WALLYS DR5018 User manual

DR5018
1.IPQ5018 UI settings
2.DR5018 UART configuration
THIS DOCUMENT CONTAINS PROPRIETARY TECHNICAL INFORMATION, WHICH IS THE PROPERTY OF
THE WALLYSTECH AND SHALL NOT BE DISCLOSED TO OTHERS IN WHOLE OR IN PART, REPRODUCED,
COPIED, OR USED AS THE BASIS FOR DESIGN, MANUFACTURING, OR SALE OF APPARATUS WITHOUT
WRITTEN PERMISSION OF WALLYSTECH.

www.wallystech.com 1
Wallys | User Manual | DR5018
IPQ5018 UI setting
• IP Setting: setting IP in the path "network->Interfaces->LAN-
>IPV4 address"
• DHCP setting:DHCP and other protocol setting in the path
network-> Interfaces-> LAN->protocol”
1.Input the IP 192.168.1.1 and login
2.Input the username “admin” password
“password” then press the button “Login”
3. Network setting

www.wallystech.com 2
Wallys | User Manual | DR5018
IPQ5018 UI setting
login the path network->Interfaces->WIFI, then choose one
wifi,we select
the red marked as example,click the button ‘Edit’
4. Wireless setting

www.wallystech.com 3
Wallys | User Manual | DR5018
IPQ5018 UI setting
The detail information show in the picture as below:
• Channel:for channel select;
• Transmit Power:signal chain power setting; ESSID:for ID
• Mode:it support 4 mode AP,AP(WDS),client,client(WDS)
Wireless
• Security: for Encryption setting

www.wallystech.com 4
Wallys | User Manual | DR5018
IPQ5018 UI setting
In advance setting you can select which chain do you
need,which BW do you need and so on
In the end, you need click the button “Save & Apply”, and wait
for 2 minutes, then you can enjoy it.

www.wallystech.com 5
Wallys | User Manual | DR5018
IPQ5018 UI setting
Login System->Backup/Flash Firmware;
Then click the button “Generate archive”
Then download the archive
5. Backup archive

www.wallystech.com 6
Wallys | User Manual | DR5018
IPQ5018 UI setting
Login System->Backup/Flash Firmware;
Then click the button “ flash image”
Then click the button “Proceed” warning don't power off wait for
about three minutes
Then the system will reboot automatic.
Then login again,you can enjoy it.
6.Update new image

www.wallystech.com 7
Wallys | User Manual | DR5018
IPQ5018 UI setting
Login System->Network/wifi/Edit->Choose 5G radio
Country Coad choose “ US ” click the button“Wireless Security”
Then choose “WPA3” and set password
Notice:SAE/SAE PWE/SAE MFP click “ √ ”
7. wireless encryption

www.wallystech.com 8
Wallys | User Manual | DR5018
IPQ5018 UI setting
7. wireless encryption

www.wallystech.com 9
Wallys | User Manual | DR5018
DR5018 UART configuration
The photo below shows how to use the Uart for DR5018
1. Introduction

www.wallystech.com 10
Wallys | User Manual | DR5018
DR5018 UART configuration
2. Device connect
Step 1:Connect the cable to the DR5018
As the picture as above,the sequence of the signal in the
UART
Connector:GND,TX,RX,VCC, And we need use GND connect
black cable,TX connect to white cable,RX connect to
Green cable VCC don't use.
Step 2:Check the Com number on the PC
Connect the console board to the PC with USB connector,
Then check the com number on the PC,the com number on the
test PC is COM15

www.wallystech.com 11
Wallys | User Manual | DR5018
DR5018 UART configuration
2. Device connect
Step 3 Login with the software
You can use putty,Xshell or some others,enjoy it.

DR5018
