MODELS: VC44E SERIES Double Deck Electric Convection Ovens
VC44E SERIES
DOUBLE DECK ELECTRIC CONVECTION OVENS
SPECIFICATIONS:
Double section electric convection oven, Vulcan-Hart Model
No. (VC44ED) (VC44EC). Stainless steel front, sides, top and
legs. Inde-pendently operated stainless steel doors with
double pane windows. Non-sag insulation applied to the top,
rear, sides, bottom and doors. Porcelain enamel on steel oven
interiors measure 29"w x 221/8"d x 20"h. Two interior oven
lights per section. Five nickel plated oven racks per section
measure 281/4" x 201/2". Eleven position nickel plated rack
guides with positive rack stops per section. Each section
heated by electric solid sheath elements rated at 12 KW.
Furnished with a two speed 1/2H.P. oven blower-motor per
section. Oven cool switch for rapid cool down. 208 or 240 volt,
60 Hz, 1 or 3 phase.
Exterior dimensions: 40"w x 421/4"d x 70"h on 8" legs. Depth
measurement includes door handles.
NSF listed. U L listed. U L listed to Canadian safety standards.
VC44ED Solid state temperature controls adjust from 150°
to 500°F. 60 minute timer with audible alarm.
VC44EC Computer controls with digital time and temperature
readouts. 99-hour timer with audible alarm. Roast
and Hold cycle. Six preset menu selections.
Shelf I.D. programming.
STANDARD FEATURES
■Stainless steel front, sides, top and legs.
■Independently operated stainless steel doors with double
pane windows.
■25 total KW.
■1/2H.P. two speed oven blower-motor.
■Moisture vent damper control.
■Oven cool switch for rapid cool down.
■Porcelain enamel on steel oven interiors.
■Five nickel plated oven racks with eleven rack positions per
section.
■One year limited parts and labor warranty.
OPTIONS
Five hour timer in place of 60 minute timer (Model VC44ED).
Casters.
480V/60 Hz/1 or 3 phase.
Second year extended limited parts and labor warranty.
ACCESSORIES
Stainless steel rear motor enclosure.
Extra oven rack(s).
Rack hanger(s).
Stainless steel drip pan.
Model VC44ED

VULCAN-HART COMPANY, P.O. BOX 696, LOUISVILLE, KY 40201, TEL. [phone]
502-778-2791 QUOTE & ORDER FAX: [phone]
Printed On Recycled Paper
NOTE: In line with its policy to continually improve its products, Vulcan-Hart Company reserves the right to change materials and
specifications without notice.
F-32536 (03-08)
VC44E SERIES
DOUBLE DECK ELECTRIC CONVECTION OVENS
OPTIONAL VOLTAGES:
480 volt, 60 Hz, 3 phase.
220/380 volt, 50 Hz, 1 phase, 3 wire.
220/380 volt, 50 Hz, 3 phase, 4 wire.
240/415 volt, 50 Hz, 3 phase, 4 wire.
NOMINAL AMPS PER LINE WIRE
TOTAL 3 PHASE LOAD 3 PHASE
MODEL CONN. KW PER PHASE 208 VOLT 240 VOLT 480 VOLT 1 PHASE
NO. KW X-Y Y-Z X-Z X Y Z X Y Z X Y Z 208V 240V
VC44E 25 88 9 706670665866283030120104
