Voith BTG CPM-1300 User manual

User Manual
CPM
Communication Platform

Copyright© 2020 BTG Instruments AB
The contents of this document are subject to revision without notice due to continued progress
in methodology, design, and manufacturing. BTG shall have no liability for any error or
damages of any kind resulting from the use of this document.
All rights reserved. No part of this document may be copied, photocopied, published,
reproduced, translated or converted into electronic or machine-readable form
without written permission of BTG Instruments AB.
Original Instructions
BTG Instruments AB, 2020

© BTG 2020 User Manual CPM M2066/12en I
Important Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
1 Product Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
1.1 Communication Platform CPM . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
1.1.1 Technical Data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
1.1.2 Dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
1.1.3 Type Plate Explanations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
1.1.4 CE-Declaration. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
1.1.5 Supplier's Declaration of Conformity . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
2 Installation Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . 15
2.1 Communication Platform CPM . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
2.1.1 Mounting Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
2.1.2 Cabling Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
2.1.3 Connection Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
2.1.3.1 AC Connection to Power Supply Unit . . . . . . . . . . . . . . . . . . . . . . . . . . 17
2.1.3.2 HCM Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
2.1.3.3 FCM Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
2.1.3.4 Sensor Control Module SCM-8000 . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
2.1.3.5 Communication Module CCM-8200 . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
2.1.4 Backup Card . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
2.1.5 RS-485 Connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
3 Service Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
3.1 Maintenance Routines . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .29

II User Manual CPM M2066/12en © BTG 2020
4 Parts List . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
4.1 CPM . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
4.1.1 CPM-1300 with HCM/FCM-8000 and
SCM-8000 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
4.1.2 CPM-1300 with HCM/FCM-8000 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
4.1.3 CPM-1300 with HCM/FCM-8010 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
4.1.4 CPM-1400 with HCM/FCM-8000 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
4.1.5 CPM-1410 with HCM/FCM-8010 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
4.1.6 CPM-1510 with HCM/FCM-8010 and
SCM-8000 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
4.1.7 CPM-1510 with HCM/FCM-8010 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
4.1.8 CPM Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
5 Appendix . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
5.1 HCM-8000 Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
5.2 HCM-8010 Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
5.3 FCM-8000 Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52
5.4 FCM-8010 Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54

© BTG 2020 User Manual CPM IN2066en Rev. B 1
Important Information
This user manual contains all necessary instructions for installation,
maintenance, and basic service of the Communication Platform (CPM).
Safety instructions and regulations for installation and service are found in the
BTG Safety Manual, M2076.
NOTE!
Always read the safety instructions before installation and service of the
instrument!
NOTE!
If the CPM is used in a manner not specified by BTG the protection provided
by the equipment may be impaired.
For operation instructions, see the CPM operation manual for the appropriate
instrument. CPM operation manuals are available for the following
instruments:
Instrument CPM Operation manual
ACT-2500
MBT-2500
MEK-2500
MEK-3000
OM2003
DRT-5500 OM2005
TCR-25xx OM2006
MBT-4500 OM2007
TCT-25x1
RET-25x2
OM2009
RET-55x3 OM2010
BT-5500 OM2011
BLT-5500 OM2012
SPK-5500 OM2013
DLT-5500 OM2014
RT-5500 OM2015
TCS-2531 OM2016
OCT-25x1 OM2017
SPM-5500 OM2018
SPC-5500 OM2019

2 User Manual CPM IN2066en Rev. B © BTG 2020
Recycling
Recycle the instrument and all replaced parts according to local, first and
foremost national, laws and regulations. Contact BTG to get detailed
information on how to disassemble and recycle the instrument safely. BTG
should have no liability for any error or damage of any kind due to disassembly
or recycle work done.
the unit is not falling under the RoHS/WEEE CE-directives according to:
RoHS According to Article 2 (4) and (4e) alt. (4d) and
according to Article 3 (3) alt. (4), the unit shall not
apply to RoHS.
WEEE According to Article 2 (3b) and (4c; f), and according
to Article 3 (1b) and (1c, I, II, III), the unit shall not
apply to WEEE.

Product Introduction
© BTG 2020 User Manual CPM PI2066en Rev.C 3
2 Product Introduction
2.1 Communication Platform CPM
The CPM is delivered as a complete unit from BTG, normally in conjunction
with an instrument.
The CPM has the following functions:
• Local display and console for full configuration and operation of the
instrument
• Large illuminated display for easy reading
• Protected from splash and sun
1
3
2
6
4
5
7
Fig 1 CPM overview
1. Protective cover
2. Front cover
3. Scroll keys
4. LCD display with
backlight
5. Function keys
6. Closing screw
7. Cable glands

Product Introduction
4 User Manual CPM PI2066en Rev.C © BTG 2020
2.1.1 Technical Data
General
Type
CPM Communication Platform.
Manufacturer
BTG, Säffle, Sweden.
Quality Assurance
Quality-assured in accordance with ISO 9001.
Product Safety
Fulfills all relevant CE-directive requirements, RCM requirements, and ETL listed.
Radio Approvals
US, Canada, EU, Japan, Australia, and New Zealand.
Emission / Immunity / Safety
FCC Part 15 Class B
EN 61010-1:2010
EN 61326-1:2013
EN 301489-1 V2.1.1
EN 301489-17 V3.1.1
EN 300328 V2.1.1
EN 300893 V1.8.1
UL 61010-1:2012 Ed.3 +R:29Apr2016
CSA C22.2#61010-1-12:2012 Ed.3+U1;U2
Function Specifications
HCM-8000
Hart communication module using HART® protocol.
Equipped with slot for SD memory card.
Analog output (AO1)
4 - 20 mA. Galvanic isolated. Current limited to min. 3.9 and max. 20.5 mA.
Loop load signal: Voltage supply/load 24 V DC
Active or passive output
Superimposed signal over 4 - 20 mA current loop according to standard HART® protocol.
Analog input (AI1)
4 - 20 mA 250 Ω input resistance
Digital input (DI1 - DI3)
Galvanic isolated
High-ohmic = logical 0
+24 V ≥ 12 mA = logical 1
Digital output (DO)
Galvanic isolated
Maximum 120 mA
Maximum 30 V DC

Product Introduction
© BTG 2020 User Manual CPM PI2066en Rev.C 5
HCM-8010
Hart communication module using HART® protocol.
Equipped with slot for SD memory card.
Analog output (AO1- AO5)
4 - 20 mA. Galvanic isolated. Current limited to min. 3.9 and max. 20.5 mA.
Loop load signal: Voltage supply/load 24 V DC
Active output
Superimposed signal over 4 - 20 mA current loop according to standard HART® protocol.
Analog input (AI1 - AI4)
4 - 20 mA 250 Ω input resistance
Digital input (DI1 - DI4)
Galvanic isolated
High-ohmic = logical 0
+24 V ≥ 12 mA = logical 1
Digital output (DO1 - DO2)
Galvanic isolated
Maximum 120 mA
Maximum 30 V DC
Solenoid valve (SV1 - SV5)
Open drain output for solenoids
Maximum 500 mA
Maximum 30 V DC
FCM-80x0
Fieldbus communication module programmed for PROFIBUS.
Equipped with slot for SD memory card.
Output / Input signal
PROFIBUS (PA)
CCM-8200
Network Interfaces:
Wired Network Connectivity
Ethernet, 10/100 Mbit - RJ45.
Ethernet interface supporting up to 100baseTx.
IEC 11801:2002 CatV compliant M12 type D socket.
The interface supports Auto MDI-X (crossover).
Wireless Network Connectivity
Wi-Fi, Dual-band 802.11 a/b/g/n/ac 1x1
CPM User Interface
Illuminated display. Key pad for adjustment of instrument settings.

Product Introduction
6 User Manual CPM PI2066en Rev.C © BTG 2020
Support System Specifications
Supply Voltage
Power supply unit 100 - 240 V AC, 50-60 Hz.
AC input range: 90 - 264 V continuous operation.
Disconnecting Device
An external 2-pole switch close to the CPM is required. The switch must be approved in
accordance with the IEC 60947-2 and IEC 60947-3 requirements.
Power Consumption
100 - 300 VA
Altitude
0 to 2000 m (0-6560ft) without any restrictions.
2000 to 6000 m (6560 to 20000ft) reduce output power or ambient temperature.
Altitude de-rating = 5 W / 1000 m or 5 °C / 1000 m.
Humidity
5 to 95% r.h (IEC 60068-2-30)
Over-voltage Category
Category III: IEC 62103, EN 50178, altitudes up to 2000 m
Category II: altitudes from 2000 m to 6000 m
Degree of Pollution
2: IEC 62103, EN 50178, not conductive
Physical Specifications
Materials
Casing: Polycarbonate thermo plastic
Cable fittings: Polyamide thermo plastic
Storage Temperature
Max. 80 °C (176 °F)
Min. -25 °C (-13 °F)
Operation Temperature
Max. 50 °C (122 °F)
Min. 0 °C (32 °F)
Degree of Protection
IP 65, comparable to NEMA 4x and better, the CPM is intended for use indoors.
Weight
CPM: 2 - 2.5 kg (4.4 - 5.5 lbs) depending on configuration
Cables
Power supply flexible cable: 0.3 - 2.5 mm2 (AWG = 28-12)
Signalling cable: 0.2 - 2.5 mm2 (AWG = 24-12)
Transmitter Cable
Standard length: 10 m [33 ft]
Cable Inlets
There are cable glands for signal cables (diameter 4-8 mm) and for power supply cable
(diameter 4-12 mm) in the bottom of the CPM.

Product Introduction
© BTG 2020 User Manual CPM PI2066en Rev.C 7
2.1.2 Dimensions
180
7.1"
267
10.5"
255
10"
10 (4x)
0.4"
5 (4x)
0.2"
285
."11 2
315
.4"12
270
10.8"
222
8.9"
162
6.5"
152
6"
50
2"
Fig 2 Dimensions
207
8.1"
50
2"
180
7.1"
152
6"
267
10.5"
255
10"
Fig 3 Dimensions

Product Introduction
8 User Manual CPM PI2066en Rev.C © BTG 2020
2.1.3 Type Plate Explanations
1. Manufacturer
2. CE-marking
The CPM is approved in accordance with CE directives.
3. FCC Declaration of Conformity
Certifies that the electromagnetic interference from the device is under
limits approved by the Federal Communications Commission.
4. Radio label marking
R: 202-LSF056
5. C-TIC marking
The CPM is approved in accordance with Australian C-TIC N1619
directives.
6. ETL-marking
The CPM is approved by ETL.
7. Warning sign
The CPM is designed for industrial use. Installation, handling and service
must only be carried out by trained and authorized personnel and in
accordance with relevant standards. Read the manual for detailed
information and pay particular attention to the warning signs!
8. QR code
QR code to scan for more information about the CPM on the site:
www.btg.com/mybtg/en/instruments/cpm.
CPM-XX00
PH 0 M 2 H3/C /R15 RA1/ESPK/Q / 0/S / 10 /
123456
100-240 V AC 50-60 Hz XX W III
PRODUCT
VOLTAGE FREQUENCY
SERIAL NUMBER
APP. POW CATEGORY FACTORY ID
TYPE
3068754
Conforms to UL 61010-1
Certified to CAN/CSA-C22.2 No.61010-1
Contains FCC ID: MCQ-CCIMX6UL
IC: 1846A-CCIMX6UL
N1619
BTG Instruments AB
Industrigatan 1-3
661 32 Säffle
SWEDEN
Hereby, BTG Instruments AB declares that the radio equipment (see type) is in
compliance with Directive 2014/53/EU. The full text of the EU declaration of conformity
is available at the following internet address: www.btg.com/mybtg/en/instruments/cpm/
R202-LSF056
6 7 851 2 3 4
9
15
10 11 12 13 14
16
Fig 4 Type plate

Product Introduction
© BTG 2020 User Manual CPM PI2066en Rev.C 9
9. Product
The instrument model is specified according to the code system explained
below:
10. Voltage
100-240 V AC to power supply.
11. Frequency
The CPM operates at both 50 and 60 Hz.
12. Apparent power
Maximum power consumption (W).
13. Installation category
In accordance with CE-Directive. Fixed installation. Resistant to
transients.
14. Factory identification
1Product Group
CPM Communication platform
2Power type
13 50 W Power supply
14 240 W Power supply
15 80 W Power supply
3Input/Output Unit
00
If field 4 = PH: HCM-8000
If field 4 = PP: FCM-8000
10
If field 4 = PH: HCM-8010
If field 4 = PP: FCM-8010
CPM-XX00
123

Product Introduction
10 User Manual CPM PI2066en Rev.C © BTG 2020
15. Type specification
The instrument variant is specified according to the code system
explained below:
4Communication Protocol
PH Analog 4-20 mA with HART® (HCM-80x0)
PP Profibus PA (FCM-80x0)
PF Foundation Fieldbus supplied with FCI-1000
5Sensor Control Module
Q0 No module
Q1 Sensor control module SCM-8000
6Sensor Control Module
M0 No module
M1 Communication module CCM-8200
7Serial Connector
S0 No serial connector
S1 One serial connector
S2 Two serial connectors
8Housing
H1 Standard housing with protecting cover
H2 Standard housing without protecting cover
H3 Large housing with protecting cover
H4 Large housing without protecting cover
9 Sensor cable
Blank = no sensor cable
Cxx xx = 0.5, 5, 10, 20, 30, 40, or 50 meters (10 m [32.8 ft])
CxxHF HF = Halogen free
10 Interlock relay
Blank = no relay
RI1 Interlock interface relay 12 V DC
PH/Q0/M0/S2/H3/C10/RI5/RA1/ESPK
45678910 11 12

Product Introduction
© BTG 2020 User Manual CPM PI2066en Rev.C 11
16. Serial number
BTG internal product identification number.
RI2 Interlock interface relay 24 V AC/DC
RI3 Interlock interface relay 48 V DC
RI4 Interlock interface relay 60 V DC
RI5 Interlock interface relay 120 V AC/ 110 V DC
RI6 Interlock interface relay 230 V AC/ 220 V DC
11 Alarm relay
Blank = no alarm relay
RA1 Alarm relay max 230 V AC/ 220 V DC
12 Extended information
Blank = no information
ESEC Configured as secondary CPM
ESPK Only for SPK-5500
ESPM Only for SPM-5500

Product Introduction
12 User Manual CPM PI2066en Rev.C © BTG 2020
2.1.4 CE-Declaration
When using the units in combinations other than those tested for, BTG can not
guarantee CE-directive conformity.
The units in combination with customer-installed external devices may conform
with EMC and safety requirements when properly installed and CE-marked
equipment is used.
The system operator is responsible for CE-directive conformity.
Conformity must be verified by inspection.

Product Introduction
© BTG 2020 User Manual CPM PI2066en Rev.C 13
2.1.5 Supplier's Declaration of Conformity
47 CFR § 2.1077 Compliance Information
Unique Identifier: CPM-1300, CPM-1310, CPM-1400, CPM-1410, CPM-1510
Responsible Party - U.S. Contact Information
BTG Americas Inc.
Instruments (USA)
5085 Avalon Ridge parkway
Suite 100
Norcross GA 30071
www.btg.com
FCC Compliance Statement
This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) This device may not cause harmful interference,
and (2) this device must accept any interference received, including
interference that may cause undesired operation.

Product Introduction
14 User Manual CPM PI2066en Rev.C © BTG 2020

Installation Instructions
© BTG 2020 User Manual CPM II2066en Rev. C 15
3 Installation Instructions
3.1 Communication Platform CPM
3.1.1 Mounting Instructions
NOTE!
The CPM must be installed in an easily accessible position.
Mount the CPM in the selected location by fastening the protective cover to a
flat surface. Use four suitable screws. See figure 5 for recommended clearanc-
es.
Tools required:
Screwdriver
Drilling machine
300
12"
200
8"
300
12"
300
12"
Fig 5 Recommended
clearances

Installation Instructions
16 User Manual CPM II2066en Rev. C © BTG 2020
3.1.2 Cabling Instructions
NOTE!
BTG recommends that separate cables be used for analog and digital signals.
Multi conductor cables can be used.
NOTE!
Unused cable glands must be sealed in order to fulfill the IP 65 requirement.
3.1.3 Connection Instructions
All electrical connections are made inside the CPM.
To access the terminal blocks, loosen the two screws on the right side of the
front cover and open the CPM.
NOTE!
Secure all cables with cable ties to avoid short circuit.
DANGER
Hazardous voltage
in the equipment
