WAGNER ZIP52 Finishing User manual

B_04044
B_04043
B_04045
Pneumatic Double
Diaphragm Pump
Spray Pack
Version 12 / 2012
Translation of the Original
Operating Manual

3
OPERATING MANUAL
VERSION 12 / 2012 ORDER NUMBER DOC 2332848
Contents
1 ABOUT THESE INSTRUCTIONS 5
1.1 Preface 5
1.2 Warnings, Notes and Symbols in these Instructions 5
1.3 Languages 6
1.4 Abbreviations in the Text 6
2 CORRECT USE 7
2.1 Device Types 7
2.2 Type of Use 7
2.3 Use in Potentially Explosive Areas 7
2.4 Safety Parameters 8
2.5 Processible Materials 8
2.6 Reasonably Foreseeable Misuse 9
2.7 Residual Risks 9
3 IDENTIFICATION 10
3.1 Explosion Protection Identication 10
3.2 Maximum Surface Temperature 10
4 GENERAL SAFETY INSTRUCTIONS 11
4.1 Safety Instructions for the Operator 11
4.1.1 Electrical Equipment 11
4.1.2 Personnel Qualications 11
4.1.3 Safe Work Environment 11
4.2 Safety Instructions for Sta 12
4.2.1 Safe Handling of WAGNER Spray Units 12
4.2.2 Earthing the Unit 12
4.2.3 Material Hoses 13
4.2.4 Cleaning 13
4.2.5 Handling Hazardous Liquids, Varnishes and Paints 13
4.2.6 Touching Hot Surfaces 14
4.2.7 Explosion Azard 14
4.2.8 Noise Risk 14
4.2.9 Material Chemical Compatibility 14
4.2.10 Emergency Stop 14
4.2.11 Tightness Check 15
4.2.12 Maintenance 15
4.3 Use in Areas Subject to Explosion Hazards 15
4.3.1 Safety Regulations 15
4.3.2 Operation without Fluid 16
4.3.3 Maximum Surface Temperature 16
4.3.4 Maximum Surface Temperature - Exothermic Reactions 16
4.3.5 Connection Pipes 16
4.3.6 Pump Protection 16
5 DESCRIPTION 17
5.1 Areas of Application 17
5.2 Scope of Delivery 17

4
OPERATING MANUAL
VERSION 12 / 2012 ORDER NUMBER DOC 2332848
Contents
5.3 Data 17
5.3.1 Materials of the Fluid Transporting Parts 17
5.3.2 Technical Data 18
5.3.3 Dimensions and Connections 20
5.3.4 Performance Diagrams 22
5.4 Mode of Operation 24
6 ASSEMBLY AND COMMISSIONING 25
6.1 Transportation 25
6.2 Storage 25
6.3 Assembly 25
6.4 Grounding 27
6.5 Commissioning 29
6.5.1 Safety Regulations 29
6.5.2 Preliminary Operations 30
6.5.3 Unit Pressure Tightness Test 31
7 OPERATION 32
7.1 Operation 32
7.2 Ending or Interrupting Work 33
7.3 Ending Work: Cleaning 34
7.4 Storage Over Longer Periods of Time 34
8 TROUBLE SHOOTING AND RECTIFICATION 35
9 CLEANING AND MAINTENANCE 36
9.1 Safety Instructions 37
9.2 Filter Cleaning 37
9.3 Diaphragm Replacement (Preventive Maintenance) 39
9.4 Diaphragm Replacement (Due to Breakage) 41
9.5 Cleaning / Replacement of the Suction and Delivery Ball Valves 42
9.6 Replacement of the Reversing Valve 42
9.7 Material Hoses 42
9.8 Decommisioning 43
10 ACCESSORIES 44
11 SPARE PARTS 46
11.1 How can Spare Parts be Ordered? 46
11.2 ZIP52 Finishing 47
11.3 ZIP52 PF Eco-Finishing – Aluminium 50
11.4 ZIP52 Pump – Metal 52
11.5 ZIP52 Pump - Conductive Acetal 54
11.6 ZIP Motor 56
11.7 Trolley, Stand Set, and Wheel Set 58
11.8 Fine Flow Controller 60
11.9 Material Filter 62
11.10 Service Sets 63
12 GUARANTEE AND CONFORMITY DECLARATIONS 64
12.1 Important Notes Regarding Product Liability 64
12.2 Guarantee Claim 64
12.3 CE Declaration of Conformity 65

5
OPERATING MANUAL
VERSION 12 / 2012 ORDER NUMBER DOC 2332848
1.2 WARNINGS, NOTES AND SYMBOLS IN THESE INSTRUCTIONS
1 ABOUT THESE INSTRUCTIONS
Warning instructions in this operating manual highlight particular dangers to users and
device and state measures for avoiding the hazard.These warning instructions fall into the
following categories:
Danger - immediate risk of danger.
Non-observance will result in death or serious injury.
Warning - possible imminent danger.
Non-observance may result in death or serious injury.
Caution - a possibly hazardous situation.
Non-observance may result in minor injury.
Notice - a possibly hazardous situation.
Non-observance can cause material damage.
Note - provides information about particular characteristics and how to proceed.
This information warns you of a hazard!
Here are the possible consequences of not observing the warning
instructions. The signal word indicates the hazard level.
The measures for preventing the hazard and its
consequences.
DANGER
This information warns you of a hazard!
Here are the possible consequences of not observing the warning
instructions. The signal word indicates the hazard level.
The measures for preventing the hazard and its
consequences.
WARNING
Here is information that warns you of a hazard!
Here are the possible consequences of not observing the warning
instructions. The signal word indicates the hazard level.
The measures for preventing the hazard and its
consequences.
CAUTION
This information warns you of a hazard!
Here are the possible consequences of not observing the warning instructions. The
signal word indicates the hazard level.
The measures for preventing the hazard and its consequences.
NOTICE
The operating manual contains information about safely operating, maintaining, cleaning
and repairing the device.
The operating manual is part of the device and must be available to operating and service
sta.
The operating and service sta should be instructed according to the safety instructions.
The device may only be operated in compliance with this operating manual.
This equipment can be dangerous if it is not operated according to the denitions in this
operating manual.
1.1 PREFACE

6
OPERATING MANUAL
VERSION 12 / 2012 ORDER NUMBER DOC 2332848
1.3 LANGUAGES
1.4 ABBREVIATIONS IN THE TEXT
Number of pieces
Position
Labeling in the spare parts lists
Order No. Order number
Double stroke
Fine-Flow Controller (precisely adjustable lter ow controller with lter
and integrated pulsation damper)
2K Two components
Materials:
POM Polyoxymethylen (Acetal)
PPS Polypropylene sulde
PTFE Polytetrafluorethylene
UHMWPE High molecular weight Polyethylene
The operating manual is available in the following languages:
Language: Order No. Language: Order No.
German 2332847 English 2332848
Italian 2332849 French 2335763
Spanish 2335762

7
OPERATING MANUAL
VERSION 12 / 2012 ORDER NUMBER DOC 2332848
2 CORRECT USE
2.1 DEVICE TYPES
2.2 TYPE OF USE
2.3 USE IN POTENTIALLY EXPLOSIVE AREAS
A) Metallic versions (aluminium and stainless steel):
Pneumatic double diaphragm pumps with order number
Aluminum Stainless steel Aluminum
U760.00 U765.00 U731.00
The unit is suitable for working liquid materials like paints and varnishes in accordance
with the classication into explosion classes IIA or IIB.
Metallic (aluminium and stainless steel) and conductive acetal versions:
The pneumatic double diaphragm pumps can be employed in explosion hazard zones
(Zone 1).
B) Conductive acetal versions:
Pneumatic double diaphragm pumps with order number
(POM) acetal
U773.00

8
OPERATING MANUAL
VERSION 12 / 2012 ORDER NUMBER DOC 2332848
2.4 SAFETY PARAMETERS
WAGNER accepts no liability for any damage arising from incorrect use.
Use the unit only to work with the materials recommended by WAGNER.
Operate only the entire unit.
Do not deactivate safety xtures.
Use only WAGNER original spare parts and accessories.
2.5 PROCESSIBLE MATERIALS
Fluid materials like paints and varnishes.
Abrasive materials and pigments!
Greater wear of the parts carrying the material.
Use the application-oriented model (ow rate/cycle, material, valves, etc.) as
indicated in Section 5.3.2.
Check if the uids and solvents used are compatible with the pump construction
materials as indicated in Section 5.3.1.
NOTICE
The operation of the pneumatic double diaphragm pump is only allowable under the
following conditions:
The operating sta have previously been trained on the basis of this operating
manual.
The safety regulations listed in this operating manual must be observed.
The operating, maintenance and repair information in this operating manual must
be observed.
The statutory requirements and accident prevention regulations standard in the
country of use must be observed.

9
OPERATING MANUAL
VERSION 12 / 2012 ORDER NUMBER DOC 2332848
2.6 REASONABLY FORESEEABLE MISUSE
2.7 RESIDUAL RISKS
Residual risks are risks which cannot be excluded even in the event of correct use.
If necessary, warning and prohibition signs at the relevant points of risk indicate residual
risks.
Residual risk Source Consequences specic measures Lifecycle phase
Skin contact with
paints and cleaning
agents
Handling of paints
and cleaning agents
Skin irritations, Wear protective
clothing,
Operation,
allergies observe safety data
sheets
maintenance,
disassembly
Paint in air outside
the dened working
area
Painting outside the
dened working
area
Inhalation of
substances which
are hazardous to
health
Observe working
and operating
instructions.
Operation,
maintenance
The following is prohibited:
coating work pieces which are not grounded,
unauthorized conversions and modications to the device,
processing dry or similar coating materials, and
using defective components, spare parts or accessories other than those described
in Chapter 10 of this operating manual.
The forms of misuse listed below may result in health issues and/or damage to property:
use of powder as a coating material, and
incorrectly set values for processing.
Wagner double diaphragm pumps are not designed for pumping food.

10
OPERATING MANUAL
VERSION 12 / 2012 ORDER NUMBER DOC 2332848
3 IDENTIFICATION
3.1 EXPLOSION PROTECTION IDENTIFICATION
3.2 MAXIMUM SURFACE TEMPERATURE
Metallic (aluminium and stainless steel) and conductive acetal versions:
Pneumatic double diaphragm pumps with order number
As dened in the Directive 94/9/EC (ATEX 95), the unit is suitable for use in areas where
there is an explosion hazard.
+4°C Tamb +40°C
European Communities
Symbol for explosion protection
Unit class II
Category 2 (Zone 1)
Ex-atmosphere gas
Explosion group
Temperature class: maximum surface temperature < 135 °C; 275 °F
Tamb +4 °C to +40 °C: permissible ambient temperature area
Aluminium Stainless steel (POM) acetal Aluminum
U760.00 U765.00 U773.00 U731.00
U760.00 U765.00 U773.00 U731.00
Aluminium Stainless
steel
Conductive
acetal Aluminium
Maximum surface temperature °C +90 +90 +80 +90
°F +194 +194 +176 +194
Permissible ambient temperature: °C +4 ÷ +40
°F +39 ÷ +104

11
OPERATING MANUAL
VERSION 12 / 2012 ORDER NUMBER DOC 2332848
4 GENERAL SAFETY INSTRUCTIONS
4.1 SAFETY INSTRUCTIONS FOR THE OPERATOR
4.1.1 ELECTRICAL EQUIPMENT
4.1.2 PERSONNEL QUALIFICATIONS
4.1.3 SAFE WORK ENVIRONMENT
Keep this operating manual at hand near the device at all times.
Always follow local regulations concerning occupational safety and accident
prevention.
Electrical devices and equipment
To be provided in accordance with the local safety requirements with regard to the
operating mode and ambient inuences.
May only be maintained by skilled electricians or under their supervision.
Must be operated in accordance with the safety regulations and electrotechnical
regulations.
Must be repaired immediately in the event of problems.
Must be decommissioned if they pose a hazard.
Must be de-energized before work is commenced on active parts. Inform sta about
planned work. Observe electrical safety regulations.
Ensure that the device is operated and repaired only by trained persons.
Make sure that the oor in the area where you are working is electrostatically
conductive in accordance with EN 61340-4-1.
Ensure that all persons within the working area wear electrostatically conductive
shoes.
Ensure that during spraying, persons wear electrically conductive gloves. The
grounding takes place via the handle of the spray gun.
Paint mist extraction systems must be tted on site according to local regulations.
Ensure that the following components of a safe working environment are available:
– material/air hoses adapted to the working pressure.
– Personal safety equipment (breathing and skin protection).
Ensure that there are no ignition sources such as naked ames, sparks, glowing wires
or hot surfaces in the vicinity. Do not smoke.

12
OPERATING MANUAL
VERSION 12 / 2012 ORDER NUMBER DOC 2332848
4.2.1 SAFE HANDLING OF WAGNER SPRAY UNITS
4.2.2 EARTHING THE UNIT
The spray jet is under pressure and can cause dangerous injuries.
Avoid injection of paint or cleaning agents:
Never point the spray gun at people.
Never reach into the spray jet.
Before all work on the device, in the event of work interruptions and functional faults:
- Switch o the energy/compressed air supply.
- Secure the spray gun against actuation.
- Relieve the pressure from the spray gun and unit.
In the event of functional faults: remedy the fault as described in the "Trouble Shooting"
Chapter.
The liquid emitters are to be checked for safe working conditions by an expert (e.g.
Wagner Service Technician) as often as necessary or at least every 12 months, in
accordance with the guidelines for liquid emitters (ZH 1/406 and BGR 500 Part 2
Chapter 2.36).
– For shut down devices, the examination can be suspended until the next start-up.
In the event of skin injuries caused by paint or cleaning agents:
Note down the paint or cleaning agent that you have been using.
Consult a doctor immediately.
Avoid danger of injury through recoil forces:
Ensure that you have firm footing when operating the spray gun.
Only hold the spray gun briey in a position.
Depending on the electrostatic charge and the ow speed of the spray, an electrostatic
charge may occur in the equipment. In the event of discharge, this may result in the
formation of sparks or ames.
Ensure that the unit is grounded for every spraying operation.
Ground the work pieces to be coated.
Ensure that all persons inside the working area are grounded, e.g. that they are wearing
electrostatically conductive shoes.
Wear electrostatically conductive gloves when spraying.The grounding takes place via
the handle of the spray gun.
4.2 SAFETY INSTRUCTIONS FOR STAFF
Always follow the information in these instructions, particularly the general safety
instructions and the warning instructions.
Always follow local regulations concerning occupational safety and accident
prevention.

13
OPERATING MANUAL
VERSION 12 / 2012 ORDER NUMBER DOC 2332848
4.2.4 CLEANING
4.2.5 HANDLING HAZARDOUS LIQUIDS, VARNISHES AND PAINTS
De-energize the unit electrically.
Disconnect the pneumatic supply line.
Relieve the pressure from the unit.
Ensure that the flash point of the cleaning agent is at least 5 K above the ambient
temperature.
To clean, use cloths and brushes moistened with solvent. Never use hard objects or
spray on cleaning agents with a gun.
An explosive gas/air mixture forms in closed containers.
When cleaning units with solvents, never spray into a closed container.
Ground the container.
When preparing or working with paint and when cleaning the unit, follow the working
instructions of the manufacturer of the paints, solvents and cleaning agents being
used.
Take the specied protective measures. In particular, wear safety goggles, protective
clothing and gloves, as well as hand protection cream if necessary.
Use a mask or a breathing apparatus if necessary.
For sucient health and environmental safety: Operate the unit in a spray booth or on
a spraying wall with the ventilation (extraction) switched on.
Wear suitable protective clothing when working with hot materials.
4.2.3 MATERIAL HOSES
Ensure that the hose material is chemically resistant to the sprayed materials.
Ensure that the material hose is suitable for the pressure generated in the unit.
Make sure that the hoses are laid only in suitable places. In no case, should hoses be laid
in the following places:
– in high traffic areas,
– on sharp edges,
– on moving parts or
– on hot surfaces
Make sure that the hoses are never used to pull or move the equipment.
The electrical resistance of the complete high pressure hose must be less than 1 MOhm.
Several liquids have a high expansion coecient. In some cases its volume can rise with
consequent damage to pipes, ttings, etc. and cause uid leakage.
When the pump sucks liquid from a closed container, ensure that air or suitable gas can
enter the container to avoid a vacuum being generated in the container itself. Thus a
negative pressure is avoided. The vacuum could implode the container (squeeze) and can
cause it to break. The container would leak and the liquid would ow out.
The pressure ratio is 1:1. Therefore the pressure generated by the pump is equal to the
input air pressure.

14
OPERATING MANUAL
VERSION 12 / 2012 ORDER NUMBER DOC 2332848
4.2.8 NOISE RISK
4.2.9 MATERIAL CHEMICAL COMPATIBILITY
4.2.10 EMERGENCY STOP
In some working conditions, the pump can be particularly noisy: for example when the
air feeding pressure is high and when there is no pressure or a very low pressure in the
pumped uid (free ow operation). In these cases, all personnel working next to the pump
shall wear adequate individual protections and/or use valves and seats in plastic material,
provided the working conditions and the compatibility with the pumped uid allow it.
Make sure the materials employed in manufacturing the pump are chemically compatible
with the uid to be pumped. A wrong choice can cause harming people (as a result of
prosection of noxious and irritant products) as well as polluting the environment, besides
prematurely damaging the pump and its hoses.
To quickly stop the unit in case of emergency, close the air cut-o valve or the pressure
regulator; to interrupt the air supply to the pump’s motor. For the ZIP52 PF Eco-Finishing,
the cut-o valve is not supplied with the pump. It has to be provided and properly installed
by the user.
Caution : delivery circuits of pneumatic pumps can remain pressurized, even when the air
input valve is closed.
4.2.7 EXPLOSION AZARD
Never use chloride or halogenated solvents (such as trichloroethane and methylene
chloride) with units containing aluminium or galvanized and zinc-plated parts. They may
react chemically thus producing an explosion danger.
Read the classication and information leaet concerning the product and solvent to be
used.
4.2.6 TOUCHING HOT SURFACES
Touch hot surfaces only if you are wearing protective gloves.
When operating the unit with a coating material with a temperature of > 43 °C; 109.4°F:
- Identify the unit with a warning sticker "Warning - hot surface".
Order No.
9998910 Instruction sticker
9998911 Protection sticker
Note: Order the two stickers together.

15
OPERATING MANUAL
VERSION 12 / 2012 ORDER NUMBER DOC 2332848
4.3.1 SAFETY REGULATIONS
4.3 USE IN AREAS SUBJECT TO EXPLOSION HAZARDS
Only the pneumatic double diaphragm metallic pumps (aluminium and stainless steel)
and conductive acetal versions can be used in explosion hazard zones.The following safety
regulations must be observed and followed.
Safe handling of WAGNER spray units
Mechanical sparks can form if the unit comes into contact with metal.
In an explosive atmosphere:
Do not knock or push the unit against steel or rusty iron.
Do not drop the unit.
Use only tools that are made of a permitted material.
Ignition temperature of the pumped material
Check that the ignition temperature of the pumped material is higher than the max.
allowable surface temperature.
Medium supporting atomizing
To atomize the material, use only weakly oxidizing gases, e.g. air.
Surface spraying, electrostatic
Do not spray system parts with electrostatic.
4.2.11 TIGHTNESS CHECK
4.2.12 MAINTENANCE
When using the pump after a long period of inactivity, check tightness of all parts subject
to pressure.
Depending on the type of use and the substances used, the user has to check for the
presence of deposits on the pump as well as check its cleanliness at regular intervals and
the state of wear of the components and proper operation of the pump assembly.
The operation has to be carried out in conformity with what is written in this manual.

16
OPERATING MANUAL
VERSION 12 / 2012 ORDER NUMBER DOC 2332848
4.3.2 OPERATION WITHOUT FLUID
4.3.3 MAXIMUM SURFACE TEMPERATURE
4.3.4 MAXIMUM SURFACE TEMPERATURE  EXOTHERMIC REACTIONS
4.3.5 CONNECTION PIPES
4.3.6 PUMP PROTECTION
Avoid running the pump sucking air, without uid inside. The air, combined with the
vapour of ammable uids, can generate internal areas with an explosion hazard.
Periodically check that the pump is working regularly, paying special attention to the
presence of air in the pumped uid, which may be caused by a breakage in the pump.
Avoid operating the pump with damaged diaphragms.
The maximum surface temperature of the pump depends on the temperature of the
pumped uid, that must not exceed the values indicated in the section "Technical Data".
Fluids incompatible with the pump’s materials or particularly reactive mixtures of products
with several components may cause exothermic reactions and develop dangerous
temperatures or pressure.
Connection pipes must be made of conductive material and properly grounded.
Pumping uids can contain solid particles, which could damage the internal parts of the
pump.The suction lter prevents solid bodies which are too large from entering the pump.
Refer to the paragraph Technical Data to verify the maximum size of solids that can be
pumped.
Keep metal surfaces clean. Electric conductivity of the surfaces is essential for explosion
protection.
Frequently clean the equipment so as to prevent insulating substance residue from
accumulating.
Do not use rusted parts or metal tools that may cause sparks of a mechanical origin inside
the explosion hazard area.
Cleaning
If there are deposits on the surfaces, the unit may form electrostatic charges. Flames or
sparks can form during discharge.
Remove deposits from the surfaces to maintain conductivity.
Use only a damp cloth to clean the unit.

17
OPERATING MANUAL
VERSION 12 / 2012 ORDER NUMBER DOC 2332848
5 DESCRIPTION
5.1 AREAS OF APPLICATION
5.2 SCOPE OF DELIVERY
5.3 DATA
Abrasive materials and pigments!
Greater wear of the material transporting parts.
Use the application-oriented model (ow rate/cycle, material, valves, etc.) as
indicated in Section 5.3.2.
Check if the uids and solvents used are compatible with the pump construction
materials as indicated in Section 5.3.1.
NOTICE
- Diaphragm pump
- Suction hose with lter
- On ZIP52 Finishing: Fine-Flow Controller FFC (precisely adjustable lter ow controller
with lter and integrated pulsation damper)
- On ZIP52PF Eco-Finishing: Materiallter (as an alternative to the above-mentioned FFC)
- Connection elements
- On ZIP52 PF Eco-Finishing: stand
CE Conformity see Chapter 12
Operating manual German Order No.: 2332847
Operating manual for other languages see Chapter 1
The delivery note shows the exact scope of delivery.
Accessories: see Chapter 10
5.3.1 MATERIALS OF THE FLUID TRANSPORTING PARTS
Pump No. Pump body Diaphragm Diaphragm disc Valve seat Valve ball O-rings
U550.AHSS0-A Aluminium UHMWPE PPS Stainless steel Stainless steel PTFE
U550.SHSS0-B Stainless steel UHMWPE PPS Stainless steel Stainless steel PTFE
U552.GHSS1 Acetal (POM) UHMWPE POM Stainless steel Stainless steel PTFE
U551.AHSS1 Aluminium UHMWPE PPS Stainless steel Stainless steel PTFE
Positions of the individual parts: see spare parts list.

18
OPERATING MANUAL
VERSION 12 / 2012 ORDER NUMBER DOC 2332848
Description Unit
U760.00 U765.00 U773.00 U731.00
Wetted parts materials Aluminum Stainless
steel
Conductive
acetal Aluminum
Transmission ratio 1:1 1:1 1:1 1:1
Flow volume per double stroke
(DH)
cm³ 108 108 108 62
cc
Maximum operating pressure MPa 0.8 0.8 0.8 0.8
bar 8 8 8 8
psi 116 116 116 116
Maximum possible speed DH/min 490 490 490 490
Maximum ow rate (1) l/min 52 52 52 28
(free ow - ooded inlet) (5) GPM 13.7 13.7 13.7 7.4
Minimum air inlet pressure MPa 0.15 0.15 0.15 0.10
bar 1.5 1.5 1.5 1.0
psi 22 22 22 15
Maximum air inlet pressure MPa 0.8 0.8 0.8 0.8
bar 8 8 8 8
psi 116 116 116 116
Air inlet connection BSP(G) 1/4" F 1/4" F 1/4" F 8 mm
Maximum suction height (2) m 4.8 4.8 4.8 2.8
feet 15.7 15.7 15.7 9.2
Maximum solid body size (5) mm 2.0 2.0 2.0 2.0
inches 0.08 0.08 0.08 0.08
Sound pressure equivalent
50cycles/min. (feeding 5 bar)
(3)
(5) dB(A) 73 73 73 73
Sound pressure equivalent
maximum ow rate (feeding 8 bar)
(3)
(5) dB(A) 85 85 85 85
Sound power at maximum ow
rate (feeding 8 bar)
(4)
(5) dB(A) 99 99 99 99
Fluid connections BSP(G) 1/4" M 1/4" M 1/4" M 1/4" M
Weight kg 9 11.8 8.9 7.9
lb 19.8 26 19.6 17.4
Material temperature °C +4 ÷ 90 +4 ÷ 90 +4 ÷ 80 +4 ÷ 90
°F +39 ÷ 194 +39 ÷ 194 +39 ÷ 176 +39 ÷ 194
Ambient temperature °C +4 ÷ +40
°F +39 ÷ +104
Allowable inclination for operation 10°
(1) PF = Perfect Flow = low pulsation pump with a shorter stroke
(2) Pump with stainless steel valves (start condition: empty pump / dry valves)
(3) LqA (10s)
(4) ISO 3744
(5) Technical data apply to the pump without using a lter
5.3.2 TECHNICAL DATA

19
OPERATING MANUAL
VERSION 12 / 2012 ORDER NUMBER DOC 2332848
Outgoing air containing oil!
Risk of poisoning if inhaled.
Air motor switching problems.
Provide compressed air free from oil and water
(Quality Standard 5.5.4 according to ISO 8573.1)
5.5.4 = 40 μm / +7 / 5 mg/m³.
WARNING

20
B_04046
BC
AE
FGG
D (x4)
H
B_04047 B
A
C
D
E
OPERATING MANUAL
VERSION 12 / 2012 ORDER NUMBER DOC 2332848
5.3.3 DIMENSIONS AND CONNECTIONS
ZIP52 Finishing on the trolley
