Walker Edison B48MXEB User manual

.1
Assembly Instructions
Item # : B48MXEB
Revised 26/04/2019 (E)
Copyright © 2019 by Walker Edison Furniture Co., LLC. All rights reserved.
lease visit our website for the most current instructions, assembly tips, report damage,
or request parts. .alkeredison.com
Walker Edison
TM

VIII. Drill may be needed for securing product to wall.
.2
General Assembly Guidelines
I. Ensure that all parts and hardware are available before beginning assembly.
II. Follow each step carefully to ensure the proper assembly of this product.
21
III. Two people are recommended for ease in the assembly of this product.
IV. The three main types of hardware used to assemble this product are: wood
dowels, screws and bolts.
V. The provided glue is to secure wood dowels in place. When first inserting dowels,
locate the appropriate hole for the dowel, place a small amount of glue in the hole
and insert the dowel. Wipe away excess glue immediately.
In future assembly steps when dowels are necessary to attach assembly parts
together, place a small amount of glue on the end of the dowel before attaching
parts together. Wipe away excess glue immediately.
VI. A hillips head screwdriver is required for the assembly of this product .
VII. ower tools should not be used to assemble this product.
Copyright © 2019, by Walker Edison Furniture Co., LLC. All rights reserved.

.3
Copyright © 2019, by Walker Edison Furniture Co., LLC. All rights reserved.
arts List
1
10
5
4
3
7
6
2
8
9
11
9
8

Hardware List
The hardware quantities listed above are required for proper assembly.
Some extra hardware may also have been included.
A
hilips head screwdriver required for assembly
(not included)
.4
12 pcs Wooden dowelØ8x30mm
Copyright © 2019, by Walker Edison Furniture Co., LLC. All rights reserved.
B 8 pcs Cam boltØ6x35mm
C 8 pcs Cam lockØ15x11mm
D 8 pcs StickerØ30mm
E 6 pcs ScrewØ6x50mm
F 1 pc Hex KeyM 4
G 8 pcs BoltØ6x15mm
H 8 pcs Ø6x15mm
J 4 pcs L shape bracket
K 6 pcs lastic wedge
L 6 pcs ScrewØ3x17mm
M 1 pc Glue tube
Bolt

Step 1
.5
Copyright © 2019, by Walker Edison Furniture Co., LLC. All rights reserved.
B
B
B
B
1
Using cam bolt (B) secure part (1) with Philips head screwdriver .

Step 2
.6
Copyright © 2019, by Walker Edison Furniture Co., LLC. All rights reserved.
A
A
A
A
B
J
G
B
J
G
B
J
G
B
J
G
F
4
5
6
7
Attach cam bolts (B) to parts (4,5,6,7) using Phillip’s head screwdriver. Then attach bracket (J) to
parts (4,5,6,7) using bolts(G) and hex key (F) as per diagram.

Step 3
.7
Copyright © 2019, by Walker Edison Furniture Co., LLC. All rights reserved.
FF
H
HH
H
4
4
5
8
8
Using bolt (H) secure part (8) to part (4) ,then secure to part (5) as per diagram.

Step 4
.8
Copyright © 2019, by Walker Edison Furniture Co., LLC. All rights reserved.
FF
H
H
H
H
6
6
7
8
8
Using bolt (H) secure part (8) to part (6) ,then secure to part (7) as per diagram.

Step 5
.9
Copyright © 2019, by Walker Edison Furniture Co., LLC. All rights reserved.
311
A
AA
Edge banding
A
AA
A
A
Edge banding
Insert wooden dowel (A) to part (3,11) as per diagram.

Step 6
.10
Copyright © 2019, by Walker Edison Furniture Co., LLC. All rights reserved.
E
E
F
2
9
9
Attach part (9) to part (2) using screw (E) and hex key (F) .

Step 7
.11
Copyright © 2019, by Walker Edison Furniture Co., LLC. All rights reserved.
E
E
E
E
F
2
3
11
Using screw (E) secure parts (2) to part parts (3,11) using hex key (F) .

Step 8
.12
Copyright © 2019, by Walker Edison Furniture Co., LLC. All rights reserved.
C
C
21 3
2
6
7
Using cam lock (C) connect part (2) to parts (6,7) as per diagram.

Step 9
.13
Copyright © 2019, by Walker Edison Furniture Co., LLC. All rights reserved.
C
C
21 3
2
4
5
Using cam lock (C) connect part (2) to parts (4,5) as per diagram.

Step 10
.14
Copyright © 2019, by Walker Edison Furniture Co., LLC. All rights reserved.
2
5
7
10
Insert part (10) to parts (2,5,7) as per diagram.

Step 11
.15
Copyright © 2019, by Walker Edison Furniture Co., LLC. All rights reserved.
CC
CC
F
G
G
G
G
J
J
J
J
21 3
1
311
4
5
6
7
F
G
J
Put part (1) to parts (3,4,5,6,7,11) ,and using bolt (G) secure L shape bracket (J) with hex key
(F) as per diagram .

Step 12
.16
Copyright © 2019, by Walker Edison Furniture Co., LLC. All rights reserved.
K
K
L
10
Using screw (L) secure plastic wedge (K) to part (10) with Philips head screwdriver
as per diagram.

Step 13
.17
Copyright © 2019, by Walker Edison Furniture Co., LLC. All rights reserved.
D
D
D
D
D
D
Place sticker (D) cover the holes as per diagram.

Step 14
.18
Copyright © 2019, by Walker Edison Furniture Co., LLC. All rights reserved.
Final Assembly
