Waring CB15 SERIES User manual

1 GALLON BLENDERS WITH SPIGOT
LICUADORAS DE 4 L CON GRIFO
MÉLANGEURS DE 4 L AVEC ROBINET
120V
For your safety and continued enjoyment of this product,
always read the instruction book carefully before using.
Para su seguridad y para disfrutar plenamente de este producto,
siempre lea las instrucciones cuidadosamente antes de usarlo.
Afin que votre appareil vous procure en toute sécurité beaucoup de satisfaction,
lire attentivement le mode d’emploi avant de l’utiliser.
CB15 SERIES
SERIE CB15
SÉRIE CB15

2
IMPORTANT SAFEGUARDS
When using electrical appliances, basic safety precautions
should always be taken, including the following:
1. READ ALL INSTRUCTIONS.
2. Unplug from outlet when not in use, before putting
on or taking off parts, and before cleaning.
3. To protect against electrical hazards, do not immerse
the blender base in water or other liquids.
4. Avoid contact with moving parts.
5. Do not operate any appliance with a damaged cord or
plug, or after the appliance malfunctions or is dropped
or damaged in any manner. Return appliance to the
nearest authorized service facility for examination, repair
or electrical or mechanical adjustment.
6. The use of attachments, including canning jars, not
recommended by the appliance manufacturer may
cause hazards.
7. Do not use outdoors.
8. Do not let cord hang over edge of table or counter, or
touch hot surfaces.
9. Keep hands and utensils out of container while blending
to prevent the possibility of severe personal injury and/or
damage to the blender. A rubber scraper may be used
but must be used only when the blender is not running.
10. Blades are sharp. Handle carefully.
11. Always operate blender with cover in place.
12. When blending hot liquids, completely remove the
stopper in the cover before turning on the blender.
See Hot Blending Instructions, page 12.
13. This appliance is not intended for use by persons
(including children) with reduced physical, sensory
or mental capabilities, or lack of experience and
knowledge.

3
14. Children should be supervised to ensure that they do not
play with the appliance.
15. DO NOT use carbonated liquids in the blender jar or
any blending container. Using carbonated liquids in the
included blender jar or any other compatible blender jar
may result in injury.
16. DO NOT blend oil or oil-based products such as peanut
butter for greater than 5 minutes.
17. Never remove blender jar from base unit until the blade
and coupling have completely stopped.
18. Spigot assembly must be handwashed only. Do not run
the spigot through the dishwasher.
19. The contents of the blender cannot reach beyond 140˚F
when operating with a spigot. Note that when blending
the temperature of the contents will increase due to the
friction of the blade.
SAVE THESE INSTRUCTIONS
SPECIFICATIONS
• Capacity: 4 Litre Working Capacity
• Rating: 120 Volts–60HZ–Single Phase AC –15.0 Amps.
(U.S. models only)
• Base: Die-cast – grey coating
• Container: Stainless steel with stainless steel blades –
rubber clamp-on lid
• Bearing: High-performance ball bearing
• Cord: 7 foot (2.44 m) – 3-conductor ground cord with
strain relief in base
• Overall Height: 26 inches (66 cm)
• Weight: 38 pounds (17.2 kg) net
Shipping Weight 41 pounds (18.6 kg)
• cETLus, NSF, Listed
• Operating Cycle: 3 min ON/1 min OFF

4
120V GROUNDING INSTRUCTIONS
For your protection, this appliance is equipped with a
3-conductor cordset.
120-volt units are supplied with a molded 3-prong
grounding-type plug (NEMA 5-15P) and should be used
in combination with a properly connected grounding type
outlet as shown in Figure 1.
If a grounding type outlet is not available, an adapter, shown
in Figure 2, may be utilized to enable a 2-slot wall outlet to
be used with a 3-prong plug. (Note: Use of an adapter is
not permitted in Canada and Europe.)
Referring to Figure 3, the adapter must be grounded by
attaching its grounding lug under the screw of the outlet
cover plate.
Caution: Before using an adapter, it must be determined
that the outlet cover plate screw is properly grounded. If in
doubt, consult a licensed electrician. Never use an adapter
unless you are sure it is properly grounded.
Green/Yellow: Earth Ground • Blue: Neutral • Brown: Live
Note: User-installed cordset plugs are not permitted
in Europe.

5
SPIGOT ASSEMBLY (FOR SF MODELS ONLY)
Your spigot assembly includes the main spigot housing,
O-ring and rubber insert.
1. Plastic Feed Cap
2. Vinyl Lid
3. Metal Clamps
4. Spigot Adapter
5. O-ring
6. Spigot housing
7. Lever
8. Rubber Insert
1
2
3
4
8
7
6
5

6
SPIGOT ASSEMBLY (FOR SF MODELS ONLY)
Your spigot assembly includes the main spigot housing,
O-ring and rubber insert.
The O-ring comes assembled
in the jar spigot adapter but
can be removed for cleaning.
Always make sure the O-ring
is positioned securely in the
adapter on the jar before
inserting and operating the
spigot function. Figure 1.
The rubber insert has two loops
on the inside to t the lever
(refer to gure 2). The lever only
needs to be positioned into the
bottom loop. In the event that
one loop breaks, you can ip
the insert upside down and use
the other loop.
To assemble the rubber insert
pinch both sides as seen in
gure 3 and position the insert
inside the housing so that the
lever slides inside the rubber
insert and the bottom loop (for
the lever) is near the spigot
hole. Be sure that the bottom
of the rubber insert is ush
with the bottom of the spigot
housing.
Push the bottom of the lever
through the bottom loop of the
rubber insert.
g. 1
g. 2
g. 3
g. 4

7
Once assembled, insert the
spigot into the adapter on the
jar and rotate clockwise until
the spigot completely stops
as shown in gure 5.
CB15/CB15SF OPERATION
1. Before starting, make sure that the blender cord is
unplugged.
2. Position container assembly on
motor base so that it is rmly
seated and not tilting to one side.
Plug blender cord into outlet.
3. Put ingredients into container.
Always add liquid ingredients rst, unless otherwise
specied in recipe. Do not ll above MAX line.
Place cover securely on container and fasten the
cover clamps.
4. Press the STANDBY button to turn on the blender.
Green LED will illuminate. For continuous operation,
press either the LOW, MED, or HIGH button. When
nished blending, press STOP. For momentary
operation, press the PULSE button; motor will run
on HIGH speed until the button is released.
Note: Your CB15 utilizes a Slow Start™ feature.
When pressing MED or HIGH, the unit will start in the
LOW position for 1 second and then switch to the
setting selected. This allows for a more even blending
of ingredients in container.
5. Always hold container with one hand when starting
and while blending. Never operate without jar lid
properly clamped in place.
g. 5

8
6. Allow motor to come to a complete stop before
removing container. Never place the container on the
motor base or remove it from the motor base while
the motor is running.
7. Press the STANDBY button again to turn off the
blender.
8. Remove the container from the motor base and
empty the contents.
9. Wash and dry container after each use, according to
Cleaning and Sanitizing Instructions, page 13.
10. Not for waterjet cleaning.
11. The use of ear protection is recommended during
extended operating periods.
Spigot Instructions
When pouring jar contents through the spigot, simply
push the lever toward the blender jar. If contents are
too thick, it can be difcult to pour through the spigot.
Running the blender on LOW while pouring can help
the ow. Make sure to always have the lid positioned on
the blender with the clamps locked when running the
blender.
CB15T/CB15SF OPERATION
1. Before starting, make sure that the blender cord is
unplugged.
2. Position container assembly
on motor base so that it is
rmly seated and not tilting
to one side. Plug blender cord
into outlet.

9
3. Put ingredients into container. Always add liquid
ingredients rst, unless otherwise specied in recipe.
Do not ll above MAX line. Place cover securely on
container and fasten the cover clamps.
4. Press the STANDBY button to turn on the blender.
Press the UP arrow or DOWN arrow. The initial time
will be 10 seconds.
5. Push the UP arrow to set the time required. The timer
will advance only in 10-second intervals. Timer can be
set to the maximum of 3 minutes.
6. Select and press a speed button; the blender will
start and run for that selected time. It will count
down in 1-second intervals and stop at 0. NOTE: If
you want to increase or decrease time while timer is
counting down, press UP or DOWN arrows. Timer will
increase or decrease in 10-second intervals. After
5 seconds the timer will turn off and return to manual
mode.
7. When using the timer again, the initial time will be the
last time set. NOTE: If unit has been unplugged, the
timer will default back to 10 seconds.
8. Always hold container with one hand when starting
and while blending. Never operate without container
lid properly clamped in place.
9. Allow motor to come to a complete stop before
removing container. Never place the container on the
motor base or remove it from the motor base while
the motor is running.
7. Press the STANDBY button again to turn off the
blender.
8. Remove the container from the motor base and
empty the contents.

10
9. Wash and dry container after each use, according to
Cleaning and Sanitizing Instructions, page 13.
10. Not for waterjet cleaning.
11. The use of ear protection is recommended during
extended operating periods.
Spigot Instructions
When pouring jar contents through the spigot, simply
push the lever toward the blender jar. If contents are
too thick, it can be difcult to pour through the spigot.
Running the blender on LOW while pouring can help
the ow. Make sure to always have the lid positioned on
the blender with the clamps locked when running the
blender.
CB15V/CB15SF OPERATION
1. Before starting, make sure that the blender cord is
unplugged.
2. Position container assembly
on motor base so that it is
rmly seated and not tilting
to one side. Plug blender cord
into outlet.
3. Put ingredients into container. Always add liquid
ingredients rst, unless otherwise specied in recipe.
Do not ll above MAX line. Place cover securely on
container and fasten the cover clamps.
4. Press the green STANDBY button to turn on the
blender. Green LED will illuminate and remain steady.
Select the desired speed with the variable speed
control knob. Press the red START/STOP button to
begin blending. You may change the speed with the
variable speed control knob anytime during blending.
When nished blending, press START/STOP button.

11
For momentary operation, press the grey PULSE
button; motor will run on HIGH speed until the button
is released. The green LED will blink during operation.
5. Always hold container with one hand when starting
and while blending. Never operate without container
lid properly clamped in place.
6. Allow motor to come to a complete stop before
removing container. Never place the container on the
motor base or remove it from the motor base while
the motor is running.
7. Press the STANDBY button again to turn off the
blender.
8. Remove the container from the motor base and
empty the contents.
9. Wash and dry container after each use. See Cleaning
& Sanitizing Instructions.
10. Not for waterjet cleaning.
11. The use of ear protection is recommended during
extended operating periods.
Spigot Instructions
When pouring jar contents through the spigot, simply
push the lever toward the blender jar. If contents are
too thick, it can be difcult to pour through the spigot.
Running the blender on LOW while pouring can help
the ow. Make sure to always have the lid positioned on
the blender with the clamps locked when running the
blender.

12
TO REALIZE MAXIMUM SERVICE LIFE, OBSERVE THE
FOLLOWING PRECAUTIONS:
1. Do not lubricate container bearing, drive shaft,
or shaft seals. These parts are lubricated and
sealed at the factory and do not require any further
lubrication.
2. Reduce amounts of material processed to less than
the full 4-liter capacity when working with viscous or
brous materials.
3. When cleaning exterior of container, keep it in normal
upright operating position to prevent liquids from
running into the bearing through the bottom end.
HOT BLENDING INSTRUCTIONS: IMPORTANT!
To minimize the possibility of scalding when blending hot
materials, the following precautions and procedures must be
observed:
• Hot materials are those which are 100˚F (38˚C) or hotter.
• Always start blending on lowest speed setting, then
progress to desired speed.
• Never stand directly over blender when it is being started
or while it is running.
• Constant monitoring of the condition of the container lid
gasket and the container lid clamps is mandatory. Replace
these parts if they become worn or loose, or are damaged
in any way.

13
CLEANING AND SANITIZING INSTRUCTIONS
THE CONTAINER MUST BE CLEANED AND DRIED
ACCORDING TO THE FOLLOWING INSTRUCTIONS
AFTER EACH USE OF THE BLENDER. FAILURE TO DO
SO MAY ALLOW RESIDUES OF PROCESSED MATERIAL
TO COLLECT ON THE INTERNAL SEALS OF THE BLADE
ASSEMBLY, RENDERING THEM INEFFECTIVE.
For Food Service Applications
• Wash, rinse, sanitize and dry container prior to initial use
and whenever it will not be used again within a period of
1 hour.
• Wash and rinse container after each use.
• Clean and sanitize motor base prior to initial use and after
each use.
• Washing solutions based on non-sudsing detergents and
chlorine-based sanitizing solutions having a minimum
chlorine concentration of 100 PPM are recommended.
The following washing, rinsing and sanitizing solutions, or
their equivalents, may be used.
SOLUTION PRODUCT DILUTION TEMP.
IN WATER
Washing: Diversey Wyandotte 4 Tbsp/Gallon Hot 115° F
Diversol BX/A (46° C)
Or CX/A
Rinsing: Plain Water – Warm 95° F
(35° C)
Sanitizing: Clorox®Institutional 1 Tbsp/Gallon Cold
Bleach 50°–70° F
(10°–21° C)
• In repetitive batch-processing applications, frequent
cleaning of the container will prolong the life of the blade
assembly. In no case should actual running time between
cleanings exceed ½ hour.
• Do not use container to store processed foods or
beverages.

14
To Wash and Rinse Container:
1. REMOVE CONTAINER FROM MOTOR BASE. Remove
lid. Rinse container interior and lid under running water.
Add washing solution to container. Scrub and ush out
the container interior and lid to dislodge and remove as
much food residue as possible. Empty container.
2. Wipe down exterior of container with a soft cloth or
sponge dampened with washing solution.
Wash lid and lid insert in fresh washing solution. Fill
container ¼ full with fresh washing solution, cover,
place on motor base, and run on high speed for two (2)
minutes. Empty container.
3. Repeat step (2) using clean rinse water in place of
washing solution.
To Wash and Rinse Spigot:
NOTE: Spigot is to be handwashed only.
4. Remove spigot assembly from jar adaptor by rotating
counterclockwise. Separate the lever from the rubber
insert by pushing the ball tip out of the loop. Remove the
rubber insert.
5. Wash spigot assembly and rubber insert in fresh
washing solution.
6. Repeat step (5) using clean rinse water in place of the
washing solution. Be sure all debris has been removed.
NOTE – IMPORTANT
IN ORDER TO MINIMIZE POSSIBILITY OF SCALDING,
TEMPERATURE OF WASHING SOLUTION AND RINSE
WATER MUST NOT EXCEED 115° F (46° C), AND
QUANTITY USED MUST NOT EXCEED ¼
CONTAINERFUL .

15
IF HIGHER TEMPERATURES OR LARGER QUANTITIES
ARE USED, OBSERVE ALL PRECAUTIONS GIVEN IN
THE OPERATING MANUAL UNDER “HOT BLENDING
INSTRUCTIONS”.
To Sanitize and Dry Container
1. Wipe down exterior of container with a soft cloth or
sponge dampened with sanitizing solution.
2. Fill container with sanitizing solution, cover, place on
motor base, and run on high speed for two (2) minutes.
Empty container. When operating with the spigot
function, empty the container using the spigot. Dislodge
any residual moisture from blade assembly by placing
empty container on motor base, and running on high
speed for two (2) seconds.
3. If using the spigot function, sanitize spigot assembly,
rubber insert, lid and lid insert by immersing in sanitizing
solution for two (2) minutes.
4. Do not rinse container, spigot assembly, rubber insert,
lid, or lid insert after sanitizing is completed. Allow all
parts to air-dry.
To Clean and Sanitize Motor Base
1. UNPLUG POWER CORD. Wipe down exterior surfaces
of motor base with soft cloths or sponges dampened
with washing solution, rinse water, and sanitizing
solution. Prevent liquid from running into motor base
by wringing all excess moisture from cloths or sponges
before using them.
MAINTENANCE
Motor – Not for waterjet cleaning.
The Waring Commercial Blender ball-bearing motor requires
no greasing or oiling. Sealed-in lubrication provides smooth
unit operation.

16
Container – The stainless steel container can be sterilized
without injury to the bearing.
Container pad is to be washed and rinsed in solutions as
noted in the separate Cleaning and Sanitizing Instructions.
Depending on the operating conditions, service life of the
main components of the container blade assembly, socket
head shaft and shaft seals is 500 hours actual running time.
When any one of these main components has worn to the
extent that replacement is required, it is likely that the other
components will need to be replaced also. It is therefore
recommended that container blade assemblies be replaced
as a unit.
Die-cast lock nut must be tightened securely (65 to 70
foot-pounds torque) when reassembling container.
Power Supply Cord – The power supply cord should not be
replaced by the end user. The power supply cord should be
replaced only by the manufacturer’s authorized importer
(or, in the United States and Canada, by an authorized
Service Center).
Note: All parts require constant monitoring for conditions
requiring replacement. For assistance, contact your nearest
Service Center.
LIMITED THREE-YEAR MOTOR WARRANTY
LIMITED TWO-YEAR WARRANTY
Waring warrants every new Waring®Commercial Blender
to be free from defects in material and workmanship for a
period of two years from the date of purchase when used
with foodstuffs, nonabrasive liquids (other than detergents)
and nonabrasive semi-liquids, providing it has not been
subject to loads in excess of the indicated rating. In addition,
the motor in this appliance has a full three-year warranty.
Under this warranty, Waring, during the warranty period, will
repair or replace any part which, upon our examination, is
defective in materials or workmanship, provided the product
is delivered prepaid to the Waring Service Center at:

17
314 Ella T. Grasso Ave. Torrington, CT 06790, or any Factory
Approved Service Center. This warranty does not:
a) apply to any product that has become worn, defective,
damaged or broken due to misuse or due to repairs or
servicing by other than the Waring Service Center or
a Factory Approved Service Center, or due to abuse,
misuse, overloading or tampering; or b) cover incidental or
consequential damages of any kind.
The two-year warranty is applicable only to appliances
used in the United States or Canada; this supersedes all
other express product warranty or warranty statements.
For Waring products sold outside of the U.S. and Canada,
the warranty is the responsibility of the local importer
or distributor. This warranty may vary according to local
regulations.
Warning: This warranty is void if appliance is used on Direct
Current (DC).
SERVICE
Should service on this product in USA or Canada be
required at any time, call or write to:
Waring Service Center • P.O. Box 3201 • 314 Ella T. Grasso
Ave. • Torrington, CT 06790
Tel. [phone] • FAX [phone]
or nearest Authorized Service Center
Replacement parts for Waring out-of-warranty repairs are
obtainable at the above address.
Note: If your application involves the processing of
biologically active materials, any items returned for service
must be sterilized before being shipped. Such items must
be clearly identied as having been sterilized, both by a tag
on the item itself and by a statement in the accompanying
correspondence. Waring will not accept delivery of any
returns unless they are so identied.

18
MEDIDAS DE SEGURIDAD
IMPORTANTES
Siempre que use aparatos eléctricos, debe tomar
precauciones básicas de seguridad, entre las cuales las
siguientes:
1. LEA TODAS LAS INSTRUCCIONES.
2. Desconecte el aparato cuando no esté en uso, antes
de instalar o remover piezas y antes de limpiarlo.
3. Para reducir el riesgo de electrocución, no sumerja el
aparato en agua u otro líquido.
4. Evite el contacto con las piezas móviles.
5. No utilice este aparato si el cable o la clavija estuviesen
dañados, después de que hubiese funcionado mal o
que se hubiese caído o si estuviese dañado. Regrese
el aparato a un centro de servicio autorizado para su
revisión, reparación o ajuste.
6. El uso de accesorios, incluso frascos para conservas,
no recomendados por el fabricante, presenta un peligro.
7. No lo utilice en exteriores.
8. No permita que el cable cuelgue del borde de la
encimera o de la mesa, ni que haga contacto con
superficies calientes.
9. Para reducir el riesgo de herida seria o de daño al
aparato, mantenga las manos y los utensilios fuera
de la jarra durante el funcionamiento. Se podrá usar
una espátula de goma, siempre que el aparato esté
apagado.
10. Las cuchillas son muy filosas. Manipular con sumo
cuidado.
11. No encienda el aparato a menos que la tapa esté
debidamente puesta.
12. Para licuar líquidos calientes, quite el tapón (pieza
central de la tapa) antes de encender la licuadora.
Consulte la sección "Líquidos calientes".
13. Los niños o las personas que carezcan de la experiencia
o de los conocimientos necesarios para manipular

19
el aparato, o aquellas cuyas capacidades físicas,
sensoriales o mentales estén limitadas, no deben utilizar
este aparato.
14. Asegúrese de que los niños no jueguen con este
aparato.
15. NO procese líquidos carbonatados con este aparato ni
con ninguna licuadora. Esto puede causar heridas.
16. NO procese aceite o productos a base de aceite
(por ej. mantequilla de maní) durante más de 5 minutos.
17. Espere hasta que el motor se haya detenido
completamente y que las cuchillas estén inmóviles antes
de retirar la jarra de la base.
18. El grifo debe lavarse a mano solamente. No lo meta al
lavavajillas.
19. Asegúrese de que el contenido de la jarra no pase de
140 °F (60 °C). Tenga presente que la temperatura del
contenido aumentará durante el licuado debido a la
fricción de las cuchillas.
GUARDE ESTAS INSTRUCCIONES
ESPECIFICACIONES TÉCNICAS
• Capacidad: 4 litros
• Clasificación nominal: Corriente monofásica de 120V
C.A. – 15 amperios (modelos destinados al mercado
estadounidense solamente)
• Base: de fundición, con revestimiento gris
• Jarra: Acero inoxidable, con cuchillas de acero inoxidable
– tapa de caucho con seguro
• Accionamiento: Cojinete de bolas de alto desempeño
• Cable: Cable de 2.45 m con clavija de tierra reforzada
• Altura total: 66 cm
• Peso: 17.2 kg (neto) – 18.6 kg (embalado)
• Certificación cETLus y NSF
• Ciclo de operación: 3 minutos encendido/1 minuto
apagado

20
INSTRUCCIONES DE PUESTA A TIERRA
(MODELOS DE 120V)
Para su protección, este aparato está equipado con un
cable eléctrico con conductor de tierra.
Los aparatos de 120V están equipados con clavija tripolar
de conexión con tierra (NEMA5-15P), la cual debe ser
conectada a una la toma de corriente puesta a tierra (Fig. 1).
Si una toma de corriente puesta a tierra no está disponible,
se podrá usar un adaptador para conectar el aparato a una
toma de corriente polarizada (Fig. 2). Nota: Está prohibido
usar un adaptador en el Canadá y en Europa.
El adaptador debe ser puesto a tierra mediante un tornillo de
metal que conecte la lengüeta del adaptador a la placa de la
toma de corriente (Fig. 3).
Precaución: Antes de conectar el adaptador, asegúrese
de que la toma de corriente esté puesta a tierra. Si no está
seguro/a, comuníquese con un electricista. Nunca use un
adaptador sin estar seguro de que la toma de corriente esté
puesta a tierra.
Verde/Amarillo: Tierra • Azul: Neutro • Marrón: Tensión
Importante: No se permite el uso de clavijas instaladas por
el usuario en Europa.
