Operator’s Manual
Pump
PT 6L

Copyright
notice
© Copyright 2010 by Wacker Neuson Corporation.
All rights, including copying and distribution rights, are reserved.
This publication may be photocopied by the original purchaser of the machine. Any
other type of reproduction is prohibited without express written permission from
Wacker Neuson Corporation.
Any type of reproduction or distribution not authorized by Wacker Neuson Corporation
represents an infringement of valid copyrights. Violators will be prosecuted.
Trademarks All trademarks referenced in this manual are the property of their respective owners.
Manufacturer Wacker Neuson Corporation
N92W15000 Anthony Avenue
Menomonee Falls, WI 53051 U.S.A.
Tel: [phone] · Fax: [phone] · Tel: [phone]
www.wackerneuson.com
Original
instructions
This Operator’s Manual presents the original instructions. The original language of this
Operator’s Manual is American English.

PT 6L Foreword
wc_tx001594gb.fm 3
Foreword
Machines
covered by
this manual
Machine
documentation
Keep a copy of the Operator’s Manual with the machine at all times.
Use the separate Parts Book supplied with the machine to order replacement
parts.
Refer to the separate Repair Manual for detailed instructions on servicing and
repairing the machine.
If you are missing any of these documents, please contact Wacker Neuson
Corporation to order a replacement or visit www.wackerneuson.com.
When ordering parts or requesting service information, be prepared to provide
the machine model number, item number, revision number, and serial number.
Expectations
for
information in
this manual
This manual provides information and procedures to safely operate and
maintain the above Wacker Neuson model(s). For your own safety and to
reduce the risk of injury, carefully read, understand, and observe all instructions
described in this manual.
Wacker Neuson Corporation expressly reserves the right to make technical
modifications, even without notice, which improve the performance or safety
standards of its machines.
The information contained in this manual is based on machines manufactured
up until the time of publication. Wacker Neuson Corporation reserves the right
to change any portion of this information without notice.
CALIFORNIA
Proposition
65 Warning
Engine exhaust, some of its constituents, and certain vehicle components, contain
or emit chemicals known to the State of California to cause cancer and birth
defects or other reproductive harm.
Laws
pertaining to
spark
arresters
NOTICE: State Health Safety Codes and Public Resources Codes specify that in
certain locations spark arresters be used on internal combustion engines that use
hydrocarbon fuels. A spark arrester is a device designed to prevent accidental
discharge of sparks or flames from the engine exhaust. Spark arresters are
qualified and rated by the United States Forest Service for this purpose. In order to
comply with local laws regarding spark arresters, consult the engine distributor or
the local Health and Safety Administrator.
Manufacturer’s
approval
This manual contains references to approved parts, attachments, and
modifications. The following definitions apply:
Approved parts or attachments are those either manufactured or provided by
Wacker Neuson.
Approved modifications are those performed by an authorized Wacker
Neuson service center according to written instructions published by Wacker
Neuson.
Machine Item Number
PT 6LT
PT 6LS
0007175
0007174

Foreword PT 6L
4 wc_tx001594gb.fm
Unapproved parts, attachments, and modifications are those that do not
meet the approved criteria.
Unapproved parts, attachments, or modifications may have the following
consequences:
Serious injury hazards to the operator and persons in the work area
Permanent damage to the machine which will not be covered under warranty
Contact your Wacker Neuson dealer immediately if you have questions about
approved or unapproved parts, attachments, or modifications.

wc_bo0154629en_008TOC.fm 5
Table of ContentsPT 6L
Foreword 3
1 Safety Information 9
1.1 Signal Words Used in this Manual ....................................................... 9
1.2 State Regulations Concerning Trailers ............................................... 10
1.3 Safety Guidelines for Operating the Machine ..................................... 10
1.4 Operator Safety while Using Internal Combustion Engines ............... 12
1.5 Service Safety .................................................................................... 13
1.6 Towing Safety ..................................................................................... 14
1.7 Reporting Trailer Safety Defects ........................................................ 14
2 Labels 16
2.1 Label Locations .................................................................................. 16
2.2 Label Meanings .................................................................................. 17
3 Lifting and Transporting 20
3.1 Lifting the Machine ............................................................................. 20
3.2 Tires ................................................................................................... 21
3.3 Wheels and Lug Nuts ......................................................................... 21
3.4 Tongue Jack ....................................................................................... 21
3.5 Safety Chains ..................................................................................... 22
3.6 Lights .................................................................................................. 23
4 Operation 24
4.1 Preparing the Machine for First Use ................................................... 24
4.2 Control / Component Descriptions ..................................................... 24
4.3 Control / Component Locations .......................................................... 25
4.4 Recommended Fuel ........................................................................... 26
4.5 Before Starting the Engine ................................................................. 26
4.6 Before Starting the Pump ................................................................... 26
4.7 Starting ............................................................................................... 27
4.8 Stopping ............................................................................................. 28

6 wc_bo0154629en_008TOC.fm
Table of Contents PT 6L
4.9 Automatic Shutdown System ..............................................................29
4.10 Important Operation Note ....................................................................29
4.11 Hoses ..................................................................................................30
4.12 Hose Couplings ...................................................................................30
4.13 Hose Clamps .......................................................................................30
4.14 Strainer ................................................................................................30
4.15 Discharge Port .....................................................................................31
4.16 Covers .................................................................................................32
4.17 Towing the Machine ............................................................................34
4.18 Emergency Shutdown Procedure ........................................................35
5 Maintenance 36
5.1 Periodic Maintenance Schedule ..........................................................36
5.2 Engine Fuel Delivery System Maintenance .........................................37
5.3 Servicing the Air Cleaner .....................................................................37
5.4 Maintaining the Fuel Filter ...................................................................38
5.5 Priming the Fuel System .....................................................................38
5.6 Lubrication ...........................................................................................39
5.7 Engine Oil ............................................................................................40
5.8 Valve Clearances ................................................................................40
5.9 Fan Belt ...............................................................................................41
5.10 Pump Housing Mounting Bolts ............................................................42
5.11 Mechanical Seal Lubrication ...............................................................43
5.12 Bearing Housing Lubrication ...............................................................44
5.13 Impeller Inspection ..............................................................................44
5.14 Engine Cooling Fins ............................................................................47
5.15 Battery .................................................................................................47
5.16 Troubleshooting ...................................................................................48
5.17 Long-Term Storage .............................................................................49
6 Technical Data 50
6.1 Engine .................................................................................................50
6.2 Pump ...................................................................................................51
6.3 Lubrication ...........................................................................................51
6.4 Trailer and Skid ...................................................................................51
6.5 Dimensions ..........................................................................................52

wc_bo0154629en_008TOC.fm 7
Table of ContentsPT 6L
7 Schematics 53
7.1 Trailer Wiring ............................................................................................... 53
7.2 Electrical Wiring (0007174 < Rev 120; 0007175 < Rev 123) ..................... 54
7.3 Electrical Wiring Components (0007174 < Rev 120; 0007175 < Rev 123) . 55
7.4 Electrical Wiring (0007174 > Rev 119; 0007175 > Rev 122) ..................... 56
7.5 Electrical Wiring Components (0007174 > Rev 119; 0007175 > Rev 122) . 57

8 wc_bo0154629en_008TOC.fm
Table of Contents PT 6L

PT 6L Safety Information
wc_si000524gb.fm 9
1 Safety Information
1.1 Signal Words Used in this Manual
This manual contains DANGER, WARNING, CAUTION, NOTICE, and
NOTE signal words which must be followed to reduce the possibility
of personal injury, damage to the equipment, or improper service.
NOTICE: Used without the safety alert symbol, NOTICE indicates a
situation which, if not avoided, could result in property damage.
Note: A Note contains additional information important to a procedure.
This is the safety alert symbol. It is used to alert you to potential personal hazards.
fObey all safety messages that follow this symbol.
DANGER
DANGER indicates a hazardous situation which, if not avoided, will result in death
or serious injury.
fTo avoid death or serious injury from this type of hazard, obey all safety mes-
sages that follow this signal word.
WARNING
WARNING indicates a hazardous situation which, if not avoided, could result in
death or serious injury.
fTo avoid possible death or serious injury from this type of hazard, obey all safety
messages that follow this signal word.
CAUTION
CAUTION indicates a hazardous situation which, if not avoided, could result in
minor or moderate injury.
fTo avoid possible minor or moderate injury from this type of hazard, obey all
safety messages that follow this signal word.

Safety Information PT 6L
10 wc_si000524gb.fm
1.2 State Regulations Concerning Trailers
Trailer laws covering such things as brakes, lights, safety chains, etc.,
will vary from state to state. Make certain that your trailer is in
compliance with the regulations of the state in which the trailer will be
used. If you are not sure what these regulations are, contact the state
motor vehicle department for information.
In some states, trailers must be registered and licensed by the State
Department of Transportation. Before towing, be sure to check
licensing requirements.
1.3 Safety Guidelines for Operating the Machine
Familiarity and proper training are required for the safe operation of the
machine. Machines operated improperly or by untrained personnel
can be hazardous. Read the operating instructions contained in this
manual and the engine manual, and familiarize yourself with the
location and proper use of all controls. Inexperienced operators should
receive instruction from someone familiar with the machine before
being allowed to operate it.
Operator qualifications
Only trained personnel are permitted to start, operate, and shut down
the machine. They also must meet the following qualifications:
• have received instruction on how to properly use the machine
• are familiar with required safety devices
The machine must not be accessed or operated by:
• children
• people impaired by alcohol or drugs
Personal Protective Equipment (PPE)
Wear the following Personal Protective Equipment (PPE) while
operating this machine:
• Close-fitting work clothes that do not hinder movement
• Safety glasses with side shields
• Hearing protection
• Safety-toed footwear
1.3.1 Do not touch the engine or muffler while the engine is on or
immediately after it has been turned off. These areas get hot and may
cause burns.
1.3.2 Do not use accessories or attachments that are not recommended by
Wacker Neuson. Damage to equipment and injury to the user may
result.
WARNING

PT 6L Safety Information
wc_si000524gb.fm 11
1.3.3 Never leave the machine running unattended.
1.3.4 Never operate this machine in applications for which it is not intended.
1.3.5 Do not open the priming plug when the pump is hot. Do not loosen or
remove inlet or discharge hose fittings when the pump is hot. Hot water
inside could be pressurized much like the radiator on an automobile.
Allow the pump to cool to the touch before loosening the plug and
before loosening or removing the inlet or discharge hose fittings.
1.3.6 NEVER position the pump on a loose, uneven, or unstable surface
where it can tip, roll, slide or fall! The pump must be secure before
operating. Position the pump on a firm, flat surface; adjust the trailer
jacks to be sure the pump is level and supported firmly.
1.3.7 NEVER open the pump housing cover while the pump is operating or
start the pump with the cover off. The rotating impeller inside the pump
can cut or sever objects caught in it.
1.3.8 NEVER block or restrict flow from the inlet line or the discharge line.
Remove kinks from the discharge line before starting the pump.
Operation with a blocked inlet line or discharge line can cause water
inside the pump to overheat.
1.3.9 NEVER reach into or insert anything into the pump while the engine is
on! The impeller inside the pump housing is turning at all times while
the engine is running.
1.3.10 DO NOT allow anyone to stand in front of the discharge port when
starting the engine or while priming the pump! The sudden out-rush of
water could push or knock a person down.
1.3.11 ALWAYS make sure the hose connections on the pump are tight. A
loose connection could cause water to spray or result in a hose falling
off the pump while it is in operation.
1.3.12 ALWAYS make sure the water stream from the pump discharge is not
directed in such a way so as to cause erosion to the surrounding
ground or damage or weakening of nearby structures!

Safety Information PT 6L
12 wc_si000524gb.fm
1.4 Operator Safety while Using Internal Combustion Engines
Operating safety
When operating the pump:
• Keep the area around exhaust pipe free of flammable materials.
• Check the fuel lines and the fuel tank for leaks and cracks before
starting the engine.
When operating the pump:
• Do not smoke while operating the machine.
• Do not run the machine if fuel leaks are present or the fuel lines
are loose.
• Do not run the engine near sparks or open flames.
• Do not touch the engine or muffler while the engine is running or
immediately after it has been turned off.
• Do not operate a machine when its fuel cap is loose or missing.
• Do not start the engine if fuel has spilled or a fuel odor is present.
Move the machine away from the spill and wipe the machine dry
before starting.
Refueling safety
When refueling the engine:
• Clean up any spilled fuel immediately.
• Refill the fuel tank in a well-ventilated area.
WARNING
Internal combustion engines present special hazards during operation and fueling.
Failure to follow the warnings and safety standards could result in severe injury or
death.
fRead and follow the warning instructions in the engine owner’s manual and the
safety guidelines below.
DANGER
Asphyxiation hazard. Using a pump indoors CAN KILL YOU IN MINUTES. Pump
exhaust contains carbon monoxide. This is a poison you cannot see or smell.
fNEVER use this pump inside a home or garage, EVEN IF doors and windows
are open. Only use OUTSIDE and far away from windows, doors, and vents.
fNEVER use a pump inside an enclosed area, such as a tunnel or a trench,
unless adequate ventilation is provided through such items as exhaust fans or
hoses.

PT 6L Safety Information
wc_si000524gb.fm 13
• Replace the fuel tank cap after refueling.
When refueling the engine:
• Do not smoke.
• Do not refuel a hot or running engine.
• Do not refuel the engine near sparks or open flames.
• Do not refuel if the machine is positioned in a truck fitted with a
plastic bed liner. Static electricity can ignite the fuel or fuel vapors.
1.5 Service Safety
A poorly maintained machine can become a safety hazard! In order
for the machine to operate safely and properly over a long period of
time, periodic maintenance and occasional repairs are necessary.
Personal Protective Equipment (PPE)
Wear the following Personal Protective Equipment (PPE) while
servicing or maintaining this machine:
• Close-fitting work clothes that do not hinder movement
• Safety glasses with side shields
• Hearing protection
• Safety-toed footwear
In addition, before servicing or maintaining the machine:
• Tie back long hair.
• Remove all jewelry (including rings).
1.5.1 Do not attempt to clean or service the machine while it is running.
Rotating parts can cause severe injury.
1.5.2 Do not use gasoline or other types of fuels or flammable solvents to
clean parts, especially in enclosed areas. Fumes from fuels and
solvents can become explosive.
1.5.3 DO NOT attempt to clean or service the machine while it is running.
1.5.4 DO NOT operate the machine without an air cleaner.
When replacement parts are required for this machine, use only
Wacker Neuson replacement parts or those parts equivalent to the
original in all types of specifications, such as physical dimensions,
type, strength, and material.
1.5.5 Keep the machine clean and labels legible. Replace all missing and
hard-to-read labels. Labels provide important operating instructions
and warn of dangers and hazards.
WARNING

Safety Information PT 6L
14 wc_si000524gb.fm
1.5.6 ALWAYS replace the safety devices and guards after repairs and
maintenance.
1.5.7 ALWAYS check all external fasteners at regular intervals.
1.5.8 ALWAYS remain aware of moving parts and keep hands, feet, and
loose clothing away from the moving parts of the machine.
1.6 Towing Safety
Towing a large trailer requires special care. Both the trailer and vehicle
must be in good condition and securely fastened to each other to
reduce the possibility of an accident.
1.6.1 ALWAYS check that the hitch and coupling on the vehicle are rated
equal to, or greater than, the trailer’s “gross vehicle weight rating”
(GVWR).
1.6.2 ALWAYS inspect the hitch and coupling for wear or damage. DO NOT
tow the trailer using defective parts.
1.6.3 ALWAYS make sure the coupling is securely fastened to the vehicle.
1.6.4 ALWAYS check the tires on the trailer for tread wear, inflation, and
condition. Replace worn tires.
1.6.5 ALWAYS connect the safety chains.
1.6.6 ALWAYS connect the breakaway cable safety hook to the bumper or
rear of the vehicle. DO NOT attach it to the hitch.
1.6.7 ALWAYS test the surge brakes on the trailer and the brakes on the
vehicle that will be used for towing.
1.6.8 ALWAYS make sure directional and trailer lights are connected and
working properly.
1.6.9 ALWAYS check that the lug nuts holding the wheels are tight and that
none are missing.
1.7 Reporting Trailer Safety Defects
If you believe your trailer has a defect which could cause a crash or
could cause injury or death, you should immediately inform the
National Highway Traffic Safety Administration (NHTSA) in addition to
notifying Wacker Neuson Corporation.
WARNING

PT 6L Safety Information
wc_si000524gb.fm 15
If NHTSA receives similar complaints, it may open an investigation;
and if it finds that a safety defect exists in a group of vehicles, it may
order a recall and remedy campaign. However, NHTSA cannot
become involved in individual problems between you, your dealer, or
Wacker Neuson Corporation.
To contact NHTSA, you may either contact the Auto Safety Hotline toll-
free at 1-800-424-9393 (or 366-0129 in Washington DC area),
www.nhtsa.com, or write to NHTSA, U.S. Department of
Transportation, 400 7th Street SW, (NSA-11), Washington, DC 20590.
You can also obtain other information about motor vehicle safety from
the Auto Safety Hotline.

Labels PT 6L
16 wc_si000523gb.fm
2Labels
2.1 Label Locations
wc_gr001145
1
13
3
7
6
3
814 10
9
5
6
4
12
11
2

PT 6L Labels
wc_si000523gb.fm 17
2.2 Label Meanings
1
DANGER!
Asphyxiation hazard.
Engines emit carbon monoxide.
Do not run the machine indoors or in an
enclosed area.
NEVER use inside a home or garage, EVEN
IF doors and windows are open.
Only use OUTSIDE and far away from win-
dows, doors, and vents.
Read the Operator’s Manual.
No sparks, flames, or burning objects near
the machine.
Stop the engine before refueling.
CAUTION!
Use only clean, filtered diesel fuel.
2
Storage location of Operator’s Manual. The
Operator’s Manual should be stored on the
machine.
3
CAUTION!
Read and understand the supplied Operator’s
Manual before operating this machine. Failure to
do so increases the risk of injury to yourself and
others.
4
NOTICE
Lifting point.
5
WARNING!
Hot surface!
6
WARNING!
Pressurized contents. Do not open when hot!

Labels PT 6L
18 wc_si000523gb.fm
7
WARNING!
Never pump volatile, flammable, or low-flash-
point fluids. These fluids could ignite or
explode.
8
Tire Information
Certification Label (VIN Number)
Also attached to each unit is a Certification
Label. This label specifies that the trailer con-
forms with all Federal Motor Vehicle Standards
in effect at the time of manufacture. The label
includes the Vehicle Identification Number (VIN)
for the trailer.
9
This machine may be covered by one or more
patents.
10
A nameplate listing the model number, item
number, revision number, and serial number is
attached to each unit. Please record the infor-
mation found on this nameplate so it will be
available should the nameplate become lost or
damaged. When ordering parts or requesting
service information, you will always be asked to
specify the model number, item number, revision
number, and serial number of the unit.
11
CAUTION!
Service oil bath air filter daily before starting
engine. Severe engine damage will occur if oil
bath filter is low or empty.
12
CAUTION!
Engine overheat - Check fan belt.

PT 6L Labels
wc_si000523gb.fm 19
13
Low sulfur fuel or ultra low sulfur fuel only.
14
Transport position of the jack
15
NOTICE
Add oil to air cleaner before starting engine.

Lifting and Transporting PT 6L
20 wc_tx001595gb.fm
3 Lifting and Transporting
3.1 Lifting the Machine
See Graphic: wc_gr003180
Attach a sling or chain to the lifting eye (a) using a suitable hook or
shackle. Each lifting device must have capacity of at least 1090 Kg
(2400 lbs.).
Only use steel ropes or chains for hoisting. The rope or chain must
have the suitable specified lifting capacity of 1090 Kg (2400 lbs.). Do
not use improvised ropes or chains.
Never use any other part of the PT6 Pump to lift the machine, as
severe damage may occur.
Do not stand under or get onto the machine while it is being hoisted or
moved.
WARNING
CAUTION
WARNING
wc_gr003180
a
