W Box Technologies 0E-HDMIEXTDR User manual

130FT HDMI
EXTENDER
0E-HDMIEXTDR

1
Introduction
Congratulations and thank you for purchasing W Box
Technologies 0E-HDMIEXTDR.
0E-HDMIEXTDR is a HDMI extender over single Cat5e/6 cable.
It is capable of transmitting full 1080p HD video, HD audio and
bi-directional IR control together up to 130ft.
It features EQ DIP switches on both transmitter and receiver in
the event of installation difficulties, it supports one side power
supply by using a special Cat5e/6 cable, which means as long
as either transmitter or receiver is connected to power, the
extender still works. The extender provides affordable, high
quality HDMI signal transmission solutions for your audio/video
and IR control needs.
Please follow the instructions in this manual to assure proper
installation and to achieve the full performance and satisfaction
you would expect from W Box Technologies.

2
Features
Easy to use, one pair as a full functional module
HDMI and Bi-directional IR pass through
1080P@60Hz up to 130ft over a single Cat5e/6 cable
Bulit-in ESD and surge protection
HDMI 1.3a compliant.
HDMI 1.4 compliant with 3D formats
Supports HDMI or DVI inputs
Bi-direction IR control
Transfers IR control signal together with the HDMI signal
Package Contents
Before you start the installation of the matrix, please check the
package contents.
1 x0E-HDMIEXTDR
2 x 12V 0.5A DC Power Supply
1 x IR Emitter
1 x IR Receiver (30-50KHz)
2 x Mounting Brackets (Pair)

3
Panel
Transmitter Front Panel
1 2
ID
Name
Description
1
Power
Displays power status
2
Status
Displays signal connection status
Rear Panel
1 2 3 4 5 6
ID
Name
Description
1
Power 1
12V 0.5A DC power supply input
2
VIDEO OUT
RJ45 port
3
IR OUT
Connects to an IR emitter
4
IR IN
Connects to an IR receiver (30-50KHz)
5
HDMI IN
Connects to an HDMI source
6
EDID
EDID DIP switch

4
Receiver Front Panel
1 2
ID
Name
Description
1
Power
Displays power status
2
Status
Displays HDMI signal status, this indicator
is on if there is HDMI signal
Rear Panel
1 2 3 4 5 6
ID
Name
Description
1
Power 1
12V 0.5A DC power supply input
2
VIDEO IN
RJ45 port
3
IR IN
Connects to an IR receiver (30-50KHz)
4
IR OUT
Connects to an IR emitter
5
HDMI OUT
Connects to an HDMI display
6
EQ
Equalization. The EQ value is up to the
cable length.

5
Installation Instructions
1. Connect HDMI source (such as a DVD player) to
transmitter.
2. Connect transmitter and receiver with a Cat5e cable.
3. Connect HDMI display (such as HD-LCD) to receiver.
4. Connect the IR receiver unit into transmitter IR IN, connect
the IR emitter unit into receiver IR OUT.
5. Power on all the devices.
Blu-ray Player
Display
CATxCable
HDMIIR TX
IR TX HDMI
TV Remote
DVD Remote
IR RX
IR RX
Audio/Video Intput
Audio/Video Output

6
DIP Switch Description
Transmitter
Position
Functions
0 (default)
1080p stereo
1
1080p 5.1
2
EDID Copy Mode (Copy EDID from display )
3
1080i stereo
4
1080p stereo Long Cable mode (LC mode)
5
1080p 5.1 LC mode
6
EDID Copy Mode LC mode
7
1080i stereo LC mode

7
Receiver
Occasionally, the installation environment, such as the distance
between source and sink may be a factor in the perfect
transmission and reception of a signal. The receiver can be
further fine-turned depending on the length of Cat5e/6 cable
used for optimum performance.
Position
Functions
0 to1
0-10m transmission distance
2 to 5
10-30m transmission distance. The default value
is 4.
6 to 7
30-40m transmission distance
8 to F
Reserved
Note: This table is for your reference, the impedance of the
cable may affect the performance as well.

8
Troubleshooting
W Box Technologies products are designed to function
trouble-free. Most problems that occur are due to simple issues.
If you have trouble, please check the list of simple fixes below.
EXTENDER TROUBLESHOOTING
PROBLEM
SOLUTION
STATUS LED OFF
Ensure the power is on.
Check the cables are qualified and
connected properly.
Check the source output is normal
NO IMAGE
Verify that all the devices are on, all the
cables are qualified and connected
properly.
Verify that a picture is achieved when
connecting the source to the display
directly.
Check the EQ value.

9
Specification
Technical
Input / Output
Transmitter:
1 x RJ45 port,
1 x HDMI IN,
1 x IR IN,
1 x IR OUT
Receiver:
1 x RJ45 port,
1 x HDMI OUT,
1 x IR IN,
1 x IR OUT
Input/Output Signal Type
HDMI: HDMI1.3
Input/Output Resolution
Support
DTV/HDTV;
1080P/1080i/720P/576P/480P/5
76i/480i
Input Video Signal
1.2 volts p-p
Input DDC Signal
5 volts p-p (TTL)
Data Rate
2.25Gbps Maximum
Output Audio
DTS-HD, Dolby-HD
IR Wavelength
940 nm
IR Frequency
38 KHz
Maximum Distance
40 meters
General
Power Supply
DC 12V 0.5A
Power Consumption
5W (Maximum)
