VSETT MINI User manual

NINGBO VSETT INTELLIGENT TECHNOLOGY CO., LTD
USER MANUAL
PLEASE READ THE INSTRUCTIONS CAREFULLY BEFORE RIDING
TEMPERATURE CONTROL
NFC
DISC BRAKE
TUBELESS TYRE

GENERAL INFORMATION
VSETT RANGE-CONTROL LAYOUT,FUNCTIONS AND SPECIFICATIONS
INTELLIGENT TEMPERATURE CONTROL MANAGEMENT SYSTEM
VSETT DISPLAY OPERATION AND PROGRAMMING
EXTERNAL BATTERY INSTALLATION
ASSEMBLE THE SCOOTER
FOLDING HANDLE BARS
BATTERY AND CHARGING
PRE RIDE CHECKS
WARNING
LIMITED WARRANTY
ERROR CODES
AFTER-SALES SERVICE
1
2~3
4~5
6~14
15
16~17
18~19
20~21
22
23
24~25
26~27
28~29
· · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · ·
· · · · · · · · · · · · · ·
· · · · · · · · · · · · · · · · · ·
· · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · ·
· · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · ·
· · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · ·
· · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · ·
· · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · ·
· · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · ·
· · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · ·
· · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · ·
· · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · ·
· · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · ·
CONTENT

IMPORTANT INFORMATION
WARNING!
WHY IS IT NECESSARY TO READ THIS MANUAL BEFORE OPERATING?
This manual was written to help you undertsand the proper use and maintenance of the VSETT line of Electric Scooter.
It is important to understand the functions and features of the new VSETT before operating it as it will allow you to enjoy the most of it from the
first and every ride.
It is also important for you to note that the first trial of the VSETT should be in a remote area where obstacle are minimal to none.
The VSETT unit will require some adjustments and break-in period for all moving parts to adjust themselves into the correct position.
BEFORE RIDING: Please ensure that the folding mechanism is firmly locked in place and that the safety lock is engaged.
The product and its brand VSETT is not liable for any accidental damages related to the usage of this product.
The responsibility for VSETT maintenance is yours! Proper and frequent maintenance will reduce risks of injuries.
- ALWAYS WEAR A HELMET WHEN RIDING
- ALWAYS FOLLOW LOCAL LAWS AND REGULATIONS
- NEVER RIDE SCOOTER IN POOR VISIBILITY
- DO NOT DO STUNTS, WHEELIES or JUMPS IF YOU DO NOT HAVE THE PROPER SAFETY GEARS.
DISCLAIMER & WARNING
READ THIS MANUAL BEFORE USING
1Warning & General

2
VSETT MINI
LED SPOTLIGHT
MAX SPEED 30KM/H
DISC BRAKE
NFC KEY LOCK
FOLDING SWITCH
CONTROLLER 36V 15A
MAX RANGE SINGLE BATTERY 25KM
DUAL BATTERY 38KM
MOTOR POWER 350W
BATTERY 36V7.8AH
REAR SHOCK SPRING
REAR TUBELESS TIRE 8*2INCH
FRONT TUBELESS TIRE 8*2INCH

3TECHNICAL FEATURES VSETT MINI
VSETT MINI
Maximum load and speed may vary depending on the rider's weight, riding style and terrain.
Model
Battery
Tire
Brakes
Max Range(Single battery)
Max Range(External battery)
Max Speed
Weight
Suspension
Lights
Motor Power
Controller
Max Load
VSETT MINI
36V 7.8Ah
Tubeless Tire + Solid Tire
Disc brake
25KM
38KM
30KM/H
18KG
Front and rear double spring shock absorption
Front spotlight + Brake ligh
36V 350W Brushless Motor
36V (15A)
90KG

INTELLIGENT TEMPERATURE CONTROL MANAGEMENT SYSTEM
20S
Intelligent overheat protection
The motor controller/s fitted to your VSETT electric
scooter feature overload protection. Should the controller
temperature exceed the safety threshold, the management
system will enter a 20s protection cycle. Should you
experience a loss of power due to overload,please stop
riding and allow the controller time to cool.
4 Intelligent temperature control management system
Intelligent temperature control management system

5Intelligent temperature control management system
Intelligent temperature control management system
VSETT series electric scooter intelligent temperature control system
（A 75KG load was tested according to the summer climate in Ningbo, China）
Model
Protection temperature
（According to the local topography±5℃）
Protection time
（According to local climatic conditions±5s）
VSETT MINI
100℃
20s

Basic operation:
6 Vsett display operation and porgramming
Vsett display operation and porgramming
1、Function
1. Displayed content
Speedometer / Odometer / Trip meter / Battery level / Cruise-control active light / Gear ondocator / Fault warning light
2. All content on display(power on within 1 second)
Token IR Reader
NFC card area
+ Button/- Button
Switch button
Battery Indicator
Speed (KM/H)
External Battery Indicator

7Vsett display operation and porgramming
3.1 Speed display area
Unit：MPH, KM/H
The speed signal is taken from the Hall signal inside the motor.Sent to controller by controller(Time of single Hall period,unit:1MS).The display
calculate the true speed based on wheel diameter and signal data calculate the true speed(The motor Holzer also needs to set the number of magnetic
steel)
3.2 Vehicle power gear adjustment，ECO is Ecological mode, D is Drive mode, S is Sport mode;
3.3 vehicle status display area
High temperature warning;
Constant speed cruise hint;
The headlight turns on the prompt;
Set mode;
Vsett display operation and porgramming

8 Vsett display operation and porgramming
P00: LED brightness, level 0 is the darkest, level 7 is the brightest
P01: Mileage Unit : 0：KM；1：MILE ; default: KM
P02: Sleep time: 0, not sleep; The other numbers are sleep times,the range : 1-60; unit :minute; default : 5
P03: Limit speed:the range 0-100%, Default : 100%
P04: Zero start, non-zero start Settings, 0：zero start; 1: non-zero start; Default: 0
P06: Soft and hard start strength, the range: 1-5, 1:Weakest, 5:Strongest, Default: 3
P07: 0: Can't cruise ,1: can cruise; Automatic cruise is optional , Default: 0
P09: Binding ID card, shows ID card quantity
Vsett display operation and porgramming
To accsee this menu,long-press .Use button to scroll through P-codes, to change parameterd
Display P-Codes(programming codes)

9Vsett display operation and porgramming
2、Introduction of buttons and interfaces
2. When it is power on, long-press hold button continuously for 2s to turn off,press to change gear.
3. Long-press to enter P-code menu - refer to functions on page 18.
Enter the menu setting interface, press to increase or decrease the value, after the modification is finished;Press to switch to the next
parameterand save the value of the previous parameter;After parameter modification, long press again to exit the setting interface,
or wait for 8 seconds for automatic exit and save parameters
Vsett display operation and porgramming

10 Vsett display operation and porgramming
3、Card binding instructions
1.The instrument is not bound to ID card:
2.How to bind ID card:
After starting up, the LCD displays the normal contents. At this time, the meter can directly enter the working state.
The diagram below:
CARDS are bound by factory default
Late setting: When using mobile phone or NFC functional card binding, refer to the following methods
On the p09 interface, bring the NFC device or card close to the sensing area, and the number +1 at the bottom means the binding is successful.
Click 15 times in a row display 0. At this time, all ID CARDS that have been unbound are displayed.
Vsett display operation and porgramming

11Vsett display operation and porgramming
3. The instrument has been bound with ID card: after starting up, the LCD displays card, and the swiping indicator flashes, indicating that the card
needs to be swiped to start up. At this time, the accelerator does not work.
The diagram below:
Note:Due to the upgrade of the company's products, some of the displayed contents of the products you get may be different from the instruc-
tions, but it will not affect your normal use.
If the NFC cards are lost accidentally, you can try to contact the local agents. (each E-Scooter is equipped with 3 keys).
Vsett display operation and porgramming

12 Vsett display operation and porgramming
Vsett display operation and porgramming
Brake Displayer
NFC
Mode switch button/Turn on the light
Switch button

13Vsett display operation and porgramming
While power is on, press [4] button to turn on or off headlight.
Power On/Off
Speed Control
Headlight
Long-press the power button [3] for 2 seconds to turn on/off the scooter. then use NFC card to active it The scooter
turns off automatically if not used for 90 seconds
While stationary, and with the power on, Long-press the [3] button to cycle through the three different speed levels 1
to 3.Use the throttle to control the speed within each speed level.
Vsett display operation and porgramming

TURNING IT ON
Press the for 3 seconds and wait to be prompted for the Token (Card).
Tap the Token (Card) to the IR reader NFC
PSETTING
Press and hold both simultaneously for 5 seconds to access the P Setting interface.
CHANGING OF SPEED
Press the to toggle between increasing between ECO to S.
Function is to limit max limit, S being themax speed able to achieve.
14 Vsett display operation and porgramming
Vsett display operation and porgramming

Tighten the fixing screws on both sides
Open the dust cover
1
Make sure the battery is in place
34
Insert external battery
2
15External battery installation
External battery installation

16 Assemble the scooter
Assemble the scooter
Check whether the accessories
are complete
1
Apply screw glue to the handlebar
threads on the left
2
Tighten the left handlebar
3
After adjusting the position of the
brake lever, tighten the screw
4
Install the grip
5
Tighten the headless screw below
6

17Assemble the scooter
Assemble the scooter
Apply screw glue to the handlebar
threads on the right
7
Tighten the handlebar on the right
8
Install the accelerator clip (pay attention
to the notch direction of the clip)
9
Tighten the headless screw below
10
Tuck the wires into the handlebar
after connecting the wires
11
Install the grip
12

Folding is completed by inserting the hook into the slot
Pull the safety clip up
1
Simultaneously fold the handle bar down
34
Open the foldable buckle outwards
2
18Folding handle bar
Expand Folding
