VOX electronics EBC405 DB User manual

EBC405 DB
EBC415 DB
OPERATING INSTRUCTIONS BUILT-IN VITROCERAMIC HOB
UPUTSTVO ZA UPOTREBU STAKLO KERAMIČKA KUHINJSKA PLOČA
УПАTСТВА ЗА РАКУВАЊЕ ВИТРОКЕРАМИЧКА ПЛОЧА НА ШПОРЕТ
NAVODILA ZA UPORABO STEKLOKERAMIČNA KUHALNA PLOŠČA
UPUTSTVO ZA UPORABU STAKLOKERAMIČKA PLOČA ZA KUHANJE
MANUAL DO USUÁRIO 󶂢PLACA VITROCERÂMICA ENCASTRÁVEL
GBR
SRB
SVN
MKD
HRV
PRT

EBC405 DB
EBC415 DB

DESCRIPTION OF THE HOB 3
SAFETY INSTRUCTIONS 4
INSTALLATON 6
Locating Your Bui t-in Hob 6
E ectrica Connection of Your Hob 8
USAGE 10
Turn On and Turn Off The Contro 11
Se ect Heater 11
Turn on dua zones ............12
Set Cooking Leve With and Without Heat Boost 12
Turn Off Individua Heaters 13
Key Lock 16
Chi d Lock 17
Stop & Go Function 18
TOUCH CONTROL SAFETY FUNCTIONS 20
Sensor Safety Cut Off 20
Over Temperature Switch Off 21
Operating Time Limitations 21
Residua Heat Functions 22
CLEANING AND CARE 23
CONTENTS:
........................................................
..............................................................
...............................................................................
...........................................................
...............................................
...........................................................................................
...............................................
.................................................................................
.....................................................
......................
..........................................................
..............................................................................
........................................................................................
......................................................................
....................................
...................................................................
.......................................................
..........................................................
...............................................................
..................................................................

3
DESCRIPTION OF THE HOB
Dear Customer,
It is important that you should read this manual for best performance and
to extend the life of your appliance. We recommend you to keep this manual
for future reference.
Your new hob is uaranteed and will ive lastin service. This uarantee
is only applicable if the appliance has been installed and operated in
accordance with the operatin and installation instructions detailed in this
manual.
Note: Appearance of your hob maybe different than the model shown above
due to its confi uration.
EBC405 DB
SINGLE
HEATER ZONE
TOUCH CONTROL PANEL
VITROCERAMIC
SURFACE

EBC415 DB
SINGLE
HEATER ZONE
DUAL
HEATER ZONE
TOUCH CONTROL PANEL
VITROCERAMIC
SURFACE

PART 2 SAFETY WARNINGS
4
READ THESE INSTRUCTIONS CAREFULLY AND COMPLETELY BEFORE USING YOUR
APPLIANCE, AND KEEP IT IN A CONVENIENT PLACE FOR REFERENCE WHEN NECESSARY.
THIS MANUAL IS PREPARED FOR MORE THAN ONE MODEL IN COMMON. YOUR APPLIANCE
MAY NOT HAVE SOME OF THE FEATURES THAT ARE EXPLAINED IN THIS MANUAL. PAY
ATTENTION TO THE EXPRESSIONS THAT HAVE FIGURES, WHILE YOU ARE READING THE
OPERATING MANUAL.
General Safety Warnings
- This appliance can be used by children aged
from 8 years and above and persons with
reduced physical, sensory or mental capabilities
or lack of experience and knowledge if they
have been given supervision or instruction
concerning use of the appliance in a safe way
and understand the hazards involved. Children
shall not play with the appliance. Cleaning and
user maintenance shall not be made by children
without supervision.
- WARNING: The appliance and its accessible
parts become hot during use. Care should be
taken to avoid touching heating elements.
Children less than 8 years of age shall be kept
away unless continuously supervised.
- WARNING: Unattended cooking on a hob with
fat or oil can be dangerous and may result in
fire. NEVER try to extinguish a fire with water,
but switch off the appliance and then cover
flame e.g. with a lid or a fire blanket.
- WARNING: Danger of fire: do not store items
on the cooking surfaces.

5
- WARNING: If the surface is cracked, switch off
the appliance to avoid the possibility of electric
shock.
- For hobs incorporating a lid, any spillage
should be removed from the lid before opening.
And also the hob surface should be allowed to
cool before closing the lid.
- The appliance is not intended to be operated
by means of an external timer or separate
remote-control system.
- Do not use harsh abrasive cleaners or sharp
metal scrapers to clean the oven door glass and
other surface since they can scratch the surface,
which may result in shattering of the glass or
damage to the surface.
- Do not use steam cleaners for cleaning the
appliance.
- Your appliance is produced in accordance with all applicable local and international standards and
regulations.
- Maintenance and repair work must be made only by authorized service technicians. Installation and
repair work that is carried out by unauthorized technicians may endanger you. It is dangerous to alter or
modify the specifications of the appliance in any way.
- Prior to installation, ensure that the local distribution conditions (nature of the gas and gas pressure or
electricity voltage and frequency) and the requirements of the appliance are compatible. The
requirements for this appliance are stated on the label.
- CAUTION: This appliance is designed only for cooking food and is intended for indoor domestic
household use only and should not be used for any other purpose or in any other application, such as
for non-domestic use or in a commercial environment or room heating.
- All possible security measures have been taken to ensure your safety. Since the glass may break, you
should be careful while cleaning to avoid scratching. Avoid hitting or knocking on the glass with
accessories.
- Ensure that the supply cord is not wedged during the installation. If the supply cord is damaged, it
must be replaced by the manufacturer, its service agent or similarly qualified persons in order to prevent
a hazard.

6
Installation Warnings
- Do not operate the appliance before it is fully installed.
- The appliance must be installed by an authorized technician and put into use. The producer is not
responsible for any damage that might be caused by defective placement and installation by
unauthorized people.
- When you unpack the appliance, make sure that it is not damaged during transportation. In case of
any defect; do not use the appliance and contact a qualified service agent immediately. As the
materials used for packaging (nylon, staplers, styrofoam...etc) may cause harmful effects to children,
they should be collected and removed immediately.
- Protect your appliance against atmospheric effects. Do not expose it to effects such as sun, rain,
snow etc.
- The surrounding materials of the appliance (cabinet) must be able to withstand a temperature of min
100°C.
During usage
- Do not put flammable or combustible materials, in or near the appliance when it is operating.
- Do not leave the cooker while cooking with solid or liquid oils. They may catch fire on condition of
extreme heating. Never pour water on to flames that are caused by oil. Cover the saucepan or frypan
with its cover in order to choke the flame that has occured in this case and turn the cooker off.
- Always position pans over the centre of the cooking zone, and turn the handles to a safe position so
they cannot be knocked or grabbed.
- If you will not use the appliance for a long time, plug it off. Keep the main control switch off. Also
when you do not use the appliance, keep the gas valve off.
- Make sure the appliance control knobs are always in the "0" (stop) position when it is not used.
During cleaning and maintenance
- Always turn the appliance off before operations such as cleaning or maintenance. You can do it after
plugging the appliance off or turning the main switches off.
- Do not remove the control knobs to clean the control panel.
TO MAINTAIN THE EFFICIENCY AND SAFETY OF YOUR APPLIANCE, WE RECOMMEND YOU
ALWAYS USE ORIGINAL SPARE PARTS AND TO CALL ONLY OUR AUTHORIZED SERVICE
AGENTS IN CASE OF NEED.
-The temperature of the bottom surface of the hob might rises during the operation.
Therefore, a board must be installed underneath the product.

6
The e ectrica connection of this hob shou d be carried out by an
authorised service persona or a qua ified e ectrician, according to the
instructions in this guide and in comp iance with the current regu ations.
· Prior to installation, ensure that the local distribution conditions and the
adjustment of the appliance are compatible.
· The laws, ordinances, directives and standards in force in the country of
use are to be followed (safety re ulations, proper recyclin in accordance
with the re ulations, etc.)
Locating your bui t-in hob
After removin the packa in material from the appliance and its accessories,
ensure that the hob is not dama ed. If you suspect any dama e, do not use
the appliance and contact an authorised service personal or a qualified
electrician immediately.
· This built-in hob is to be inserted into a cut out of a worktop. It will be
electrically connected with the switch box below, especially provided for this
purpose.
INSTALLATION

7
520mm
590mm
41mm
560mm
490mm
Min.
A
Min.
B
Min.
130mm
Min.
25mm
· Create an openin with the dimensions shown in the picture below.The
distance between the rear ed e of the hob and any adjacent wall is depend on wall
surface. Please dont use easily combustible material like curtain, paper at nearby
hob.
· Screw the 4 worktop mountin brackets on the side walls of product.
· Apply the one-sided self-adhesive sealin tape supplied all the way round
the lower ed e of the cookin surface alon the outer ed e of the lass
ceramic panel. Do not stretch it.
worktop mountin bracket
Nei hboorhood walls A [mm] B [mm]
Combustible 50 50
Non-combustible 50 50

E ectrica connection of your hob
. Before proceedin with the electrical connection, verify that the current
carryin capacity of the system and the socket is adequate for the maximum
power ratin of the hob.
· Electrical installation of the residence and the electrical current plu in
use must be earthed and conform with safety re ulations.
· If there is no dedicated hob circuit and fused switch, they must be installed
by a qualified electrician before the hob is connected.
· Fused switch must be easily accessible once the hob has been installed.
· Do not use adaptors, multiple sockets and/or extension leads.
· This appliance conforms with the requirements ofthe followin EEC
Directives:
· A circuit breaker with a contact openin of at least 3 mm, rated 20 A and
delayed functionin type must be installed inside the supply circuit.
25 A and

9
. For the touch controlled vitroceramic hob, the cable must be H05VV-F
3X2,5 mm² / 60227 IEC 53. You will find the connection dia ram shown
on the back of your appliance.
· Durin installation, please insure that isolated cables are used. An incorrect
connection mi ht dama e your appliance. The uarantee will not cover
such dama es.
· All repairs must be carried out by an authorised service personnel or a
qualified electrician.
· Unplu your appliance before each maintenance. For reconnection, follow
the connection dia rams strictly.

Mode Descriptions
USAGE
The appliance is operated by touchin buttons and the functions are
confirmed by displays and acoustic si nals.
10
Stand-By-Mode S-Mode The mains are applied to the hob control
and all heater displays are off or a residual
heat display is active.
Operatin -Mode B-Mode At least one heater display shows a heat
settin between ´0` and ´9`
Lock Mode VR-Mode The hob control is locked.
- Wait until `F' disappears for all zones,turn the hob on by touching
and continue to use.
Dual zone selection

11
Turn On and Turn Off The App iance
If the appliance is in Stand-By-Mode, it is put in Operating-Mode by pressin
the On/Off button at least 1 second. A buzzer si nal indicates the
successful operation acoustically.
On all heaters a ´0` appears and all Decimal Point of the heater flashes (1
sec on, 1 sec off).
If there is no operation within 10 sec, the display of all heaters will turn off.
If the displays are turned off, the heater will be set into Stand-By-Mode.
If is pressed more than 2 sec (in Operating-Mode), the appliance is
switched off and is set into the S-Mode a ain. The appliance can be turned
off by pressin at any time; even if other buttons are pressed
simultaneously.
If there is a residual heat of a heater remainin , this will be indicated in the
correspondent heat settin Heater Display.
Se ect Heater
If a sin le heater is chosen with the correspondin Active/Deactive Heater
Button , the Decimal Point of the related Heater Display flashes. For the
selected heater, you can set the heat level between 1-9 by touchin the
Heat Setting Buttons or .
The buttons must be pressed within 3 sec, otherwise the heater selection
is erased and heat settin dot will disappear (Decimal Point). If there is no
further operation within 10 sec, the heater falls back into the S-Mode.
The heat settin can always be chan ed by pressin or between
level 1-9.
Each button operation or each display chan e is quitted by a buzzer si nal.

12
Turn on dua zones (avai ab e on y in some mode s)
Turn on the dual zone (EBC415)
The activation of the dual zone is done after selectin the desired heater
by actuatin . This is confirmed by a buzzer si nal. At the same time, the
correspondin Dual one Indicator oes on statically. Touchin for a
second time, the status of the dual zone to les: it chan es from dual zone
on to dual zone off and back a ain.
The extension zone can be activated only, after a level between 1-9 is set
on the basic zone of the heater.
Set Cooking Leve With and Without Heat Boost
(Heat Boost is available only for Induction hobs)
All heaters are equipped with heat boost functionality.
If the heat boost is active, than the heater will be operated with maximum
power for the period of the heat boost time, that is dependent from the
selected heat settin . This is indicated throu h a flashin ´A`, alternatin
with the heat settin value (e. . 0,5 sec ´A` and 0,5 sec ´9`) in the heater
display. Once the heat boost time ended only the heat settin will be indicated.
If the heat boost should be used for a heater, heater level 9 must be operated
by pressin startin from level 0. After settin the heat to level 9 , ´A`
will be indicated alternatin . This means that level 9 and heat boost is active
now.

13
The heat boost can be turned off by pressin until heat settin ´0`
appears.
If the heat boost should be used, it can always be activated by actuatin
a ain if the heat settin is set to level 9. In the heat display ´A/9` flashes.
Turn Off Individua Heaters
A selective heater can be turned off with 3 different ways:
. Simultaneous operation of and buttons
· Reduction of the heat settin to ´0` by operatin button
Simultaneous operation of and buttons
The correspondin heater must be chosen with the Active/Deactive Heater
Button , the Decimal Point of the related Heater Display flashes. To turn
off the heater, and must be pressed at the same time. A buzzer
si nal sounds and ´0` appears in the heat settin display.
If there is a residual heat for this heater remainin , this will be indicated by
a static display ´H` in the heat settin display.
Reduction of the heat settin to ´0` by operatin button
The heater can also be turned off by reducin the operated heat settin to
´0`.
When Heater Display indicates ´0`, an associated Decimal Point of the
heater will also be turned off.
If there is a residual heat for this heater remainin , this will be indicated by
a static display ´H` in the heat settin display.
An assi ned Dual one Selection Indicator also disappears if it is active.
Key Lock
Key lock functionality is for blockin and set the appliance into a save
modus durin operation. Touch modifications as for example rise heat
settin s and others should not be possible. It is only possible to switch the
appliance off.
The lock function is active, if the Key Lock button is pressed at least 2
sec. This operation is acknowled ed by a buzzer. After successful operation
of more than 2 sec, the Key Lock Indicator flashes and the heater is locked.
The heater can only be locked in Operating Mode (B-Mode).

17
If the heater is locked, only can be operated, all other buttons are blocked.
If there is any other button operated in the blocked mode, the buzzer si nal
sounds and the Key Lock Indicator flashes as indication for the activated
key lock functionality. Only the switch off by operation of is possible. But
if you switched off the appliance, you can not restart it a ain without
unlockin .
After pressin 2 sec, the Key Lock Indicator disappears. Now, the hob
control is unlocked and can be operated in normal order.
Chi d Lock
Child lock functionality is foreseen to lock the appliance in a complicated
Multi-Step process.
Child lockin and unlockin is only available in the S-Mode.
First has to be pressed until the buzzer beeps, then the and have
to be pressed for at least 0,5 sec, but max 1 sec. simultaneously. Followin
that, the appliance can be locked by touchin the . All 4 heater displays
´L` is showed as a confirmation.
In the case the minute minder is still runnin , it will proceed until ´00` is
reached and the timer will beep. After confirmation of timer run out, the
appliance is fully locked. None of the buttons can be used as lon as the
appliance is locked.

18
The same way the child lock is activated, it can also et deactivated. After
pressin until the beep, then the and have to be pressed
simultaneously for at least 0,5 sec, followed by touchin only the . As
a confirmation for successful unlockin , ´L` symbol in the displays will be
erased immediately.
Stop & Go Function (avai ab e on y in some mode s)
The Stop & Go functionality can be used only alternatively to Key lock
functionality. It is not possible to use both.
The Stop & Go function is activated by pressin for 1 sec. Afterwards
it is acknowled ed acoustically by two beeps.
The Stop-function is active and all heaters which are turned on will be
reduced to heat settin ´1` for 1 minute, then for the remainin 9 minutes
a runnin li ht with a horizontal bar startin from the bottom to the top is
displayed. Afterwards all heaters are reduced to heat settin 0 for the rest
of the time. For all inactive heat settin s, there is ´0` or the residual heat
´H` indicated.
The heater completely turns off after 10 minutes or after immediate operation
of .
If the heater is turned off via , the heater is in S-Mode and the Stop-
function is deleted. If the heater is turned on a ain, there is no Stop & Go
function.

19
If the heat boost for a heater is active, then the expired time of the heat
boost is stored and after deactivatin the Stop & Go function, the remainin
heat boost time will expire (meanin the heat boost time does not continue
durin the Stop & Go condition).
To deactivate the Stop & Go function, must be pressed for 1 sec. It is
acknowled ed acoustically with a beep.
Afterwards release and actuate any button within 10 sec (except and
), than the operatin conditions active before the Stop & Go operation
will be activated a ain. All reduced heater continue to work with the last
chosen heat settin . If no further button or is actiavted within 10 sec,
the heater turns off.

20
TOUCH CONTROL SAFETY FUNCTIONS
The followin safety functions are available to avoid unintended operations
of the hob control.
Sensor Safety Cut Off
To prevent the appliance from unwanted, random sensor operation, a sensor
monitorin is included.
In case of one or more buttons are pressed lon er than 12 sec, the sensor
monitorin routine indicates acoustically that wron operation (pot or other
object placed on the button, sensor failure, etc.) and switches off the
appliance.
The safety turn off causes that the hob control is turned off to the S-Mode.
An ´F` will flash in all heater displays.
If residual heat is present, it will be displayed in all other heater displays.
The hob control will then o in S-Mode. At the same time a buzzer si nal
appears. After 10 minutes the acoustic si nalin will stop.
If there is no erroneous operation present any lon er, both the visual and
the acoustic si nal will disappear.
