Vulcan-hart 148l Manual

MODEL

24L ML-52947

36L/LC ML-52948

48L ML-52949

481L/LC ML-52950

148L/LC ML-52951

60L/LC/LCC ML-52952

160L/LC ML-52953

260L/LC/LCC ML-52954

CATALOGOF

REPLACEMENTPARTS

GAS RESTAURANT RANGE

MODELS 24L, 36L/LC, 48L, 481L/LC,

148L/LC, 60 L/LC/LCC, 160L/LC, 260L/LC/LCC

For additional information on Vulcan-Hart or to locate an authorized

partsandserviceproviderinyourarea,visitourwebsiteatwww.vulcanhart.com

VULCAN-HART

DIVISION OF ITW FOOD EQUIPMENT GROUP, LLC

WWW.VULCANHART.COM

P.O. BOX 696, LOUISVILLE, KY 40201-0696

TEL. (800) 814-2028

F-30536 Rev. C (May 2006)

- 2 -

GASRESTAURANTRANGEREPLACEMENTPARTS

F-30536 Rev. C (May 2006)

PRODUCTIDENTIFICATIONCODE

L= STANDARD OVEN

LC= (1) STANDARDOVEN/(1)CONVECTIONOVEN

LCC = 2 CONVECTION OVENS

*TOPCONFIGURATIONSVARY

MODEL

*WIDTH

(INCHES) OVEN DESCRIPTION

24L 24 (1) STD. OVEN

48L 48 (2) STD. OVENS

481L 48 (1) STD. OVEN

481LC 48 (1) CONVECTION OVEN

148L 48 (1) STD. OVEN

148LC 48 (1) CONVECTION OVEN

36L 36 (1) STD. OVEN

36LC 36 (1) CONVECTION OVEN

60L 60 (2) STD. OVEN

60LC 60 (1) STD. OVEN &

(1) CONVECTION OVEN

60LCC 60 (2) CONVECTION OVENS

160L 60 (1) STD. OVEN

160LC 60 (1) CONVECTION OVEN

260L 60 (2) STD. OVENS

260LC 60 (1) STD. OVEN &

(1) CONVECTION OVEN

260LCC 60 (2) CONVECTION OVENS

- 3 -

GASRESTAURANT RANGE REPLACEMENT PARTS

F-30536 Rev. C (May 2006)

OVEN RACKS

ILLUS. PART NO. NAME OF PART AMT.

PL-56796

1 00-415430-00003 Support – Rack Assy. (RH) (Conv. Oven) ............................................................................... AR

2 00-413991-00002 Rack – Oven (Conv. Oven) (Shown) ...................................................................................... AR

3 00-413300-00001 Rack – Oven (Std. Oven)

(36L, 148L, 481L, 60L/LC, 160L, & 260L/LC) ......................................................................... AR

4 00-417248-00001 Rack – Oven (Std. Oven) (24L & 48L) .................................................................................... AR

5 00-415430-00004 Support – Rack Assy. (LH) (Conv. Oven) ............................................................................... AR

00-417632-00001 Rack – Broiler-Griddle .............................................................................................................. AR

- 4 -

GASRESTAURANTRANGEREPLACEMENTPARTS

F-30536 Rev. C (May 2006)

OVEN BODY

ILLUS. PART NO. NAME OF PART AMT.

PL-56746C

*1 00-417330-00001 Back Splash (24 In. High, SST) (24L) ...................................................................................... AR

2 00-417335-00001 Back Splash (12 In. High, SST) (24L) ...................................................................................... AR

*3 00-417331-00001 Back Splash (24 In. High, SST) (36L/LC)................................................................................. AR

4 00-417336-00001 Back Splash (12 In. High, SST) (36L/LC)................................................................................. AR

*5 00-417337-00001 Back Splash (24 In. High, SST) (48L & 481L/LC) .................................................................... AR

6 00-417332-00001 Back Splash (12 In. High, SST) (48L & 481L/LC) .................................................................... AR

*7 00-417329-00001 Back Splash (24 In. High, SST) (148L/LC)............................................................................... AR

8 00-417348-00001 Back Splash (12 In. High, SST) (148L/LC)............................................................................... AR

- 5 -

GASRESTAURANT RANGE REPLACEMENT PARTS

F-30536 Rev. C (May 2006)

OVEN BODY (Cont.)

ILLUS. PART NO. NAME OF PART AMT.

PL-56746C

9 00-417333-00001 Back Splash (24 In. High, SST) (60L/LC/LCC & 160L/LC) ....................................................... AR

10 00-417338-00001 Back Splash (12 In. High, SST) (60L/LC/LCC & 160L/LC) ....................................................... AR

*11 00-417334-00001 Back Splash (24 In. High, SST) (260L/LC/LCC) ....................................................................... AR

12 00-417339-00001 Back Splash (12 In. High, SST) (260L/LC/LCC) ....................................................................... AR

13 00-418760-000G1 Low Riser Assy. 11 In. (S.S.) (for 36” Unit) ............................................................................ AR

14 SC-121-26 Mach. Screw 1/4-20 x 25/16 Rd. Hd. (Used for Shelf Mounting)..................................................4

15 NS-044-14 Nut1/4-20Hex KEPS ................................................................................................................. AR

16 00-417243-000G1 Shelf (SST) (24L) (Shown) ..................................................................................................... AR

17 00-417244-000G1 Shelf (SST) 36 In. ..................................................................................................................... AR

18 00-417245-000G1 Shelf (SST) (48L, 148L/LC, & 481L/LC) .................................................................................. AR

19 00-417246-000G1 Shelf (SST) (60L/LC/LCC, 160L/LC, & 260L/LC/LCC) ............................................................. AR

20 SD-032-07 Self-Tapping Screw 10-24 x 1/2Hex Washer Hd., Type TT .................................................... AR

21 00-417252-00001 Channel – Bayonet (Used With Items 1 thru 25) ..................................................................... AR

22 00-417212-00003 Side Body (SST) RH/LH ...........................................................................................................AR

23 00-417595-00001 Panel – Manifold Cover (24L) .................................................................................................. AR

24 00-417596-00001 Panel – Manifold Cover (36L & 160L)...................................................................................... AR

25 00-417624-00001 Panel – Manifold Cover (36L W/Griddle) ................................................................................. AR

26 00-417597-00001 Panel – Manifold Cover (36L & 160LC) ................................................................................... AR

27 00-417628-00001 Panel – Manifold Cover (36LC W/Griddle) ............................................................................... AR

28 00-417603-00001 Panel – Manifold Cover (48L) .................................................................................................. AR

29 00-417591-00001 Panel – Manifold Cover (48L W/Griddle) ................................................................................. AR

30 00-417588-00001 Panel – Manifold Cover (148LC) .............................................................................................. AR

31 00-417601-00001 Panel – Manifold Cover (481L) ................................................................................................ AR

32 00-417589-00001 Panel – Manifold Cover (481L W/Griddle) ............................................................................... AR

33 00-417602-00001 Panel – Manifold Cover (481LC) .............................................................................................. AR

34 00-417590-00001 Panel – Manifold Cover (481LC W/Griddle) ............................................................................. AR

35 00-417604-00001 Panel – Manifold Cover (60L) .................................................................................................. AR

36 00-417592-00001 Panel – Manifold Cover (60L W/Griddle) ................................................................................. AR

37 00-417605-00001 Panel – Manifold Cover (60LC) ................................................................................................ AR

38 00-417593-00001 Panel – Manifold Cover (60LC W/Griddle) ............................................................................... AR

39 00-417606-00001 Panel – Manifold Cover (60LCC).............................................................................................. AR

40 00-417594-00001 Panel – Manifold Cover (60LCC W/Griddle)............................................................................. AR

41 00-417598-00001 Panel – Manifold Cover (260L) ................................................................................................ AR

42 00-417599-00001 Panel – Manifold Cover (260LC) .............................................................................................. AR

43 00-417600-00001 Panel – Manifold Cover (260LCC)............................................................................................ AR

44 00-417206-00001 Drip Pan (12 In.)........................................................................................................................ AR

45 00-417631-00001 Drip Pan (24 In.)........................................................................................................................ AR

46 00-417229-00001 Drip Pan (36 In.)........................................................................................................................ AR

47 00-414370-00001 Oven Access Plate, Convection Oven Standing Pilot Only ..................................................... AR

48 NS-047-28 Lock Nut 3/16 Stud Special.......................................................................................................... AR

49 00-417700-00001 Plate – Logo.............................................................................................................................. AR

50 00-425246-00001 Leg – Flanged 6 In.................................................................................................................... AR

*Shelf Mounting Holes Provided.

- 6 -

GASRESTAURANTRANGEREPLACEMENTPARTS

F-30536 Rev. C (May 2006)

OVEN BODY AND DOOR

ILLUS. PART NO. NAME OF PART AMT.

PL-56747C

1 00-417340-00001 Shield – Heat (27 In. High) (24L).............................................................................................. AR

2 00-417344-00001 Shield – Heat (143/4In. High) (24L)........................................................................................... AR

3 00-417341-00001 Shield – Heat (27 In. High) (36L/LC) ........................................................................................ AR

4 00-417345-00001 Shield – Heat (143/4In. High) (36L/LC) ..................................................................................... AR

5 00-417342-00001 Shield – Heat (27 In. High) (48L, 148L/LC, & 481L/LC) ........................................................... AR

6 00-417346-00001 Shield – Heat (143/4In. High) (48L, 148L/LC, & 481L/LC)........................................................ AR

7 00-417343-00001 Shield – Heat (27 In. High) (60L/LC/LCC, 160L/LC, & 260L/LC/LCC)...................................... AR

- 7 -

GASRESTAURANT RANGE REPLACEMENT PARTS

F-30536 Rev. C (May 2006)

OVEN BODY AND DOOR (Cont.)

ILLUS. PART NO. NAME OF PART AMT.

PL-56747C

8 00-417347-00001 Shield – Heat (143/4In. High) (60L/LC/LCC, 160L/LC, & 260L/LC/LCC)................................... AR

9 00-405016-00001 Cord – Electric Supply (120 V.) (Conv. Oven) ........................................................................ AR

10 00-417379-000G1 Front Top Assy. (36L) .............................................................................................................. AR

11 00-422012-000G4 Front Top Assy. (60L) .............................................................................................................. AR

12 00-421945-000G1 Door Assy. (PTD) (24 In. Std. Oven) ........................................................................................ AR

13 00-421945-00G17 Door Assy. (SST) (24 In. Std. Oven) ....................................................................................... AR

14 00-421945-000G3 Door Assy. (PTD) (36 In. Std. Oven) ........................................................................................ AR

15 00-421945-00G40 Door Assy. (SST) (36 In. Std. Oven) ....................................................................................... AR

16 00-421945-000G6 Door Assy. (SST) (36 In. Conv. Oven) .................................................................................... AR

17 00-421945-000G7 Door Assy. (PTD) (30 In. Std. Oven) ........................................................................................ AR

18 00-421945-00G27 Door Assy. (SST) (30 In. Std. Oven) ....................................................................................... AR

19 00-421945-00G10 Door Assy. (SST) (30 In. Conv. Oven) .................................................................................... AR

20 00-421950-00002 Post – Door Handle (RH) .......................................................................................................... AR

21 00-421950-00001 Post – Door Handle (LH) .......................................................................................................... AR

22 00-425091-00001 Insert (25 In.) (Red).................................................................................................................. AR

23 00-425091-00002 Insert (30 In.) (Red).................................................................................................................. AR

24 00-425091-00003 Insert (36 In.) (Red).................................................................................................................. AR

25 00-419765-00005 Handle – Oven Door (24 In.) .................................................................................................... AR

26 00-419765-00006 Handle – Oven Door (30 In.) .................................................................................................... AR

27 00-419765-00004 Handle – Oven Door (36 In.) .................................................................................................... AR

28 00-414976-00001 Block – Trunion (Std. Oven) .....................................................................................................AR

29 00-417461-00001 Block – Trunion (Conv. Oven).................................................................................................. AR

30 00-413785-00001 Stud – Trunion Block ................................................................................................................ AR

31 00-414370-00001 Burner Closure Entry (Behind Kick Panel) (Standing Pilot Convection Oven) ........................ AR

32 00-417865-00001 Turnbuckle (36L/LC, 60L/LC/LCC, 160L/LC, 148L/LCC, 481L/LC, & 260L/LC/LCC)............... AR

33 00-412014-00001 Spring W/Swivel Hook (24L & 48L) ......................................................................................... AR

34 00-404053-00001 Spring – Oven Door (36L/LC, 148L/LC, 481L/LC, & 160L/LC) ................................................ AR

35 00-413342-00001 Spring – Oven Door (60L/LC/LCC & 260L/LC/LCC)................................................................. AR

36 00-417367-00001 Bracket – Spring (24L & 48L) .................................................................................................. AR

37 NS-047-73 Lock Nut 5/16-18 Hex ................................................................................................................. AR

38 00-417366-00001 Bolt – J 1/4-20 (24L & 48L) ........................................................................................................ AR

39 00-403956-00001 Crank – Bell .............................................................................................................................. AR

40 PC-003-34 Cotter Pin 3/32 x 3/4...................................................................................................................... AR

41 00-403971-00001 Pin– Bell Crank......................................................................................................................... AR

42 00-413381-00001 Hook – Bell Crank (RH)............................................................................................................. AR

43 00-413381-00002 Hook – Bell Crank (LH) ............................................................................................................. AR

44 00-411928-00001 Cover – Lighter Hole (Std. Oven)............................................................................................. AR

45 00-421115-000G1 Kick Panel Assy. (24L) ............................................................................................................. AR

46 00-428195-000G1 Kick Panel Assy. (36L/LC, 148L/LC, & 160L/LC)..................................................................... AR

47 00-421117-000G1 Kick Panel Assy. (48L) ............................................................................................................. AR

48 00-421118-000G1 Kick Panel Assy. (60L/LC/LCC & 260L/LC/LCC) (Std. Oven) .................................................. AR

49 00-426242-000G1 Kick Panel Assy. (60L/LC/LCC) (Conv. Oven) ......................................................................... AR

50 00-425218-000G1 Bottom – Perforated (Service Only) ........................................................................................ AR

51 00-425219-00001 Bottom – Solid (Service Only).................................................................................................. AR

52 00-417235-00001 Bottom – Solid (Gas) ................................................................................................................ AR

53 00-414380-00002 Bottom – Oven (Conv. Oven) (Not Shown)............................................................................. AR

54 00-413371-00001 Clip – Spring (Kick Panel) ......................................................................................................... AR

55 00-417362-00001 Retainer – Kick Panel ............................................................................................................... AR

56 00-410118-00021 Caster W/Brake ........................................................................................................................ AR

57 00-410118-00020 Caster ....................................................................................................................................... AR

58 00-417426-00001 Gasket – Oven Door (Conv. Oven & Both Ovens on 60LC & 260LC) .................................... AR

59 00-426260-00001 Gasket – Door (W/Spark Ignition) (30 In. & 36 In.)................................................................... AR

60 00-413112-00001 Leg 6 In. (PTD).......................................................................................................................... AR

61 00-413112-00012 Leg 6 In. (SST) ......................................................................................................................... AR

62 00-406734-00001 Box – Jct. (Octagon) (Conv. Oven) ......................................................................................... AR

63 00-406734-00002 Cover – Junction Box (Conv. Oven) ........................................................................................ AR

64 00-414479-00001 Bar – Bumper (Conv. Oven) .................................................................................................... AR

00-404092-00004 Insulation .................................................................................................................................. AR

00-413228-00001 Baffle........................................................................................................................................ AR

00-417853-00002 Nut – Door Post 1/4-20............................................................................................................... AR

SC-122-19 Bolt – Door Post........................................................................................................................ AR

00-426276-1 Oven Burner Closure for Spark Convection Ovens................................................................ AR

- 8 -

GASRESTAURANTRANGEREPLACEMENTPARTS

F-30536 Rev. C (May 2006)

GAS MANIFOLD AND TUBING

ILLUS. PART NO. NAME OF PART AMT.

PL-56748

1 00-417279-00001 Manifold (24L) .......................................................................................................................... AR

2 00-417281-00001 Manifold (48L & 481L/LC) ........................................................................................................AR

3 00-417280-00001 Manifold (36L/LC)..................................................................................................................... AR

4 00-417273-00001 Manifold (148L/LC)................................................................................................................... AR

5 00-417282-00001 Manifold(60L/LC/LCC) ............................................................................................................. AR

6 00-417278-00001 Manifold (160L/LC)................................................................................................................... AR

7 00-417283-00001 Manifold(260L/LC/LCC) ........................................................................................................... AR

8 00-415677-00001 Clip– Capillary .......................................................................................................................... AR

9 00-417490-00001 Dial – Thermostat (Fahrenheit) (Conv. Oven) ......................................................................... AR

10 00-417490-00002 Dial – Thermostat (Centigrade) (Conv. Oven) (Red) ............................................................... AR

11 00-413976-00001 Dial – Thermostat (Centigrade) (Black) ................................................................................... AR

12 00-411506-00011 Thermostat (KXT) (Conv. Oven) .............................................................................................. AR

13 00-420786-00001 Valve – Pilot (Dual) (Open Top)................................................................................................ AR

14 00-417576-00001 Dial – Control (Std. Oven)......................................................................................................... AR

15 00-417424-000G1 Thermostat (BJWA) (Std. Oven).............................................................................................. AR

16 00-417576-00002 Thermostat (Dial) (T Model) .....................................................................................................AR

17 00-417424-000G2 Thermostat (Fahrenheit) (60T Model)...................................................................................... AR

18 00-415677-00001 Clip– Capillary .......................................................................................................................... AR

19 FP-086-43 Fitting – Tube 7/16 x 1/4FPT Brass Elbow 90 Deg...................................................................... AR

- 9 -

GASRESTAURANT RANGE REPLACEMENT PARTS

F-30536 Rev. C (May 2006)

GAS MANIFOLD AND TUBING (Cont.)

ILLUS. PART NO. NAME OF PART AMT.

PL-56748

20 00-421949-00002 Knob – Control (Open & Hot Top) (Black) (Service Open Only) ............................................. AR

21 00-426745-00001 Knob – Control (Ergonomic) (Black) ........................................................................................ AR

22 00-420560-00001 Knob – Gas Valve (Red) ..........................................................................................................AR

23 00-412787-00001 Pilot – Oven (Nat.) .................................................................................................................... AR

24 00-426233-00001 Pilot – Spark Oven .................................................................................................................... AR

25 00-412787-00002 Pilot – Oven (L.P.) ..................................................................................................................... AR

26 00-426233-00002 Pilot – Spark Ignition (Propane) ................................................................................................AR

27 00-417455-00001 Tubing – LH Supply to Elbow (LCC Units) ............................................................................... AR

28 00-414543-00001 Tube – Pilot to Safety (Conv. Oven) ........................................................................................ AR

29 00-417499-00001 Tube – Pilot to Safety (Std. Oven) ........................................................................................... AR

30 00-417499-00002 Tube – Pilot to Safety (24L & 48L)........................................................................................... AR

31 00-412788-00001 Thermocouple (for TS11 Prior to September 2004) ................................................................ AR

00-412788-00003 Thermocouple (September 2004 to Present) .......................................................................... AR

32 00-415486-00001 Insulator – Microswitch (Conv. Oven)..................................................................................... AR

33 00-411496-000F1 Switch – Microswitch (Door) (Conv. Oven)............................................................................ AR

34 00-413370-00005 Tubing – Safety to Nozzle (24L & 48L) ................................................................................... AR

35 00-413370-00001 Tubing – Safety to Nozzle (Std. Oven).................................................................................... AR

36 00-413370-00003 Tubing – Safety to Nozzle (Conv. Oven)................................................................................. AR

37 FP-085-42 Fitting – Tube (7/16 Tube to 3/8MPT) ........................................................................................... AR

38 00-411497-000F2 Solenoid – Gas Valve (240 V.) (Conv. Oven) ......................................................................... AR

39 00-428067-000G1 Solenoid – Gas Valve (120 V.) (Conv. Oven) ......................................................................... AR

40 00-426252-00001 Solenoid – Valve (24 V.) (Spark Ignition) ................................................................................. AR

41 00-407789-00003 Valve – Service ........................................................................................................................ AR

42 00-402957-00002 Handle – Gas Cock (Red) ........................................................................................................ AR

43 FP-086-07 Fitting – Tube (7/16 Tube to 3/8FPT)............................................................................................ AR

44 00-414454-00001 Tubing – Safety to Valve.......................................................................................................... AR

45 00-405569-00002 Pilot – Auto (Safety Shutoff) (Prior to September 2004) (TS11)............................................. AR

00-720719 Pilot – Auto (Safety Shutoff) (September 2004 to Present) (BASO) ..................................... AR

46 00-405569-00003 Sleeve – Breakaway 1/4(Use With Item 45) ............................................................................ AR

47 00-405569-00004 Sleeve – Breakaway 7/16 (Use With Item 45) ........................................................................... AR

48 00-413332-00001 Tubing – Pilot (Tee to Right Safety) (60L/LC/LCC & 260L/LC/LCC) ........................................ AR

49 00-417406-00001 Tubing – Pilot (Tee to Right Safety) (48L)................................................................................ AR

50 FP-019-08 Connector – Tee (1/4Tube) ....................................................................................................... AR

51 00-413331-00001 Tubing – Pilot (Tee to Left Safety) ........................................................................................... AR

52 00-404079-0000F Nozzle – Oven Burner ............................................................................................................. AR

53 00-010901-00036 Orifice – Spud (Nat.) (Sea Level to 2000 Ft.) (Conv. Oven) ................................................... AR

54 00-010901-00039 Orifice – Spud (Nat.) (2000 to 4000 Ft.) (Conv. Oven) ........................................................... AR

55 00-010901-00040 Orifice – Spud (Nat.) (4000 to 6000 Ft.) (Conv. Oven) ........................................................... AR

56 00-010901-00041 Orifice – Spud (Nat.) (6000 to 8000 Ft.) (Conv. Oven) ........................................................... AR

57 00-010901-00052 Orifice – Spud (L.P.) (Sea Level to 2000 Ft.) (Conv. Oven).................................................... AR

58 00-010901-00053 Orifice – Spud (L.P.) (2000 to 4000 Ft.) (Conv. Oven) ............................................................ AR

59 00-010901-00054 Orifice – Spud (L.P.) (4000 to 6000 Ft.) (Conv. Oven) ............................................................ AR

60 00-010901-00055 Orifice – Spud (L.P.) (6000 to 8000 Ft.) (Conv. Oven) ............................................................ AR

61 00-010901-00053 Orifice – Spud (Butane) (Conv. Oven) .................................................................................... AR

62 00-413225-000G1 Burner Assy. – Oven ............................................................................................................... AR

63 00-417414-00001 Tubing – Pilot (Pilot Elbow to Safety) (Single Oven) ............................................................... AR

64 00-417371-00001 Tubing – Pilot (Pilot Elbow to Tee) (Double Oven) ................................................................... AR

65 00-417419-00001 Tubing – Burner (Safety to Fitting) .......................................................................................... AR

66 FP-085-97 Fitting – Tube 7/16 x 7/16 Brass Elbow 90 Deg. ........................................................................... AR

67 00-417455-00001 Tubing – LH Supply to Elbow (LC Units) ................................................................................. AR

68 FP-085-42 Fitting – Tube (7/16 Tube to 3/8MPT) ........................................................................................... AR

69 FP-078-86 Street Elbow 3/4x 90 Deg. ........................................................................................................ AR

70 FP-019-26 Tee 3/4x 3/4x 3/4.......................................................................................................................... AR

71 FP-085-01 Pipe 3/4x 1 Close ......................................................................................................................AR

72 00-408279-00020 Regulator – Pressure (Nat.).....................................................................................................AR

73 00-408279-00021 Regluator – Pressure (L.P. & Butane) ..................................................................................... AR

74 00-408279-00005 Regulator (Nat.) 60/72.............................................................................................................. AR

75 00-408279-00006 Regulator (L.P.) 60/72 .............................................................................................................. AR

76 FP-019-26 Tee 3/4x 3/4x 3/4.......................................................................................................................... AR

77 FP-085-01 Pipe 3/4x 1 Close ......................................................................................................................AR

78 FP-013-22 Elbow 3/4x 90 Deg.................................................................................................................... AR

79 FP-026-17 Bushing 3/4to 3/8(RED).............................................................................................................. AR

- 10 -

GASRESTAURANTRANGEREPLACEMENTPARTS

F-30536 Rev. C (May 2006)

GAS MANIFOLD AND TUBING (Cont.)

ILLUS. PART NO. NAME OF PART AMT.

PL-56748

80 FP-085-42 Fitting – Tube (7/16 Tube to 3/8MPT) ........................................................................................... AR

81 00-047456-00001 Tubing – Right Supply to Elbow (LCC Units) ........................................................................... AR

00-417449-000G1 Cable – Oven Control (LH) (Standing Pilot Convection Ovens Only)...................................... AR

00-420795-000G1 Cable – Oven Control (Short) (Standing Pilot Convection Ovens Only) ................................. AR

00-420796-000G1 Cable – Oven Control (Long) (Standing Pilot Convection Ovens Only) .................................. AR

00-417576-00001 Dial – T-Stat Sub-Assy. (Red Dial) ........................................................................................... AR

00-417576-00005 Dial – T-Stat Sub-Assy. (Black Dial) ......................................................................................... AR

00-542155 Sleeving – T-State Plastic Insulation (NS) ................................................................................ AR

00-417980-00001 IgnitionModule .......................................................................................................................... AR

00-425955-00001 Transformer ............................................................................................................................. AR

FE-023-65 Fuse.......................................................................................................................................... AR

00-425535-00001 Fuse Holder .............................................................................................................................. AR

00-428149-00001 Spark Module Cover ................................................................................................................. AR

- 11 -

GASRESTAURANT RANGE REPLACEMENT PARTS

F-30536 Rev. C (May 2006)

GAS BURNERS

- 12 -

GASRESTAURANTRANGEREPLACEMENTPARTS

F-30536 Rev. C (May 2006)

GAS BURNERS

ILLUS. PART NO. NAME OF PART AMT.

PL-56749C

1 00-417260-000G1 Venturi – Rear .......................................................................................................................... AR

2 00-413302-00001 Clip–PilotMounting .................................................................................................................. AR

3 00-417608-00002 Head – Burner (12 In.) (Open Top) .......................................................................................... AR

4 00-417256-00002 Grate......................................................................................................................................... AR

5 00-417370-00001 Casting – Hot Top (Not Shown) ............................................................................................... AR

6 00-417234-00001 Support – Grate........................................................................................................................ AR

7 00-421652-00001 Grate – Top (VG Only) ............................................................................................................. AR

8 00-421629-000G2 Casting – Open Top (Porcelain) ............................................................................................... AR

9 00-412063-00002 Tip–Pilot .................................................................................................................................. AR

10 FP-047-14 Fitting – 3/16 Compression Nut ................................................................................................... AR

11 FP-077-23 Fitting – Tube 1/2Compression ................................................................................................. AR

12 00-428112-000G1 Tube – Pilot Rear (Open Top) ................................................................................................... AR

13 00-428111-000G1 Tube – Pilot Front (Open Top) .................................................................................................. AR

14 00-417258-000G1 Venturi – Front.......................................................................................................................... AR

15 00-404060-00001 Mixer – Air (12 In. Open Top) ...................................................................................................AR

16 SD-035-59 Self-Tapping Screw 10-24 x 3/8Slotted Pan Hd., Type F ........................................................ AR

17 00-411496-000B1 Switch – Rocker (Conv. Oven On-Off) .................................................................................. AR

18 00-411496-000E8 Indicator Light – Oven (Conv. Oven) ....................................................................................... AR

19 00-426745-00001 Knob – Black Ergonomic (Open & Hot Top Gas Valve) ........................................................... AR

20 00-404076 Valve – Burner ......................................................................................................................... AR

21 00-418051-0000F Hood, Orifice ............................................................................................................................ AR

22 00-010901-00041 Orifice – Spud (Nat.) (Sea Level to 2000 Ft.) (Open) ............................................................. AR

23 00-010901-00042 Orifice – Spud (Nat.) (2000 to 4000 Ft.) (Open) ..................................................................... AR

24 00-010901-00043 Orifice – Spud (Nat.) (4000 to 6000 Ft.) (Open) ..................................................................... AR

25 00-010901-00044 Orifice – Spud (Nat.) (6000 to 8000 Ft.) (Open) ..................................................................... AR

26 00-010901-00053 Orifice – Spud (L.P.) (Sea Level to 4000 Ft.) (Open) .............................................................. AR

27 00-010901-00054 Orifice – Spud (L.P.) (4000 to 6000 Ft.) (Open) ...................................................................... AR

28 00-010901-00055 Orifice – Spud (L.P.) (6000 to 8000 Ft.) (Open) ...................................................................... AR

*29 00-010901-00048 Orifice – Spud (Nat.) (Sea Level to 2000 Ft.) (Std. Griddle) ................................................... AR

*30 00-010901-00049 Orifice – Spud (Nat.) (2000 to 4000 Ft.) (Std. Griddle)............................................................ AR

*31 00-010901-00050 Orifice – Spud (Nat.) (4000 to 6000 Ft.) (Std Griddle)............................................................. AR

*32 00-010901-00051 Orifice – Spud (Nat.) (6000 to 8000 Ft.) (Std. Griddle)............................................................ AR

*33 00-010901-00057 Orifice – Spud (L.P.) (Sea Level to 2000 Ft.) (Std. Griddle) .................................................... AR

*34 00-010901-00058 Orifice – Spud (L.P.) (2000 to 4000 Ft.) (Std. Griddle) ............................................................ AR

*35 00-010901-00060 Orifice – Spud (L.P.) (4000 to 6000 Ft.) (Std. Griddle) ............................................................ AR

*36 00-010901-00063 Orifice – Spud (L.P.) (6000 to 8000 Ft.) (Std. Griddle) ............................................................ AR

37 00-404038-00002 Valve – Pilot 3/16 (Griddle).......................................................................................................... AR

38 00-417389-00001 Tubing – Manifold to Elbow (1/4Dia.) ........................................................................................ AR

39 00-417420-00001 Tubing – Burner (Fitting to RH Thermostat) (260L & 260LC) .................................................. AR

40 00-417423-00001 Tubing – Burner (Fitting to LH Thermostat) (Std. Oven) ......................................................... AR

41 00-417422-00001 Tubing – Burner (Fitting to RH Thermostat) (60L & 60LC) ...................................................... AR

42 FP-086-07 Fitting ........................................................................................................................................ AR

43 FP-047-24 Fitting – Tube 1/4x 1/4Brass Elbow 90 Deg. ............................................................................. AR

44 FP-085-42 Fitting – Safety Valve (7/16 Tube) .............................................................................................. AR

45 00-404079-0000F Nozzle – Oven Burner ............................................................................................................. AR

46 00-010901-00032 Orifice – Spud (Nat.) (Sea Level to 2000 Ft.) (Std. Oven) ...................................................... AR

47 00-010901-00035 Orifice – Spud (Nat.) (2000 to 4000 Ft. (Std. Oven)................................................................ AR

48 00-010901-00036 Orifice – Spud (Nat.) (4000 to 8000 Ft.) (Conv. Oven) ........................................................... AR

49 00-010901-00051 Orifice – Spud (Sea Level to 2000 Ft.) (Std. Oven) ................................................................ AR

50 00-010901-00052 Orifice – Spud (L.P.) (2000 to 4000 Ft.) (Std. Oven) ............................................................... AR

51 00-010901-00053 Orifice – Spud (L.P.) (4000 to 6000 Ft.) (Std. Oven) ............................................................... AR

52 00-010901-00054 Orifice – Spud (L.P.) (6000 to 8000 Ft.) (Std. Oven) ............................................................... AR

53 00-010901-00052 Orifice – Spud (Butane) (Std. Oven) ....................................................................................... AR

54 00-414343-00001 Bracket – Door Switch (LH) .................................................................................................... AR

55 00-414343-00002 Bracket – Door Switch (RH) .................................................................................................... AR

FP-085-53 Plug – Pipe 1/8-27 (Use to Plug Manifold).................................................................................. AR

FP-079-20 Plug – Manifold 9/16-27 NPT (Conv. Oven) ................................................................................ AR

00-413302-00001 PilotClip

00-411496-00E21 Indicator Light, ON/Ready (Convection Oven)

00-417234-00001 Support Rail for Grates

*Griddle Without Thermostat Control (Refer to Page 16 for Burner Valve

Used on Griddle with Thermostat.)

- 13 -

GASRESTAURANT RANGE REPLACEMENT PARTS

F-30536 Rev. C (May 2006)

CONVECTION OVEN VENT MOTOR

- 14 -

GASRESTAURANTRANGEREPLACEMENTPARTS

F-30536 Rev. C (May 2006)

CONVECTION OVEN VENT MOTOR

ILLUS. PART NO. NAME OF PART AMT.

PL-56750

1 00-413990-000G4 Cover – Fan.............................................................................................................................. AR

2 SC-111-03 Mach. Screw 1/4-20 x 3 Rd. Hd. ............................................................................................... AR

3 00-411289-00003 Spacer – Pipe 1/4I.D. x 25/16 Lg.................................................................................................. AR

4 00-415780-00008 Wheel – Blower (7 In. Dia.) (Incls. Set Screws)..................................................................... AR

5 00-413987-00001 Mount – Motor........................................................................................................................... AR

6 00-414367-00001 Insulator – Motor (970 Paper) .................................................................................................. AR

7 00-419730-00001 Motor (1/4Hp., 115 V.) ............................................................................................................... AR

8 00-419730-00002 Motor (1/4Hp., 240 V.)............................................................................................................... AR

9 00-414368-00002 Insulator – Rear Closure (970 Paper)...................................................................................... AR

10 SC-120-14 Mach. Screw 1/4-20 x 2 Flat Hd................................................................................................ AR

11 NS-044-14 Nut 1/4-20 Hex KEPS ................................................................................................................. AR

12 00-413627-000G2 Tube Assy. – Snorkel ............................................................................................................... AR

13 00-413588-000G2 Vent Assy. ................................................................................................................................AR

00-414413-00001 Cover – Controls ...................................................................................................................... AR

00-414001-00002 Deflector – Air .......................................................................................................................... AR

00-412630-00002 Spacer 11/16 Dia. x 11/16 Lg........................................................................................................... AR

00-412630-00003 Spacer 1/4Dia. x 5/8Lg............................................................................................................... AR

00-419719-00002 Bracket – Motor Mount ............................................................................................................ AR

- 15 -

GASRESTAURANT RANGE REPLACEMENT PARTS

F-30536 Rev. C (May 2006)

GRIDDLE

- 16 -

GASRESTAURANTRANGEREPLACEMENTPARTS

F-30536 Rev. C (May 2006)

GRIDDLE

ILLUS. PART NO. NAME OF PART AMT.

PL-56751C

1 00-358783-00041 Griddle Assy. (12 In.) (Chrome Plated, Special Order) ............................................................ AR

2 00-418861-000G1 Griddle Assy. (12 In.) ............................................................................................................... AR

3 00-418862-000G1 Griddle Assy. (24 In.) ............................................................................................................... AR

4 00-418863-000G1 Griddle Assy. (36 In.) ............................................................................................................... AR

5 00-418864-000G1 Griddle Assy. (48 In.) ............................................................................................................... AR

6 00-419229-000G1 Trough Assy. – Grease (Broiler-Griddle) ................................................................................ AR

7 00-419227-00001 Baffle – Grease Trough ........................................................................................................... AR

8 00-426745-00001 Knob – Control (Griddle & Broiler-Griddle) .............................................................................. AR

9 00-404076 Valve – Burner ......................................................................................................................... AR

10 00-418051-0000F Hood, Orifice ............................................................................................................................ AR

11 00-010901-00048 Orifice – Spud (Nat.) (Sea Level to 2000 Ft.) (Broiler-Griddle)............................................... AR

12 00-010901-00049 Orifice – Spud (Nat.) (2000 to 6000 Ft.) (Broiler-Griddle)....................................................... AR

13 00-010901-00050 Orifice – Spud (Nat.) (6000 to 8000 Ft.) (Broiler-Griddle)....................................................... AR

14 00-010901-00056 Orifice – Spud (L.P.) (Sea Level to 2000 Ft.) (Broiler-Griddle) ............................................... AR

15 00-010901-00057 Orifice – Spud (L.P.) (2000 to 4000 Ft.) (Broiler-Griddle) ....................................................... AR

16 00-010901-00058 Orifice – Spud (L.P.) (4000 to 6000 Ft.) (Broiler-Griddle) ....................................................... AR

17 00-010901-00059 Orifice – Spud (L.P.) (6000 to 8000 Ft.) (Broiler-Griddle) ....................................................... AR

18 00-404193-00001 Valve – Pilot (Hot Top) .............................................................................................................. AR

19 00-417663-00001 Cover – Manifold (Broiler-Griddle) ........................................................................................... AR

20 00-417576-00002 Dial (Griddle W/Thermostat).....................................................................................................AR

21 00-410662-000G1 Tube Assy. – Pilot Lighter (Broiler-Griddle) ............................................................................. AR

22 00-425882-000G1 Brick Set (12 In. Section) (Griddle & Hot Top) ......................................................................... AR

23 00-412063-00002 Tip–Pilot .................................................................................................................................. AR

24 FP-047-14 Fitting – 3/16 Compression Nut ................................................................................................... AR

25 00-428414-000G1 Tube – Pilot (Hot Top & W/O Thermostat) ................................................................................ AR

26 00-428414-000G2 Tube – Pilot (W/Thermostat) .................................................................................................... AR

27 00-404738-00002 Valve – Pilot 3/16 (Griddle).......................................................................................................... AR

28 FP-077-23 Fitting – Compression Tube 3/16 ................................................................................................ AR

29 00-412793-000G1 Tube – Burner .......................................................................................................................... AR

30 00-417214-00001 Support – Burner ..................................................................................................................... AR

31 00-417291-000G2 Baffle Assy. (Large) (Hot Top & Griddle) ................................................................................ AR

32 00-417292-000G2 Baffle Assy. (Large) (Hot Top & Griddle) ................................................................................ AR

33 00-408726-000G6 Brick Set (Griddle - Broiler) ...................................................................................................... AR

34 00-417424-000G2 Thermostat (BJWA) ................................................................................................................. AR

**35 00-417615-00F48 Nozzle – Griddle T (Nat.) (Sea Level to 2000 Ft.) ................................................................... AR

**36 00-417615-00F49 Nozzle – Griddle T (Nat.) (2000 to 4000 Ft.) ........................................................................... AR

**37 00-417615-00F50 Nozzle – Griddle T (Nat.) (4000 to 6000 Ft.) ........................................................................... AR

**38 00-417615-00F51 Nozzle – Griddle T (Nat.) (6000 to 8000 Ft.) ........................................................................... AR

**39 00-417615-00F57 Nozzle – Griddle T (L.P.) (Sea Level to 2000 Ft.).................................................................... AR

**40 00-417615-00F58 Nozzle – Griddle T (L.P.) (2000 to 4000 Ft.) ............................................................................ AR

**41 00-417615-00F60 Nozzle – Griddle T (L.P.) (4000 to 6000 Ft.) ............................................................................ AR

**42 00-417615-00F63 Nozzle – Griddle T (L.P.) (6000 to 8000 Ft.) ............................................................................ AR

43 00-411684-000G1 Burner Assy. (Broiler) .............................................................................................................. AR

00-404738-00002 Valve – Pilot 3/16 (Griddle).......................................................................................................... AR

FP-085-53 Plug – Pipe 1/8(Use to Plug Manifold) ....................................................................................... AR

00-417669-000G1 Tray Assy. (Broiler-Griddle)..................................................................................................... AR

* - Drip Pan Assy. (Broiler-Griddle)............................................................................................... AR

*Contact Vulcan-Hart Service.

**Thermostat Controlled Griddle (Refer to Page 12 for Burner Valve).

- 17 -

GASRESTAURANT RANGE REPLACEMENT PARTS

F-30536 Rev. C (May 2006)

RECOMMENDED SPARE PARTS LIST

STANDARD RESTAURANT RANGE

PART NO. NAME OF PART AMT.

00-413342-00001 Door Spring (60, 260).................................................................................................................2

00-412014-00001 Door Spring (24, 48)...................................................................................................................2

00-404053-00001 Door Spring (36, 148, 481, 160) ................................................................................................2

00-403956-00001 BellCrank ...................................................................................................................................2

00-413381-00001 BellCrank Hook (RH)..................................................................................................................2

00-413381-00002 Bell Crank Hook (LH) ..................................................................................................................2

00-408279-00006 Regulator, LP ..............................................................................................................................2

00-417424-000G1 Thermostat, BJWA Oven............................................................................................................2

00-417424-000G2 Thermostat, Griddle....................................................................................................................2

00-412787-00002 Pilot,Oven,LP ............................................................................................................................2

00-720719 Valve, Safety, BASO..................................................................................................................2

00-412788-00003 Thermocouple, used with 720719 .............................................................................................2

00-405569-00002 Valve, Safety, RobertShaw .......................................................................................................2

00-412788-00001 Thermocouple, used with 405569-2 .........................................................................................2

00-404076 Valve, Top Burner ......................................................................................................................2

00-408279-00005 Regulator, Natural .......................................................................................................................2

00-412787-00001 Pilot,Oven, Natural .....................................................................................................................2

00-418051-00044 Burner Valve Orifice, Natural.....................................................................................................2

00-418051-00055 Burner Valve Orifice, LP ............................................................................................................2

- 18 -

GASRESTAURANTRANGEREPLACEMENTPARTS

F-30536 Rev. C (May 2006)

RECOMMENDED SPARE PARTS LIST

CONVECTION OVENS BUILT AFTER 9-00 WITH SPARK IGNITION

PART NO. NAME OF PART AMT.

CONVECTIONOVENS

00-413342-00001 Door Spring (60, 260).................................................................................................................2

00-412014-00001 Door Spring (24, 48)...................................................................................................................2

00-404053-00001 Door Spring (36, 148, 481, 160) ................................................................................................2

00-417865-00001 Turnbuckle..................................................................................................................................2

00-413381-00001 BellCrank Hook (RH)..................................................................................................................2

00-413381-00002 Bell Crank Hook (LH) ..................................................................................................................2

00-408279-00006 Regulator, LP ..............................................................................................................................2

00-417424-000G2 Thermostat, Griddle....................................................................................................................2

00-419730-000G1 Motor 120 V................................................................................................................................1

00-404076 Valve, Top Burner ......................................................................................................................2

00-408279-00005 Regulator, Natural .......................................................................................................................1

00-408279-00006 Regulator, LP ..............................................................................................................................1

FE-023-65 Fuse............................................................................................................................................4

00-425535-00001 Fuse Holder ................................................................................................................................4

00-411496-000E8 Indicator, Light (Red) ..................................................................................................................2

00-411506-00011 Thermostat, Oven ......................................................................................................................2

00-411496-000F1 Switch, Micro .............................................................................................................................2

00-411496-000B1 Switch, ON/OFF .........................................................................................................................2

00-417980-00001 IgnitionModule ............................................................................................................................2

00-411496-00E21 Light, ON/Ready .........................................................................................................................2

00-428066-000G3 Solenoid ......................................................................................................................................2

00-425955-00001 Transformer 120 V ....................................................................................................................2

00-426233-00001 Pilot, Spark Assy. Nat. ................................................................................................................2

00-426233-00002 Pilot, SparkAssy. LP ...................................................................................................................2

RECOMMENDED SPARE PARTS LIST

CONVECTION OVENS BUILT BEFORE 9-00

PART NO. NAME OF PART AMT.

CONVECTIONOVENS

00-413342-00001 Door Spring (60, 260).................................................................................................................2

00-412014-00001 Door Spring (24, 48)...................................................................................................................2

00-404053-00001 Door Spring (36, 148, 481, 160) ................................................................................................2

00-417865-00001 Turnbuckle..................................................................................................................................2

00-417366-00001 J-Bolt for Springs .......................................................................................................................2
