Vulcan-Hart ECO2C Manual

HALF SIZE ELECTRIC
CONVECTION OVENS
MODEL
ML-114570 ECO2D
ML-114572 ECO2C
CATALOG OF
REPLACEMENT PARTS
MODEL ECO2C
FORM 31000 Rev. C (Dec. 2008)
VULCAN-HART
DIVISION OF ITW FOOD EQUIPMENT GROUP, LLC
WWW.VULCANHART.COM
P.O. BOX 696, LOUISVILLE, KY 40201-0696
TEL. [phone]
For additional information on Vulcan-Hart or to locate an authorized
parts and service provider in your area, visit our website at www.vulcanhart.com

– 2 –
ECO2D & ECO2C HALF SIZE ELECTRIC CONVECTION OVENS REPLACEMENT PARTS
CABINET
5
6
9
10
11
12
34
7
8
12 13 THRU 15
16
17
20
21-22
35-36
37
38
39
23
24
25
26 THRU 30
31-32
33-34
40
41
PL-52611A-3
New Old
18
19
Old
Style
New
Style
NOTE: Item 33 removed
for clarity
43
111
44
45
46 47
33
39
33-34
48
49 50
42 New

– 3 –
REPLACEMENT PARTS ECO2D & ECO2C HALF SIZE ELECTRIC CONVECTION OVENS
CABINET
ILLUS. PART
PL-52611A-3 NO. NAME OF PART AMT.
1 00-427855-00001 Striker-Door Switch (Old Style) (Prior to December 2008) ........................................................... 1
00-499340-00001 Bracket, Shaft, Micro Switch (New Style) (Beginning December 2008) ............................... 1
2 SD-034-52 Self-Tapping Screw 8-32 x 1 Hex Washer Hd., Type T ............................................................... 1
3 SD-034-47 Self-Tapping Screw 6-32 x 1 Hex Washer Hd., Type T ............................................................... 2
4 NS-046-52 Nut - 1/4-20 Hex “Keps” ................................................................................................................ 2
5 00-353782-00001 Switch-Door (Prior to August 2001) ............................................................................................ 1
00-411496-000F1 Switch-Door (August 2001 to Present) ....................................................................................... 1
6 00-353780-00001 Bracket-Switch (Prior to August 2001) ........................................................................................ 1
00-426854-00001 Bracket-Switch (August 2001 to Present) ................................................................................... 1
7 SD-036-30 Self-Tapping 8-32 x 1/4Slotted Hex Washer Hd., Type T ............................................................. 1
8 00-353778-00001 Support-Switch (Prior to August 2001) ....................................................................................... 1
9 00-353482-00001 Spacer ......................................................................................................................................... 1
10 00-353483-00002 Plate-Door (3 Holes) .................................................................................................................... 1
11 00-347080-00002 Bearing - Door Shaft (Old Style) .................................................................................................. 1
00-347080-00001 Bearing - Door Shaft (Old Style) .............................................................................................. 1
12 SC-022-40 Mach. Screw 1/4-20 x 3/4Phil. Flat Hd. .......................................................................................... 2
13 00-423281-00001 Seal-Door (RH or LH Side) .......................................................................................................... 2
14 00-423280-00001 Seal-Door (Top & Bottom) ........................................................................................................... 2
15 SD-034-05 Self-Tapping Screw 6-20 x 3/8Phil. Pan Hd., Type AB ............................................................... 16
16 SC-115-51 Mach. Screw 10-32 x ½ Phil. Truss Hd. ...................................................................................... 2
17 00-499270-00001 Strike Plate (New Style) (Mounted on Upper "C" Channel) .................................................. 1
00-347545-00001 Roller Ball Door Latch (Old Style) ................................................................................................ 1
18 00-423014-000G1 Door Kit (Old Style) (Includes Items 16, 17 (Old Style) and 19) ................................................ AR
19 NS-038-03 Lock Nut – SP 10-32 ................................................................................................................... 2
20 00-354476-00002 Back (SST) .................................................................................................................................. 1
21 00-422715-00002 Panel-Side (RH)(SST) ................................................................................................................. 1
22 00-957647 Panel-Side (LH)(SST) ................................................................................................................. 1
23 00-347565-00001 Insulation Retainer Assy. ............................................................................................................. 1
24 00-354262-00001 Blower ......................................................................................................................................... 1
25 00-358516-00002 Motor ........................................................................................................................................... 1
26 00-347786-00002 Motor Mount Assy. ...................................................................................................................... 1
27 SC-116-84 Cap Screw 5/16-18 x 11/8Hex Hd. ................................................................................................. 4
28 WS-029-46 Washer ........................................................................................................................................ 4
29 NS-046-86 Nut Assy. 5/16-18 “KEPS” Hex ...................................................................................................... 4
30 00-358723-00001 Spacer - Steel .............................................................................................................................. 2
31 00-360869-000G1 Blower Baffle Weldment (Enamel) .............................................................................................. 1
32 00-360869-000G2 Blower Baffle Weldment (SST) ................................................................................................... 1
33 00-422714-00001 Cover-Lower (Old Style) (Prior to December 2008) ..................................................................... 1
00-957632-00001 Cover-Lower (New Style) (Beginning December 2008) ......................................................... 1
34 00-422592-00001 Sill Door ....................................................................................................................................... 1
35 00-347498-00003 Guide-Rack (LH) .......................................................................................................................... 1
36 00-347498-00004 Guide-Rack (RH) ......................................................................................................................... 1
37 00-499269-00001 Support, Upper Door (New Style) ............................................................................................ 1
00-422590-00001 Support-Door Upper Reversible (Old Style) ................................................................................. 1
38 00-422588-00001 Plate-Cover ................................................................................................................................. 1
39 00-347593-00001 Cover-Top ................................................................................................................................... 1
40 00-422595-00002 Top (SST) ................................................................................................................................... 1
41 00-354482-00001 Vent Extension ............................................................................................................................ 1
42 00-499274-00001 Probe Guard (New) ................................................................................................................... 1
43 00-411496-000F1 Door Switch (August 2001 to Present) ......................................................................................... 1
44 00-499338-00001 Bracket, Door Switch (New Style) (Beginning December 2008) ........................................... 1
00-426854-00001 Switch Mounting Bracket (Old Style) (Prior to December 2008) .................................................. 1
45 SD-034-52 Screw .......................................................................................................................................... 1
46 00-353790-00001 Door Stop .................................................................................................................................... 1
47 SD-008-27 Screw .......................................................................................................................................... 1
48 00-343143-00002 Washer ........................................................................................................................................ 1
49 SC-123-87 Screw .......................................................................................................................................... 1
50 NS-046-89 6-32 KEPS Nut ........................................................................................................................... 1
FE-023-56 Bushing, Motor ............................................................................................................................ 1
00-355344 Channel - Latch (Prior to December 1997) .................................................................................. 1
00-417810-00003 Spring - Compression (Prior to December 1997) ......................................................................... 1
00-411794-00001 Catch - Door (Prior to December 1997) ....................................................................................... 1

– 4 –
ECO2D & ECO2C HALF SIZE ELECTRIC CONVECTION OVENS REPLACEMENT PARTS
DOOR
1
2
3-4
9-10
11
12
13
17
16
PL-52612A-1
14
5 THRU 8
15
18
7
8
19
8
7
New
Mounted to Upper
“C” Channel
See Page 2
Old Style
6
Mounted
to Door

– 5 –
REPLACEMENT PARTS ECO2D & ECO2C HALF SIZE ELECTRIC CONVECTION OVENS
DOOR
ILLUS. PART
PL-52612A-1 NO. NAME OF PART AMT.
1 SC-113-98 Self-Tapping Screw 10-16 x 1/2Hex Washer Hd., Type AB ........................................................ 4
2 00-357929-00002 Door Handle Assy ...................................................................................................................... 1
3 SC-053-41 Mach. Screw 1/4-20 x 1/2Truss Hd. SST ..................................................................................... 2
4 WL-013-14 Lockwasher
1/4Internal Shakeproof ............................................................................................ 2
5 00-423014-000G1 Door Kit (Old Style) (Includes Items 6 (Old Style), 7, 8 and 18) ................................................. 2
600-499270-00001 Strike – Door (New Style Door) (Attaches to Upper “C”Channel Assy.) (See Pg. 2) ........ 1
00-423847-00001 Strike - Door (Old Style) (Mounted to Door) ............................................................................... 2
7 SC-117-73 Screw ......................................................................................................................................... 4
8 WL-019-35 Lockwasher 10 Int ...................................................................................................................... 4
9 00-360887-00001 Panel-Outer Door (W/Window) ................................................................................................... 1
00-360887-00002 Panel-Outer Door (W/O Window) ............................................................................................... 1
10 SD-034-22 Mach. Screw ............................................................................................................................. 20
11 00-359703-000G1 Door Frame Assy. ...................................................................................................................... 1
12 SD-034-62 Self-Tapping Screw 10-32 x 1/2Hex Washer Hd., Type T .......................................................... 1
13 00-358534-00001 Window Assy. ............................................................................................................................ 7
14 SD-034-22 Mach. Screw .............................................................................................................................. 1
15 00-360889-000G1 Panel-Inner Door Weldment (W/Window) .................................................................................. 1
00-360888-00002 Panel-Inner Door Weldment (W/O Window) ............................................................................... 1
16 00-347080-00002 Bearing - Door Shaft .................................................................................................................. 1
17 00-343143-00001 Washer ....................................................................................................................................... 2
18 00-499264-00001 Cover, Cutout (New Style) .......................................................................................................1
19 00-497586-00001 Roller Latch (New Style) (Mounted to Top of Door) ............................................................. 1
00-360886-000G1 Door Assy (Old Style) ................................................................................................................ 1
00-499305-000G1 Door Assy. (New Style) ............................................................................................................ 1
NOTE: When ordering item 9 for an old style oven, 1 of part 423014-G1 is also needed.

– 6 –
ECO2D & ECO2C HALF SIZE ELECTRIC CONVECTION OVENS REPLACEMENT PARTS
CONTROL PANEL COMPONENTS
VIEWED FROM BACK OF PANEL.
PL-52386
13
14-15
1
HI
LO
ON
ON
COOL
DOWN
OFF
OFF
MASTER
SWITCH
2 SPEED
MOTOR
THERMOSTAT
425
450
475
400
350
300
250
225
150
300
500
T
E
M
P
F
40
45
50
55
25
30
35
20
15
5
10
60
0
O
F
F
FORCONTINUEDPROTECTION
AGAINSTFIREANDSHOCK
HAZARDREPLACEWITH
15AMP
CLASSG
FUSES
WARNING
DISCONNECTSUPPLYBEFORE
CHANGINGFUSES, CLEANING
ORANYOTHERSERVICE
TIMER
23
4
5-6-7
8
9-10-11
12
16
20
19
18
17
CONTROL PANEL (ECO2D)
Old Style
New Style

– 7 –
REPLACEMENT PARTS ECO2D & ECO2C HALF SIZE ELECTRIC CONVECTION OVENS
CONTROL PANEL (ECO2D)
ILLUS. PART
PL-52386 NO. NAME OF PART AMT.
1 00-422560-000G1 Panel-Control (Prior to February 2003) ....................................................................................... 1
2 00-340324-00006 Switch (D.P.S.T.) (Prior to February 2003) .................................................................................. 1
3 00-354575-00001 Light Indicator (On/Heat) (200-240V) ........................................................................................... 1
4 00-340324-00009 Switch (D.P.D.T.) ........................................................................................................................ 2
5 00-353613-00002 Controller - Temperature ............................................................................................................. 1
6 SC-114-83 Mach. Screw 6-32 x 1/4Pan Hd. ................................................................................................... 2
7 WS-028-20 Washer ........................................................................................................................................ 2
8 00-411690-00002 Timer (200-240 V.)(1 Hr.) ............................................................................................................ 1
9 00-411499-00003 Buzzer (230 V.) ............................................................................................................................ 1
10 SD-034-49 Self-Tapping Screw 8-32 x 1/2Hex Washer Hd., Type T .............................................................. 1
11 WL-014-10 Lockwasher 1/4Ext. “Shakeproof” ................................................................................................ 1
12 FE-023-55 Holder - Fuse ............................................................................................................................... 2
FE-019-40 Fuse ............................................................................................................................................ 1
13 00-360881-00001 Overlay-Control Panel (Prior to February 2003) ........................................................................... 1
14 SC-114-27 Mach. Screw 8-32 x 1/2Phil. Pan Hd. ........................................................................................... 4
15 NS-046-51 Nut Assy. 8-32 Hex ..................................................................................................................... 4
16 00-358538-00001 Plate - Dial Timer (Prior to February 2003) .................................................................................. 1
17 00-411242-00001 Knob ............................................................................................................................................ 2
18 SC-114-83 Mach. Screw 6-32 x 1/4Pan Hd. ................................................................................................... 2
19 WS-028-20 Washer ........................................................................................................................................ 2
20 00-358539-00001 Plate - Temperature Dial (Fahrenheit) ......................................................................................... 1
00-353589-00001 Probe Assy. ................................................................................................................................. 1
ILLUS. PART
Fig. 1 NO. NAME OF PART AMT.
1 00-428131-000G1 Control Panel Weldment ............................................................................................................. 1
2 00-340324-00008 Master Switch (D.P.D.T.) ............................................................................................................ 1
3 00-354575-00001 Light Indicator (On/Heat) (200-240V) ........................................................................................... 1
4 00-340324-00009 Switch (D.P.D.T.) ........................................................................................................................ 2
5 00-428125-00001 Overlay-Control Panel (February 2003 to present) ...................................................................... 1
6 00-411242-00001 Knob ............................................................................................................................................ 2
7 SC-114-83 Mach. Screw 6-32 x 1/4Pan Hd. ................................................................................................... 2
8 WS-028-20 Washer ........................................................................................................................................ 2
9 FE-023-55 Holder - Fuse ............................................................................................................................... 2
FE-019-40 Fuse ............................................................................................................................................ 1

– 8 –
ECO2D & ECO2C HALF SIZE ELECTRIC CONVECTION OVENS REPLACEMENT PARTS
CONTROL PANEL (ECO2C)
COMPUTERIZED CONTROLS
PL-52421
1
2
3
4
5
8
6-7
WARNING
FOR CONTINUED PROTECTION
AGAINST FIRE AND SHOCK
HAZARD REPLACE WITH
15 AMP. CLASS G FUSES
DISCONNECT SUPPLY BEFORE
CHANGING FUSES. CLEANING
OR ANY OTHER SERVICE.
TEMPERATURE
HEAT
ROAST HOLD
READY
TIME
TIME GENTLE
BAKE
START
STOP
Fig. 2
6
5
4
1-3
Old Style New Style

– 9 –
REPLACEMENT PARTS ECO2D & ECO2C HALF SIZE ELECTRIC CONVECTION OVENS
CONTROL PANEL (ECO2C)
COMPUTERIZED CONTROLS
ILLUS. PART
PL-52421 NO. NAME OF PART AMT.
1 00-355903-00004 Controller W/Cook, Hold & Pulse (Prior to November 1999) ........................................................ 1
2 00-358628-00002 Switch - Rocker (2 Position) (Prior to November 1999) .............................................................. 1
3 00-422585-000G1 Panel-Control (Prior to November 1999 ....................................................................................... 1
4 00-422584-00001 Overlay ........................................................................................................................................ 1
5 FE-023-55 Fuse Holder ................................................................................................................................ 2
FE-019-40 Fuse ............................................................................................................................................ 2
6 SC-114-83 Mach. Screw 6-32 x 1/4Pan Hd. ................................................................................................... 4
7 WS-028-20 Washer ........................................................................................................................................ 4
00-920883-00002 Probe - Thermocouple W/40" Leads (Prior to October 1999) ....................................................... 1
00-424841-00001 Guard-Thermo ............................................................................................................................. 1
ILLUS. PART
Fig. 2 NO. NAME OF PART AMT.
1 FE-023-55 Fuse Holder ................................................................................................................................ 2
FE-019-40 Fuse ............................................................................................................................................ 2
2 SC-114-83 Mach. Screw 6-32 x 1/4Pan Hd. ................................................................................................... 4
3 WS-028-20 Washer ........................................................................................................................................ 4
4 00-358628-00001 Switch - Rocker (3 Position) ........................................................................................................ 1
5 00-426694-00001 Control Panel Weldment (October 1999 to present) .................................................................... 1
6 00-426698-00001 Overlay (October 1999 to [present) ..............................................................................................1
00-920883-00003 Probe - Thermocouple (October 1999 to present) ........................................................................ 1
00-424846-00001 Watlow 734 Controller (October 1999 to present) ........................................................................ 1
00-423918-00001 Electronic Buzzer (October 1999 to present) ............................................................................... 1

– 10 –
ECO2D & ECO2C HALF SIZE ELECTRIC CONVECTION OVENS REPLACEMENT PARTS
PL-52389
1
2-3
13-14
4-5
6-7
8-9
10-11
12
COMPONENT PANEL
ILLUS. PART
PL-52389 NO. NAME OF PART AMT.
1 00-422712-00001 Panel-Component ....................................................................................................................... 1
2 00-358629-00001 Transformer-Controls (ECO2C) (Prior to November 1999) .......................................................... 1
3 SD-034-49 Self-Tapping Screw 8-32 x 1/2Hex Washer Hd., Type T .............................................................. 2
4 00-411497-000C5 Contactor 3 pole .......................................................................................................................... 1
5 SD-034-49 Self-Tapping Screw 8-32 x 1/2Hex Washer Hd., Type T .............................................................. 2
6 00-410472-00008 Terminal Block ............................................................................................................................ 1
7 SD-034-49 Self-Tapping Screw 8-32 x 1/2Hex Washer Hd., Type T .............................................................. 2
8 00-417856-00001 Lug - Grounding (With Set Screw) ............................................................................................... 1
9 SD-034-49 Self-Tapping Screw 8-32 x 1¦2Hex Washer Hd., Type T .............................................................. 2
10 00-417934-000G1 Porcelain - Block Assy. ................................................................................................................ 2
11 SD-034-52 Self-Tapping Screw 8-32 x 1 Hex Washer Hd., Type T ............................................................... 2
12 FE-016-32 Bushing-Snap (Electrical) ............................................................................................................ 2
13 00-821875-00002 Relay-Solid State 50A (ECO2C) .................................................................................................. 1
14 SD-034-49 Self-Tapping Screw 8-32 x 1/2Hex Washer Hd., Type T .............................................................. 2
00-421758-000G4 Transformer Assy (November 2002 to present)
00-411500-00013 Transformer (November 1999 to present) (Used in 421758-G4)

– 11 –
REPLACEMENT PARTS ECO2D & ECO2C HALF SIZE ELECTRIC CONVECTION OVENS
ELECTRIC HEATERS
ILLUS. PART
PL-52388 NO. NAME OF PART AMT.
1 00-351393-00002 Heater Unit Assy. (Outer)(208V) .................................................................................................. 1
2 00-351393-00004 Heater Unit Assy. (Outer)(240V) .................................................................................................. 1
3 00-351393-00001 Heater Unit Assy. (Inner)(208V) ................................................................................................... 1
4 00-351393-00003 Heater Unit Assy. (Inner)(240V) ................................................................................................... 1
5 00-342131-00001 Clamp-Large ................................................................................................................................2
6 SC-114-02 Mach. Screw 10-32 x 3/4Slotted Hex Washer Hd. ....................................................................... 2
7 NS-046-88 Nut Assy. 10-32 HEX “KEPS” ..................................................................................................... 2
8 00-342133-00001 Clamp-Small ............................................................................................................................... 6
9 SC-114-02 Mach. Screw 10-32 x 3/4Slotted Hex Washer Hd. ....................................................................... 6
10 NS-046-88 Nut Assy. 10-32 HEX “KEPS” ..................................................................................................... 6
11 00-347430-00001 Seal Plate Assy. .......................................................................................................................... 1
12 00-342145-00001 Plate ............................................................................................................................................ 1
00-347563-00001 Cover-Heater Unit ........................................................................................................................ 1
00-347494-00001 Heater Assy. (208V)(Incls items 1, 3, 5 Thru 8) ........................................................................... 1
00-347494-00002 Heater Assy. (240V)(Incls. items 2, 4 & 5 Thru 12) ...................................................................... 1
PL-52388
1-2 3-4
5
89-10
6-7
11-12

– 12 –
ECO2D & ECO2C HALF SIZE ELECTRIC CONVECTION OVENS REPLACEMENT PARTS
OPTIONS AND ACCESSORIES
PART
NO. NAME OF PART AMT.
00-347498-00003 Guide-Rack (LH) .......................................................................................................................... 1
00-347498-00004 Guide-Rack (RH) ......................................................................................................................... 1
00-347497-00002 Rack .......................................................................................................................................... AR
00-340445-00002 Leg - Adjustable (6") .................................................................................................................... 4
00-348164-00001 Leg - Adjustable (4") .................................................................................................................... 4
00-341655-00006 Caster - 6" High (Swivel)(W/Brake) ............................................................................................. 2
00-341655-00007 Caster - 6" High (Rigid) ................................................................................................................ 2
00-347798-00001 Stand Assy. ................................................................................................................................. 1
00-342150-00006 Leg Assy (For Stacked Units) ...................................................................................................... 4
00-342150-00007 Leg Assy (For Stacked Units) ...................................................................................................... 4
RECOMMENDED SPARE PARTS
PART
NO. NAME OF PART AMT.
00-353589-00001 Probe Assy "D" Model ................................................................................................................. 2
00-358516-00002 Motor ........................................................................................................................................... 1
00-411499-00003 Buzzer, 230V "D" Model .............................................................................................................. 2
00-411497-000C5 Contactor, 3 -pole ........................................................................................................................ 2
00-821875-00002 50-amp Relay .............................................................................................................................. 2
00-411496-000F1 Door Switch ................................................................................................................................. 2
00-497586-00001 Roller Latch (New Style) ........................................................................................................... 2
00-499270-00001 Strike Plate (New Style) ............................................................................................................. 2
00-423014-000G1 Door Kit (Old Style) .................................................................................................................... 2
00-340324-00008 Hold Switch "D" Model ................................................................................................................ 2
00-340324-00009 Switch (D.P.D.T.) "D" Model ....................................................................................................... 2
00-353613-00002 Temperature Controller "D" Model .............................................................................................. 2
00-411690-00002 Timer, 208V / 240V "D" Model ....................................................................................................2
00-351393-00001 Element, 208V Inner .................................................................................................................... 2
00-351393-00003 Element, 240V Inner .................................................................................................................... 2
00-351393-00002 Element, 208V Outer ................................................................................................................... 2
00-351393-00004 Element, 240V Outer ................................................................................................................... 2
FE-023-55 Fuse Holder ................................................................................................................................. 2
FE-019-40 15-amp Fuse, 300V ..................................................................................................................... 4
00-411500-00013 Transformer ................................................................................................................................. 1
00-920883-00003 Thermocouple "C" Model ............................................................................................................ 2
00-424846-00001 Watlow Controller "C" Model ....................................................................................................... 1
