VWR T Series User manual

0160.8131 / 141219
Operating Instructions
Bedienungsanleitung
Manuel d'utilisation
Ultrasonic Cleaning Units
Ultraschallreinigungsgeräte
Appareils de nettoyage par ultrasons
USC 300, USC 500, USC 600,
USC 900, USC 1200, USC 1700,
USC 2100, USC 2600
Series
Serien T, TH, THD, THD/HF
Séries
VWR International bvba / spr
B-3001 Leuven

0160.8131 / 141219
ENGLISH
You will find the Operating Instructions in English language beginning at page 3.
DEUTSCH
Die Bedienungsanleitung in deutscher Sprache finden Sie ab Seite 19.
FRANCAIS
Vous trouvez le manuel d'utilisation en langue français à partir du page 35.
Betjeningsvejledningen på Deres sprog kan downloades under www.vwr.com eller bestilles hos filialen i Deres land
som printversion.
Las instrucciones de manejo en el idioma de su país pueden descargarse a través de www.vwr.com u obtenerse en
la sucursal de su país como versión impresa.
"Il Manuale d'uso nella propria lingua nazionale si può scaricare da www.vwr.com oppure se ne può chiedere la
versione stampata presso la propria rappresentanza locale."
De bedieningshandleiding in uw landstaal is downloadbaar via www.vwr.com of als drukversie verkrijgbaar bij uw
landsvestiging.
Bruksanvisning i ditt landsspråk kann lastes ned hos www.wwr.com eller kann fåes som trykket versjon i avdelingen i
ditt land.
O manual de instruções no idioma do seu país pode ser obtido por ‘’download’ a partir de www.vwr.com ou junto à
sua sucursal nacional como versão impressa.
Bruksanvisningen på svenska kan laddas ned under www.vwr.com eller erhållas som tryckt version hos filialen i ditt
land.
Suomenkielisen käyttöohjeen voit siirtää tietokoneeseesi osoitteesta www.vwr.com tai hankkia painetun version
maan haaraliikkeestä.

Introduction
0160.8131 / 141219 Page 3 / 51
E
Dear Customer
Thank you for purchasing a USC ultrasonic cleaning unit from VWR International.
The product you have purchased is one of the most innovative in ultrasonics and provides a maximum of
performance and comfort.
This documentation was created in order to make all information concerning the installation, handling and operation
of ultrasonic cleaning unit available to the operator.
This documentation corresponds to the latest release of the date of publication and is not included in revision service.
We reserve the right to make technical changes and improvements at any time.
All devices of the USC-series comply with the regulatory affairs and the normative standards.
This is indicated by the -symbol on the label.
Any enclosed documentation of other vendors serves only for information.
We assume no liability for its completeness or correctness.
If you require information extending beyond this documentation, we will be pleased to offer you technical advice at
any time.
Technical service
Web Resources
Visit the VWR’s website at www.vwr.com for:
•Complete technical service contact information
•Access to VWR’s Online Catalogue, and information about accessories and related products
•Additional product information and special offers
Contact us for information or technical assistance contact your local VWR representative or visit www.vwr.com.
Warranty
VWR International warrants that this product will be free from defects in material and workmanship for a period of
two (2) years from date of delivery. If a defect is present, VWR will, at its option and cost, repair, replace, or refund
the purchase price of this product to the customer, provided it is returned during the warranty period. This warranty
does not apply if the product has been damaged by accident, abuse, misuse, or misapplication, or from ordinary wear
and tear. If the required maintenance and inspection services are not performed according to the manuals and any
local regulations, such warranty turns invalid, except to the extent, the defect of the product is not due to such non-
performance.
Items being returned must be insured by the customer against possible damage or loss. This warranty shall be limited
to the aforementioned remedies. IT IS EXPRESSLY AGREED THAT THIS WARRANTY WILL BE IN LIEU OF ALL
WARRANTIES OF FITNESS AND IN LIEU OF THE WARRANTY OF MERCHANTABILITY.
Equipment disposal
This equipment is marked with the crossed out wheeled bin symbol to indicate that this equipment must not be
disposed of with unsorted waste.
Instead it's your responsibility to correctly dispose of your equipment at lifecycle -end by handling it over to an
authorized facility for separate collection and recycling. It's also your responsibility to decontaminate
the equipment in case of biological, chemical and/or radiological contamination, so as to protect from
health hazards the persons involved in the disposal and recycling of the equipment.
For more information about where you can drop off your waste of equipment, please contact your
local dealer from whom you originally purchased this equipment.
By doing so, you will help to conserve natural and environmental resources and you will ensure that
your equipment is recycled in a manner that protects human health.
Thank you.
VWR International

Contents
Page 4 / 51 0160.8131 / 141219
E
1. SAFETY INFORMATION............................................................................. 5
2. GENERAL.................................................................................................... 8
2.1. Intended purpose / lifetime .................................................................. 8
2.2. Cleaning liquid.....................................................................................8
3. START-UP................................................................................................... 8
4. OPERATION................................................................................................ 9
4.1. Operating and display elements .......................................................... 9
4.2. Ultrasonic Cleaning............................................................................ 11
4.3. Emptying the tank.............................................................................. 11
4.4. Accessories ....................................................................................... 12
5. MAINTENANCE......................................................................................... 12
6. APPENDIX................................................................................................. 13
6.1. Technical Data................................................................................... 13
6.2. Operating elements / front view......................................................... 15
6.3. Connections....................................................................................... 15
6.4. Dimensions and weights.................................................................... 15
6.5. Persistency of the front overlay to solvents ....................................... 16
6.6. Error messages ................................................................................. 17
7. NOTES....................................................................................................... 18

Safety Information
0160.8131 / 141219 Page 5 / 51
E
1. SAFETY INFORMATION
Explanation of the used symbols:
Symbol Explanation
or
This symbol points to some danger for persons or the unit, maximum attention is needed in this case.
Read the referring chapters especial carefully and follow the requirements strictly.
Globally this symbol is also used as reference to follow the operating instructions resp. special
advices.
This symbols shows, that the unit can have hot surfaces.
or
Information on the product, that the operating instructions are a part of the unit and must be read in all
details.
CE-sign (Communauté Européenne). The product which carries this symbol meets the requirements
of the referring EU-directives (European standards).
This symbols shows, that the unit must not be disposed with the domestic waste, but collected at
special collection points for disposal.
This symbol marks the unit as unit protection class 1. All electrical conductive parts of the housing are
connected to the protective earthing system of the installation, which has earth potential.
This symbol indicates that the unit has a heating system to warm up the cleaning liquid.

Safety Information
Page 6 / 51 0160.8131 / 141219
E
Following safety information must be read and respected before start-up and operation of the ultrasonic cleaning unit:
•Any person using this product must have read and understood this manual. Keep this manual close to the device;
it must be permanently accessible to the operator. This will prevent operator error and ensure operation free of
trouble.
•Check your device for any transport damage. If you find shipping damage, the device must not be connected to
the mains.
•The power cord must be removed from the socket only by pulling the plug, do not pull at the cable. The plug must
not be touched with wet / damp hands.
•Power cords must be routed without loops and must not be bent or wrapped around sharp edges.
•The intended use of the ultrasonic cleaning unit is described in this documentation and must be followed.
•Insufficient information about handling or operation can cause irreparable damage and injuries. As a result, the
unit must be operated by trained personnel only.
•The ultrasonic cleaning unit must be located on a dry, hard and flat horizontal surface.
•The ultrasonic cleaning unit must be connected to the supply voltage specified on the rating label only. The mains
connection must be designed for the rated power consumption.
Always use the correct power cord or –adapter for the available socket outlet.
•Only use cleaning liquids which are approved for use with ultrasonic energy.
•Cleaning liquid in use becomes hot. When cleaning temperature sensitive parts check temperature of cleaning
liquid frequently.
•Flammable or explosive liquids and liquids which will corrode the tank material (CrNi steel 1.4301) must not be
used. Liquids which contain halogens (chlorine, bromine or iodine ions) can cause irreparable damages.
•Never switch on the ultrasonic cleaning unit without cleaning liquid. The cleaning tank must be filled at least to 7/8
of volume (approx. up to the seam). Also ensure that the tank is filled enough during operation.
•The temperature rise of the cleaning liquid caused by heaters or ultrasonic energy can result in steaming. Ensure
adequate ventilation at the environment of installation.
•Fluid must not get inside the unit. Wipe off any fluid which has slopped over and is leaking down the side walls as
soon as possible
•The items to be cleaned must not be placed directly on the bottom of the tank. Use a suitable cleaning basket.
•Never leave the ultrasonic cleaning unit unattended during operation.
•If the unit does not have to be ready for operation, disconnect it from the power supply (unplug it from mains).
•Never operate the unit if it has been damaged. Inspect the device and the power cord for outer damages
frequently. Repairs must only be carried out by the manufacturer.
•Observe the statutory regulations when disposing of the cleaning liquid and disposing the unit.

Safety Information
0160.8131 / 141219 Page 7 / 51
E
WARNING:
To avoid risk of electric shock, this equipment must only be connected to supply mains with
protective earth.
Take special note on using the proper power cable and/or adapter for the available power outlet.
WARNING:
There is a danger of injury and burns through:
•Ultrasonic energy!
Never grab in the tank with your hands when the ultrasonic energy is switched on. Always
switch off the ultrasound when inserting or removing the items to be cleaned!
•Hot liquid!
•Hot surfaces!
•Toxic vapor!
During operation it is permitted to touch or to handle the unit with the handles or at the control panel
only.
After use the unit must cool down min. 30min prior to touching the housing.
WARNING:
For usage of the cleaning unit and handling with cleaning agent you generally have to wear adequate
personal protective equipment (PPE) corresponding to the standards:
•Safety gloves
•Safety glasses
•Ear protection
•Breathing protection
•Protective clothing
•Protective boots
WARNING:
No modification of this equipment is allowed.
Do not carry out any repair. In case of service, send the unit back to the manufacturer.

General / Start-up
Page 8 / 51 0160.8131 / 141219
E
2. GENERAL
2.1. Intended purpose / lifetime
The USC ultrasonic cleaning units were especially developed for cleaning tasks in laboratory facilities of commercial
use.
The expected life time of the USC ultrasonic cleaning units depends basically on the quality of maintenance and
cleaning. With proper use, maintenance, cleaning and any necessary repairs a lifetime of five years can be expected.
This does not include consumables such as cable / connectors, cleaning baskets and similar.
Only accessories which are approved by or can be obtained from the manufacturer have to be used.
2.2. Cleaning liquid
The cleaning liquid which has to be used depends on the material of the items to be cleaned and the type of soiling.
Please contact the supplier of the cleaning agent.
3. START-UP
•Check if the mains connection, which must have a protective earth conductor, confirms with the specification on
the rating label of your device.
•Connect the power socket (circular connector at the cable) to the flange connector at the rear of the unit and lock
the connection by turning the cap nut. The cap nut must latch noticeably and needs to be disconnected in locked
condition with increased force only.
If the power cord is already installed to the unit, check if it is locked properly as described before.
•The ultrasonic cleaning unit must be located on a dry, hard and flat horizontal surface.
•Fill the cleaning tank with a suitable cleaning liquid depending on the application. The level must be at least 7/8 of
volume (approx. up to the seam).
Take note of the respective safety regulations for handling chemicals.
•Connect the ultrasonic cleaning unit to the mains, when the display lights up, the unit is ready for operation.
WARNING:
To avoid risk of electric shock, this equipment must only be connected to supply mains with
protective earth.
Take special note on using the proper power cable and/or adapter for the available power outlet.
As a result of the design, the EU connector (CEE 7/7) fits mechanically into the DK socket outlet
(Denmark) but does not connect the protective earth conductor (PE).
Never use the EU connector in combination with DK socket outlets
DANGER TO LIFE AND LIMB!
Adapters are one-time mountable only and cannot be removed after applying to the connector.
Therefore be sure to mount the proper adapter.
WARNING:
The power plug is used to disconnect the unit from mains.
The used power outlet must be permanently accessible and must not be covered by the unit or any
other objects, so the mains plug can be unplugged at any time.

Operation
0160.8131 / 141219 Page 9 / 51
E
4. OPERATION
The units have a digital operator interface which allows comfortable setting and operation.
Depending on the version there are different configurations available:
Series
Configuration T TH THD THD/HF
Table top cleaning unit with digital control and display, ultrasonic
frequency approx. 45kHz X X X
Table top cleaning unit with digital control and display, ultrasonic
frequency approx. 132kHz X
Timer for ultrasonic operation adjustable from 1 to 99 minutes in steps
of 1 minute or continuous X X X X
Integrated heater, liquid temperature adjustable in steps of 1K up to
80degC X X X
Ultrasonic power adjustable in nine steps from approx. 40% to 100 %
power X X
DEGAS-function X X
DEGAS-function:
For degasification of the cleaning fluid the unit can be operated in a so-called DEGAS mode. The cleaning liquid will
be also degassed during standard cleaning operation but this can be considerably speeded up in the DEGAS mode.
With degassing the cleaning result during the following cleaning process is considerably more effective and uniform.
During the DEGAS mode, the ultrasound is automatically switched on and off in short intervals. This causes the
entrapped air to form into larger bubbles during the acoustic irradiation of the fluid. The bubbles can then rise freely to
the surface in the pauses between the acoustic irradiation.
4.1. Operating and display elements
Button 'Sonic / Ultraschall / Ultrasons'
With this button you can switch on and off the ultrasonic operation. The operating status 'Ultrasonic ON' is indicated
by the green light-emitting diode (LED) in this button.
Button 'Heater / Heizung / Chauffage' (TH, THD and THD/HF types only)
With this button you can switch on and off the liquid heater. The operating status 'Heating ON' is indicated by the
green LED in this button.
Button 'Degas / Dégazage' (THD and THD/HF types only)
With this button you can switch on and off the DEGAS mode (see description below). The operating status is
indicated by the green LED in this button.
Button Taste 'Select / Auswahl / Choix'
With this button the following operating parameters can be selected and set (time, temperature, power):

Operation
Page 10 / 51 0160.8131 / 141219
E
Display 'Time / Zeit / Durée' (two digits)
During ultrasonic switched off, the pre-selected cleaning time is shown in minutes in this display. When the
ultrasonic is switched on, the remaining cleaning time is shown and the decimal point in the display flashes, thus
indicating that the pre-selected cleaning time is counting down.
Display 'Temperature / Temperatur / Tempèrature' (two digit, TH, THD and THD/HF types only)
In cleaning mode, the current bath temperature is shown in degC in this display. If the pre-selected temperature has
not yet been reached, the decimal point in the display flashes; the bath is being heated. Once the pre-selected
temperature has been reached, the decimal point is steady. During the process 'Setting the bath temperature', the
target temperature for the cleaning bath is shown in the display.
Display 'Power / Leistung / Puissance' (single digit, THD and THD/HF types only)
The current set value of the ultrasonic power is shown in steps from 1-9 in this display. Step 9 corresponds to
maximum power (100%).
Setting the cleaning time
With ultrasonic switched off press the 'Select / Auswahl / Choix' button until the 'Time / Zeit / Durée' display flashes.
The desired cleaning time can be set in steps from 1 – 99 minutes with the '+' and '–' adjusting buttons.
The time pre-selection can be disabled by pressing the '-' button until two horizontal lines are shown in the display ('- -
').
Once the desired time has been set, release the '+' and '–' adjusting buttons and wait until the display stops flashing
(approx. 5 sec). The value is stored now.
Setting the bath temperature ('TH', 'THD' und 'THD/HF' types only)
With ultrasonic switched off press the 'Select / Auswahl / Choix' button until the 'Temperature / Temperatur /
Tempèrature' display flashes. The desired liquid temperature can be set up to 80degC with the '+' and '–' adjusting
buttons.
Once the desired temperature has been set, release the '+' and '–' adjusting buttons and wait until the display stops
flashing (approx. 5 sec). The value is stored now.
Setting the ultrasonic power ('THD' und 'THD/HF' types only)
The ultrasonic power can be set during ultrasonic on or off.
Ultrasonic 'OFF':
During ultrasonic switched off press the 'Select / Auswahl / Choix' button until the 'Power / Leistung / Puissance'
display flashes. The desired power can be set in steps from 1 – 9 with the '+' and '–' adjusting buttons (step 9 = max.
power).
Once the desired power is set, release the '+' and '–' adjusting buttons and wait until the display stops flashing
(approx. 5 sec). The value is stored now.
Ultrasonic 'ON':
During ultrasonic switched on press the 'Select / Auswahl / Choix' button until the 'Power / Leistung / Puissance'
display flashes. The desired power can be set in steps from 1 – 9 with the '+' and '–' adjusting buttons (step 9 = max.
power).
Once the desired power is set, release the '+' and '–' adjusting buttons and wait until the display stops flashing
(approx. 5 sec). The value is stored now.
Degassing the fluid (DEGAS, 'THD' und 'D/HF' types only)
In order to obtain an optimum cleaning process after the unit has been refilled, first of all the liquid should be
degassed. The cleaning result is considerably impaired by the solved gas bubbles (usually ambient air) in the liquid.
Ultrasonic vibrations dispense these gases.
In the DEGAS mode the unit is periodically switched on and off, the gas bubbles can raise out of the fluid in the OFF
period.

Operation
0160.8131 / 141219 Page 11 / 51
E
Degassing can be speeded up by adding a few drops of a surface-active agent (e.g. washing-up liquid) to the
cleaning fluid.
Most ultrasonic cleaning agents already contain a surface-active agent.
The degassing process does not have to be repeated when reusing the cleaning liquid.
Heating the cleaning bath (TH, 'THD' und 'THD/HF' types only)
If a specified bath temperature is required for the cleaning operation, the cleaning bath can be heated up to a pre-
selected temperature (see process 'Setting the bath temperature'). Cleaning is normally considerably more effective if
the cleaning fluid is warmed up.
WARNING:
Consider the temperature tolerance of the material to be cleaned!
4.2. Ultrasonic Cleaning
•Immerse the items to be cleaned in the cleaning bath the distance of the items from the bottom must be at least
20 mm (0.8 inches).
If required, use the cleaning basket which is available as an accessory.
•Set the required cleaning time, temperature and ultrasonic power for the cleaning process (if applicable).
The parameters 'required cleaning time' and 'ultrasonic power level' excessively depend on the cleaning fluid,
temperature, type and degree of soiling of the items requiring cleaning. The time can vary from a few seconds to
a few minutes.
The best combination of the parameters may have to be experimentally determined.
•Start the cleaning process by switching on the ultrasonic energy.
•After the cleaning process remove the items out of the liquid with suitable care. We recommend rinsing the parts
in clean water.
•Disconnect the ultrasonic cleaning unit from mains if the unit is not needed.
WARNING:
Please note that the bath temperature rises considerably with duration of the ultrasonic operation.
For safety reasons the heater and the ultrasonic energy are switched off if the bath temperature
exceeds approx. 90degC (194F), an error message appears in the display.
Never put the items to be cleaned directly on the bottom of the tank.
Never clean too many items at once, the cleaning result can deteriorate.
4.3. Emptying the tank
If the cleaning result becomes worse or if the cleaning liquid has got contaminated, the cleaning liquid should be
replaced.
Prior to any emptying or cleaning the unit must be disconnected from mains.
For this purpose the units USC 900, USC 1200, USC 1700, USC 2100 and USC 2600 have a drain on the rear side
of the unit.

Operation / Maintenance
Page 12 / 51 0160.8131 / 141219
E
4.4. Accessories
•Tank cover (stainless steel)
To prevent evaporation of the tank contents and odor nuisance.
•Cleaning basket (stainless steel)
For carrying the items to be cleaned. The basket can be suspended in the cleaning tank and it also
can be placed on the edge of the tank with the handles for draining.
•Cover with openings for beakers (different sizes)
•easy cleaning of small parts
•less needs of cleaning solvent
•cleaning in different cleaning solvents
The ultrasonic energy is coupled inside the filled beaker by the liquid around through the glass. Fill
the tank with water and add a surface-active agent (e.g. washing-up liquid).
5. MAINTENANCE
WARNING:
The ultrasonic cleaning unit needs low maintenance.
Regard following notes:
•Prior to any emptying or cleaning the unit must be disconnected from mains.
•Keep the device clean. Wipe the housing frequently with a damp cloth. Remove cleaning agent residues
immediately.
•Ensure that the cleaning liquid does not soil the housing during cleaning.
Clean, replace and dispose the cleaning liquid in accordance with the supplier's recommendations.
•Avoid scratching the inner tank surface, this accelerates cavitation (erosion). Ensure the items to be cleaned have
no direct contact with the bottom or inner sidewalls of the tank and try to keep none or only small amounts of
pollution on the bottom of the cleaning tank. If necessary, the cleaning liquid should be drained off prematurely, so
the tank can be cleaned.
•Check the unit and the power cord for damages frequently and prior to any use.
A visibly damaged unit or cable must not be put in operation and must be disconnected from the mains.
Do not carry out repairs yourself. Send the unit to the manufacturer for servicing or repair.
•There are any parts to maintain or which have to be changed by the user inside the unit.
If the power cord is damaged, it can be removed by unlocking the cap nut (circular plug at rear side of unit). The
power cord must be replaced with the manufacturer's original part only.

Appendix
0160.8131 / 141219 Page 13 / 51
E
6. APPENDIX
6.1. Technical Data
Intended Use Cleaning applications in laboratory facilities of commercial use.
Executions Table top cleaning unit with digital control and display
Unit series Execution
USC - T •ultrasonic energy with approx. 45kHz
USC - TH •ultrasonic energy with approx. 45kHz
•built-in liquid heater
USC - THD
•ultrasonic energy with approx. 45kHz
•built-in liquid heater
•adjustable ultrasonic power
•DEGAS-function
USC - THD/HF
•ultrasonic energy with approx. 132kHz
•built-in liquid heater
•adjustable ultrasonic power
•DEGAS-function
Output ultrasonic energy with frequency of approx. 45kHz resp. 132kHz
switch-on duration: 100% (continuous operation)
Environment conditions
Operating ambient temperature: 0degC ... +40degC (32F ... 104F)
Transportation & storage temperature: - 20degC ... +65degC (- 4F ... 149F)
Humidity: 20% … 70%, non-condensing
Altitude (sea level): max. 2000m (a.s.l.)
Classification:
Protection class: class I equipment (earthed housing)
Protection category according IEC 529: IP 21
Moisture degree 2
Over voltage category II

Appendix
Page 14 / 51 0160.8131 / 141219
E
Mains connection 230V-versions: AC230V ±10%, 47...53Hz, 1~, N, PE / 16A
Unit type (230V) HF-power connected load heater power *)
peak effective 'T'
'
TH
',
'THD' 'TH', 'THD'
USC 300
S
TH
THD
160W 80W 150VA 370VA 200W
USC 500 200W 100W 170VA 390VA 200W
USC 600 240W 120W 190VA 620VA 400W
USC 900 400W 200W 320VA 950VA 600W
USC 1200 360W 180W 280VA 910VA 600W
USC 1700 480W 240W 360VA 1170VA 800W
USC 2100 480W 240W 360VA 1170VA 800W
USC 2600 600W 300W 420VA 1430VA 1000W
Unit type (230V) HF-power connected load heater power *)
peak effective
USC 300
THD/HF
160W 80W 400VA 200W
USC 600 240W 120W 660VA 400W
USC 1200 320W 160W 960VA 600W
USC 2100 420W 210W 1250VA 800W
*) approx. values
Mains connection AC 115V ±10%, 47...63Hz, 1~, N, PE / 15A
Unit type (115V) HF-power connected load heater power *)
peak effective 'T'
'
TH
',
'THD' 'TH', 'THD'
USC 300
S
TH
THD
160W 80W 160VA 370VA 200W
USC 500 200W 100W 180VA 390VA 200W
USC 600 240W 120W 190VA 620VA 400W
USC 900 400W 200W 320VA 950VA 600W
USC 1200 360W 180W 280VA 910VA 600W
USC 1700 480W 240W 370VA 1180VA 800W
USC 2100 480W 240W 370VA 1180VA 800W
USC 2600 600W 300W 430VA 1440VA 1000W
Unit type (115V) HF-power connected load heater power *)
peak effective
USC 1200
THD/HF 320W 160W 980VA 600W
USC 2100 420W 210W 1280VA 800W
*) approx. values

Appendix
0160.8131 / 141219 Page 15 / 51
E
6.2. Operating elements / front view
Series 'T' Series 'TH'
Series 'THD' Series 'THD/HF'
6.3. Connections
Mains connection, single phase 230V:
power cord detachable with power plug CEE 7/7
cord length approx. 2.0m (6.5ft)
Adapters available for
- United Kingdom – BS-1363
- Switzerland – SEV1011
- Denmark – DS 60884-2-D1
- China CPCS-CCC / Australia – AS 3112
Attention:
Adapters are one-time mountable only and cannot be removed after applying to the connector.
Therefore be sure to mount the proper adapter.
Mains connection, single phase 115V:
power cord detachable with power plug NEMA 5-15P
cord length approx. 2.0m (6.5ft)
6.4. Dimensions and weights
Unit type
Tank
capacity
(liters)
inner dimensions
(LxWxD / mm)
outer dimensions
(LxWxD / mm)
weight
(kg)
USC 300 2.8 237x134x100 265x162x235 4.1
USC 500 4.2 237x134x150 265x162x295 4.9
USC 600 5.4 297x148x150 325x176x295 5.5
USC 900 9.2 502x134x150 515x150x270 8.5
USC 1200 12.3 297x237x200 325x265x335 8.2
USC 1700 16.8 324x297x200 352x325x335 9.7
USC 2100 19.6 502x297x150 530x325x365 12.7
USC 2600 26.1 502x297x200 530x325x365 12.9

Appendix
Page 16 / 51 0160.8131 / 141219
E
6.5. Persistency of the front overlay to solvents
The front overlay is based on a polyester foil with a biaxial alignment and has therefore a higher persistence against
solvents compared with e.g. polycarbonate or PVC. It is stronger and more durable than other foils generally used for
plastic foil keyboards and front panels.
The material is resistant against following chemicals over a period of more than 24 hours without any perceptible
changes:
Ethanol
Cyclohexane
Diaceton alcohol
Glycol
Isopropanol
Glycerin
Methanol
Triacetine
Dowandol DRM/PM
Formaldehyde 37 – 42 %
Acetaldehyde
Aliphatic
Toluene
Xylene
Thinning agent (white spirit)
Trichloroethylene
Ethyl acetate
Diethyl ether
N-butyl acetate
Amyl acetate
Butylcellosolve
Ether
Acetone
2-butanone
Dioxane
Cyclohexane
MIBK
Isophorone
Formic acid < 50 %
Acetic acid < 50 %
Phosphoric acid < 30 %
Hydrochloric acid < 36 %
Nitric acid < 10 %
Trichloroacetic acid < 50 %
Sulphuric acid < 10 %
Soda chlorine < 20 %
Hydrogen peroxide < 25 %
Potash soft soap
Detergents
Tensides
Softening agents
Iron (II) chloride (FeCl2)
Iron (III) chloride (FeCl3)
Dibutyl phthalate
Dioctyl phthalate
Sodium carbonate
Ammonia < 40 %
Sodium hydroxide solution < 40%
Potassium hydroxide
Alkali carbonate
Dichromate
Potassium hexacyanoferrate
Acetonitrile
Sodium bisulphate
Cutting emulsions
Diesel oil
Varnish
Paraffin oil
Castor oil
Silicone oil
Turpentine substitute
Brake fluid
Decon
Aviation fuel
Petrol
Water
Salt water

Appendix
0160.8131 / 141219 Page 17 / 51
E
6.6. Error messages
The ultrasonic cleaning units have an error detection system which shows the following messages in the two most left
displays in case of an error:
•nC or E0
In this case, an internal error occurred.
Disconnect the ultrasonic cleaning unit from mains by unplugging the power connector and reconnect
it. Restart the cleaning operation, if the error message still occurs, the device must be sent to the
manufacturer for servicing.
•E1
In this case, an error has been detected in the ultrasonic generator or the generator control system.
Disconnect the ultrasonic cleaning unit from mains by unplugging the power connector and reconnect
it. Restart the cleaning operation, if the error message still occurs, the device must be sent to the
manufacturer for servicing.
•E2
In this case, the maximum permissible bath temperature of 90degC has exceeded. The heater and
the ultrasonic operation are automatically switched off.
Press the button 'Select / Auswahl / Choix' to quit the error condition and wait minimum 5 minutes
before restarting the cleaning operation.
•E3
In this case, the temperature protection of the ultrasonic generator has automatically switched off the
unit.
Please check that there is enough liquid in the cleaning tank (7/8 of the volume), the ambient
temperature is in the specified range and there is sufficient ventilation of the unit. Press the button
'Select / Auswahl / Choix' to quit the error condition and wait minimum 5 minutes before restarting the
cleaning operation.

Notes
Page 18 / 51 0160.8131 / 141219
E
7. NOTES

Einleitung
0160.8131 / 141219 Seite 19 / 51
D
Sehr geehrte Kundin, sehr geehrter Kunde,
wir bedanken uns für den Kauf eines VWR International Reinigungsgerätes aus der USC – Serie
Das von Ihnen erworbene Produkt gehört zu den innovativsten in der Ultraschalltechnologie und bietet ein Maximum
an Leistung und Komfort.
Diese Dokumentation wurde erstellt, um dem Anwender alle Informationen zur Installation, Bedienung und Betrieb
der Ultraschallsysteme zur Verfügung zu stellen.
Diese Dokumentation entspricht dem aktuellen Stand zum Zeitpunkt der Veröffentlichung und unterliegt keinem
Änderungsdienst.
Technische Änderungen und Verbesserungen bleiben jederzeit vorbehalten.
Alle Reinigungsgeräte der USC – Serie entsprechen den gesetzlichen und normativen Vorgaben. Dies erkennen Sie
an der - Kennzeichnung der Geräte auf dem Typenschild.
Eventuell beigefügte Unterlagen von Fremdherstellern dienen nur der Information.
Für deren Vollständigkeit und Richtigkeit übernehmen wir keinerlei Haftung.
Sollten Sie über diese Dokumentation hinausgehende Informationen benötigen, bieten wir Ihnen unsere technische
Beratung gerne jederzeit an.
Technischer Kundendienst
Web-Ressourcen
Auf der VWR Website unter www.vwr.com finden Sie die folgenden Informationen:
•• Alle Kontaktdaten des technischen Kundendienstes
•• VWR Online-Katalog sowie Informationen über Zubehör und zugehörige Produkte
•• Weiterführende Produktinformationen und Sonderangebote
Kontakt: Wenn Sie Informationen oder technische Unterstützung benötigen, wenden Sie sich an Ihr VWR
Vertriebszentrum oder besuchen Sie unsere Website unter www.vwr.com
Gewährleistung
VWR International gewährleistet, dass dieses Produkt ab Lieferung zwei (2) Jahre frei von Material- und
Herstellungsfehlern ist. Liegt ein Fehler vor, entscheidet VWR nach eigenem Ermessen, das Produkt kostenlos zu
reparieren oder auszutauschen oder dem Kunden den Kaufpreis des Produkts zu erstatten, sofern es innerhalb des
Gewährleistungszeitraums zurückgesendet wird. Diese Gewährleistung erlischt, wenn das Produkt, versehentlich
oder absichtlich, durch unsachgemäßen Gebrauch oder durch normalen Verschleiß beschädigt wurde. Sofern die
erforderlichen Wartungsarbeiten und Inspektionen nicht entsprechend der Bedienungsanleitung und den lokalen
Erfordernissen durchgeführt werden, erlischt die Gewährleistung, es sei denn, dieses Unterlassen ist nicht ursächlich
für den auftretenden Fehler des Produktes.
Zurückgesendete Artikel müssen vom Kunden gegen Schäden und Verlust versichert werden. Diese Gewährleistung
ist auf die zuvor genannten Rechte beschränkt. ES WIRD AUSDRÜCKLICH VEREINBART, DASS DIESE
GEWÄHRLEISTUNG ANSTELLE JEGLICHER GEWÄHRLEISTUNG DER EIGNUNG UND ANSTELLE DER
GEWÄHRLEISTUNG DER ALLGEMEINEN GEBRAUCHSTAUGLICHKEIT GILT.
Entsorgung des Produktes
Dieses Produkt ist mit dem Symbol der „durchgestrichenen Mülltonne“ versehen. Das bedeutet, dass dieses Produkt
nicht mit dem Restmüll entsorgt werden darf. Stattdessen ist es in Ihrer Verantwortung, das Produkt am Ende der
Nutzungsdauer ordnungsgemäß zu entsorgen, indem Sie es an eine autorisierte Entsorgungseinrichtung geben, die
das Produkt separat sammelt und dem Recycling zuführt. Sie sind außerdem dafür verantwortlich, die Anlage im
Falle einer biologischen, chemischen bzw. radioaktiven Verunreinigung zu dekontaminieren, um die Personen, die
mit der Entsorgung und dem Recycling beauftragt sind, keiner Gesundheitsgefahr auszusetzen. Weitere
Informationen über den Ort, an dem Sie Ihr Produkt abgeben können, erhalten Sie bei Ihrem Händler vor Ort, bei
dem Sie das Produkt ursprünglich gekauft haben.
Wenn Sie wie oben beschrieben vorgehen, helfen Sie, natürliche Ressourcen zu schonen und stellen sicher, dass Ihr
Produkt so recycelt wird, dass die Gesundheit der Menschen geschützt wird.
Vielen Dank.
VWR International

Inhalt
Seite 20 / 51 0160.8131 / 141219
D
1. SICHERHEITSHINWEISE ......................................................................... 21
2. ALLGEMEINES......................................................................................... 24
2.1. Verwendungszweck / Lebensdauer................................................... 24
2.2. Reinigungsflüssigkeit......................................................................... 24
3. INBETRIEBNAHME................................................................................... 24
4. BEDIENUNG.............................................................................................. 25
4.1. Bedien- und Anzeigeelemente........................................................... 25
4.2. Ultraschall-Reinigung......................................................................... 27
4.3. Entleeren der Wanne......................................................................... 27
4.4. Zubehör............................................................................................. 28
5. WARTUNG ................................................................................................ 28
6. ANHANG ................................................................................................... 29
6.1. Technische Daten.............................................................................. 29
6.2. Bedienelemente / Frontansicht.......................................................... 30
6.3. Anschlüsse ........................................................................................ 30
6.4. Maße und Gewichte........................................................................... 30
6.5. Beständigkeit der Frontfolie gegen Lösungsmittel............................. 31
6.6. Fehlermeldungen............................................................................... 32
7. NOTIZEN ................................................................................................... 33
