Vortex CROSSFIRE User manual

C ROSSFIRE
TM
Congratulations on your purchase of a Crossfire
binocular. We know you’ll find this binocular offers
excellent optical resolution and performance—a
tremendous value for all your outdoor experiences.
Binoculars are not intended for looking at the sun, or any other
intense light source. Such viewing could damage the retina and
cornea of your eyes—even to the point of causing blindness.
Caution:
The
Binocular Series
C ROSSFIRE
The Crossfire features fully multi-coated optics for
high light transmission and bright images.
Optical Quality.
TM
TM
2
www.vortexoptics.com

3 4
www.vortexoptics.com www.vortexoptics.com
Center Focus
Diopter Ring
Roof Prism Housing
Objective
Lenses
Center Hinge
Tripod Adapter
Socket
Neckstrap
Attachment
Point
The Crossfire is lightweight, but very rugged and durable.
Sporting an internal focusing mechansim,O-rings at
all open points, and nitrogen purging, this binocular is
waterproof, dustproof, and internally fogproof.
Rugged Design.
Adjustable Eyecup
The Crossfire binocular comes with two tethered
objective lens covers and a one-piece rainguard that
covers the eyepieces. For convenience, the rainguard
can be attached to the
neckstrap where it is within
easy reach. Simply slip
the neckstrap through the
attachment point on the
rainguard before connecting
the neckstrap to the
binocular.
The Lens Covers
The soft case of the Crossfire provides protection for
the binocular when not in use
and comes with a woven nylon
neckstrap for an easy carry in
the field.
The Case
Preparing the Crossfire for Use

3
5 6
www.vortexoptics.com www.vortexoptics.com
Attach the padded neckstrap to the binocular in
three simple steps. Begin with the right barrel of the
binocular and repeat the process for the left barrel.
The Neckstrap
1.Push a few inches of the
strap through the neckstrap
attachment point on the
binocular.
2.Loop the strap over the
attachment point, then
thread the strap through
the strap buckle.
3.Secure the end of the
strap by slipping it
through the strap loop.
IPD
The eyecups on the Crossfire binocular twist up and
down so any viewer can take advantage of the long eye
relief and enjoy comfortable, full-field viewing.
With eyeglasses or sunglasses,
retract the eyecups.
Without eyeglasses or sunglasses,
extend the eyecups.
Adjusting the Eyecups.
The twist-up eyecups are built on a solid frame and
covered with rubber.
Adjusting the Interpupillary Distance.
The interpupillary distance (IPD) is the distance
between the centers of the left and right eye pupils.
Match the IPD of your eyes
to that of the binocular by
rotating the binocular barrels
inward or outward until you
see a single image that is free of
shading.
Customizing the Crossfire

7
www.vortexoptics.com
Focusing the Binocular.
Choose an object that is about 20 yards away from you
and follow this two-step process to properly adjust
the focus. Be sure to stay in the same spot until you
have adjusted both the center focus and diopter.
1.Adjust the center focus – Start by closing your right
eye or covering the right objective lens with your hand.
Focus your left eye on the
object and adjust the center
focus wheel until the image is
in focus. Leave the center focus
in this position as you adjust the
diopter.
2.Adjust the diopter – Start by closing your left eye
or covering the left objective lens with your hand. Look
through your right eye and
adjust the diopter (ring found
on the right eyepiece) until the
object is in focus. Make note of
this diopter setting in case you
need to set it again.
From this point on, you will only need to use the center focus dial.
8
www.vortexoptics.com
Maintain the optical brilliance of the Crossfire binocular
by keeping the lens surfaces free of dirt, dust, and oils.
Protect Lenses While Out in the Field.
Caring for the Lenses
Make use of the rainguard and tethered objective lens
covers to protect the lenses when not viewing. Store the
Crossfire in its custom carry case.
Keep Lenses Clean.
Along with normal use comes the need to clean the
binocular lenses. Follow these guidelines for cleaning:
1.Remove any dust or grit from lenses before wiping.
Use a can of pressurized air or soft camel hair brush
(acrylic optical brushes also work well).
2.Clear lens of smudges, fingerprints, or eyelash
oil.
Fog the lenses with your own breath and wipe with
the non-abrasive lens cloth included with the Crossfire
binocular.
Cleaning fluid and optical paper can also be used. However, you
should never use facial tissue, heavy cotton, or flannel clothing
on lenses—these materials can scratch the lens surfaces.
Other cleaning options:

5
9
www.vortexoptics.com
The VIP Warranty
We build optics based on our commitment to your
absolute satisfaction. That’s why Vortex products are
unconditionally guaranteed.
Vortex Optics
2120 West Greenview Drive
Middleton, WI 53562
[email protected]
Vortex pledges this Very Important Promise to you—a
Very Important Person. That’s why we call it the
VIP warranty. In the event that
a Crossfire requires service,
no matter the cause, Vortex
Optics will repair or replace the
binocular at no charge to you.
Call Vortex Optics at 800-426-0048 for prompt,
professional, and friendly service.
The Vortex VIP warranty is completely transferable and has no warranty
card to fill out. The VIP warranty does not include occurrences of loss,
theft, deliberate damage, nor damage as a result of unauthorized repair,
modification, or disassembly. Vortex Optics reserves the right to replace
warranted products with a product of similar value and/or specifications
in the event that the original product is no longer manufactured or has
been discontinued.
