Vremi VRM050715N User manual

6-Drawer Dresser | 1
Give Me
Some Space!
6-Drawer Dresser
This Is A Manual.

6-Drawer Dresser | 3
Important Safety Instructions
1. Before throwing away the package, please identify the parts and the hardware to ensure that you
have everything you need.
2. Check and measure the bolts before fastening them to the parts.
3. Do not completely tighten all hardware until the entire assembly is complete, unless indicated
otherwise.
4. For safety precautions, this product should be assembled by two people.
CAUTION: We do not recommend using a drill or a power screwdriver. It may cause the screws to
break or strip.
SAVE THESE INSTRUCTIONS
For Household Use Only
In the event this product malfunctions, or you believe it
is defective, contact Customer Service at Vremi.com/
chat, 1-(646)-490-9904 or suppor[email protected] and retain
the defective product pending further instructions. Defective
product should be clearly marked or stored where it cannot
be used again by mistake. Failure to retain the product may
impede Vremi’s ability to correct any legitimate problem and
may limit the extent to which Vremi may provide recourse.

4| 6-Drawer Dresser 6-Drawer Dresser | 5
Hardware List
1
M4 Allen Key
1 Pc
8
Nail
50 Pcs
2
Screw M6.3 × 50
18 Pcs
9
12” Drawer Slide
6 Sets
3
Handle (7.6”) MH2
6 Pcs
10
Screw M3.5 × 16
84 Pcs
4
Screw M4 × 22
12 Pcs
11
Dowel 8 × 30
8 Pcs
5
Sticker
12 Pcs
12
Screw M8 × 32
24 Pcs
6A
Cam Lock
30 Pcs
13A
Minfix Cam Lock
6 Pcs
6B
Cam Nut
30 Pcs
13B
Minfix Cam Nut
6 Pcs
7
Bottom Pin
6 Pcs
14
Screw M4 × 38
6 Pcs
Anti-tipover Hardware
Anchor
2 Pcs
Screw M3.5 × 16
2 Pcs
Bracket
2 Pcs
Screw M4 × 38
2 Pcs
Parts List
A
Left Side Panel
26.6 × 14.0 × 0.6”
1 Pc
I
Top Panel
46.9 × 15.6 × 0.7”
1 Pc
B
Right Side Panel
26.6 × 14.0 × 0.6”
1 Pc
J
Back Panel
23.7 × 11.7 × 0.1”
4 Pcs
C
Divider Panel
22.8 × 14.0 × 1.0”
1 Pc
K
Drawer Front
23.1” × 7.6 × 0.6”
6 Pcs
D
Horizontal Shelf
45.6 × 3.1 × 0.6”
1 Pc
L
Drawer Left Side
13.5 × 5.5 × 0.6”
6 Pcs
E
Divider Support (Front)
45.6 × 3.1 × 0.6”
1 Pc
M
Drawer Base
20.6 × 13.4 × 0.1”
6 Pcs
F
Divider Support (Back)
45.6 × 3.1 × 0.6”
1 Pc
N
Drawer End
20.1 × 5.4 × 0.6”
6 Pcs
G
Leg (Front)
45.6 × 3.1 × 0.6”
1 Pc
O
Drawer Right Side
13.5 × 5.5 × 0.6”
6 Pcs
H
Leg (Back)
45.6 × 3.1 × 0.6”
1 Pc
P
Drawer Base Support
12.9 × 1.7 × 0.5”
6 Pcs

6| 6-Drawer Dresser 6-Drawer Dresser | 7
The Breakdown...
P
LN
M
O
K
I
A
J
D
F
H
E
G
J
C
JJ
B
Installation
STEP 1
Place the Drawer Slides (9) marked with CL at the predrilled holes on Panel A (Left Side Panel), and make sure the
end with the roller is aligned with the left side of Panel A. Tighten the drawer slides with Screw (10).
Put Panel C (Divider Panel) with the slot pointing to the right. Place the drawer slides (9) marked with CR at the
predrilled holes on Panel C, and make sure the end with the roller is aligned with the right side of the Panel C.
Tighten the drawer slides with Screw (10).
Insert Cam Nut (6B) with the cross arrow mark facing upwards. You will be able to see the opening of the Cam
Nut (6B) thru the top edges of Panel A.
1
10
96B
A
C
CL
CR
CR
CR
CL
CL

8| 6-Drawer Dresser 6-Drawer Dresser | 9
InstallationInstallation
STEP 3STEP 2
Screw Panels D, E, and F to Panels A and C using Screw (2) and the Allen Key. Make sure the edge banding
sides of Panels D and E are facing outwards.
Place the Drawer Slides (9) marked with CR at the predrilled holes on Panel B (Right Side Panel) as shown. Make
sure the end with the roller is aligned with the right side of panel B. Tighten the drawer slides (9) with Screw (10).
Insert Cam Nut (6B) into Panels B and C with the cross arrow mark facing upwards. You will be able to see the
opening of the Cam Nut (6B) thru the top edges of Panels B and C.
Turn over Panel C. Place the Drawer Slides (9) marked with CL at the predrilled holes on Panel C. Make sure the
end with the roller is aligned with the left side of Panel C. Tighten the Drawer Slides (9) with Screw (10).
9
10
16B
B
C
CL
CR
CR
CR
CL
CL
A
C
D
E
F
1
2

10 | 6-Drawer Dresser 6-Drawer Dresser | 11
InstallationInstallation
STEP 5STEP 4
1. First prepare the Top Panel (I).
2. Insert the blue end of Cam Lock (6A) into the holes at the bottom of Panel I. (You will use 6 pcs)
VERY IMPORTANT: Use your hands to insert the Cam Locks. Do not use a hammer.
3. Put Panel I on Panels A, B and C while inserting the other end of Cam lock (6A) into the
predrilled holes on Panels A, B and C. Push and gently tap Panel I. Tighten Cam Nut (6B) clockwise
to lock the Cam Lock Nut up by going under Panel I, then tighten it upon both sides (Panels A and B) and
upon the middle piece (Panel C).
Insert Wood Dowel (11) into both left and right sides of Panels G and H, then align the Wood Dowels with the
pridrilled holes on Panels A and B, slightly tapping them in with a hammer.
Fix Screw (2) using predrilled holes on Panel B into Panels D, E and F by using the Allen Key (1).
Insert 2pcs Screw (2) using predrilled holes on Panel E into Panel G with the Allen Key (1), then insert another 2pcs
Screw (2) using predrilled holes on Panel F into Panel H, again with the Allen Key (1).
Insert Bottom Pin (7) onto the bottom edge of Panels A, B, G and H, slightly tapping them in with a hammer.
G
H
A
B
11
7
2
1
A
I
C
B
6A
6B
1

12 | 6-Drawer Dresser 6-Drawer Dresser | 13
InstallationInstallation
STEP 7STEP 6
1. Insert the blue end of Cam Lock (6A) into Panel K (Drawer Front).
2. Insert Drawer Base (M) into the slot of Panels O, L, and K and align properly.
3. Insert Cam Nut (6B) with the cross arrow mark facing downward while aiming at Panels L & O thru
holes.
4. Insert Panels L and O into Panels M and K, and align properly. Fix the 4pcs Cam Nuts (6B) with the
screwdriver (1).
5. Insert the minifix Cam Nut (13B) into Panel P with the cross arrow mark facing downward. Screw
the minifix Cam Lock (13A) from the bottom of Panel K ( Drawer Front) into Panel P (Drawer Base
Support) aiming to Panel P’s thru hole, then fix 13B using the screwdriver.
Fix 50 pcs Nails (8) into Panel J using a hammer.
Attention: Upper edge of Panel J should be 0.2” down from top face of Panel I.
Cover all the Screw (2) head with Sticker (5) .
6A
6B
6A 1
1
13A
13B
K
O
P
K
L
M
5
7
J
J
J
I
J

14 | 6-Drawer Dresser 6-Drawer Dresser | 15
InstallationInstallation
STEP 9STEP 8
Fix Drawer Slides at the bottom of Panels L and O by Screw (10). One slide uses 3 screws.
Note:
1. The Drawer Sides are marked with “DL” and “DR”. Assemble them correctly as shown in the figure
below.
2. The white roller of the drawer slides should face outward and the other end should touch the tip
of Panel K (as shown).
Place Panel N on each side of Panel L and Panel O as shown.
Then, tighten Screw (12) to Panel L and Panel O’s upper thru holes to fix them onto Panel N.
Tighten Screw (14) to Panel N’s thru hole to fix it to Panel P.
Flip the drawer over.
Tighten 2 Screw (4) from the inner side of Panel K to attach the handle (3) .
1
12
1
14
4
P
N
O
LN
M
K
O
L
3
1
10
9
K
DL
DR
O
K

16 | 6-Drawer Dresser 6-Drawer Dresser | 17
Anti-Tipover AssemblyAnti-Tipover Assembly
Warning:
Serious or fatal injuries can occur from furniture tipping over. To prevent the furniture from tipping over, we
recommend to have it permanently fixed to the wall.
Wall anchor and hardware are included with this product. Please make sure hardware is suitable for your
walls before installing, as different wall materials may require different types of anchors.
Note: You can choose to assemble the anti-tipover bracket to the top or sides of the dresser.
Children may die from furniture tipping
over. To reduce the risk:
• ALWAYS install the tip over restraint provided.
• NEVER put a TV on the dresser.
• NEVER allow children to stand, climb, sit, or hang on
the dresser.
• NEVER open more than one drawer at a time.
• Place the heaviest items in the bottom drawers.
K
K
I
B
K
K
K
K
Use 6mm diameter driller
to drill holes and insert the
anchors in the wall
Screw the bracket to the wall using
the long screw.
Fix the other end of the bracket to
the dresser using the short screw.
Wall
Anchor Wall
Top

18 | 6-Drawer Dresser
This manual covers all items with the model number:
Keep all plastic bags away from children.
Warranty Information
Vremi offers a 12-month warranty on all of our products purchased new and unused from Vremi LLC or an
authorized reseller, with an original proof of purchase and where a defect has arisen, wholly or substantially, as
a result of faulty manufacturing, parts or workmanship during the one-year warranty period. The warranty does
not apply where damage is caused by other factors, including but without limitation to: (a) normal wear and tear;
(b) abuse, mishandling, accident or failure to follow operating instructions; (c) exposure to liquid or infiltration of
foreign particles; (d) servicing or modification of the product other than by Vremi. These are our general terms for
the warranty service, but we always urge our customers to reach out to us with any issue, regardless of warranty
terms. If you experience an issue with a Vremi product, please contact us at [e-mail], and we will do
our best to resolve it for you.
VRM050715N
Warning
Dimension (W × H × D): 47.0 × 27.6 × 15.7”
Drawer weight capacity: 20 Ib
vremi.com/chat
CHAT WITH US
(646) - 490 - 9904
CALL US
[email protected]
EMAIL US
Drop Us A Line
Specifications

20 | 6-Drawer Dresser
vremi.com/chat [e-mail] (646) - 490 - 9904Questions?
