VS Sassoon The All-Rounder VSM837A Assembly instructions

1
TOOL TIPS
THEALL-ROUNDER
for the waterproof multi-purpose
face, body & head trimmer
VSM837A

2
HEY YOU!
TAKE A BOW FINE SIR.
THINGS ARE LOOKING UP
& YOU’VE JUST MADE A
QUALITY PURCHASE
WITH THIS NEW GROOMING TOOL.
WE KNOW YOU’VE GOT THIS, BUT BEFORE YOU JUMP INTO
USING YOUR NEW SIDE KICK, HERE’S A FEW TIPS & TRICKS
TO KNOW BEFORE LETTING YOUR CREATIVITY RUN LOOSE.
HIT UP VSFORMEN.COM.AU FOR MORE GROOMING & INSPIRATION.

THE ALL-ROUNDER / TOOL TIPS
3

44
1. Precision W-Tech blades
2. 100% waterproof
3. Cordless use
4. 32mm trimming blade
5. Foil shaver
6. 7mm precision blade
7. Rotary blade
8. 6 position comb guide
(0.5mm to 3mm) for short or
shadow stubble
9. 7 position comb guide (2mm
to 14mm) for keeping your
beard in top shape
10. 7 position comb guide (3mm
to 15mm) for trimming head
& body hair
11. Charging and storage stand
12. Cleaning brush
13. Oil
THE ALL-ROUNDER
BRAVO. YOU’VE MADE A QUALITY PURCHASE.
The All-Rounder is the waterproof multi-purpose face, body
& head trimmer.
1
76 8
11
95
1
10
4
2
3
THE ALL-ROUNDER / TOOL TIPS
13
12

THE ALL-ROUNDER / TOOL TIPS
5
PREPPING YOUR
NEW TOOL
CHARGING
The All-Rounder is so easy to use. But before you start using your new tool, you must
take the time to charge it overnight for 16 hours before its first use. Your new tool comes
with a small amount of charge, but the initial charge will ensure your new tool will have
optimum power performance to give you smooth fast cutting, every time.
- Before using for the first time, fully charge your new tool continuously for 16 hours.
- Maximum battery capacity will only be reached after 3 charging & discharging cycles.
The All-Rounder can be charged whilst standing in the charging/storage stand or without
the stand.
To charge the trimmer whilst in the stand, remove the trimmer, attachments and
accessories from the stand. Hold the recharging/storage stand upside down and insert
the small plug on the charging adaptor into the hole on the base of the stand and push
firmly into position. Then, route the cord through the channel on the base of the stand.
Place your thumb on the hinged back cover and push the cover over the charging adaptor
plug (to the right) to secure the cord and plug in place (Fig.1).
To charge the trimmer without the stand, simply insert the small plug on the charging
adaptor into the hole on the base of the trimmer.
- The red charging LED indictor light on your new tool will illuminate when correctly
connected to the mains power.
- A full charge will supply 40 minutes cordless runtime.
- To maintain optimum capacity of the rechargeable battery, it is highly recommended
to fully discharge & then recharge your tool for 16 hours every 3 months.
- Subsequent recharges will only require 8 hours charging time.

THE ALL-ROUNDER / TOOL TIPS
6
HOW TO USE
THE ALL-ROUNDER
BEFORE USING
• Always inspect the trimmer blades for noticeable signs of damage.
• Always inspect the trimmer blades before use to ensure they are free from
hair, debris etc.
• Ensure the trimmer is sufficiently charged before use.
• If the foil is cracked, broken or loose, do not use it again and replace with a
new foil. Using a foil in a faulty condition can cause injury.
• Do not shave on open wounds, cuts, burns, warts, moles or on sunburned
skin.
• Do not use the foil shaver if you suffer from skin irritations or infections,
such as psoriasis or eczema. If at all unsure always consult your doctor
before use.

THE ALL-ROUNDER / TOOL TIPS
7
CHANGING THE ATTACHMENT HEADS
1. Before changing the attachment heads, make sure your trimmer is switched
off.
2. Remove any comb guides attached to your trimmer.
3. To remove an attachment head, hold the handle of the trimmer with one
hand, while holding the attachment head with the other hand. Push up on the
attachment head with your free hand to remove it (Fig.2)
4. To attach an attachment head, fit the base of the attachment had onto the
trimmer pressing it until you hear a click.

THE ALL-ROUNDER / TOOL TIPS
8
TRIMMING TIPS
Hit up www.vsformen.com.au for more grooming tips & inspiration.
USING THE 32MM TRIMMING BLADE
The 32mm trimming blade has been designed for body, face & hair trimming. It’s
also ideal for stubble & beard shaping.
The following comb guides are for use with the 32mm trimming blade:
• 6 position comb guide (0.5mm to 3mm) for short or shadow stubble;
• 7 position comb guide (2mm to 14mm) for keeping your beard in top shape; and
the
• 7 position comb guide (3mm to 15mm) for trimming head & body hair.
The 32mm trimming blade can also be used without any comb guide attached to
outline, and for an even closer finish.
Using the 32mm trimming blade to outline
The 32mm trimming blade without a comb guide attached will cut roughly to a
length of 0.5 mm.
1. Do not attach a comb guide.
2. Hold the trimmer upside down with the blade facing downwards, yet flat against
the skin.
3. Move the trimmer gently downwards in small strokes around the edge of the
area you wish to outline.
4. Having defined the outline, hold the trimmer with the blades pointing upwards,
yet flat against the skin and move the trimmer upwards against the direction of
hair growth. This will trim the unwanted hair adjacent to the outline.
BE CAREFUL NOT TO APPLY EXCESS PRESSURE
TO THE BLADE, AS THIS MAY DAMAGE THE BLADE
AND CAN RESULT IN INJURY TO THE SKIN DURING
TRIMMING.

THE ALL-ROUNDER / TOOL TIPS
9
Using the 32mm trimming blade with the 6 position comb guide (0.5mm to 3mm)
for short or shadow stubble
1. To attach the 6 position comb guide, place the comb guide onto the back of
the trimmer, ensuring that the two plastic lugs are aligned correctly over the
top of the trimmer. Push the comb guide down until it clicks into place. The
comb guide is now secured onto the trimmer and the longest cutting length
should be shown – 3mm.
2. The comb guide has 6 length settings, 0.5mm, 1mm, 1.5mm, 2mm, 2.5mm and
3mm. The trimming length is manually adjustable. The selected length in
mm is displayed in white at the back of the trimmer. To change the trimming
length, push in the middle section of the comb guide and adjust the comb
guide up or down. Stop at the required cutting length when it is displayed
at the back of the trimmer. The comb guide should then be secured at the
selected cutting length.
3. Select the required cutting length setting (0.5mm to 3mm). If you require
more than one cutting length, start with the longest length first.
4. Switch the trimmer on.
5. Hold the trimmer with the teeth of the trimmer pointing upwards, yet flat
against the skin.
6. Move the trimmer upwards and outward through the hair, against the
direction of hair growth.
7. The trimmer will work most efficiently when cutting through hair at its own
speed.
8. Never switch the appliance off whilst in the hair.
9. To remove the comb guide, simply press in the middle section of the comb
guide and push all the way to the top until you can remove it from the
trimmer.

THE ALL-ROUNDER / TOOL TIPS
10
Using the 32mm trimming blade with the 7 position comb guide (2mm to 14mm) for
keeping your beard in top shape
1. To attach the 7 position comb guide, place the comb guide onto the back of the
trimmer, ensuring that the two plastic lugs are aligned correctly over the top
of the trimmer. Push the comb guide down until it clicks into place. The comb
guide is now secured onto the trimmer and the longest cutting length should be
shown – 14mm.
2. The comb guide has 7 length settings, 2mm, 4mm, 6mm, 8mm, 10mm, 12mm and
14mm. The trimming length is manually adjustable. The selected length in mm
is displayed in white at the back of the trimmer. To change the trimming length,
push in the middle section of the comb guide and adjust the comb guide up or
down. Stop at the required cutting length when it is displayed at the back of the
trimmer. The comb guide should then be secured at the selected cutting length.
3. Select the required cutting length setting (2mm to 14mm). If you require more
than one cutting length, start with the longest length first.
4. Switch the trimmer on.
5. Hold the trimmer with the teeth of the trimmer pointing upwards, yet flat
against the skin.
6. Move the trimmer upwards and outward through the hair, against the direction
of hair growth.
7. The trimmer will work most efficiently when cutting through hair at its own
speed.
8. Never switch the appliance off whilst in the hair.
9. To remove the comb guide, simply press in the middle section of the comb guide
and push all the way to the top until you can remove it from the trimmer.

THE ALL-ROUNDER / TOOL TIPS
11
Using the 32mm trimming blade with the 7 position comb guide (3mm to 15mm) for
trimming head & body hair.
1. To attach the 7 position comb guide, place the comb guide onto the back of the
trimmer, ensuring that the two plastic lugs are aligned correctly over the top
of the trimmer. Push the comb guide down until it clicks into place. The comb
guide is now secured onto the trimmer and the longest cutting length should be
shown – 15mm.
2. The comb guide has 7 length settings, 3mm, 5mm, 7mm, 9mm, 11mm, 13mm and
15mm. The trimming length is manually adjustable. The selected length in mm
is displayed in white at the back of the trimmer. To change the trimming length,
push in the middle section of the comb guide and adjust the comb guide up or
down. Stop at the required cutting length when it is displayed at the back of the
trimmer. The comb guide should then be secured at the selected cutting length.

THE ALL-ROUNDER / TOOL TIPS
12
CREATING AN ALL-OVER EVEN CUT
ON YOUR HEAD
1. Ensure the trimmer is switched off.
2. Select the desired trimming length setting as required.
3. Switch the trimmer on – the blades will start to move.
4. Start cutting at the nape of the neck, holding the trimmer with the teeth of the
trimmer pointing upwards, ensuring that the comb guide is resting flat against
the head.
5. Slowly move the trimmer upwards and outwards through the hair towards your
crown, against the direction of the hair growth. The comb guide will help to lift
the hair and the blades will cut the hair to the length as shown on the comb
guide.
6. Once the desired length is achieved at the back of the hair, start trimmer the
top and sides.
7. Hold the trimmer to the front of your hair with the teeth pointing towards
the back of your head, and move the trimmer towards your crown. Repeat as
necessary, moving in rows from the front and the sides of your head to the back.
8. The trimmer will work most efficiently when cutting through hair at its own
speed.
9. Never switch the appliance off whilst in the hair.
10. To remove the comb guide, simply press in the middle section of the comb guide
and push all the way to the top until you can remove it from the trimmer.

THE ALL-ROUNDER / TOOL TIPS
13
USING THE FOIL SHAVER
The foil shaver has been specially designed for shaving all bodyzones - chest and
stomach area, back and shoulders, underarms, legs and the groin area. It will leave
the skin feeling clean, smooth and refreshed. The dual independent trimmers on
either side of the foil shaver are designed to shorten long hair and allow you to
easily achieve precise shaving.
The 100% waterproof design makes it ideal for shaving body hair in the shower, for
no mess grooming or as a dry shave. You can use shaving aids such as foam or gel
with this product to achieve a cleaner, more refreshing shave.

THE ALL-ROUNDER / TOOL TIPS
14
PREPARING THE SKIN
Before using the foil shaver, make sure that the skin is perfectly clean and free from
grease or cream. Exfoliating the skin once or twice a week before shaving helps to
maintain healthy and fresh skin, but it also helps to:
• Prevent hairs from growing under the skin, resulting in in-grown hairs
• Remove dead skin cells and refine the texture of your skin, resulting in a closer shave
• repare your skin to help it absorb skin care products.
We recommend exfoliating ideally the day before, as well as just before shaving.
This will help straighten the hair and make it easier to shave. Avoid exfoliating just after
shaving.
Having a warm shower before use will also help to soften the hair.
For optimum results, it is recommended to trim the hair first if it is quite long using the
32mm trimming blade.
1. Attach the foil shaving head.
2. Switch the trimmer on by sliding the On/Off switch upwards so that the “I”marking is
visible.
3. Always keep the shaver perpendicular to the surface to be shaved.
4. Always work with both hands: stretch the skin with one hand and move the trimmer
with the other hand.
5. Slowly move the shaver, exerting light pressure. As a precaution, the operation of
the trimmer may slow down substantially if the foil shaving head is pressed too hard
against the skin.
WET SHAVING
1. Thoroughly wet the body with warm water and apply foam or gel. This will help to
lubricate the body and enable the shaver to glide across then skin for increased
closeness and reduced irritation.
2. Move the shaver over the skin, applying minimal pressure only as this allows the hairs
to be shaved much more quickly and cleanly. Do not press.
3. For the closest shave, shave against the direction of hair growth, or with the hair
growth, whichever is preferred, but remember that hair grows in different directions.
4. Tilt the shaver up and down whilst shaving for best results.
5. Rinse the shaver regularly whilst shaving, keeping the TRIMMER running whilst rinsing
the head for faster cleaning.

THE ALL-ROUNDER / TOOL TIPS
15
USING THE 7MM PRECISION BLADE
The 7mm precision blade is for the finishing touches on your stubble, beard,
sideburns & eyebrows.
1. Switch the trimmer on.
2. Gently move the blade through the area of hair you wish to trim.
3. To make it easier to define those finishing touches, flip the trimmer over so
that you can make it even easier working with the blade close to the skin.
4. The trimmer will work most efficiently when cutting through hair at its own
speed.
5. For increased trimming performance, press and hold the turbo button, this is
often necessary for thicker areas of hair.
6. Never switch the appliance off whilst in the hair.
USING THE ROTARY BLADE
The rotary blade has been designed for trimming those hard to reach places like
nose & ear hair. No nicks, cuts or pulling.
1. Attach the rotary trimming blade.
2. Switch the trimmer on.
3. Insert the trimmer into the nose or ear and gently move the trimmer in a
circular motion.
4. Always turn the trimmer on BEFORE you insert into your nostril or ear canal
to avoid painfully snagging hairs.
5. Never insert the trimmer more than 5-6mm into your nose or ears.
6. Never turn the trimmer off whilst in the nose and ears.

THE ALL-ROUNDER / TOOL TIPS
16
TRIMMER CLEANING &
MAINTENANCE
Because the trimmer blades are precision made for a very special use, they
should always be handled with care. To ensure long-lasting performance of your
trimmer, it is important to clean the blades + the comb guides after every use.
To remove the trimming blade, follow the instructions at CHANGING THE
ATTACHMENT HEADS.
1. First, take the cleaning brush and brush away any loose hairs that have
collected in the blades.
2. Rinse the trimming blades under running water. The comb guides can also be
rinsed separately.
3. After cleaning, make sure to shake off excess water and dry the head of the
trimming blades + comb guide before replacing onto the handle.
4. Do not disassemble the blades.
• Do not use hot water to clean the attachments.
• Dry immediately and shake off excess water, then dry with a cloth.
• Whilst the power handle is waterproof, it is recommended not to immerse
unduly in hot soapy water.
OIL FREE TRIMMING BLADES, THE WAY IT
SHOULD BE
The blades of your trimmer have a reservoir pad for releasing the
necessary amount of oil for proper operation, time after time.
Nevertheless, it is recommended that the reservoir pad be refilled
occasionally when you notice cutting performance is not as high.
To remove the trimming blade, follow the instructions at CHANGING
BETWEEN THE TRIMMING BLADE. Squeeze a few drops of oil onto the
reservoir pad (Fig. 3). Then replace the blades on the trimmer.

THE ALL-ROUNDER / TOOL TIPS
17
KEEPING YOUR FOIL SHAVER IN TIP TOP SHAPE
To remove the foil shaver head, follow the instructions at CHANGING THE
ATTACHMENT HEADS.
1. To make cleaning easier, the foil of the shaving head is removable.
2. To remove it, press the fasteners on its sides using your thumb and your index
finger and lift it up.
BE CAREFUL NOT TO PUSH ON THE FOILS, THEY ARE
DELICATE AND CAN EASILY BE DAMAGED.
3. Rinse the shaver cutter and foil frame under running water or in a sink. Do not
use hot water. Use only warm or cold water.
4. After wet cleaning, allow the foil frame and cutters to air-dry before closing
the foil frame and shaver head. The cutter can also be cleaned with a cleaning
brush.
5. Replace shaver head back onto the handle until it clicks into place. Wipe the
surface of the main unit with a dry towel. Do not dry the foil area. Let the
shaving head air-dry.
NEVER use thinners, other solvents or any harsh cleaners.
6. Once the foil shaver is dried, carefully place the protective cap on.

THE ALL-ROUNDER / TOOL TIPS
18
WORLDWIDE VOLTAGE
This appliance has a multi voltage feature for worldwide use. The voltage
automatically converts for ease of use from 100v - 240v. This appliance has an
automatic internal converter which will automatically convert the voltage without
the need of a switch. A suitable plug adaptor will be required, please refer to the
chart below.
Plug adaptor
required
Voltage and
plug adaptors
Country Voltage
setting
British plug:
240V
Ireland, Great Britain, Singapore, South America,
Hong Kong (parts only), Africa (parts only)
240V
European plug:
240V
Asia, Europe, Middle East Noumea, Scandinavia,
South America, Hong Kong (parts only)
240V
Australian and
New Zealand
plug: 240V
Australia, New Zealand 240V
American
plugs: 120V
North America, Japan, Canada
(parts of)
120V

THE ALL-ROUNDER / TOOL TIPS
19
BATTERY DISPOSAL
The All-Rounder contains a Nickel Metal-Hydride battery. To protect the
environment, the appliance must be disposed of safely at the end of its useful life.
Please take the appliance to a recycling centre, where the internal
rechargeable battery should be removed by a professional and
recycled separately.
For more information about the recycling of electrical and battery operated
appliances, please contact your local council office or your household waste
disposal service.
NI-MH

THE ALL-ROUNDER / TOOL TIPS
20
LIMITED TWO
YEAR WARRANTY
Our goods come with guarantees that cannot be excluded under the Australian
Consumer Law. You are entitled to a replacement or refund for a major failure
and for compensation for any other reasonably foreseeable loss or damage. You
are also entitled to have the goods repaired or replaced if the goods fail to be
of acceptable quality and the failure does not amount to a major failure. In New
Zealand our goods come with a guarantee that cannot be excluded under the
Consumer Guarantee Act 1993.
Conair Australia Pty Ltd. will repair or replace (at our option) your appliance free
of charge for twenty-four months from the date of purchase if the appliance is
defective in workmanship or materials.
This warranty is an additional benefit and does not affect your legal rights. To
obtain service under this warranty, please read the Warranty Leaflet included or
contact Conair Customer Service at [e-mail].
TO MAKE A WARRANTY CLAIM YOU MUST
RETAIN YOUR PROOF OF PURCHASE.
