VMware VCENTER APPLICATION DISCOVERY MANAGER 6.0 User manual

vCenter Configuration Manager
and
vCenter Application Discovery Manager Integration
Guide
vCenter Configuration Manager 5.3
vCenter Application Discovery Manager 6.0
This document supports the version of each product listed and supports all
subsequent versions until the document is replaced by a new edition. To
check for more recent editions of this document, see
http://www.vmware.com/support/pubs.
EN-000447-00

Copyright You can find the most up-to-date technical documentation on the VMware Web site at:
http://www.vmware.com/support/
The VMware Web site also provides the latest product updates.
If you have comments about this documentation, submit your feedback to:
[e-mail]
© 2006-2010 VMware, Inc. All rights reserved. This product is protected by U.S. and international copyright and
intellectual property laws. VMware products are covered by one or more patents listed at
http://www.vmware.com/go/patents.
VMware is a registered trademark or trademark of VMware, Inc. in the United States and/or other jurisdictions. All
other marks and names mentioned herein may be trademarks of their respective companies.
VMware, Inc.
3401 Hillview Ave.
Palo Alto, CA 94304
www.vmware.com
vCenter Configuration Manager and Application Discovery Manager Integration Guide
2 VMware, Inc.

Contents
About This Book 5
Configuring Application Discovery Manager for Integration 7
Installing the ADM SQL Database 7
Configuring the ADM Database Synchronization 8
Preparing the Client Browsers 8
Creating Users for Integration 8
Configuring VCM for Integration 9
Configuring VCM Integration Settings 9
Using Application Discovery Manager in VCM 11
Machine Group Synchronization 11
ADM Tools in VCM 12
Viewing ADM Details 12
Viewing ADM Maps 12
VMware, Inc. 3

vCenter Configuration Manager and Application Discovery Manager Integration Guide
4 VMware, Inc.

About This Book
About This Book This manual, vCenter Configuration Manager and Application Discovery Manager Integration Guide, describes
how to integrate Application Discovery Manager with vCenter Configuration Manager (VCM). This
document describes:
nConfiguring the Application Discovery Manager integration
nConfiguring the VCM integration
nUsing Application Discovery Manager in Service Assurance Manager
Read this document and complete the associated procedures to prepare for a successful integration.
Intended Audience
The information presented in this manual is written for system administrators who are experienced
Windows or UNIX/Linux system administrators and who are familiar with managing network users and
resources, and performing system maintenance.
To use the information in this guide effectively, you must have a basic understanding of how to configure
network resources, install software, and administer operating systems. You also need to fully understand
your network’s topology and resource naming conventions.
Document Feedback
VMware welcomes your suggestions for improving our documentation. If you have comments, send
your feedback to [e-mail].
VMware vCenter Configuration Manager Documentation
The vCenter Configuration Manager and Application Discovery Manager Integration Guide consists of the
vCenter Configuration Manager documentation and this manual.
VMware, Inc. 5

Technical Support and Education Resources
The following technical support resources are available to you. To access the current version of this book
and other books, go to http://www.vmware.com/support/pubs.
Online and Telephone
Support
To use online support to submit technical support requests, view your product
and contract information, and register your products, go to
http://www.vmware.com/support.
Customers with appropriate support contracts should use telephone support for
priority 1 issues. Go to http://www.vmware.com/support/phone_support.html.
Support Offerings To find out how VMware support offerings can help meet your business needs,
go to http://www.vmware.com/support/services.
VMware Professional
Services
VMware Education Services courses offer extensive hands-on labs, case study
examples, and course materials designed to be used as on-the-job reference tools.
Courses are available onsite, in the classroom, and live online. For onsite pilot
programs and implementation best practices, VMware Consulting Services
provides offerings to help you assess, plan, build, and manage your virtual
environment. To access information about education classes, certification
programs, and consulting services, go to http://www.vmware.com/services.
vCenter Configuration Manager and Application Discovery Manager Integration Guide
6 VMware, Inc.

Configuring Application Discovery Man-
ager for Integration 1
Configuring Application Discovery Manager
for Integration
Integration between VMware vCenter Application Discovery Manager (ADM), and VMware vCenter
Configuration Manager (VCM) provides VCM-rich relationship and configuration details. The views
include the devices dependencies and underlying infrastructure configurations.
Configuring the integration between ADM and VCM requires the following:
nConfigure ADM for Integration: The ADM configuration process is primarily comprised of installing
an external ADM database on the VCM Collector (or SQL database) machine, and then configuring the
synchronization of data from the main ADM database to the external ADM SQL database. VCM
integrates with the synchronized data in the external database.
nConfigure VCM for Integration: The integration with ADM is built into VCM. Configuring
integration in VCM requires only the configuration of the settings.
Before VCM users have access to the ADM data, the Application Discovery Manager integration with
VCM requires the following:
nADM External Database: An external SQL database is installed on the VCM database machine.
nSynchronization: The main ADM database must be configured to synchronize data with the external
ADM database.
nClient Browsers: Install Internet Explorer and Java on the VCM client machines.
nUser Accounts: Create one or more ADM user accounts to be used by VCM users to access ADM.
These requirements are described next. After the integration is complete, you can access ADM data while
working in VCM. The final section of this manual provides instructions for launching ADM details and
ADM maps.
Installing the ADM SQL Database
VCM does not directly access the main ADM database. Rather, an external Microsoft SQL database is
installed on the VCM Collector machine (or on the database machine, in the case of split installations).
Detailed instructions for installing and configuring the external MS SQL database are provided in the
VMware vCenter Application Discovery Manager: Repository Reference Guide. Review that manual and follow
the directions in it for installing and configuring the SQL database. Then use this integration guide for
additional configuration information unique to the VCM integration.
When modifying the installation scripts, be sure to replace <serverName> with the name of the SQL
Server instance running the VCM database.
VMware, Inc. 7

Configuring the ADM Database Synchronization
After installing the external ADM SQL database, you must configure the synchronization of the ADM data
from the main database to external database.
Instructions for configuring the synchronization are provided in the VMware vCenter Application Discovery
Manager: Repository Reference Guide. Follow the instructions for configuring the synchronization.
The synchronization process uses FTP to send data from the main ADM database to the external database.
When creating your synchronization schedule, be sure the synchronization is set to be regular enough to
keep the external data current enough so that it is of use to VCM users.
Preparing the Client Browsers
In order to view the ADM maps, Internet Explorer and Java must be installed on any VCM machines using
the integration with the ADM Console. The requirements include:
nMicrosoft Internet Explorer 6.0, available from the Microsoft Website.
nJava Runtime Environment, version 5.0.3 or later, available from the Java Website.
Creating Users for Integration
Any user who will be accessing the ADM data must have an ADM user name and password. In ADM, you
must create user accounts and distribute the login information to all VCM users who will be accessing the
ADM data. A user login is required at the beginning of each session when a user accesses the ADM details
or ADM maps.
vCenter Configuration Manager and Application Discovery Manager Integration Guide
8 VMware, Inc.

Configuring VCM for Integration 2
Configuring VCM for Integration The integration with ADM is built into VCM. To configure the integration with ADM, you only need to
configure the ADM integration settings.
Configuring VCM Integration Settings
Before you can use the ADM integration options, you must configure the settings.
1. In VCM, Select the setting to be configured, and then click Edit Settings.
2. The Settings Wizard page appears. The information to be configured in the wizard varies depending
on selected setting. The configuration options are as follows:
nADM Integration Enabled
nSelect Yes to enable the integration or No to disable the integration.
nIf enabled, the View ADM Detail and View ADM Map buttons become active when you
are working with machine data, for example, Console | Windows | Operating Systems
| Machines.
nIf the setting is enabled, the ADM Reporting Database Name and ADM Server Name
or IP Address must also be configured.
nADM Reporting Database Name
nType the name of the SQL database created on the Collector to synchronize with the
ADM database. The default value is ADM.
nADM Server Name or IP Address
nType the IP address or server name of the ADM server.
nMaximum number of hosts that may be submitted to ADM Map View
nType the maximum number of machines/hosts to display when you select the View
ADM Map button. While 10 is the default value, it is recommended that you only view 3
or 4 devices in a map view. If you view more than 4 devices, the displayed map is too
complex to be useful.
3. Verify your settings. Click Finish. The settings are applied.
NOTE You must either press F5 to refresh the Console, or log out and log back in to view the active
buttons.
VMware, Inc. 9

vCenter Configuration Manager and Application Discovery Manager Integration Guide
10 VMware, Inc.

Using Application Discovery Manager in
VCM 3
Using Application Discovery Manager in
VCM
After configuring your integration with ADM, you can now access ADM's rich application details and
dependency maps while working in VCM.
As a dependency discovery tool, ADM enhances VCM's view of machines and machine relationships
before implementing changes in the network. The ADM discovered data, which is very detailed, is read-
only. By using ADM with VCM, you will be able to view deep details about a machine (View ADM Details)
and view the relationships between machines (View ADM Map) while still using VCM to manage changes.
Machine Group Synchronization
The ADM data is synchronized with the ADM external database, which is then reconciled with VCM data.
The machine reconciliation is based on the MAC address, machine name, and IP address. After the
machine data is reconciled, ADM's groups are replicated in VCM as Machine Groups.
To view the ADM machine group, click Administration | Machine Manager | Machine Groups | All
Machines | vCenter Application Discovery Manager. The vCenter Application Discovery Manager
data grid appears, displaying the groups. Double-click the group to display the detailed machine data grid
for each group.
VMware, Inc. 11

ADM Tools in VCM
You can view machine-related data from the Console, including Window, UNIX, and Virtual
Environments. There is no link to Active Directory data because it does not relate to a specific machine.
You can access two views of ADM data when ADM is enabled. The methods to access the options include:
nVCMtoolbar: In the data grid, select a row, and then click one of the ADM buttons in the main toolbar.
nLocal Menu: In the data grid, right-click on a row. In the local menu, select one of the menu options.
Viewing ADM Details
ADM details display the host/device properties for a single machine. The default view is the ADM
Discover | Inventory page. From this page, you can view additional ADM details about the host/device.
1. When working in the Console, in machine-related data grids, select a row, and then click the View
ADM details button. You can view only the details for a single machine. If you select more than one
machine, an error message appears. Clear the multiple selections, select one machine, and then click
View ADM details again.
2. On the first login of the session, the Application Discovery Manager Login page appears. Type the
ADM administrator-provided Username and Password.
3. Click Login. The ADM Host/Device Properties page appears.
4. The Host/Devices Properties page displays the ADM-discovered information about the selected
machine. You may also view the data provided on the other tabs. For more information about the
ADM data, click Help on the ADM menu bar.
Viewing ADM Maps
ADM maps display the relationships between two or more host/devices. The devices include hosts (servers
and clients), connections between hosts, connection details and protocols, and service details. The maps
display the devices in the selected group and the protocols connecting them.
1. When working in the Console, in machine-related data grids, select two or more rows, and then click
the View ADM map button.
2. On the first login of the session, the Application Discovery Manager Login page appears. Type the
ADM administrator-provided Username and Password.
3. Click Login. The map page appears.
4. The map page displays the ADM-discovered relationships between the selected devices. To learn more
about using the map view, select Help | Documentation on the menu bar.
vCenter Configuration Manager and Application Discovery Manager Integration Guide
12 VMware, Inc.
