Wahsega WL-ZN-CTR-1CH-INF-R Assembly instructions

InformaCast Zone Controller Installation Guide Page 1 11.11.2020
IP Paging Zone Controller
with InformaCast®
Installer’s Guide
Getting Started
This step-by-step guide will help you install your
Wahsega IP Paging Zone Controller with InformaCast.

InformaCast Zone Controller Installation Guide Page 2 11.11.2020
What’s in the Box
(1) IP Paging Zone Controller
(1) 2-Pin male connector
(1) 6-Pin male connector
(1) 8-Pin male connector
(1) Ferrite cable clamp

InformaCast Zone Controller Installation Guide Page 3 11.11.2020
What You Will Need
PoE power
Power-over-Ethernet (PoE 802.3af) switch
Remote communication point
InformaCast Server
Network cable (Cat 5e or Cat 6)
Audio cable(s) with RCA mono male connector

InformaCast Zone Controller Installation Guide Page 4 11.11.2020
Wiring
Power
Option A: To use Power-over-Ethernet (POE 802.3af), route a Cat 5e or
Cat 6 Ethernet cable from a PoE switch or injector to the LAN port.
Option B: Alternately, use the included 2-pin male connector to
connect +9-16VDC and Ground wires for power. Use standard
(unpowered) Ethernet for data.
NOTE: Use either POE or 9-16V for power. DO NOT USE BOTH.
Status
The status LED will increase in brightness as the zone controller is
powering up and will remain steadily lit when the unit is successfully
powered.
Status
LED
Ethernet or POE
If using Power Option A = POE 802.3af
If using Power Option B = Ethernet
Do Not
Use
Power
Option B
Reset

InformaCast Zone Controller Installation Guide Page 5 11.11.2020
Audio Outputs
LINE OUT (unbalanced) –Connect to amplifier via RCA mono
connector. Configure audio settings in configuration webpages as
described in User’s Guide.
RELAY (Single Channel Zone Controller only) –The relay connector is a
3-pin male connector (included), wired to a Form C relay (SPDT) with
contacts rated for 30VDC or 270VAC at 3A.
Pin 1 is a Normally Closed (NC) dry contact closure.
Pin 2 is Common.
Pin 3 is a Normally Open (NO) dry contact closure.
STAT –LED will illuminate when audio is being passed. The steadier the
STAT LED, the stronger the audio signal present.

InformaCast Zone Controller Installation Guide Page 6 11.11.2020
Dimensions
Front
Rear

InformaCast Zone Controller Installation Guide Page 7 11.11.2020
Side

InformaCast Zone Controller Installation Guide Page 8 11.11.2020
Standards Compliant
This product is designed and manufactured in the USA.
ROHS compliant
Temperature rating -40C to +60C.

InformaCast Zone Controller Installation Guide Page 9 11.11.2020
Wahsega IP Paging Zone Controller
With InformaCast
WL-ZN-CTR-1CH-INF-R
WL-ZN-CTR-2CH-INF
Installation Guide
