Vulcan-Hart ECO2D User manual

VULCAN-HART COMPANY, P.O. BOX 696, LOUISVILLE, KY 40201, TEL. [phone]
502-778-2791 QUOTE & ORDER FAX: [phone]
Item # __________________________
C.S.I. Section 11420
A2780
ISO9001
Vulcan-Hart Co.
F-32190 (03-08)
MODEL: ECO2D Half Size Electric Convection Oven
STANDARD FEATURES
■Stainless steel front, sides, top and rear enclosure panel.
■4" adjustable chrome plated legs.
■Stainless steel door with double pane window.
■Cool to the touch oven door handle.
■Stainless steel oven door gaskets.
■5.5 KW input.
■Solid state temperature control adjusts from 200° to 500°F.
■60 minute electric timer with time expired buzzer.
■1/3H.P. two speed fan motor.
■Oven cool switch for rapid cool down when door is open.
■Oven interior liners are porcelain on steel.
■Nine position rack guide with five nickel plated racks.
■Requires 208/240 volt, 60 Hz, 1 or 3 phase power supply.
■One year limited parts and labor warranty.
OPTIONS
Set of four 163/4" stainless steel legs with adjustable feet
and stack set.
Set of four 163/4" stainless steel legs with casters and
stack set.
34" stainless steel stand with legs and nine position rack
storage capacity.
34" stainless steel stand with casters and nine position rack
storage capacity.
Rack hanger.
Second year extended limited parts and labor warranty.
MODEL ECO2D
HALF SIZE ELECTRIC CONVECTION OVEN
SPECIFICATIONS:
Half size electric convection oven, Model No. ECO2D, manu-
factured by Vulcan Hart. Porcelain enamel on steel oven interior
measures 151/4"w x 21"d x 20"h. Furnished with nine position
nickel plated rack guides and five nickel plated racks measur-
ing 143/8" x 207/8". Heated by enclosed tubular heating elements
rated at 5.5 KW. Stainless steel front, sides, top and rear
enclosure panel. Insulation applied to the top, rear, both sides,
bottom and door. Stainless steel door with double pane win-
dow. Solid state temperature controls adjustable from 200° to
500°F. 60 minute electrical timer with continuous sounding
buzzer. Two speed 1/3H.P. permanently lubricated oven blower
motor. Requires 208/240 volt, 60 Hz, 1 or 3 phase supply.
Exterior dimensions: 30"w x 281/4"d x 305/8"h on 4" legs.
NSF listed. U L listed. U L listed to Canadian safety standards.
Model ECO2D
Shown on optional S/S stand with casters

VULCAN-HART COMPANY, P.O. BOX 696, LOUISVILLE, KY 40201, TEL. [phone]
502-778-2791 QUOTE & ORDER FAX: [phone]
Printed On Recycled Paper
NOTE: In line with its policy to continually improve its products, Vulcan-Hart Company reserves the right to change materials and
specifications without notice.
F-32190 (03-08)
MODEL ECO2D
HALF SIZE ELECTRIC CONVECTION OVEN
NOTE: This appliance may be installed with 1.0" clearance at
the rear and 0" clearance on both sides adjacent to combustible
construction.
This appliance is manufactured for commercial installation only
and is not intended for domestic/household installation.
ELECTRICAL DATA
208, 240Volt - 3 PHASE LOADING NOMINAL AMPS PER LINE WIRE
MODEL TOTAL KW PER PHASE 3 PHASE 1 PHASE
KW 208V 240V 208V 240V
L1-L2 L2-L3 L1-L3 L1 L2 L3 L1 L2 L3
ECO2D 5.5 2.5 0 3.0 23 10 12 20 9 11 26 23
