Vyyo V284 User manual

Document Version 1.05
November 2004
A Vyyo Inc. Technical Document
V284
W IRELESS M ODEM U NIT
User’s Guide

V
yy
ö V284 WMU User’s Guide
www.vyyo.com
i
DOCUMENT DETAILS
Copyright and Trademark Information:
© 2004 Vyyo Inc. All rights reserved.
Vyyo Inc. reserves the right to alter the equipment specifications and descriptions in
this publication without prior notice. No part of this publication shall be deemed part
of any contract or warranty unless specifically incorporated by reference into such
contract or warranty.
The information contained herein is merely descriptive in nature, and does not
constitute a binding offer for the sale of the product described herein. Any use of
the Vyyo Inc. logo or trademarks is forbidden without prior written approval from
Vyyo Inc.
All trademarks mentioned herein are the property of their respective owners. Vyyo
Inc.’s trademarks include, but are not limited to, “Vyyo” and “Wireless liberty for all.”
Details:
Product Name: V284 WMU (Wireless Modem Unit)
Software Version:
Document Type: User’s Guide
Document Number:
Document Version:
Author:
Document File Name:
Date:
Total Pages:
Status: Production
Change History:
# Date Changed By Update
1 2004-11-04 Doug Broussard
2 2004-11-15 Doug Broussard
3 2004-12-14 Doug Broussard Added FCC Comp.
Statement
Distribution and Approval:
Approved By Approval Type Date √
Baruch Leiman Content √
Yoel Halimi Technical √
Aharon Avrahami Overall

V
yy
ö V284 WMU User’s Guide
www.vyyo.com
ii
FCC Compliance Statement
NOTE: This equipment has been tested and found to comply
with the limits for a Class B digital device, pursuant to Part 15
of the FCC Rules.
These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio
communications. However, there is no guarantee that
interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct
the interference by one or more of the following measures:
•Reorient or relocate the receiving antenna.
•Increase the distance between the equipment and
receiver.
•-Connect the equipment into an outlet on a circuit different
from that to which the receiver is connected.
•-Consult the dealer or an experienced radio/TV technician
for help.
Warning!
Changes or modifications to this equipment not expressly approved by
Vyyo, Inc. could void the user’s authority to operate the equipment.
Warning!
This product was tested and shipped with shielded coaxial cable and
Category 5 Ethernet cable equipped with a shielded RJ-45 connector.
These cables must be used with the unit to ensure compliance.

V
yy
ö V284 WMU User’s Guide
www.vyyo.com
iii
CONTENTS
1Overview and Purpose ..................................................... 1
1.1 Purpose of This User’s Guide .......................................... 1
1.2 Target Audience............................................................... 1
1.3 Vyyo ................................................................................. 1
2Modem Features and Components ................................. 2
2.1 Front Panel Indicators ...................................................... 2
2.2 Back Panel Ports.............................................................. 1
3Using the Modem .............................................................. 2
4Technical Specifications .................................................. 3
5Problem Troubleshooting ................................................ 5
6Warranty Information........................................................ 7
7FCC Declaration of Conformity........................................ 9
8Contacting Vyyo................................................................ 10

V
yy
ö V284 WMU User’s Guide
www.vyyo.com
1
1 O VERVIEW AND P URPOSE
Welcome to the User’s Guide for the Vyyo Inc. V284 Modem.
Figure 1. The Vyyo V284 Wireless Modem Unit
1.1 Purpose of This User’s Guide
The purpose of this User’s Guide is to provide clear and
concise instructions for operating the Vyyo Inc. V284 modem.
1.2 Target Audience
This User’s Guide is intended for users of the V284 modem.
1.3 Vyyo
Vyyo Inc. provides fixed wireless broadband end-to-end
telephony and high-speed data connections to business and
residential subscribers. Vyyo Inc. technology uses point-to-
multipoint architecture to deliver circuit-switched telephony
and data over IP to commercial and private customers
throughout the world.

V
yy
ö V284 WMU User’s Guide
www.vyyo.com
2
2 M ODEM F EATURES AND C OMPONENTS
The V284 modem offers the following features:
•Point-to-multipoint broadband wireless Internet access
•Superior operations over a wide range of modulation formats
and IF bandwidths, including noisy channels
•Easy installation
•Robust RF performance
•Internal radio for UHF bands
2.1 Front Panel Indicators
Four Light Emitting Diode (L.E.D.) indicators are located at
the front of the modem.
The L.E.D.s provide information about the type and status of
modem operations, as described in Table 1.
Figure 2 – V284 WMU Front Panel L.E.D. Indicators

V
yy
ö V284 WMU User’s Guide
www.vyyo.com
1
Table 1. L.E.D. Status and Functions
L.E.D. Indicator Function
POWER •On = Power On
•Off = Power Off
•Flashing = Fatal Error
STATUS •On = Modem is connected to the Internet
•Off = Modem is not connected to the Internet
RF LINK When Status L.E.D. is Off:
•RF On = The downstream link is operational
•RF Off = The modem has not yet begun
downstream acquisition, the
downstream link is idle, or there is a
problem with data reception
•RF Flashing = Downstream link is being acquired
When Status L.E.D. is On:
•RF Flashing = Data is transferring in either in the
Upstream or Downstream direction
LAN&
USB
•On = The LAN link is operational
•Off = The LAN link is not operational
•Flashing = Data is transferring to or from the LAN

V
yy
ö V284 WMU User’s Guide
www.vyyo.com
1
2.2 Back Panel Ports
There are four ports and one button located at the back panel
of the V284 modem.
Figure 3 – V284 WMU rear Panel Ports
Port or Button Function
POWER Connect the 9 volt external power source to this port.
RESET Press this button to reset the modem to its default
settings.
Note: Use a straightened paper clip or a straight pin
to depress the Reset button.
LAN Connect an RJ-45 Ethernet cable to this port.
The other end of the cable can be connected to the
subscriber’s computer or an Ethernet hub or switch.
USB Use a USB A-B cable to connect this Universal
Serial Bus port to the customer’s computer. Use this
port when the customer’s computer is not equipped
with an Ethernet port.
Note: The USB port is not currently supported.
Cable Connect this F-type connector to the UHF antenna.
Table 2. V284 Rear Panel Ports

V
yy
ö V284 WMU User’s Guide
www.vyyo.com
2
3 U SING THE M ODEM
Follow the steps below to use the modem properly.
To use the modem:
1 Check that the computer with which you are using the V284
modem contains a working Ethernet network card, and has
the following software installed and operational:
•Microsoft Windows 95 operating system or later
•Access to the Internet
•A standard Internet browser application
•The Telnet communications utility
2 Attach your computer to the modem’s LAN port with the
included RJ-45 Ethernet cable.
3 Connect the antenna cable to the CABLE port at the back
of the modem.
4 Plug the 9-Volt modem power supply jack into the POWER
port at the back of the modem, and plug the power supply
transformer unit into a standard electrical wall outlet.
Note: As with any household electrical device, avoid the risk of accidental
electrical shock. Make sure that your hands are completely dry and that there is
no moisture on the floor or other surfaces in the immediate area of the electrical
wall outlet.
After connecting the power adapter to the modem, verify that
the three green front panel LEDs light up for approximately 2
seconds before going out.
The orange POWER LED at the left of the front panel lights
up and remains lit, indicating that the modem is powered up.
WARNING: To comply with FCC RF exposure compliance requirements, the
modem should be located in a distance of at least 20 cm from all persons during
normal operation. The antennas used for this product must be outdoor or
indoor, fixed mounted on permanent structures, providing a separation distance
of at least 20 cm from all persons during normal operation.

V
yy
ö V284 WMU User’s Guide
www.vyyo.com
3
4 T ECHNICAL S PECIFICATIONS
General
Dimensions 5.25 x 4.25 x 1.00 in. (13 x 11 x 2.5 cm)
Operating Temperature 32 to 112° F (0 to 45° C)
Power 800 mA at 9V
Power Supply 110 - 220 VAC
LED Indicators (4) Power, Status, RF/Link, LAN/USB
Interface
Data Interface RJ45 – 10/100 baseT Ethernet full/half duplex
USB [Not currently supported]
IF Interface 75 ohm Type F Female Connector
IF /RFCharacteristics
Downstream
Frequency Range 740 – 746 MHz Downstream Receive
Channel Bandwidth 6, 3.5, 2.75, 1.75 MHz
Modulation Format QPSK, 16QAM, & 64 QAM
Data Rates 3-30 Mbps
Rx Sensitivity (dBm) BW (MHz) 64 QAM 16 QAM QPSK
6 -75 -81 -87
3.5 -78 -84 -90
1.75 -81 -87 -93
IF /RFCharacteristics
Upstream
Frequency Range 710 – 716 MHz
Channel Bandwidth 400, 800, 1600, & 3200 kHz
Modulation Fomat QPSK & 16QAM
Data Rates 640 kbps – 10.24 Mbps
RF Output P1dB 27 dBm
Linear Output Power 22.3 dBm
Service
Network Management Protocol: SNMP
MIB: RFC1213, RFC1493,
RFC2233, RFC2669,
RFC2670, DOCSIS Privacy
MIB
Provisioning: As per DOCSIS
Security Link Layer Encryption: DES CBC, 40 and 56 Bits
per user
Key Distribution: Two-layer key distribution
protocol, which include DES-
ECB and RSA public key
encryption and HMAC-SHA1
authorization
Upstream QoS Committed Information
Rate (CIR) per user:
32 Kbps - 2 Mbps (up to 4
Mbps best effort)
Peak Information Rate
(PIR) per user:
32 Kbps - 2 Mbps
Downstream QoS Supported by an add-on packet-shaping device at the
Base Station
IP Protocols Network Protocols: IP, ICMP, ARP, PPPoE,
802.1Q/p, IP Multicast
VoIP: G711, G729, G723
Transport Protocols: TCP, UDP, RTP
Application Protocols: SNMP, TFTP, DHCP
# IP Data Services 64 CPE MAC Addresses
