wampol Nana VAGABUND Easy Cross ALU User manual

WARRANTY CARD
CART PRAM „VAGABUND Easy Cross ALU”
● COMFORT FOR YOUR CHILD ●
CONGRATULATE!
Please to know the manual and preserve for the future
to clarify any doubts.
We are confident that you have made the right choice with our product
and your child in a NANA - baby pram is safe.
Would you have still problems, set up, please contact your dealer.
in accordance with EN-1888: 2003/A1,A2,A3: 2005

General safety:
Parents are responsible for their children.
Please follow these instructions to ensure the child’s safety. Of course, not all conditions are met. Caution, supervision and
thoughtfulness are qualities that can not ensure this product. This is a requirement of Public Safety, in dealing with children.
Caution
- It is risky to leave a child unattended.
- As soon as the child can sit unaided , the seat belt should always be used . See Section : „Handling the 5-point - belt „ .
- During the trip, the bag / carrying tray must always be attached to the frame fix (left and right are buckles in the carrycot 4 locks) .
- All locks must be locked .
- The baby pram is intended solely for a child.
- The seat unit or the bag may not be used in the baby pram.
- Children under 6 months should not use the baby pram seat . The pushchair seat is for a child at the age of about 6 months to about 3 years
(15 kg) intended . We recommend that you place the child until an independent seat capacity in the pushchair seat . Up to the age of
6 months is to use a carrying case.
- Carrying bags or children’s and sports baby pram are not bed or cradle replacement .
- The baby pram is not intended as a Game Show for children and should therefore be out of reach for children.
- Prior to the shutdown of the baby pram the brake is to be determined. Check that the brake is engaged.
- When placing therein or removing your child from the baby pram, the brakes should always be observed.
- The turning the baby pram off at a slope should be avoided.
- In public transport the baby pram should always have a firm foothold .
- Do not use other than those contained in the delivery or manufacturer-approved accessories and replacement parts.
- When stairs the baby pram should be rolled mindful.
- On the handlebar mounted ballasts affect the stability of the baby pram.
- Put on the deck never from utensils .
- The maximum load on the network is 5 kg .
- We would also like to point out that the use of a child or sports baby pram on the customary use of addition could be dangerous.
The baby pram is not suitable for running or skating.
- When setting up and collapsing the baby pram you should be careful not to pinch others.
- Too heavy loads , inadequate folding or the use of non-approved accessories can the baby pram damage or ruin .
- The footrest is not there to transporting children or any ballast .
- Before you start, please remove all tags and tapes that have nothing to do with safety instructions .
- The Fußstützte is neither to raise nor to carry the baby pram there.
Important information for use:
Erection of the frame
Drag the slider up until the lock is engaged. Check yet before use if all locks
are actually closed.
Collapsing the frame
Tighten the two draw sleeves on both sides simultaneously high.
Folding and design of the frame
www.wampol.eu
www.babynana.eu
Height adjustment of the slide
Attachment (move bar)
1
2
3
4
● COMFORT FOR YOUR CHILD ●

Assembly and disassembly of the wheels
Before assembly and disassembly, the detent spring must be pressed.
Seat cover
The cover can be completely removed from the seat unit to wash him.
Caution: When mounting the reference is not to forget to pull the straps through the
respective gaps.
Height adjustable and foldable slide
Press the adjuster knobs and move the slider to the desired position.
Apply the parking brake
The brake is activated by depressing the brake long wing.
When it comes to minor problems when you press the brake, push the baby pram back
and forth a little. Make sure that the brake is engaged. The brake is released again by
stepping down the wing.
Important: The manufacturer is recommended to occasionally spray the brake cable
with a silicone spray.
Application of the folding
Insert the male parts of the top joints in the corresponding, appropriate places on the
tubes.
Caution: Fix getting the push buttons on the rear side of the backrest (Drop-out protec-
tion). To provide assembly / disassembly of the hood / take the screw purely / out along
with the spring as it is stated on the image („Mounting the hood”).
Important: Please do not screw together too!
Important: When adjusting the roof should be supported with the other hand the
center bracket.
Backrest adjustment
To raise the backrest, pull the free end of the strap. To tilt the brake.
Adjustable footrest
To get the lying position, raise the foot rest up and press the bracket.
Application of the 5-point belt
To release the belt, press the two lock. Put you into the child and give them his hands
through the corresponding loops. Now close the strap through the locks stuck together.
The belt can be changed by the adjuster will.
Caution: Always use the crotch together with the waist belt. Otherwise there is only
diminished safety for the child.
Guard
Insert the small parts of the safety bar into the holes on the seat
Caution: Make sure that the guard snaps on both sides. To remove, press the release
buttons on the insert parts. In order to facilitate the entry and exit of your child, it is
sufficient to solve one side of the strap and fold up.
Adjustment of the backrest
Brake circuit. Assembly and disassembly of the wheels
Handling of the 5-point belt
www.wampol.eu
www.babynana.eu
Installation of the hood
Important:
Correct assembly of the folding parts
(part 5).
Please not too strong bolt together!
Variation: Child car seats (group 0 +)
Roof with (concealable) mosquito net use
Adjustable backrest of the carrycot (3-position)
● COMFORT FOR YOUR CHILD ●

Construction
Put the top onto the frame, put the parts into the small holes until it clicks. To take down the frame, press the four red
buttons
Warning: Before you use must always be checked if the seat bracket is actually engaged. The upper part is located in the
secured state, when the red box is no longer visible behind the detents. Then try the side-mounted on the backrest straps
once from inside to outside to the slide tube and close the button. Then put the pieces of fabric from the inside out to the
slide tubes and also close the snaps. To remove the front cover, please press the locking levers to stop down. Then pull the
top part of the incisions and take it off.
General
The baby pram has been tested in a temperature range from -20 ° C to +60 ° C . Despite many positive characteristics of
our materials such as air permeability, etc. many textiles react to intense sunlight sensitive. It is better to avoid the sun for
longer stays, and maintain the fresh colors of your baby pram. Between the individual production batches to color differen-
ces can not be avoided. Unfortunately Corresponding complaints can not be accepted. Please understand that improper
handling, any rain edges or color differences in the material , as described above , are not a legitimate complaint. Regular
maintenance of all metal parts , especially the chrome parts and especially after spending time by the sea, on the baby pram
is required to get the high-quality optics . Commercially available cleaning agents are sufficient . Small kits for repairing any
damage to the paintwork on the frame you can contact the dealer . The shaft ends must be cleaned at intervals of about 4
weeks and lightly oiled .
6) Loss of small parts during maintenance errors
7) Damage caused by operator error.
8) Repairs by unauthorized third parties.
9) Warranty does not apply to attempt repairs your-
self.
construction
Adjustment of the bracket and footrest
www.wampol.eu
www.babynana.eu
Adjustable suspension 2 position (hard and soft)
WARRANTY CONDITIONS
These instructions are part and condition of warranty. Complaints are generally handled by the dealer.
Design errors that were found during the warranty period will be repaired within 4 weeks.
The warranty does not include:
1) Wear by abrasion.
2) Damage due to improper storage.
3) Mechanical and thermal defects.
4) Rust by poor maintenance and road salt in winter.
5) Color fading due to UV degradation.
stamp signature
charging: .................. the buyer: .................. sale date: ..................
THE WARRANTY CARD IS INVALID WITHOUT SALES DATE STAMP!
● COMFORT FOR YOUR CHILD ●
