Viztek Ultra U-Arm User manual

Ultra Installation Guide v2.0
1
Customer Support
1.800.366.5343 – [e-mail]
VZ0022UG201509-2.0
Ultra U-arm
Installation Guide
Table of Contents
Unpacking Guide pg.2
Panel System Parts pg.24
Stand Installation pg. 27
Generator Installation pg. 32
Panel Interface Wiring pg. 34
Generator Jumper Configuration pg. 37
Generator Tech Service Configuration pg. 38
Generator Auto Calibration pg. 40
Stand Calibration pg. 42
Panel Setup and Calibration pg. 45
AEC Calibration pg. 49
Anti Crushing Verification pg. 50
J4 missing wiring pg. 50
Install Guide Checklist pg.51
Checks to be completed prior to Applications
arrival pg. 52

Ultra Installation Guide v2.0
2
Customer Support
1.800.366.5343 – [e-mail]
VZ0022UG201509-2.0
Unpacking Guide
Main Crate
Main Crate packing list
1. U-Arm
2. Tube Neck
3. Wall Support
4. X-ray Tube
5. Collimator
6. HV Cables
7. Detector Assembly Support (Bucky)
8. Base cover
9. Top Cover
10. Manuel
11. CF Card
12. Handle
13. Grease
14. Wrench
15. Bags of screws,
16. Column Harness

Ultra Installation Guide v2.0
3
Customer Support
1.800.366.5343 – [e-mail]
VZ0022UG201509-2.0
U-Arm
Tube Neck
Wall Support

Ultra Installation Guide v2.0
4
Customer Support
1.800.366.5343 – [e-mail]
VZ0022UG201509-2.0
X-ray Tube
Collimator

Ultra Installation Guide v2.0
5
Customer Support
1.800.366.5343 – [e-mail]
VZ0022UG201509-2.0
HV Cables
Detector Assembly Support (Bucky)
U-arm Base cover

Ultra Installation Guide v2.0
6
Customer Support
1.800.366.5343 – [e-mail]
VZ0022UG201509-2.0
U-arm Top Cover
Tube Head Cover
U-Arm Manuel

Ultra Installation Guide v2.0
7
Customer Support
1.800.366.5343 – [e-mail]
VZ0022UG201509-2.0
CF Card (Sedecal) , Rotation Handle, Grease, Wrench, Bags of screws, Cable Wrap, Tube Shims, &AEC Manual

Ultra Installation Guide v2.0
8
Customer Support
1.800.366.5343 – [e-mail]
VZ0022UG201509-2.0
Second Crate
Second Crate packing list
1. Generator
2. Generator Manuel
3. CD (software)
4. Bolts bag
5. Generator adapter backing
6. Handswitch
7. Generator cables
8. PCI chip (on/off Board) – (not used by Viztek)

Ultra Installation Guide v2.0
9
Customer Support
1.800.366.5343 – [e-mail]
VZ0022UG201509-2.0
Generator
Generator Manuel

Ultra Installation Guide v2.0
10
Customer Support
1.800.366.5343 – [e-mail]
VZ0022UG201509-2.0
CD (software)
Bolts bag
Generator adapter backing (attaches to stand box)

Ultra Installation Guide v2.0
11
Customer Support
1.800.366.5343 – [e-mail]
VZ0022UG201509-2.0
Mini Console (Handswitch)
Generator Cables
(Left: rotor cable Right: stand power box to generator J5 cable)

Ultra Installation Guide v2.0
12
Customer Support
1.800.366.5343 – [e-mail]
VZ0022UG201509-2.0
PCI chip (on/off Board) – (not used by Viztek)

Ultra Installation Guide v2.0
13
Customer Support
1.800.366.5343 – [e-mail]
VZ0022UG201509-2.0
Third Crate
Third Crate packing list
1. Stand box

Ultra Installation Guide v2.0
14
Customer Support
1.800.366.5343 – [e-mail]
VZ0022UG201509-2.0
Pallet
Pallet packing list
1. Crate four
a. Toshiba panel
b. Toshiba software
c. Toshiba manual
d. (2) ground cables
e. Generator power cord
2. Pc Box
a. Tower
b. Keyboard
c. Catch all box
i. Manual
ii. Install checklist
iii. (2) dell software cds
iv. U25 generator chip
v. Usb mouse
vi. 8gb thumb drive
vii. CF Card (Viztek version)
viii. Warning label for
Handswitch
ix. Blue 14ft standard Ethernet
cable
x. Black 75ft standard Ethernet
cable
xi. (2) power cords
xii. Toshiba Integration Board
xiii. Toshiba Integration board
screws
xiv. Viztek antivirus pamphlet
xv. 3ft DB9 to DB9 cable
xvi. 25ft DB9 to DB9 Cable
xvii. IR Remote
3. (2) Battery Backup
4. Monitor Box
a. Manual
b. Software
c. VGA cable
d. Serial cable
5. Grid
6. Grid frame

Ultra Installation Guide v2.0
15
Customer Support
1.800.366.5343 – [e-mail]
VZ0022UG201509-2.0
Crate four
Toshiba panel

Ultra Installation Guide v2.0
16
Customer Support
1.800.366.5343 – [e-mail]
VZ0022UG201509-2.0
Toshiba software, Manual
(2) Ground cables, and Generator power cord

Ultra Installation Guide v2.0
17
Customer Support
1.800.366.5343 – [e-mail]
VZ0022UG201509-2.0
Pc Box
Tower
Keyboard

Ultra Installation Guide v2.0
18
Customer Support
1.800.366.5343 – [e-mail]
VZ0022UG201509-2.0
Accessories and Wire Box
PC Manual, Installation checklist, (2) dell software cds
Viztek Mouse Pad, Usb mouse, 8gb thumb drive, CF Card (Viztek version), Warning label for Handswitch, Blue 14ft
standard Ethernet cable

Ultra Installation Guide v2.0
19
Customer Support
1.800.366.5343 – [e-mail]
VZ0022UG201509-2.0
U24 generator chip, Black 75ft standard Ethernet cable
(2) Power cords, 3ft DB9 to DB9 cable, 25ft DB9 to DB9 Cable

Ultra Installation Guide v2.0
20
Customer Support
1.800.366.5343 – [e-mail]
VZ0022UG201509-2.0
Toshiba Integration Board, Toshiba Integration board screws
Viztek antivirus pamphlet
IR Remote
