Vivotek MD7530 User manual

MD7530/7530D
MD7560/7560D
P/N:625011800G Ver1.0
Copyright 2010 VIVOTEK INC. All rights reserved.
c
Vandal-proof .Mobile Surveillance

EN - 1
English
Power off the Network Camera as
soon as smoke or unusual odors are
detected.
Contact your distributor in the event of
occurrence.
Refer to your user’s manual for
the operating temperature.
Warning Before Installation
Do not place the Network Camera on
unsteady surfaces.
Do not touch the Network Camera
during a lightning storm.
Do not drop the Network Camera.
Do not insert sharp or tiny objects
into the Network Camera.

EN - 2
Software CD
MD7530 / MD7560 or MD7530D / MD7560D
Quick Installation Guide /
Warranty Card
Screwdriver
Alignment Sticker
Ground Wire / Screws
5
1
0
0
0
0
2
1
0
G
Package Contents
1
Silica Gel / RJ45 Female/Female
Coupler
(PoE) General I/O Terminal Block
(With power cord)
Ethernet 10/100 RJ45 Plug
Microphone In (pink)
Power Cord Socket (black)

EN - 3
English
Network Camera
Model No: MD7530
Made in Taiwan
This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions:
(1)This device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that may cause undesired operation.
Pat. 6,930,709
RoHS
V I
MAC:0002D107258A
Record the MAC address
before installing the camera.
Screw Holes
Physical Description
2
Inner View
Outer View
Lens
MicroSD/SDHC Card Slot
Reset Button
Status LED
Temperature Sensor
The event will be triggered
once the temparature inside the
Network Camera reaches 60°C.
Waterproof Level: IP67

EN - 4
First, use the supplied screwdriver to detach the dome cover from the camera base. Insert your
MicroSD/SDHC Card if necessary.
Then, follow the steps below to install the camera to either the ceiling or the wall:
1. Attach the supplied alignment sticker to the ceiling/wall.
2. Using the 3 screw circles on the sticker, drill 3 pilot holes into the ceiling/wall. Then hammer the
plastic anchors into the holes if necessary.
3. This Network Camera can be mounted with the cable routed through the ceiling/wall or from the
side. If you want to feed the cable through the ceiling/wall, drill a cable hole A as shown in the
picture. If the cable goes through the side of the dome cover, please remove the rubber stopper
(B).
4. Through the 3 holes on the camera base, insert the screws to corresponding holes and secure
the camera base with a screwdriver.
1
2
3
4
A
B
A
Dome Cover
Hardware Installation
3
Tamper-proof Screw
Camera Base
Rubber Stopper
Ceiling Mount

EN - 5
English
1
2
B
A
3
4
Wall Mount
Installing the Ground Wire
As shown in the following figure, please secure one side of the supplied ground wire to the screw
hole, then route the other side of the ground wire to the ground.
Please secure the screws tightly to
avoid moisture.

EN - 6
General Connection (without PoE) (MD7530D / MD7560D)
Network Deployment
4
+ : Digital input
- : Digital input
POWE
RC
OLLIS
ION
LINK
R
E
C
E
IVE
PAR
TITION
12345
2
3
Ethernet Switch
1
1. If you have external DI devices, make the connection from general I/O terminal block.
2. Use the supplied RJ45 female/female coupler to connect the Network Camera to a switch.
Use a Category 5 Cross Cable when Network Camera is directly connected to PC.
3. Connect the power cable from the Network Camera to a power outlet.

EN - 7
English
Power over Ethernet (PoE) (MD7530 / MD7560)
POWE
RC
OLLIS
ION
LINK
R
E
C
E
IVE
PAR
TITION
12345
PoE Switch
When using a non-PoE switch
Use a PoE power injector (optional) to connect between the Network Camera and a non-PoE
switch.
When using a PoE-enabled switch
This Network Camera is PoE-compliant, allowing transmission of power and data via a single
Ethernet cable. Follow the below illustration to connect the camera to a PoE-enabled switch via
Ethernet cable.
POWER COLLISION
LINK
RECEIV E
PARTITION
12345
PoE Power Injector
(optional)
Non-PoE Switch

EN - 8
Network Camera
Model No: MD7530
Made in Taiwan
This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions:
(1)This device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that may cause undesired operation.
Pat. 6,930,709
RoHS
V I
MAC:0002D107258A
1. Install “Installation Wizard 2” from the Software Utility directory on the software CD.
2. The program will conduct an analysis of your network environment. After your network is ana-
lyzed, please click on the “Next” button to continue the program.
3. The program will search for VIVOTEK Video Receivers, Video Servers, and Network Cameras
on the same LAN.
4. After searching, the main installer window will pop up. Click on the MAC that matches the one
labeled on the bottom of your device to connect to the Network Camera via Internet Explorer.
0002D107258A
00-02-D1-07-25-8A 192.168.5.151 MD7530
Installation
Wizard 2
Assigning an IP Address
5

EN - 9
English
For further setup, please refer to the user's manual on the software CD.
Ready to Use
6
1. Access the Network Camera on the LAN.
2. Retrieve live video through a web browser or recording software.
To adjust the viewing angle
Adjust the lens to a desired viewing angle as the diagram shown below.
90°
Adjusting the Lens
7
DO NOT over rotate the lens. Doing
so will damage the camera lens
module.

EN - 10
Attach the dome cover to camera.
Secure the dome screws with the
supplied screwdriver. Finally, make sure
all parts of the camera are securely
installed.
Completion
8
Fine-tune the Camera Focus
The focus of this network camera is set from 1.0m to infinity by factory default. If you want to focus
on objects closer than 1.0m or the lens has lost focus, please fine tune it in the following way.
Tighten the lens lock screw.
1. Loosen the lens lock screw.
2. Manually rotate the lens to fine-tune the focus
until the live image is clear.
3. Tighten the lens lock screw.
Please secure the screws tightly to
avoid moisture.
Tear down the aluminum foil vacuum bag and
take out the silica gel. Attach the supplied silica
gel to the inner side of the Network Camera.
(Please replace the silica gel with a new one if
you open the back cover after installation.)
