set position.
LINE UP THE DIAL NUMBER WITH THE
DIAL INDICATOR.
7
15
16
46
18
48
48
47
Model 34 Gear Box
22
Model 54 & 64 Gear Box
45 for Model 34 Only
8” x 2.25”
Super Duty
8.5” x 3.5”
Pneumatic
50 24
43
53 - Cover
(Models 34 & 64)
55 - Cover
(Model 54)
Read Before Using
Exploded View

SPEED - ACCURACY - FREEDOM FROM STRIPES AND STREAKS
are yours - when you use this Spreader.
The spread width ranges from 4 ft. to 12 ft. wide, depending on the volume/density,
particle size of the material and the rate of travel.
The spread thins or feathers at the outer edges, eliminating sharp, “Edge of spread”
lines which cause stripes and streaks. Extra coverage can be given under trees and
other heavy feeding areas without showing “edge of spread” lines.
Gaps and double overlaps are less likely. Small errors in travel are forgiven and do not
show.
WARNING: When spreading products containing herbicides, exercise extreme
caution with respect to careless spreading and to wind-drift.
CONTACT OF SOME PRODUCTS ON SOME PLANTS CAN BE FATAL.
If a dial setting is not found, use the size and weight comparison table found on the
back page.
Determine a dial setting on the low side. If the setting proves to be too low, cover the
area more than one time. A higher setting can be used when a proven dial setting is
established.
REMEMBER - Published dial settings can be approximate only. The operation of the
spreader, the condition of the material (damp or dry or over-pulverized) and weather
conditions, are all contributing factors.
For these reasons, it’s often a good idea to spread the area 2 times - at one-half rate -
in cross directions (SEE INFORMATION ON ONE-HALF RATE DIAL SETTINGS ON REFER-
ENCE CHART ON THE BACK PAGE. SPREADING AT ONE-HALF RATE DIAL SETTINGS IS
HIGHLY RECOMMENDED UNDER DAMP & HUMID CONDITIONS.
BECOME FAMILIAR WITH THE OPERATION OF THE SPREADER BEFORE YOU PUT
MATERIAL IN THE HOPPER.
Practice walking with the spreader, opening and closing the rate gate at the appropriate
times.
Travel at a constant speed and operate the spreader lever position.
Remember: Open the rate gate after the spreader is in motion at operating speed
(about 3 mph., or at a brisk walking pace).
Close the rate gate while spreader is still at operational speed.
Rotary Agitator
Use the rotary agitator only if needed. Free-flowing, lump-free materials will
not require the agitator. The rotary agitator is easily installed or removed.
Note the clockwise rotation & sweep. Place felt washer around spinner shaft
before inserting agitator. - See page #8.
OIL BEARINGS AND ALL MOVING PARTS
Make certain the spreader is running freely!
10
Item # Part # Quantity Description
1 SL-HP-1205 1 Hopper Only, 304 Stainless Steel
2 SS-90-0011 6 1/4 - 20 X 1 1/4” Bolt
3 SS-90-0012 3 1/4 - 20 X 1 1/2” Bolt
4 SS-91-0004 10 1/4 - 20 Lock Nut
5 SS-94-0007 1 Hopper Bottom Bearings
6 05-94-0068 1 Rate Gate
7 SS-94-0004 2 Rate Gate Guide
8 05-24-1101 1 Rate Gate Linkage
9 SS-94-0006 1 Dial Only
10 05-94-0069 1 Dial Mount
11 SS-94-0012 1 Spinner
12 SS-97-0004 1 Spinner Shaft
13 SS-96-0003 1 Rotary Agitator
14 SS-94-0009 1 Pinion Gear
15 SS-90-0001 2 1/8” x 3/4” Roll Pin/Pinion Gear/Bevel Gear
16 SS-90-0002 2 1/8” x 7/8” Roll Pin/Bevel Gear/Spinner
17 SS-97-0001 1 Axle
18 SS-90-0010 1 Drive Pin
19 SS-94-0010 1 Bevel Gear
20 SL-HP-1045 1 Gear Box with Bushing (Less Clamp Rings)
21 SS-94-0014 4 Clamp Rings Only
22 SL-HP-1004 1 Spinner Assembly/Axle, Gears, Gear Box, Spinner
23 SS-94-0011 2 Bushings for Axle at Frame
24 SS-95-0003 2 8” x 2.25” Super Duty Hard Rubber Wheel
25 SS-91-0001 2 Push Cap Nuts for Wheel Retention
26 SL-HP-1024 1 Painted Frame
27 SL-HP-1030 2 Support Brace Between Ground Prop & Frame
28 SS-92-0002 2 Felt Washer
29 05-94-0029 1 Bushing Only
30 05-24-1010 1 Top “T” Handle Section
31 SL-HP-1015 1 Center Handle Section
32 SL-HP-1120 1 Bottom Ground Prop Section
33 SS-94-0013 2 Handle Grips
34 05-98-0048 -1 1 On/Off Lever Control
35 05-91-0008 2 On/Off Lever Control Nut
36 05-90-0042 2 On/Off Lever Control Bolt
37 05-90-0044 1 Cable Fastener
38 05-24-1105 1 Cable Clamp
39 SS-90-0011 1 Cable Clamp Bolt
40 SS-91-0004 1 Cable Clamp Nut
41 SL-HP-1113 1 Rate Gate Assembly
42 05-90-0054 1 1/4 - 20 X 1-1/2” Hex Head/Frame/Ground Prop
05-99-0064 1 Manual
Model 54 Only
43 05-46-0500 1 Plastic Hopper
44 05-94-0065 1 Cover, Clear Plastic with Black
45 05-94-0064 3 Washer, Plastic
Model 34 Only
46 SS-97-0006 1 Axle 18 3/4” Long Drilled
47 SL-HP-1044 Axle, Gears, Gear Box, Spinner Assembly
48 99-50-1081 2 Axle, Cotter Pin
49 05-97-0008 1 Spinner Shaft 3/8 x 6 1/2
50 SS-95-0004 1 Pneumatic 8.5 x 3.5
51 05-24-1070 1 Hand Hold
Optional
52 05-82-0000 Extension Hopper
53 05-99-0021 Cover - Model 64 & 34
54 SL-EH-1005 Screen
55 05-94-0065 Cover - Model 54
Model 30 Only
56 05-54-0004 1Spinner Shaft
57 05-300-0500 1 Hopper
Parts List
9
Spreader Assembly

CONDITION Spreader pushes hard:
LOOK FOR . . . . . Dry bushings and corroded
shafts.
PROCEDURE. . . . Oil these points:
1. Bearing in hopper
bottom.
2. Axle bearings.
3. Idle wheel bushing.
4. Bushing in gear box: a. Spinner shaft
below gear; b. Hub end bevel gear;
c. Hub end of spinner gear; d.
Gears; e. Spinner shaft at gear box;
f. Axle shaft at gear box.
LOOK FOR . . . . . Corrosion on axle at
frame bushings - (A)
PROCEDURE. . . . Note: If bushings are corroded,
the corrosion must be removed,
preferably by filing or scraping.
The axle must be moved endways,
out of the axle bearing area. Remove
one wheel & open gear box to permit
sliding of axle. Gear box holding rings
are removed by prying - replaced by
forcing. Wheel holding push caps are
removed & replaced as shown.
To remove hubcap,
place chisel point on
lock tab. Strike
sharply with hammer.
To re-use hubcap,
place round punch in
lock tab opening. Strike
lightly. Deform each
tab 1/32”.
1
3
2
4
B
F
C
E
D
A
A
Round Punch
Tab
Hub Cap
12
Read Before Using
Now You are Ready to Put Material in the Hopper
• Make certain the rate gate is in closed position.
• As insurance against spill damage and spill loss, put material in the hopper with the
spreader on a walk, driveway, paper, plastic, etc.
• The spreader will be easier to use if you only half-fill the hopper. Later on you can fill the
hopper if you so choose.
• Or for added capacity, the inverted bag in the hopper can serve as a capacity extension.
Also, an extension hopper, complete with filtering and pulverizing screen, is available from
the manufacturer.
Now You are Ready to Spread
• Spread header strips at the ends of the area OPPOSITE the direction of spreading. This will
provide a “turn-around” area, an area to re-align the spreader for the return spread.
• Example is for 6 ft. wide spread: Make the first spreading
pass at one-half the spread width from the edge of the
spreading area or in this case approximately 3 feet or one
big step.
• Additional spreading passes will be at the full spread width
or approximately 6 feet apart.
• TAKE A SIGHTING AT THE FAR END. Keep your eye on the
sighting as you spread. You will not need to wonder where
you are or where you have been. Continue until spreading
is completed.
• Left over fertilizer can be spread under trees and other
high feeding areas without showing “edge of spread” lines.
NOTE: With the rotary agitator installed, the rate gate closed (not
spreading) and with material in the hopper, the spreader will push
harder than normal. (This is because the agitator is stirring the
material and it has no place to go.)
RECOMMENDATION: When not spreading and the spreader is being pushed some
distance, tip the spreader so only the idle wheel is on the ground.
Cleaning the Spreader is Part of the Spreading Job.
IMMEDIATELY AFTER USE - CLEAN AND OIL THE SPREADER
• Method #1 - Wipe spreader thoroughly with an oily cloth. Oil all bearings and
bearing areas.
•Method #2 - Wash, rinse, and dry the spreader. Note: Drying takes time. (Moisture
trapped in bearing areas is slow to go.) Immediately after drying - oil all bearings and
moving parts. Make certain all operations are thorough.
Note: Good “Dry Cleaning” is preferable to poor “Wet Cleaning”.
• It is virtually impossible to have rust and corrosion on a clean, dry, oiled surface.
• Again - just before using - oil all bearings and moving parts.
• In storage, ideally the spreader should be hung by the handle. In any case, do not pile
weight on the spreader, as excess weight over a period of time can distort the tires.
Header
Header
6’3’6’
11
Spreader Assembly

THERE'S MORE TO A SPREADER THAN MEETS THE EYE ––– LOTS MORE
Spreadability - Dial-a-matic regulator ensures exact spread rate. Accuway®
Spread Pattern Equalizer assures exact placement of the spread pattern - Bull's
Eye - dead to the center of the spreader. All products - All spreading conditions.
Skewing is eliminated.
Durability - Series 22 spreaders will survive use and abuse. Welded steel
construction is double braced, finished in baked on epoxy enamel. Generous
use of highest quality stainless steel. Guaranteed metal gears.
Reliability - You can count on. Accuway®spread control system is so innovative,
it's patented. Is so successful it's used on all Spyker series 22 spreaders. Is so
simple a complicated problem is solved with a fundamental solution.
(Newton's law of motion: To every action there is always an opposed and equal
reaction.)
Serviceability - 24 hour replacement parts service available direct from the
factory. Series 22 spreaders shipped set up except hand hold/bump bar and
push handle or tractor pull bar.
1 YEAR LIMITED WARRANTY
This is warranted to the original purchaser only, other than used
commercially, against defects in materials and workmanship, for a period of one
year from the date of purchase.
*For Spyker Spreaders LLC, products employing metal gear systems,
pinion and bevel, these metal gears, only, not inclusive of any other parts or
materials, are warranted for the life of the spreader, not to be used for
replacement or repair past original purchase.
Spyker Spreaders LLC will not be liable for any loss, damage or expense
including, but not limited to, consequential or incidental damages, arising from
the operation, condition or use of the item. The sole and exclusive remedy
against Spyker Spreaders LLC being the replacement of the defective parts.This
warranty gives you specific legal rights, and you may also have other rights
which vary from state to state.
THIS EXPRESS WARRANTY, WHICH IS APPLICABLE ONLY TO THE ORIGINAL
PURCHASE, IS IN LIEU OF AND EXCLUDES ALL OTHER WARRANTIES,
WHETHER EXPRESSED OR IMPLIED BY OPERATION OF LAW OR OTHERWISE,
INCLUDING ANY WARRANTY OF MERCHANTABILITY OR FITNESS FOR
PARTICULAR PURPOSE.
SPYKER SPREADERS LLC
P.O. Box 7 • Urbana, IN 46990 USA
14
Dial settings are approximate only. Spreading at one half rate in cross directions is usually recommended.
Manufacturer
and Product
Manufacturer’s
Bag Rate
Bag Sq. Ft.
Weight Coverage
Micro-Dial Settings
Full Rate Half rate
Once over Twice over
Spread
Width
(In feet
based on
brisk walking)
Bent Grass or Red Top 0.5# 1,000 1.25 4
1# 1,000 2.0 4
2# 1,000 2.5 4
Park, Merion, Delta, or Kentucky Bluegrass 0.5# 1,000 2.5 4
1# 1,000 3.0 4
2# 1,000 3.5 4
Hulled Bermuda 2# 1,000 2.75 2.25 6
3# 1,000 3.0 2.5 6
4# 1,000 3.25 2.75 6
Mixtures including coarse seeds 2# 1,000 6.0 6
4# 1,000 7.0 6
6# 1,000 7.0 6
Rye Grasses or Tall Fescue 2# 1,000 6.0 6
4# 1,000 7.0 6
6# 1,000 7.75 6
Dichondra 4 oz. 1,000 1.9 8
8 oz. 1,000 2.1 8
12 oz. 1,000 2.5 8
Pensacola Bahia 4# 1,000 4.5 3.75 7
5# 1,000 4.75 4.0 7
6# 1,000 5.0 4.25 7
Grass Seed Spreading Chart
Grass Seed Spreading Chart
Granule Size - Dial Setting Guide
Dial settings are approximate only.
Mixed Fine Pellets
Large Heavy Pellets
Med. Pellets
Med. Pellets & Granules
Nitrogen Pellets Med.
Small Pellets
Fine Pellets
Product Lbs. per 1000 Sq. Ft. Full Rate Half Rate
13.6 3.1
2 4.0 3.5
3 4.2 3.7
23.7 3.2
44.7 4.1
65.2 4.5
2 3 2.2
4 4.2 3.7
64.5 4
1 3.5 3
2 4.2 3.7
3 4.7 4
23.5 3
4 4.2 3.8
65.2 4.5
2 3.5 3
44.2 3.8
6 5.2 4.5
2 3.8 3.3
44.9 4.1
6 5.9 4.9
13
Spreader Assembly
