vCenter Configuration Manager
Transport Layer Security
Implementation
VMware VCM 5.3
WHITE PAPER

TECHNICAL WHITE PAPER / 2
Table of Contents
Introduction to TLS 4
Server Authentication 4
Mutual Authentication 4
Certificates and Public Key Infrastructure 5
Expiration and Revocation 5
Certificate Standards 6
Certificate Storage 6
How VCM Uses Certificates 7
The Enterprise Certificate 7
The Collector Certificate 10
Agent Certificates 10
TLS Machine Security Level 11
Creating and Installing Certificates for Collectors 12
Installation of Certificates to Collectors 12
Installation of Certificates to Additional Collectors 12
Changing Certificates 13
Renewing Certificates 13
Replacing Certificates 13
Delivering Initial Certificates to Agents 15
Installing the Agent from the Collector 15
New Installations 15
Upgrades 15
Changing Protocols from DCOM to HTTP 15
Changing Protocol from HTTP to DCOM 15
Installing the Agent from a Disk (Windows only) 16
Using CMAgtInstall.exe via Network Share to Install the Agent (Windows only) 16
UNIX/Linux or Mac OS X 16
Installing the Agent Using a Provisioning System 16
TLS Implementation for VCM

TECHNICAL WHITE PAPER / 3
Certificate Expiration 17
Certificate Transport 17
Exporting Certificates (Windows Only) 17
Importing Certificates (Windows Only) 18
Appendix A: Creating Certificates for TLS Using Makecert 20
Create the Enterprise Certificate and the First Collector Certificate 20
Create Certificates for Additional Collectors 21
Import the Certificates on the Collector Machines 23
MakeCert Options 23
Appendix B: Updating the Collector Certificate Thumbprint in the VCM Collector Database 26
Appendix C: Managing the VCM UNIX Agent Certificate Store 27
Using CSI_ManageCertificateStore 27
Setting up the Command Line Environment for CSI_ManageCertificateStore 27
CSI_ManageCertificateStore Options 28
CSI_ManageCertificateStore Output 30
CSI_ManageCertificateStore Examples 30
TLS Implementation for VCM

TLS Implementation for VCM
TECHNICAL WHITE PAPER / 4
Introduction to TLS
Transport Layer Security (TLS) and its predecessor, Secure Sockets Layer (SSL), are cryptographic protocols that
provide endpoint authentication and secure communications over any transport. TLS is normally associated with
Internet communication but can be applied to any transport layer, including sockets and HTTP. TLS allows for two
levels of security: Server Authentication and Mutual Authentication.
Server Authentication
Server Authentication authenticates the server to the client. When server authentication is used, the end user, or
client, verifies that the server they are communicating with is actually who it says that it is. In the Internet world, your
browser is the client, and a website such as Amazon™ is the server. Millions of clients need to be able to prove that
the site to which they are giving financial information is really Amazon™.
To accomplish this using TLS, Amazon™ provides a certificate issued by a trusted authority, such as Verisign®. If
your browser has the Verisign® Certification Authority certificate in its trusted store, it can trust that the server really is
Amazon™. Typically, the server authenticates the client/user by asking for authentication information, such as a user
name and password.
VCM supports Server Authentication. That is, in VCM environments where TLS is employed, VCM Agents are able to
verify the identity of the VCM Collector (or Collectors) through the use and verification of certificates. A description of
this process is provided later in this paper.
Mutual Authentication
Mutual Authentication authenticates the server to the client, and the client to the server. When Mutual Authentication
is used, both the client and the server provide and validate certificates in order to verify each other’s identity.
VCM is Mutual Authentication ready. This means that Agent certificates can be manually created and registered to
create a Mutual Authentication environment. However, VCM does not support this mode out-of-the-box, or supply any
functionality to aid in the administration of Agent Certificates. Contact VMware Customer Support for instructions.

TLS Implementation for VCM
TECHNICAL WHITE PAPER / 5
Certificates and Public Key Infrastructure
A Public Key Infrastructure, or PKI, is a management system that aids in the administration and distribution of public
keys and certificates. TLS can use certificates managed by a public key infrastructure to guarantee the identity of
servers and clients. Certificates can be created, managed and used by TLS without a PKI. For more information about
manually creating certificates, see Creating Certificates for TLS Using Makecert on page 20.
There are two main types of encryption algorithms:
lSingle Key, symmetric, or secret key encryption algorithms use a single key, which must be kept secret.
lPublic Key, or asymmetric algorithms use a pair of keys. One key is used to encrypt information, the other to
decrypt. The process is reversible. Either key can be used to encrypt. The other must be used to decrypt. Asym-
metric encryption is much slower than symmetric encryption. It is common to use an asymmetric protocol to
securely negotiate a session key, which is a secret key used only for the duration of a single connection. The
public key in a key pair may be freely passed around. However, it is important to verify that you have the key
you think you have, and that it belongs to the entity you think it belongs to. Certificates are a mechanism for
making this identification.
A certificate is a package containing a public key, information identifying the owner or source of the key, and one or
more certifications (or signatures) verifying that the package is authentic.
To sign a certificate, an issuer adds information about itself to the information already in a certificate request. The
public key and identifying information are hashed and signed using the private key of the issuer's certificate.
If you have the public key of the issuer, you can verify that the public key in the certificate belongs to the entity
identified in the certificate (if you trust the issuer). You will have a certificate for the issuer with the same type of
information. The issuer’s certificate is, in turn, signed by another issuer. This is called a certification path, or trust
chain. The path ends when you arrive at a certificate that is issued/signed by itself, or when one of the certificates is
explicitly trusted. The path is trusted if it ends in a trusted certificate. Typically, this means that someone has installed
the certificate in a trusted certificate store.
Expiration and Revocation
Keys and certificates are not designed to be used permanently. Keys can be compromised and circumstances can
change. Certificates are created with a certain period of validity, before and after which they should not be used or
trusted. If any certificate expires (the "valid-to"/"not after" date passes without renewing or replacing the certificate),
then it cannot be used to establish a TLS session.
In addition, certificates can be revoked before they expire to indicate the withdrawal of trust. The issuing authority may
make a certificate revocation list (CRL) available as additional validation for certificates it has issued. Any certificates
in the list should not be trusted.
To view your VCM certificates at any time in the VCM Portal, click Administration | Certificates. The data grid
displays your certificates and related information and expiration dates.
For information on how to renew or replace your certificates, see Changing Certificates on page 13.

TLS Implementation for VCM
TECHNICAL WHITE PAPER / 6
Note VCM supports certificate expiration. However, it does not support revocation lists. Certificates can be
removed from the certificate stores to effectively "revoke" them.
Certificate Standards
Certificates are defined by the X.509 RFC standard. This standard includes certain standard fields and capabilities.
Those who implement certificates may add additional fields, which can be marked as either critical or non-critical.
These fields are a contract between the creator and consumer. Because they are implementation-defined, an
application might encounter a certificate with fields that it does not understand. The application is obligated to fail
validation on a certificate with critical extensions that it does not understand. Non-critical extensions may be ignored.
One of the non-critical extensions is Enhanced Key Usage. This extension is used to specify the uses for which the
certificate is valid. These usages may include Server Authentication, Client Authentication, Code Signing, and
Certificate Signing.
Certificate Storage
In Microsoft® systems, certificates are stored in certificate stores. Certificate stores may be located in files, the
registry, memory, Active Directory, and other locations. Logical certificate stores provide a unified view of a collection
of physical stores that share common properties. All discussion of Microsoft certificate stores in this document refers
to logical stores. For a description of the logical system stores provided by Microsoft, see Microsoft TechNet:
Certificate Stores.
On UNIX systems, Collector Certificates (for Server Authentication) and Agent Certificates and Agent private keys
(for Mutual Authentication) are stored in a proprietary protected store. Although this store is not encrypted, it is
protected from simple viewing. Use the CSI_ManageCertificateStore utility and the associated help provided with your
VCM UNIX Agent installation package to view or manage the UNIX Agent Certificate store. For more information, see
the VMware vCenter Configuration Manager Installation and Getting Started Guide.
All VCM Agents using HTTP should be able to trust any VCM Collector Certificate, not just the Collector that the
Agent installation package was generated on. This may be via an Enterprise Certificate or through an existing PKI
system. If this environmental requirement is not met, only the Collector that generated the Agent installation package
(and any Collectors that share an Enterprise certificate with that Collector) will be able to communicate with the Agent
using the HTTP protocol. See How VCM Uses Certificates on page 7.
All VCM Collectors should be able to trust any Agent Certificate, even those issued by other Collectors. This may be
via an Enterprise Certificate or an existing PKI system. It this requirement is not met, the Collector will fail to establish
Mutual Authentication with Agents that are certified by another Collector.

TECHNICAL WHITE PAPER / 7
How VCM Uses Certificates
There are three types of certificates that enable HTTP collector-agent communications in VCM:
lEnterprise Certificate
lOne or more Collector Certificates
lAgent Certificates for each Agent (used in optional Mutual Authentication)
Certificate information regarding the Enterprise and Collector certificates is collected in VCM. See Administration |
Certificates.
The Enterprise Certificate
The Enterprise Certificate enables VCM to operate in a multi-collector environment. Agents have the Enterprise
Certificate in their trusted certificate stores, and can use it implicitly to validate any certificate issued by the Enterprise
Certificate. All Collector Certificates are expected to be issued by the Enterprise Certificate. This is critical in
environments where a single Agent is shared between two Collectors.
Figure 1: Dedicated Collector-Agent Relationship
The diagram above illustrates a dedicated Collector-Agent relationship. This type of environment includes two
Collectors (Collector A and Collector B) that each have a dedicated set of Agents that they collect from. Each Agent
has its Collector’s Issuer (Enterprise) certificate.
TLS Implementation for VCM

TLS Implementation for VCM
TECHNICAL WHITE PAPER / 8
Figure 2: Shared Collector-Agent Relationship
As the diagram above illustrates, an Agent may communicate with more than one Collector. In this case, each
Collector has a common Enterprise Certificate. Because both of the Collector certificates were issued by the same
trusted authority, the Agent that is shared between the two can trust both Collector Certificates. This is useful in multi-
collector, Server Authentication environments.
If you employ Mutual Authenticate and if a single Agent is shared between two Collectors, then it becomes necessary
for each Collector to use an Agent Certificate that is issued by a Collector other than itself. This is described as a
shared Collector-Agent relationship.

TECHNICAL WHITE PAPER / 9
Figure 3: Trust Chain in a Shared Collector-Agent Relationship
In addition, for Mutual Authentication in a shared Collector-Agent relationship, each Collector trusts the Agent
Certificate because that Agent Certificate was issued by a Collector Certificate which was, in turn, issued by the
trusted Enterprise Certificate. Since both Collectors trust the Enterprise Certificate, then they can also trust the Agent
Certificate that was issued by a Collector Certificate that was issued by the Enterprise Certificate.
Enterprise Certificates in VCM must have the following properties:
lMust be capable of signing certificate requests.
lThe path length basic constraint, if present, must be at least two if the Collector certificate will be used for issu-
ing Agent certificates. This means that the Enterprise Certificate may issue a Collector Certificate that may
issue Agent Certificates.
lMay be self-signed. If the certificate is self-signed, it will have to be trusted itself. Trust is bestowed by placing
the certificate in the Trusted Root store (Windows) or in the VCM store (UNIX). This represents a VCM-specific
trust chain.
lMay be signed by another certificate in an existing PKI and placed in the trusted store.
lMust be stored in the local machine Trusted Root Certification Authorities store on the Windows Collector and
Agents (Windows only).
lOn UNIX platforms, the Agent has a vendor-implemented certificate store. The Enterprise Certificate(s) must
be added to this store. One will be included during initial installation, and subsequent certificate(s) must be
added manually using the CSI_ManageCertificateStore utility included with your VCM UNIX Agent installation.
TLS Implementation for VCM

TLS Implementation for VCM
TECHNICAL WHITE PAPER / 10
The Collector Certificate
The Collector Certificate is issued by the Enterprise Certificate, and must be usable for Server Authentication and,
optionally, certificate signing (also known as “issuing”). Server Authentication is required to establish a TLS
connection with an Agent. Certificate signing is required to issue Agent Certificates for Mutual Authentication. It is
technically possible to split these functions between two certificates or two Collectors.
The Collector Certificate is used to initiate and secure a TLS communication channel with an HTTP Agent. The Agent
must be able to establish that the Collector Certificate can be trusted. That means that the Collector Certificate is valid
and the certification path starting with the Collector Certificate must end in a trusted certificate. By design, the
Enterprise Certificate will be installed in the Agent's trusted store, and the chain will end with the Enterprise
Certificate.
The Collector Certificate may also be used to issue Agent Certificates. As long as all Collector Certificates are issued
by the same Enterprise Certificate, any Agent Certificate may be issued by any Collector Certificate, and all
Collectors will be able to trust all Agents. Similarly, all Agents will be able to validate all Collector Certificates.
The Collector Certificate and associated private key must be available to the Collector. This certificate will be stored in
the (local machine) personal system store. Collector Certificates in VCM must adhere to the following requirements:
lMust be located in the local machine personal certificate store of the Collector.
lMust be valid for Server Authentication (OID: 1.3.6.1.5.5.7.3.1).
lIf the Collector certificate will be used to issue Agent certificates for mutual authentication:
lIf the key usage extension is present, it must include certificate signing.
lMust be an authority rather than an end certificate.
lIf the path length is set on the basic constraints, it must be greater than or equal to 1.
Agent Certificates
Agent Certificates are used only in Mutual Authentication. The Agent machine either produces a certificate request, or
one is manually produced on the Agent's behalf. A Collector issues a certificate based on this request. Copies of the
certificate are stored on both the Agent machine and the Collector. The Agent's private key should never exist
anywhere but on the Agent machine.
When a second Collector contacts the agent, the Agent makes its certificate available, and the second Collector also
stores the certificate. Note that a second Collector cannot renew an Agent Certificate that was issued by a previous
Collector.
Certificates are also used to encrypt and distribute the ESX and ESXi Web Service credentials (Virtualization) and to
encrypt and distribute the VCM for Service Desk Integration credentials. These certificates may be the same Agent
Certificates used for TLS.
Agent certificates in VCM must adhere to the following requirements:

TECHNICAL WHITE PAPER / 11
lMust be usable for client authentication
lMust be issued by any Collector Certificate issued by the Enterprise Certificate, known to the Agent
TLS Machine Security Level
Once the Collector establishes communication with an Agent using TLS, the Collector does not permit HTTP
communication without it. To do so would allow a malicious actor to impersonate either the Collector or Agent by
downgrading the communication security level.
The restrictions concerning the establishment of Server Authentication and Mutual Authentication relationships are:
lOnce an agent has established Server Authentication, the Collector will not allow non-TLS HTTP com-
munication.
lOnce an agent has established Mutual Authentication, the Collector will not allow non-TLS HTTP or Server
(only) Authenticated TLS communication.
lThe Collector supports both TLS and non-TLS capable Agents from earlier releases. Please contact VMware
Customer Support for assistance using the current release with earlier Agents (TLS and non-TLS enabled).
These restrictions do not apply to DCOM. The Security level persists across change protocol and installation/upgrade
actions.
TLS Implementation for VCM

TLS Implementation for VCM
TECHNICAL WHITE PAPER / 12
Creating and Installing Certificates for Collectors
Certificates can either be generated during VCM installation, or created in advance of installation and stored in the
local certificate store.
When you select either of these options, the VCM Installation Manager will automatically register the selected
certificates in VCM and configure the Agents to trust these certificates.
Installation of Certificates to Collectors
VCM Installation Manager offers you the options of either generating your certificates during installation (see VMware
vCenter Configuration Manager Installation and Getting Started Guide) or browsing to your certificate store to select
pre-generated certificates.
If you will be providing your own pre-generated certificates, they must exist on the Collector machine prior to VCM
Installation. The Collector Certificate must be in the Local Machine Personal system store, and the Enterprise
Certificate must be in the Local Machine Trusted Root system store. The private key of the Enterprise certificate does
not need to be available. The certificates do not need to be available on the database machine in a split configuration.
The install interview will prompt the you for the names of the certificates to be used.
lGenerating Certificates During Installation: During VCM installation, the VCM Installation Manager allows you
to generate your Collector and Enterprise Certificates during the installation process. For more information
about generating certificates during VCM installation, refer to the VMware vCenter Configuration Manager
Installation and Getting Started Guide.
lCreating Certificates Prior to Installation: If you want to create your own certificates in advance of VCM instal-
lation, refer to The Collector Certificate on page 10 for requirements or to Creating Certificates for TLS Using
Makecert on page 20 if you are creating your own certificates without PKI support. Once your certificates are
created, you can select them during the installation process.
After VCM installation, if you decide that you want to use different certificates than the ones that you either generated
or selected during the installation process, you must replace those certificates. For more information on replacing
certificates, see Changing Certificates on page 13.
Installation of Certificates to Additional Collectors
All Collector Certificates in a customer environment should be issued by the same Enterprise Certificate to ensure
seamless operation across Agents and Collectors. Generating certificates for more than a single Collector during
installation fails to create this relationship. Just as the VCM certificates were expected to be in place prior to the
installation of the first Collector, the VCM certificates must also be installed on subsequent Collectors prior to
installation. Each Collector needs its own Collector Certificate, and access to the Enterprise Certificate. If all HTTP
Agents are to be contacted by only a single Collector, then a single trust hierarchy is not strictly necessary.
If you plan to use more than one Collector for the same Agent machine, you must establish a parent-to-multiple-
Collector children relationship, and cannot use generated certificates on additional Collectors. Contact Customer
Support for further details and assistance.

TLS Implementation for VCM
TECHNICAL WHITE PAPER / 13
Changing Certificates
Certificates always have an expiration date, after which they are no longer valid. The validity period for a certificate is a
matter of policy and ranges from minutes to decades. In these cases, you can either renew or replace your certificates.
Renewing Certificates
Renewal of a certificate means extending the validity period for the certificate, using the same key pair, issuer, and
identifying information. Whatever mechanism was used to create the VCM certificates can be used to renew them.
It is possible to renew a certificate by updating the expiration date. In this case, a new certificate is issued with the
same public key and identifying information as the old certificate. Since the only change is the validity period, it is safe
to accept the new certificate at the same level of trust as the old one. Both certificates are valid for the same purposes,
and are both are usable in keeping with their validity periods.
When the Collector initiates communication with the Agent, it sends the certification path from the Collector
Certificate to its trusted root (typically the Enterprise Certificate) to the Agent. For each certificate in the path, the
Agent checks to see if it has a matching certificate in local machine personal or root stores. If it finds a match in either
location and the ”new” certificates have different dates, the Agent will install the new certificates. The current trust
level is preserved. No certificate will be added to the trusted store unless an equivalent certificate is already present.
The old certificates are not removed.
Replacing Certificates
The only way to ensure the authenticity of a new root or trusted certificate is to receive it from a secure and trusted
source. During installation, VCM Installation Manager handles Enterprise and Collector Certificate installation and
management. You can either select your own certificates from your certificate store, or have VCM generate the
certificates automatically for you. In both cases, your VCM Agents will be automatically configured to properly trust
the certificates. In addition, Enterprise and Collector Certificates with updated begin and end times will be
automatically added to the Agents' certificate stores as described in Renewing Certificates on page 13.
However there are certain circumstances that may require you replace your Enterprise and Collector Certificates,
including:
lCompromised private keys
lCompany security policy governing the lifetime of keys
lCompany or department changes merging VCM environments
lProduct evaluations that previously used VCM-generated certificates that are moved into production without re-
installation
Use the following procedures to replace both the Enterprise and Collector Certificates, or just the Collector Certificate,
and then install them into the certificate stores of the VCM Collector and Agents.
Replace the Enterprise and Collector Certificates

TECHNICAL WHITE PAPER / 14
After VCM installation, if you decide that you want to use different certificates than the ones that you either generated
or selected during the installation process, you must replace those certificates.
Use the following procedure to replace both the Enterprise and Collector Certificates.
1. Create or obtain a new Enterprise certificate. For information on how to create an Enterprise Certificate using
MakeCert Certificate Creation Tool, see Creating Certificates for TLS Using Makecert on page 20.
2. Create or obtain a new Collector Certificate that is signed by the Enterprise Certificate. For information on how
to create a Collector Certificate using MakeCert Certificate Creation Tool, see Creating Certificates for TLS
Using Makecert on page 20.
3. Import the Enterprise Certificate into the Local Computer Trusted Root store on the VCM Collector. For more
information, see Certificate Transport on page 17.
4. Import the Collector Certificate and the private key into the Personal store on the VCM Collector. For more infor-
mation, see Certificate Transport on page 17.
5. Update the Collector Certificate thumbprint in the VCM Collector database. For more information, see Updating
the Collector Certificate Thumbprint in the VCM Collector Database on page 26
6. Restart the Collector service.
7. Import the Enterprise Certificate into the Trusted Root store on the VCM Windows Agent systems (see Cer-
tificate Transport on page 17), install the VCM Agent with the "Enable HTTP" option selected, or change pro-
tocol to DCOM and back to HTTP (only if the Collector can communicate with Agents using DCOM protocol).
On UNIX Agents, place the certificates into the VCM Agent Certificate store.
Replace Only the Collector Certificates
After VCM installation, you may find that you want to use a different Collector Certificate than you specified during
installation, but your Enterprise Certificate is still valid. In this situation, you can use the following procedure to replace
only the Collector Certificate.
1. Create or obtain a new Collector Certificate (and associated private key) that is signed by the Enterprise Cer-
tificate. For information on how to create a Collector Certificate using MakeCert Certificate Creation Tool, see
Creating Certificates for TLS Using Makecert on page 20.
2. Import the Collector Certificate and the private key into the Personal store on the VCM Collector.
3. Update the Collector Certificate thumbprint in the VCM Collector database. See Updating the Collector Cer-
tificate Thumbprint in the VCM Collector Database on page 26.
4. Restart the Collector services.
TLS Implementation for VCM

TLS Implementation for VCM
TECHNICAL WHITE PAPER / 15
Delivering Initial Certificates to Agents
VCM Agents use Enterprise Certificates to validate Collector Certificates. Therefore, the Agent must have access to
the Enterprise Certificate as a trusted certificate. In most cases, VCM will deliver and install the Enterprise Certificate
as needed.
Installing the Agent from the Collector
The Enterprise Certificate is stored in the CollectorData folder on the Collector. The Enterprise Certificate is installed
when the VCM Agent is installed or upgraded with the HTTP protocol.
New Installations
In a new Agent installation, all module files will be installed. The Enterprise Certificate will be installed if and when the
EcmComSocketListenerService module is installed. If the “Enable HTTP” option is not chosen for the installation,
then the module and certificate will not be installed.
Upgrades
All upgrades of HTTP-enabled Agents from non-TLS Agents to TLS Agents receive a new version of the
EcmComSocketListenerService, and the Enterprise Certificate. This also applies to upgrades via the “License and
Install Agent on Discovered Machines” Discovery rule option (see VCM Help for more information on VCM
Discoveries.”
Changing Protocols from DCOM to HTTP
Changing protocols to HTTP causes the EcmComSocketListenerService module to be installed. Since a secure
DCOM connection with the Agent exists, the current Enterprise Certificate can be delivered with the
EcmComSocketListenerService module.
Changing Protocol from HTTP to DCOM
The EcmComSocketListenerService module is uninstalled from the Agent during this operation. Since DCOM does
not use certificates, the Agent will simply stop using them. Any changes to the Enterprise Certificate will not be
automatically propagated to the Agent until HTTP is reinstated. Changing protocol from DCOM to HTTP in the future
will deliver the current Enterprise Certificate.

TLS Implementation for VCM
TECHNICAL WHITE PAPER / 16
Installing the Agent from a Disk (Windows only)
The VCM installation image/DVD does not contain customer-specific certificates. The manual VCM installer requests
the location of the Enterprise Certificate file prior to installing. You must have this file available at installation time. The
Certificate file (with a .pem extension) can be copied from the CollectorData folder of the Collector. This will be the
case whether you run the manual installer directly (CMAgentInstall.exe or the .msi installation package) or use the
“Agent Only” option from the DVD autorun program.
Using CMAgtInstall.exe via Network Share to Install the Agent (Windows
only)
CMAgtInstall.exe is the manual Agent installer program. As above, the manual installer will request the location of the
Enterprise Certificate file before installing. You must have this file available at installation time. The certificate file can
be copied from the CollectorData folder of the Collector. This applies to the .msi installation as well.
UNIX/Linux or Mac OS X
Each UNIX/Linux or Mac OS X installation package is targeted for one or more supported platforms. Because the
Enterprise and Collector Certificates are embedded within the Agent installation package (if they were specified when
the Collector was installed), they are automatically inserted into the UNIX Agent Certificate store during the Agent
installation process.
To manage the VCM UNIX Agent Certificate store, use the CSI_ ManageCertificateStore utility and related help
provided with your UNIX Agent installation package. For more information about UNIX/Linux or Mac OS X agent
installation or packages and platforms, refer to the VMware vCenter Configuration Manager Installation and Getting
Started Guide.
Installing the Agent Using a Provisioning System
Windows
The manual installation program is available in .exe and .msi formats. Both versions allow the Enterprise Certificate
file to be specified with a command line switch. The certificate installation step may also be omitted with a command
line switch. When these programs are run through a provisioning system, you must ensure that the Enterprise
Certificate is available (and still secure), and configure the program options appropriately.
Alternatively, you may choose to push the Enterprise Certificate to Agents by some other means and configure the
provisioning system to omit certificate installation.

TECHNICAL WHITE PAPER / 17
UNIX/Linux or Mac OS X
Each UNIX/Linux or Mac OS X installation package is targeted for one or more supported platforms. To install the
UNIX/Linux or Mac OS X Agent using a provisioning system, extract the installation package as appropriate and then
deploy the extracted file with the provisioning system. The Enterprise Certificate is embedded in the installation
package. For more information about UNIX/Linux or Mac OS X Agent installation, refer to the VMware vCenter
Configuration Manager Installation and Getting Started Guide.
Certificate Expiration
If any certificate expires (the valid-before date passes without renewing or replacing the certificate), then it cannot be
used to establish a TLS session. To verify the expiration dates of your certificates, consult the Certificates grid in
VCM (Administration | Certificates).
Certificate Transport
A certificate contains the public half of a key pair and identifying information, and an authenticating signature. Though
none of this information is ”secret”, the information should still be protected.
A certificate can be stored in a format that includes the private key. When this is the case, the data is secret and must
be safeguarded, stored, and transported securely.
Note The following information pertains to Windows platforms only. To import or export a certificate to UNIX, use
the CSI_ ManageCertificateStore utility provided with your VCM UNIX Agent installation package.
Exporting Certificates (Windows Only)
One way to export certificates is to use Microsoft® Management Console (MMC), as shown in the following
procedure.
Using MMC to Export Certificates
1. Open Microsoft Management Console (click Start | Run, and then enter MMC).
2. Click File | Add/Remove Snap-in.
3. Click Add, and then select Certificates from the Add Standalone Snap-in dialog box.
4. Click Add.
5. Select the computer account for the local machine for which the snap-in will manage certificates, and then click
Finish.
6. Click Close, and then click OK.
7. Navigate to the certificate store from which you want to export a certificate.
TLS Implementation for VCM

TLS Implementation for VCM
TECHNICAL WHITE PAPER / 18
8. Select the certificate to be exported. Right-click, and then select All Tasks | Export.
9. The Certificate Export wizard appears. Click Next.
10. The Export Private Key dialog box appears. If the private key for this certificate is available and is marked as
exportable, you will have the option of exporting the private key.
11. The Export File Format dialog box appears. If you are exporting the private key, you must use the *.pfx for-
mat. If not, choose the Base-64 encoded X.509 format. This creates a file that can be imported by several VCM
tools.
12. If you are exporting the private key, you will be prompted to enter a password. This password is intended to pro-
tect your private key during transport. The password will be required to import the file. If you leave the password
fields blank, no password is required on import.
13. The File to Export dialog box appears. Click Browse to navigate to a file. If you are exporting the private key,
the location should be secure.
14. The Summary dialog box appears. Verify your settings, and then click Finish.
Importing Certificates (Windows Only)
There are two ways in which you can import a certificate. Your machine may be set up with file associations that allow
you to view and import certificate files. This method imports certificates to the appropriate store for the current user.
Because VCM expects to find certificates in the Local Computer stores, the certificates would have to be moved.
Although MMC allows you to move certificates with drag-and-drop, it doesn’t work correctly on some versions of the
operating system.
The second way to import certificates uses MMC and the import wizard with an explicit location, as shown in the
following procedure.
Using MMC to Import Certificates
1. Open Microsoft Management Console (click Start | Run, and then enter MMC).
2. Click File | Add/Remove Snap-in.
3. Click Add, and then select Certificates from the Add Standalone Snap-in dialog box.
4. Click Add.
5. Select the computer account for the local machine for which the snap-in will manage certificates, and then click
Finish.
6. Click Close, and then click OK.
7. Navigate to the local computer certificate stores, and then right-click the store to which you will be importing cer-
tificates. Select All Tasks | Import.
8. The Certificate Import Wizard appears. Click Next.

TECHNICAL WHITE PAPER / 19
9. The File to Import dialog box appears. Select the file to import. Either format is acceptable: *.pfx or *.cer. The
*.pem format is typically a synonym for *.cer and is used more commonly on UNIX systems.
10. If the file contains a private key, you will be prompted for a password. If the file contains a private key, you will
have the option of marking it as exportable. If you do not, the private key cannot be exported from the system
(you will still have the file though). Do NOT Enable Strong Protection.
11. Verify that the certificate will be stored in the correct location, and then click Next.
12. The Summary dialog box appears. Verify your settings, and then click Finish.
TLS Implementation for VCM

TLS Implementation for VCM
TECHNICAL WHITE PAPER / 20
Appendix A: Creating Certificates for TLS Using
Makecert
VCM is designed to run in TLS mode with two levels of certificates. In this mode, an Enterprise Certificate is the
ultimate trusted authority. All Collector Certificates will be signed by this Enterprise Certificate. All Agents will have
access to the Enterprise Certificate as a trusted authority. Any Collector Certificate can be used to sign an Agent
Certificate. A given Agent should be able to mutually authenticate with multiple Collectors.
In the following process, the Enterprise machine can be the same as the Collector machine. Some of the steps can be
simplified if they are the same, or if the Enterprise or Collector machines are set up to be certificate servers. The
example is written for the case when the Enterprise machine is also the (first) Collector. When this is not the case, you
will have to follow the steps for creating a second collector for the initial collector.
Makecert (Certificate Creation Tool), cert2spc (Software Publisher Certificate Test Tool), pvkimprt (PVK Digital
Certificate Files Importer), and many related utilities are available as part of the SDK download from Microsoft. For
more information, visit the Microsoft Developer Network and search for the downloads by platform (pre-Vista or Vista):
lPre-Vista: Windows Server 2003 SP1 Platform SDK full download
lVista: Windows SDK for Windows Server 2008 and .NET Framework version 3.5
Create the Enterprise Certificate and the First Collector Certificate
Use the following procedure to create the Enterprise Certificate and the first Collector Certificate. Refer to MakeCert
Options on page 23 for a list of the options used below and their definitions.
Example:
makecert -pe -n "CN = CM Enterprise Certificate AAAAAAAA-AAAA-AAAA-AAAAAAAAAAAAAAAA"
-ss Root -sr LocalMachine -r -sky exchange -sk "CM Enterprise Certificate AAAAAAAA-
AAAA-AAAAAAAA-AAAAAAAAAAAA" -len 1024 -h 2 -cy authority -eku 1.3.6.1.5.5.7.3.1
Note VCM embeds a GUID ("AAAAAAAA-AAAA-AAAAAAAA-AAAAAAAAAAAA" or "BBBBBBBB-BBBB-BBBB-
BBBBBBBBBBBBBBBB") into the Common Name by convention to ensure that the name is unique; however, this is
not a requirement
