Insert the wood dowel (A) and cam bolts (B) to the top panel (1) and slat (22).
Insert the wood dowel (A) and cam bolts (B) to the bottom panel (2) and slat (23).

Insert the wood dowel (A) and cam bolts (B) to the legs (3,4).
Insert the wood dowel (A) and cam bolts (B) to the side panels (5,6) and panel (7).

Assemble the support panel (6) to the side panels (5,6) and secure it by cam locks (C).
Attached the support beam (23) to the bottom panel (2) and secure it by the cam locks (C).
Screw support legs (14) into bottom panel (2).

Attached the side panels (5,6) to the bottom panel (2) and secure it by the cam locks (C).
Attached the support beam (22) to the side panels (5,6) and secure it by the cam locks (C).

Attached the leg (3) to the bottom panel (2) and the support beam (22) and secure it by
cam locks (C).
Attached the leg (4) to the bottom panel (2) and the support beam (22) and secure it by
cam locks (C).

22
Place the top panel (1) on top of the side panels (3,4,5,6) and secure it by cam locks (C).
Assemble the top panel (1) to the support beam (22) and secure it by screw (E).
Secure back panels (11,12) using screws (D).Tighten screws (D) with a screwdriver.

Secure back panel (10) using screws (D).Tighten screws (D) with a screwdriver.
Secure back panel (9) using screws (D).Tighten screws (D) with a screwdriver.

Secure cam bolts (B) into panel (17), Attach handles (H) to panel (17) using bolts (J).
Tighten cam bolts (B) and bolts (J) with a screwdriver.
Attach panels (19, 20) to panel (18) using screws (E). Tighten screws (E) with a screwdriver.

Inserts the drawer bottom panels (21) to the slots of the drawers side panel (19,20).Attached
the drawers side panel (19,20) to the drawers front panel (21) and secure it by cam locks (C).
Use the stickers (N) to cover the cam locks of the unit.

Slide in the the drawers to the unit carefully.
Inserts the shelf support pin (K) to the side panels and place the shelf (8, 13) on top.

Attached the hinge (F) to the doors (15, 16) and secure it by screw (G). Attach handle (L) to
drawer the doors (15,16) using bolts (M). Tighten screws (G) and bolts (M) with a screwdriver.
Assemble the door (15) to the leg (3) by using screw (G).

Assemble the door (16) to the leg (4) by using screw (G).
