Vivotek SD8364E/ -M User manual

Speed Dome
Network Camera
SD8364E
1080p HD • 30x Zoom • NEMA 4X • IP66 •
Defog • -40°C ~ 55°C • EIS • PoE Plus
VIVOTEK SD8364E is part of the SUPREME series product line offering 1080p
Full HD resolution with superb image quality. Adopting a 30x optical zoom lens,
the SD8364E is able to capture details at top-notch quality. The IP66- and
NEMA 4X-rated housing protects the camera body against rain, dust and
corrosion within a wide temperature range between -40°C to 55°C. This feature
ensures operation under extreme weather conditions and hazardous
environments. It is especially suitable for monitoring wide open indoor/outdoor
spaces such as airports, highways and parking lots where high-level reliability
and precision are always required.
The SD8364E supports high-performance H.264/MPEG-4/MJPEG
compression technology and offers extra smooth video quality with resolution
up to 30 fps @ 1080p. Boasting WDR Pro technology, the SD8364E can also
cope with challenging lighting conditions and generate image quality close to the
capabilities of the human eye. With a sophisticated pan/tilt mechanism, the
camera provides fast, precise movement with continuous 360-degree pan and
220-degree tilt. Users can also easily control the lens position via a mouse or a
joystick to track the object of interest and set up to 128 preset positions for
patrolling. With the built-in auto tracking feature, the SD8364E provides
instantaneous reaction to suspicious moving objects in wide area locations
before operators are aware of activity.
As with all VIVOTEK true day/night cameras, the SD8364E features a
removable IR-cut filter, maintaining clear images 24 hours a day. With audio
detection, by recognizing increases or decreases in sound volume, an additional
layer of intrusion detection is ensured. With other advanced features such as
SD/SDHC/SDXC card slot, 802.3at compliant PoE Plus and 60 fps high quality
video, the SD8364E is the best choice for the most demanding outdoor
surveillance applications.
● 1080p Full HD SONY CMOS Sensor
● 30 fps @ 1080p Full HD; 60 fps @ 720p HD
● 30x Zoom Lens
● Removable IR-cut Filter for Day & Night Function
● 360° Continuous Pan and 220° Tilt
● Real-time H.264, MPEG-4 and MJPEG Compression
(Triple Codec)
● WDR Pro for Unparalleled Visibility in High Contrast
Environments
● Weather-proof IP66-rated and NEMA4X Housing
● -40°C ~ 55°C Wide Temperature Range for Extreme Weather
Conditions
● Audio Detection for Instant Alerts
● Auto Tracking for Moving Objects
● Built-in 802.3at Compliant PoE Plus
● 3D Privacy Masks for Additional Protection
● Built-in SD/SDHC/SDXC Card Slot for On-board Storage
● Defog
Features
Campus Station
Airport Port

Technical Specifications
Mounting Kits PoE Kits
Others
Power Adapter
Video Motion Detection
Auto-Tracking
Alarm Triggers
Alarm Events
Connectors
LED Indicator
Power Input
Power Consumption
Dimensions
Weight
Casing
Safety Certifications
Operating Temperature
Warranty
Operating System
Web Browser
Other Players
CD
Others
Intelligent Video
Alarm and Event
General
System Requirements
Included Accessories
Triple-window video motion detection
Auto-tracking on moving object
Video motion detection, manual trigger, periodical trigger, system
boot, recording notification, camera tampering detection, audio
detection
Event notification using digital output, HTTP, SMTP, FTP and
NAS server
File upload via HTTP, SMTP, FTP and NAS server
RJ-45 cable connector for Network/PoE connection
Audio input
Audio output
AC 24V power input
Digital input*4
Digital output*2
RS-485 for PTZ control (PelcoD protocol, Baud rate 2400)
System power and status indicator
PoE plus (IEEE 802.3at compliant)
High Power PoE
AC 24V
PoE plus:
Max. 19W
AC 24V:
Max. 48W (heater on)
Max. 19W (heater off)
High Power PoE:
Max. 48W (heater on)
Max. 19W (heater off)
Ø: 205 mm x 321 mm
Net: 3,660 g
Weather-proof IP66- and NEMA 4X-rated metal housing
Built-in electrical dehumidifier device (SD8364E-M)
CE, FCC Class A, VCCI, C-tick, NEMA 4X
-5°C ~ 55°C (PoE Plus)
-40°C ~ 55°C (AC 24V)
-40°C ~ 55°C (High Power PoE)
36 months
Microsoft Windows 7/Vista/XP/2000
Mozilla Firefox 7~10 (Streaming only)
Internet Explorer 9.x or 10.x
VLC: 1.1.11 or above
Quicktime: 7 or above
User's manual, quick installation guide, Installation Wizard 2,
ST7501 32-channel recording software
Wall mount bracket, screws, waterproof connectors, terminal
blocks, quick installation guide, warranty card, alignment sticker,
ground wire, T25 stardriver, software CD, desiccant bags
Model
CPU
Flash
RAM
Image Sensor
Maximum Resolution
Lens Type
Focal Length
Aperture
Auto-iris
Field of View
Shutter Time
WDR Technology
Day/Night
Minimum Illumination
Pan Speed
Pan Range
Tilt Speed
Tilt Range
Preset Locations
Pan/tilt/zoom Functionalities
On-board Storage
Compression
Maximum Frame Rate
Maximum Streams
S/N Ratio
Dynamic Range
Video Streaming
Image Settings
Audio Capability
Compression
Interface
Users
Protocols
Interface
ONVIF
System Information
Camera Features
Video
Audio
Network
SD8364E
SD8364E-M (With Electric Dehumidifier)
Multimedia SoC (System-on-Chip)
128 MB
256 MB
1/2.8" Progressive CMOS
1920x1080
30x Optical Zoom, Auto Focus
f = 4.3~129 mm (30x zoom)
F1.6 ~ F4.7
DC-iris
23° ~ 64° (horizontal)
13° ~ 36° (vertical)
26° ~ 73° (diagonal)
1/1 sec. to 1/10,000 sec.
WDR Pro
Removable IR-cut filter for day & night function
0.5 Lux @ F1.6, 30 IRE (Color)
0.03 Lux @ F1.6, 30 IRE (B/W)
0.05° ~ 450° / sec
360 endless
0.05° ~ 450° / sec
220° (-110° ~ +110°)
256 preset locations
48x digital zoom (4x on IE plug-in, 12x built-in)
Auto pan mode
Auto patrol mode
SD/SDHC/SDXC card slot
H.264, MJPEG & MPEG-4
H.264:
30 fps @ 1920x1080
60 fps @ 1280x720
MPEG-4:
30 fps @ 1920x1080
60 fps @ 1280x720
MJPEG:
30 fps @ 1920x1080
60 fps @ 1280x720
(Up to 30/60 fps in WDR mode)
4 simultaneous streams
Above 50 dB
Above 86 dB
Adjustable resolution, quality and bitrate
Zoom enhancement for better image quality under limited
bandwidth
Adjustable image size, quality and bit rate
Time stamp, text overlay, flip & mirror
Configurable brightness, contrast, saturation, sharpness, white
balance, exposure control, gain, backlight compensation,
privacy masks (Up to 24)
Scheduled profile settings
Defog
Audio input/output (full duplex)
AAC, G.711, G.726
External microphone input
External line output
Live viewing for up to 10 clients
IPv4, IPv6, TCP/IP, HTTP, HTTPS, UPnP, RTSP/RTP/RTCP,
IGMP, SMTP, FTP, DHCP, NTP, DNS, DDNS, PPPoE, CoS,
QoS, SNMP, 802.1X
10Base-T/100 BaseTX Ethernet (RJ-45)
Supported, specification available at www.onvif.org
Compatible Accessories
Dimensions
205 mm 316 mm
391 mm 321 mm
AA-341
AC 24V power
adapter
AM-116
20 cm
pendant pipe
AM-117
40 cm
pendant pipe
AM-118
Indoor
pendant head
AM-231
Parapet
mounting kit
AM-519
1.5" PT adapter
AP3001
PoE plus
injector
AC-212
Smoked cover
AC-111
Vandal-proof
transparent
cover
AO-001
Combo cable
AM-221
Goose neck
mounting kit
AM-103
Recessed kit
AP-331
High power
PoE injector
All specications are subject to change without notice. Copyright © VIVOTEK INC. All rights reserved.
Ver 1.2
