WARRIOR 57342 Assembly instructions

!"#"$%&'(%)*+#"$*%,$-%.$$/-00)))1.,(+&(2(*"3.$14&5
65,"7%&'(%$*4.8"4,7%#'//&($%,$-%/(&9'4$#'//&($:.,(+&(2(*"3.$14&5
Owner’s Manual & Safety Instructions
Save This Manual Keep this manual for the safety warnings and precautions, assembly,
operating, inspection, maintenance and cleaning procedures. Write the product’s serial number in the
back of the manual near the assembly diagram (or month and year of purchase if product has no number).
Keep this manual and the receipt in a safe and dry place for future reference. 20g
When unpacking, make sure that the product is intact
and undamaged. If any parts are missing or broken,
please call 1-888-866-5797 as soon as possible.
Copyright© 2020 by Harbor Freight Tools®. All rights reserved.
No portion of this manual or any artwork contained herein may be reproduced in
any shape or form without the express written consent of Harbor Freight Tools.
Diagrams within this manual may not be drawn proportionally. Due to continuing
improvements, actual product may differ slightly from the product described herein.
Tools required for assembly an d se rv ic e may n ot b e in cl uded.
Read this material before using this product.
Failure to do so can result in serious injury.
SAVE THIS MANUAL.

Page 2 ;&(%$*4.8"4,7%<'*#$"&8#=%/7*,#*%4,77%>?@@@?@AA?BCDC1 Item 57342
EF;6GH IJ6KFGLIM NFLMG6MFMO6E6GPJ
G,+7*%&2%O&8$*8$#
Safety ......................................................... 2
Specifications ............................................. 8
Setup .......................................................... 8
Operation ................................................... 13
Maintenance .............................................. 16
Parts List and Diagram .............................. 20
Warranty .................................................... 23
QFKMLMR%EHNSITE%FMU%U6;LMLGLIME
This is the safety alert symbol. It is used to alert you to potential
personal injury hazards. Obey all safety messages that
follow this symbol to avoid possible injury or death.
Indicates a hazardous situation which, if not avoided,
will result in death or serious injury.
Indicates a hazardous situation which, if not avoided,
could result in death or serious injury.
Indicates a hazardous situation which, if not avoided,
could result in minor or moderate injury.
Addresses practices not related to personal injury.
LNJIKGFMG%EF;6GH%LM;IKNFGLIM
R*8*(,7%J&)*(%G&&7%E,2*$V%Q,(8"83#
%
K*,9%,77%#,2*$V%),(8"83#=%"8#$('4$"&8#=%"77'#$(,$"&8#%,89%#/*4"2"4,$"&8#%/(&W"9*9%)"$.%$."#%/&)*(%$&&71%
Failure to follow all instructions listed below may result in electric shock, fire and/or serious injury.
E,W*%,77%),(8"83#%,89%"8#$('4$"&8#%2&(%2'$'(*%(*2*(*84*1
The term “power tool” in the warnings refers to your mains-operated (corded)
power tool or battery-operated (cordless) power tool.
1. Q&(X%,(*,%#,2*$V
a. Y**/%)&(X%,(*,%47*,8%,89%)*77%7"$1%
Cluttered or dark areas invite accidents.
b. U&%8&$%&/*(,$*%/&)*(%$&&7#%"8%*Z/7&#"W*%
,$5&#/.*(*#=%#'4.%,#%"8%$.*%/(*#*84*%&2%
27,55,+7*%7"<'"9#=%3,#*#%&(%9'#$1%Power tools
create sparks which may ignite the dust or fumes.
c. Y**/%4."79(*8%,89%+V#$,89*(#%,),V%
)."7*%&/*(,$"83%,%/&)*(%$&&71%Distractions
can cause you to lose control.

Page 3;&(%$*4.8"4,7%<'*#$"&8#=%/7*,#*%4,77%>?@@@?@AA?BCDC1Item 57342
EF;6GHIJ6KFGLIMNFLMG6MFMO6 E6GPJ
2. 67*4$("4,7%#,2*$V
a. J&)*(%$&&7%/7'3#%5'#$%5,$4.%$.*%&'$7*$1%
M*W*(%5&9"2V%$.*%/7'3%"8%,8V%),V1%U&%8&$%'#*%
,8V%,9,/$*(%/7'3#%)"$.%*,($.*9%[3(&'89*9\%
/&)*(%$&&7#1%Unmodified plugs and matching
outlets will reduce risk of electric shock.
b. FW&"9%+&9V%4&8$,4$%)"$.%*,($.*9%&(%
3(&'89*9%#'(2,4*#=%#'4.%,#%/"/*#=%
(,9",$&(#=%(,83*#%,89%(*2("3*(,$&(#1%
There is an increased risk of electric shock
if your body is earthed or grounded.
c. U&%8&$%*Z/&#*%/&)*(%$&&7#%$&%(,"8%&(%)*$%
4&89"$"&8#1%Water entering a power tool
will increase the risk of electric shock.
d. U&%8&$%,+'#*%$.*%4&(91%M*W*(%'#*%$.*%4&(9%
2&(%4,((V"83=%/'77"83%&(%'8/7'33"83%$.*%/&)*(%
$&&71%Y**/%4&(9%,),V%2(&5%.*,$=%&"7=%#.,(/%
*93*#%&(%5&W"83%/,($#1%Damaged or entangled
cords increase the risk of electric shock.
e. Q.*8%&/*(,$"83%,%/&)*(%$&&7%&'$9&&(#=%
'#*%,8%*Z$*8#"&8%4&(9%#'"$,+7*%2&(%&'$9&&(%
'#*1%Use of a cord suitable for outdoor
use reduces the risk of electric shock.
f. L2%&/*(,$"83%,%/&)*(%$&&7%"8%,%9,5/%7&4,$"&8%
"#%'8,W&"9,+7*=%'#*%,%3(&'89%2,'7$%4"(4'"$%
"8$*(('/$*(%[R;OL\%/(&$*4$*9%#'//7V1%Use of
a GFCI reduces the risk of electric shock.
3. J*(#&8,7%#,2*$V
a. E$,V%,7*($=%),$4.%).,$%V&'%,(*%9&"83%,89%
'#*%4&55&8%#*8#*%).*8%&/*(,$"83%,%
/&)*(%$&&71%U&%8&$%'#*%,%/&)*(%$&&7%)."7*%
V&'%,(*%$"(*9%&(%'89*(%$.*%"827'*84*%&2%
9('3#=%,74&.&7%&(%5*9"4,$"&81%%A moment
of inattention while operating power tools
may result in serious personal injury.
b. P#*%/*(#&8,7%/(&$*4$"W*%*<'"/5*8$1%F7),V#%
)*,(%*V*%/(&$*4$"&81%%Protective equipment
such as dust mask, non-skid safety shoes, hard
hat, or hearing protection used for appropriate
conditions will reduce personal injuries.
c. J(*W*8$%'8"8$*8$"&8,7%#$,($"831%68#'(*%$.*%
#)"$4.%"#%"8%$.*%&22?/&#"$"&8%+*2&(*%4&88*4$"83%
$&%/&)*(%#&'(4*%,890&(%+,$$*(V%/,4X=%/"4X"83%
'/%&(%4,((V"83%$.*%$&&71%Carrying power tools
with your finger on the switch or energizing power
tools that have the switch on invites accidents.
d. K*5&W*%,8V%,9]'#$"83%X*V%&(%)(*84.%
+*2&(*%$'(8"83%$.*%/&)*(%$&&7%&81%%A wrench
or a key left attached to a rotating part of the
power tool may result in personal injury.
e. U&%8&$%&W*((*,4.1%Y**/%/(&/*(%2&&$"83%,89%
+,7,84*%,$%,77%$"5*#1 This enables better control
of the power tool in unexpected situations.
f. U(*##%/(&/*(7V1%U&%8&$%)*,(%7&&#*%47&$."83%
&(%]*)*7(V1%Y**/%V&'(%.,"(=%47&$."83%
,89%37&W*#%,),V%2(&5%5&W"83%/,($#1%%
Loose clothes, jewelry or long hair
can be caught in moving parts.
g. L2%9*W"4*#%,(*%/(&W"9*9%2&(%$.*%4&88*4$"&8%
&2%9'#$%*Z$(,4$"&8%,89%4&77*4$"&8%
2,4"7"$"*#=%*8#'(*%$.*#*%,(*%4&88*4$*9%
,89%/(&/*(7V%'#*91%%Use of dust collection
can reduce dust-related hazards.
h. U&%8&$%7*$%2,5"7",("$V%3,"8*9%2(&5%2(*<'*8$%
'#*%&2%$&&7#%,77&)%V&'%$&%+*4&5*%
4&5/7,4*8$%,89%"38&(*%$&&7%#,2*$V%
/("84"/7*#1%%A careless action can cause
severe injury within a fraction of a second.
i. Only use safety equipment that has been
approved by an appropriate standards agency.
Unapproved safety equipment may not provide
adequate protection. Eye protection must be
ANSI-approved and breathing protection
must be NIOSH-approved for the
specific hazards in the work area.
j. Avoid unintentional starting.
Prepare to begin work before turning on the tool.
k. Do not leave the tool unattended when
it is plugged into an electrical outlet.
Turn off the tool, and unplug it from its
electrical outlet before leaving.
l. This product is not a toy.
Keep it out of reach of children.
m. People with pacemakers should consult their
physician(s) before use. Electromagnetic fields
in close proximity to heart pacemaker could
cause pacemaker interference or pacemaker
failure. In addition, people with pacemakers
should:
• Avoid operating alone.
• Do not use with Trigger locked on.
• Properly maintain and inspect to avoid
electrical shock.
• Properly ground power cord.
Ground Fault Circuit Interrupter (GFCI)
should also be implemented – it prevents
sustained electrical shock.
n. The warnings, precautions, and instructions
discussed in this instruction manual cannot
cover all possible conditions and situations
that may occur. It must be understood by the
operator that common sense and caution are
factors which cannot be built into this product,
but must be supplied by the operator.
4. J&)*(%$&&7%'#*%,89%4,(*
a. U&%8&$%2&(4*%$.*%/&)*(%$&&71%P#*%$.*%4&((*4$%
/&)*(%$&&7%2&(%V&'(%,//7"4,$"&81%%The correct
power tool will do the job better and safer
at the rate for which it was designed.

Page 4 ;&(%$*4.8"4,7%<'*#$"&8#=%/7*,#*%4,77%>?@@@?@AA?BCDC1 Item 57342
EF;6GH IJ6KFGLIM NFLMG6MFMO6E6GPJ
b. U&%8&$%'#*%$.*%/&)*(%$&&7%"2%$.*%#)"$4.%
9&*#%8&$%$'(8%"$%&8%,89%&221%%Any power
tool that cannot be controlled with the switch
is dangerous and must be repaired.
c. U"#4&88*4$%$.*%/7'3%2(&5%$.*%/&)*(%
#&'(4*%,890&(%(*5&W*%$.*%+,$$*(V%/,4X=%
"2%9*$,4.,+7*=%2(&5%$.*%/&)*(%$&&7%+*2&(*%
5,X"83%,8V%,9]'#$5*8$#=%4.,83"83%
,44*##&("*#=%&(%#$&("83%/&)*(%$&&7#1%%
Such preventive safety measures reduce the
risk of starting the power tool accidentally.
d. E$&(*%"97*%/&)*(%$&&7#%&'$%&2%$.*%(*,4.%&2%
4."79(*8%,89%9&%8&$%,77&)%/*(#&8#%'82,5"7",(%
)"$.%$.*%/&)*(%$&&7%&(%$.*#*%"8#$('4$"&8#%
$&%&/*(,$*%$.*%/&)*(%$&&71%%Power tools are
dangerous in the hands of untrained users.
e. N,"8$,"8%/&)*(%$&&7#%,89%,44*##&("*#1%
O.*4X%2&(%5"#,7"385*8$%&(%+"89"83%&2%5&W"83%
/,($#=%+(*,X,3*%&2%/,($#%,89%,8V%&$.*(%
4&89"$"&8%$.,$%5,V%,22*4$%$.*%/&)*(%$&&7^#%
&/*(,$"&81%L2%9,5,3*9=%.,W*%$.*%/&)*(%$&&7%
(*/,"(*9%+*2&(*%'#*1%%Many accidents are
caused by poorly maintained power tools.
f. Y**/%4'$$"83%$&&7#%#.,(/%,89%47*,81%%Properly
maintained cutting tools with sharp cutting edges
are less likely to bind and are easier to control.
g. P#*%$.*%/&)*(%$&&7=%,44*##&("*#%,89%$&&7%+"$#%
*$41%"8%,44&(9,84*%)"$.%$.*#*%"8#$('4$"&8#=%
$,X"83%"8$&%,44&'8$%$.*%)&(X"83%4&89"$"&8#%
,89%$.*%)&(X%$&%+*%/*(2&(5*91%%Use of the
power tool for operations different from those
intended could result in a hazardous situation.
h. Y**/%.,897*#%,89%3(,#/"83%#'(2,4*#%
9(V=%47*,8%,89%2(**%2(&5%&"7%,89%3(*,#*1%%
Slippery handles and grasping surfaces
do not allow for safe handling and control
of the tool in unexpected situations.
5. E*(W"4*
a. _,W*%V&'(%/&)*(%$&&7%#*(W"4*9%+V%,%
<',7"2"*9%(*/,"(%/*(#&8%'#"83%&87V%"9*8$"4,7%
(*/7,4*5*8$%/,($#1%%This will ensure that
the safety of the power tool is maintained.
b. Maintain labels and nameplates on the tool.
These carry important safety information.
If unreadable or missing, contact
Harbor Freight Tools for a replacement.
6. R',(9"83%(*7,$*9%),(8"83#
a. Y**/%3',(9#%"8%/7,4*1%R',(9#%5'#$%
+*%"8%)&(X"83%&(9*(%,89%+*%/(&/*(7V%
5&'8$*91 A guard that is loose,
damaged, or is not functioning correctly
must be repaired or replaced.
b. F7),V#%'#*%#,)%+7,9*%3',(9%,89%("W"83%
X8"2*%2&(%*W*(V%$.(&'3.?4'$$"83%&/*(,$"&81%
For through-cutting operations where the saw
blade cuts completely through the thickness
of the workpiece, the guard and other safety
devices help reduce the risk of injury.
c. L55*9",$*7V%(*,$$,4.%$.*%3',(9"83%#V#$*5%
,2$*(%4&5/7*$"83%,8%&/*(,$"&8%[#'4.%,#%
(,++*$"83=%9,9&"83%&(%(*#,)"83%4'$#\%
)."4.%(*<'"(*#%(*5&W,7%&2%$.*%3',(9%
,89%("W"83%X8"2*1%The guard and riving
knife, help to reduce the risk of injury.
d. N,X*%#'(*%$.*%#,)%+7,9*%"#%8&$%4&8$,4$"83%
$.*%3',(9=%("W"83%X8"2*%&(%$.*%)&(X/"*4*%
+*2&(*%$.*%#)"$4.%"#%$'(8*9%&81%Inadvertent
contact of these items with the saw blade
could cause a hazardous condition.
e. F9]'#$%$.*%("W"83%X8"2*%,#%9*#4("+*9%
"8%$."#%"8#$('4$"&8%5,8',71%Incorrect
spacing, positioning and alignment
can make the riving knife ineffective in
reducing the likelihood of kickback.
f. ;&(%$.*%("W"83%X8"2*%$&%)&(X=%"$%5'#$%+*%
*83,3*9%"8%$.*%)&(X/"*4*1%%The riving knife
is ineffective when cutting workpieces that
are too short to be engaged with the riving
knife. Under these conditions a kickback
cannot be prevented by the riving knife.
g. P#*%$.*%,//(&/(",$*%#,)%+7,9*%2&(%$.*%("W"83%
X8"2*1%%For the riving knife to function properly, the
saw blade diameter must match the appropriate
riving knife and the body of the saw blade must
be thinner than the thickness of the riving knife
and the cutting width of the saw blade must be
wider than the thickness of the riving knife.
7. O'$$"83%/(&4*9'(*#%),(8"83#
a. UFMR6K-%M*W*(%/7,4*%V&'(%2"83*(#%&(%
.,89#%L8%$.*%W"4"8"$V%&(%"8%7"8*%)"$.%$.*%
#,)%+7,9*1%A moment of inattention or a
slip could direct your hand towards the saw
blade and result in serious personal injury.
b. ;**9%$.*%)&(X/"*4*%"8$&%$.*%#,)%+7,9*%
&87V%,3,"8#$%$.*%9"(*4$"&8%&2%(&$,$"&81%
Feeding the workpiece in the same direction
that the saw blade is rotating above the
table may result in the workpiece, and your
hand, being pulled into the saw blade.
c. M*W*(%'#*%$.*%5"$*(%3,'3*%$&%2**9%$.*%
)&(X/"*4*%).*8%("//"83%,89%9&%8&$%'#*%
$.*%("/%2*84*%,#%,%7*83$.%#$&/%).*8%4(&##%
4'$$"83%)"$.%$.*%5"$*(%3,'3*1%Guiding
the workpiece with the rip fence and the
miter gauge at the same time increases the
likelihood of saw blade binding and kickback.

Page 5;&(%$*4.8"4,7%<'*#$"&8#=%/7*,#*%4,77%>?@@@?@AA?BCDC1Item 57342
EF;6GHIJ6KFGLIMNFLMG6MFMO6 E6GPJ
d. Q.*8%("//"83=%,7),V#%,//7V%$.*%)&(X/"*4*%
2**9"83%2&(4*%+*$)**8%$.*%2*84*%,89%
$.*%#,)%+7,9*1%Use a push stick when the
distance between the fence and the saw
blade is less than 150mm, and use a push
block when this distance is less than 50mm.
“Work helping” devices will keep your hand
at a safe distance from the saw blade.
e. P#*%&87V%$.*%/'#.%#$"4X%/(&W"9*9%+V%
$.*%5,8'2,4$'(*(%&(%4&8#$('4$*9%"8%
,44&(9,84*%)"$.%$.*%"8#$('4$"&8#1%This
push stick provides sufficient distance
of the hand from the saw blade.
f. M*W*(%'#*%,%9,5,3*9%&(%4'$%/'#.%#$"4X1%
A damaged push stick may break causing
your hand to slip into the saw blade.
g. U&%8&$%/*(2&(5%,8V%&/*(,$"&8%`2(**.,89a1%
Always use either the rip fence or the miter
gauge to position and guide the workpiece.
“Freehand’ means using your hands to support
or guide the workpiece, in lieu of a rip fence
or miter gauge. Freehand sawing leads to
misalignment, binding and kickback.
h. M*W*(%(*,4.%,(&'89%&(%&W*(%,%(&$,$"83%#,)%
+7,9*1%Reaching for a workpiece may lead to
accidental contact with the moving saw blade.
i. J(&W"9*%,'Z"7",(V%)&(X/"*4*%#'//&($%$&%$.*%
(*,(%,890&(%#"9*#%&2%$.*%#,)%$,+7*%2&(%7&83%
,890&(%)"9*%)&(X/"*4*#%$&%X**/%$.*5%7*W*71%
A long and/or wide workpiece has a tendency
to pivot on the table’s edge, causing loss of
control, saw blade binding and kickback.
j. ;**9%)&(X/"*4*%,$%,8%*W*8%/,4*1%Do not bend
or twist the workpiece. If jamming occurs, turn
the tool off Immediately, unplug the tool then
clear the jam. Jamming the saw blade by the
workpiece can cause kickback or stall the motor.
k. U&%8&$%(*5&W*%/"*4*#%&2%4'$?&22%5,$*(",7%
)."7*%$.*%#,)%"#%('88"831%The material
may become trapped between the fence
or inside the saw blade guard and the saw
blade pulling your fingers into the saw blade.
Turn the saw off and wait until the saw
blade stops before removing material.
l. P#*%,8%,'Z"7",(V%2*84*%"8%4&8$,4$%)"$.%$.*%
$,+7*%$&/%).*8%("//"83%)&(X/"*4*#%7*##%
$.,8%b55%$."4X1%A thin workpiece may wedge
under the rip fence and create a kickback.
8. Y"4X+,4X%4,'#*#%,89%(*7,$*9%),(8"83#
Kickback is a sudden reaction of the workpiece due
to a pinched, jammed saw blade or misaligned line
of cut in the workpiece with respect to the saw blade
or when a part of the workpiece binds between the
saw blade and the ("/%2*84* or other fixed object.
Most frequently during X"4X+,4X, the workpiece is
lifted from the table by the rear portion of the saw
blade and is propelled towards the operator.
Kickback is the result of saw misuse and/or incorrect
operating procedures or conditions and can be avoided
by taking proper precautions as given below.
a. M*W*(%#$,89%9"(*4$7V%"8%7"8*%)"$.%$.*%#,)%
+7,9*1%Always position your body on the
same side of the saw blade as the fence.
Kickback may propel the workpiece at
high velocity towards anyone standing in
front and in line with the saw blade.
b. M*W*(%(*,4.%&W*(%&(%"8%+,4X%&2%$.*%#,)%+7,9*%
$&%/'77%&(%$&%#'//&($%$.*%)&(X/"*4*1%Accidental
contact with the saw blade may occur or kickback
may drag your fingers into the saw blade.
c. M*W*(%.&79%,89%/(*##%$.*%)&(X/"*4*%
$.,$%"#%+*"83%4'$%&22%,3,"8#$%$.*%(&$,$"83%
#,)%+7,9*1%Pressing the workpiece being
cut off against the saw blade will create
a binding condition and kickback.
d. F7"38%$.*%2*84*%$&%+*%/,(,77*7%)"$.%
$.*%#,)%+7,9*1%A misaligned fence
will pinch the workpiece against the
saw blade and create kickback.
e. P#*%,%2*,$.*(+&,(9%$&%3'"9*%$.*%)&(X/"*4*%
,3,"8#$%$.*%$,+7*%,89%2*84*%).*8%5,X"83%
8&8?$.(&'3.%4'$#%#'4.%,#%(,++*$"83=%9,9&"83%
&(%(*#,)"83%4'$#1%A featherboard helps to
control the workpiece in the event of a kickback.
f. P#*%*Z$(,%4,'$"&8%).*8%5,X"83%,%
4'$%"8$&%+7"89%,(*,#%&2%,##*5+7*9%
)&(X/"*4*#1%The protruding saw blade may
cut objects that can cause kickback.
g. E'//&($%7,(3*%/,8*7#%$&%5"8"5"#*%$.*%("#X%
&2%#,)%+7,9*%/"84."83%,89%X"4X+,4X1%Large
panels tend to sag under their own weight.
Support(s) must be placed under all portions
of the panel overhanging the table top.
h. P#*%*Z$(,%4,'$"&8%).*8%4'$$"83%,%)&(X/"*4*%
$.,$%"#%$)"#$*9=%X8&$$*9=%),(/*9%&(%9&*#%
8&$%.,W*%,%#$(,"3.$%*93*%$&%3'"9*%"$%)"$.%,%
5"$*(%3,'3*%&(%,7&83%$.*%2*84*1%A warped,
knotted, or twisted workpiece is unstable
and causes misalignment of the kerf with
the saw blade, binding and kickback.
i. M*W*(%4'$%5&(*%$.,8%&8*%)&(X/"*4*=%#$,4X*9%
W*($"4,77V%&(%.&("c&8$,77V1%The saw blade could
pick up one or more pieces and cause kickback.

Page 6 ;&(%$*4.8"4,7%<'*#$"&8#=%/7*,#*%4,77%>?@@@?@AA?BCDC1 Item 57342
EF;6GH IJ6KFGLIM NFLMG6MFMO6E6GPJ
j. Q.*8%(*#$,($"83%$.*%#,)%)"$.%$.*%#,)%
+7,9*%"8%$.*%)&(X/"*4*=%4*8$*(%$.*%#,)%
+7,9*%L8%$.*%X*(2%#&%$.,$%$.*%#,)%$**$.%,(*%
8&$%*83,3*9%"8%$.*%5,$*(",71%If the saw
blade binds, it may lift up the workpiece and
cause kickback when the saw is restarted.
k. Y**/%#,)%+7,9*#%47*,8=%#.,(/=%,89%)"$.%
#'22"4"*8$%#*$1%Never use warped saw
blades or saw blades with cracked or broken
teeth. Sharp and properly set saw blades
minimize binding, stalling and kickback.
9. G,+7*%#,)%&/*(,$"83%/(&4*9'(*%),(8"83#
a. G'(8%&22%$.*%$,+7*%#,)%,89%9"#4&88*4$%
$.*%/&)*(%4&(9%).*8%(*5&W"83%$.*%
$,+7*%"8#*($=%4.,83"83%$.*%#,)%+7,9*%
&(%5,X"83%,9]'#$5*8$#%$&%$.*%("W"83%
X8"2*%&(%#,)%+7,9*%3',(9=%,89%).*8%$.*%
5,4."8*%L#%7*2$%'8,$$*89*91 Precautionary
measures will avoid accidents.
b. M*W*(%7*,W*%$.*%$,+7*%#,)%('88"83%
'8,$$*89*91%Turn it off and don’t leave the tool
until it comes to a complete stop. An unattended
running saw is an uncontrolled hazard.
c. T&4,$*%$.*%$,+7*%#,)%"8%,%)*77?7"$%,89%7*W*7%
,(*,%).*(*%V&'%4,8%5,"8$,"8%3&&9%2&&$"83%
,89%+,7,84*1%It should be installed in an area
that provides enough room to easily handle the
size of your workpiece. Cramped, dark areas,
and uneven slippery floors invite accidents.
d. ;(*<'*8$7V%47*,8%,89%(*5&W*%#,)9'#$%
2(&5%'89*(%$.*%#,)%$,+7*%,890&(%$.*%9'#$%
4&77*4$"&8%9*W"4*1%Accumulated sawdust
is combustible and may self-ignite.
e. G.*%$,+7*%#,)%5'#$%+*%#*4'(*91%A table saw
that is not properly secured may move or tip over.
f. K*5&W*%$&&7#=%)&&9%#4(,/#=%*$41%2(&5%$.*%
$,+7*%+*2&(*%$.*%$,+7*%#,)%"#%$'(8*9%&81%
Distraction or a potential jam can be dangerous.
g. F7),V#%'#*%#,)%+7,9*#%)"$.%4&((*4$%#"c*%
,89%#.,/*%[9",5&89%W*(#'#%(&'89\%&2%
,(+&(%.&7*#1%Saw blades that do not match
the mounting hardware of the saw will
run off-center, causing loss of control.
h. M*W*(%'#*%9,5,3*9%&(%"84&((*4$%#,)%+7,9*%
5&'8$"83%5*,8#%#'4.%,#%27,83*#=%#,)%+7,9*%
),#.*(#=%+&7$#%&(%8'$#1%These mounting
means were specially designed for your saw,
for safe operation and optimum performance.
i. M*W*(%#$,89%&8%$.*%$,+7*%#,)=%9&%8&$%
'#*%"$%,#%,%#$*//"83%#$&&71%Serious injury
could occur if the tool is tipped or if the
cutting tool is accidentally contacted.
j. N,X*%#'(*%$.,$%$.*%#,)%+7,9*%"#%"8#$,77*9%
$&%(&$,$*%"8%$.*%/(&/*(%9"(*4$"&81%Do not use
grinding wheels, wire brushes, or abrasive
wheels on a table saw. Improper saw
blade installation or use of accessories not
recommended may cause serious injury.
R(&'89"83
GI%JK6!6MG%6T6OGKLO%E_IOY%FMU%U6FG_%;KIN%
LMOIKK6OG%RKIPMULMR%QLK6%OIMM6OGLIM-%
O.*4X%)"$.%,%<',7"2"*9%*7*4$("4",8%"2%V&'%,(*%"8%9&'+$%,#%$&%).*$.*(%$.*%&'$7*$%"#%/(&/*(7V%
3(&'89*91%%U&%8&$%5&9"2V%$.*%/&)*(%4&(9%/7'3%/(&W"9*9%)"$.%$.*%$&&71%%M*W*(%(*5&W*%$.*%
3(&'89"83%/(&83%2(&5%$.*%/7'31%%U&%8&$%'#*%$.*%$&&7%"2%$.*%/&)*(%4&(9%&(%/7'3%"#%9,5,3*91%%L2%9,5,3*9=%.,W*%
"$%(*/,"(*9%+V%,%#*(W"4*%2,4"7"$V%+*2&(*%'#*1%%L2%$.*%/7'3%)"77%8&$%2"$%$.*%&'$7*$=%.,W*%,%/(&/*(%&'$7*$%"8#$,77*9%+V%
,%<',7"2"*9%*7*4$("4",81
U&'+7*%L8#'7,$*9%G&&7#-%G&&7#%)"$.%G)&%J(&83%J7'3#
%
I'$7*$#%2&(%b?J(&83%J7'3
1. Tools marked “Double Insulated” do not
require grounding. They have a special
double insulation system which satisfies
OSHA requirements and complies with
the applicable standards of Underwriters
Laboratories, Inc., the Canadian Standard
Association, and the National Electrical Code.
2. Double insulated tools may be used in either of the
120 volt outlets shown in the preceding illustration.%%%
[E**%I'$7*$#%2&(%b?J(&83%J7'31\

Page 7;&(%$*4.8"4,7%<'*#$"&8#=%/7*,#*%4,77%>?@@@?@AA?BCDC1Item 57342
EF;6GHIJ6KFGLIMNFLMG6MFMO6 E6GPJ
6Z$*8#"&8%O&(9#
1. Grounded tools require a three wire extension cord.
Double Insulated tools can use either
a two or three wire extension cord.
2. As the distance from the supply outlet increases,
you must use a heavier gauge extension cord.
Using extension cords with inadequately sized wire
causes a serious drop in voltage, resulting in loss of
power and possible tool damage. [E**%G,+7*%F1\
3. The smaller the gauge number of the wire, the
greater the capacity of the cord. For example,
a 14 gauge cord can carry a higher current
than a 16 gauge cord. [E**%G,+7*%F1\
4. When using more than one extension cord
to make up the total length, make sure
each cord contains at least the minimum
wire size required. [E**%G,+7*%F1\
5. If you are using one extension cord for more
than one tool, add the nameplate%amperes
and use the sum to determine the required
minimum cord size. [E**%G,+7*%F1\
6. If you are using an extension cord outdoors, make
sure it is marked with the suffix “W-A” (“W” in
Canada) to indicate it is acceptable for outdoor use.
7. Make sure the extension cord is properly wired
and in good electrical condition. Always replace
a damaged extension cord or have it repaired
by a qualified electrician before using it.
8. Protect the extension cords from sharp objects,
excessive heat, and damp or wet areas.
GFST6%F-%%K6OINN6MU6U%NLMLNPN%QLK6%
RFPR6%;IK%6dG6MELIM%OIKUEe%[>bf0bgf%!ITG\
MFN6JTFG6
FNJ6K6E
[,$%2'77%7&,9\
6dG6MELIM%OIKU%
T6MRG_
bBh Bfh CBh >ffh >Bfh
0 – 2.0 18 18 18 18 16
2.1 – 3.4 18 18 18 16 14
3.5 – 5.0 18 18 16 14 12
5.1 – 7.0 18 16 14 12 12
7.1 – 12.0 18 14 12 10 -
12.1 – 16.0 14 12 10 - -
16.1 – 20.0 12 10 - - -
e%S,#*9%&8%7"5"$"83%$.*%7"8*%W&7$,3*%9(&/%$&%2"W*%W&7$#%,$%
>Bfi%&2%$.*%(,$*9%,5/*(*#1
EV5+&7&3V
Double Insulated
!Volts
jAlternating Current
FAmperes
n0 xxxx/min. No Load Revolutions per Minute (RPM)
WARNING marking concerning Risk
of Eye Injury. Wear ANSI-approved
safety goggles with side shields.
Read the manual before
set-up and/or use.
WARNING marking
concerning Risk of Fire.
Do not cover ventilation ducts.
Keep flammable objects away.
WARNING marking concerning
Risk of Electric Shock.
Properly connect power cord
to appropriate outlet.

Page 8 ;&(%$*4.8"4,7%<'*#$"&8#=%/7*,#*%4,77%>?@@@?@AA?BCDC1 Item 57342
EF;6GH IJ6KFGLIM NFLMG6MFMO6E6GPJ
E/*4"2"4,$"&8#
Electrical Rating 120VAC / 60Hz / 15A
Rated No Load Speed 4250/min
Cutting Capacity at 0° 3-3/16"
Cutting Capacity at 45° 2-3/16"
Maximum Bevel 45°
Maximum Miter 90°
Saw Blade (sold separately) 10" (254mm) Diameter, 7/64" Wide
5/8" Diamond Arbor
E*$'/%?%S*2&(*%P#*-
%K*,9%$.*%6MGLK6%LNJIKGFMG%EF;6GH%LM;IKNFGLIM%#*4$"&8%,$%$.*%+*3"88"83%&2%$."#%
5,8',7%"847'9"83%,77%$*Z$%'89*(%#'+.*,9"83#%$.*(*"8%+*2&(*%#*$%'/%&(%'#*%&2%$."#%/(&9'4$1
GI%JK6!6MG%E6KLIPE%LMkPKH%;KIN%FOOLU6MGFT%IJ6KFGLIM-%
G'(8%$.*%J&)*(%E)"$4.%&2%$.*%$&&7%&22%,89%'8/7'3%$.*%$&&7%2(&5%"$#%*7*4$("4,7%&'$7*$%+*2&(*%/*(2&(5"83%,8V%
/(&4*9'(*%"8%$."#%#*4$"&81
M&$*- For additional information regarding the parts listed in the
following pages, refer to Parts List and Diagram on page 20.
N&'8$"83
M&$*- Table Saw MUST be mounted
onto a surface for proper use.
L2%5&'8$"83%&8$&%,%5*$,7%$,+7*%#$,89-
1. Select a table stand which will support
the weight of the Table Saw. Follow the
table saw stand instructions for assembly.
Tighten all connections, making sure the
assembled table is secure and balanced.
2. Mount the Table Saw to the top of the assembled
stand using four 3/8″ bolts, eight 3/8″ washers
and four 3/8″ nuts (not included).
L2%5&'8$"83%&8$&%,%+*84.%&(%&$.*(%)&&9*8%#'(2,4*-
1. Select four 3/8″ bolts, eight 3/8″ washers, and
four 3/8″ nuts* (not included).
*Screws and washers may be used instead, if desired.
2. Place the Table Saw where it will be mounted.
Make a mark in the center of each of the
4 mounting holes. Set the Saw aside.
QFKMLMRl%%GI%JK6!6MG%E6KLIPE%LMkPKH-
Before drilling the holes, make sure that there
are no electric wires, cables, utility lines or
other obstructions in the area to be drilled.
3. Drill the holes straight down, large enough
to allow your mounting hardware to fit.
4. Put the Table Saw in place and mount
using the hardware mentioned above.
Tighten all hardware securely before use1
J&)*(%E'//7V%K*<'"(*5*8$#
1. Connect to grounded 120VAC, 20A receptacle.

Page 9;&(%$*4.8"4,7%<'*#$"&8#=%/7*,#*%4,77%>?@@@?@AA?BCDC1Item 57342
EF;6GHIJ6KFGLIMNFLMG6MFMO6 E6GPJ
;'84$"&8#
S7,9*%R',(9%
E$&(,3*%,89%
U'#$%J&($
K"/%;*84*%
E$&(,3*
J'#.%E$"4X%
E$&(,3*
Q&(X%
G,+7*
N"$*(%
R,'3*
S7,9*%
R',(9
S7,9*%
_*"3.$%
_,897*
S*W*7%
E4,7*
T&4X%
Y8&+
J&)*(%
E)"$4.
Q(*84.%
E$&(,3*
N"$*(%R,'3*%
E$&(,3*%
[&8%+,4X\
K"/%
;*84*
G,+7*%
L8#*($
K"/%
;*84*
E4,7*
0
0102030405060708
0
01020304050607080910
001 02 03 04 05 06 07 08 0910
001 02 03 04 05 06 07 08 09 10 11 12

Page 10 ;&(%$*4.8"4,7%<'*#$"&8#=%/7*,#*%4,77%>?@@@?@AA?BCDC1 Item 57342
EF;6GH IJ6KFGLIM NFLMG6MFMO6E6GPJ
E,)%S7,9*%E*7*4$"&8
1. Any saw blade that will be used must be
marked as suitable for the material to be cut.
2. Match the saw blade diameter, kerf width
and body dimensions to the riving knife.
3. Use only saw blades that are marked with a speed
equal or higher than the speed marked on the tool.
S*W*7%F837*%E*$$"83
1. Loosen Lock Knob, then move Blade Height
Handle until red indicator points to desired angle.
2. Tighten Lock Knob.
S7,9*%U*/$.%F9]'#$5*8$
M&$*- Blade depth should be set so that outer
points of blade are higher than workpiece
by approximately 1/8″ to 1/4″ and bottom of
gullets are below top surface of workpiece.
1. Loosen Lock Knob, then move Blade Height
Handle until red indicator points to 0°.
2. Tighten Lock Knob.
3. Turn Height Handle until desired depth is achieved.
K"W"83%Y8"2*%F9]'#$5*8$
M&$*- Riving Knife is permanently installed. It comes
in its lowest position for shipping. Reposition the
Riving Knife according to type of cut before use.
1. Remove Table Insert, pull up by using hole.
G,+7*%
L8#*($
2. Raise Riving Knife Lock.
K"W"83%
Y8"2*%T&4X
3. Adjust Riving Knife to proper position for type of cut:
a. Through Cut
b. Non-Through Cut
4. Lower Riving Knife Lock and replace Table Insert.

Page 11;&(%$*4.8"4,7%<'*#$"&8#=%/7*,#*%4,77%>?@@@?@AA?BCDC1Item 57342
EF;6GHIJ6KFGLIMNFLMG6MFMO6 E6GPJ
L8#$,77%S7,9*%R',(9
QFKMLMRl%%F7),V#%'#*%#,)%+7,9*%3',(9%,89%("W"83%X8"2*%2&(%*W*(V%$.(&'3.?4'$$"83%&/*(,$"&81%
;&(%$.(&'3.?4'$$"83%&/*(,$"&8#%).*(*%$.*%#,)%+7,9*%4'$#%4&5/7*$*7V%$.(&'3.%$.*%$."4X8*##%&2%
$.*%)&(X/"*4*=%$.*%3',(9%,89%&$.*(%#,2*$V%9*W"4*#%.*7/%(*9'4*%$.*%("#X%&2%#*("&'#%"8]'(V1
1. Raise Blade Guard Lock, then place Blade Guard
on top of Riving Knife so the Roller slides into
open slot at top of Riving Knife. Push Guard to the
back of the slot, then lower Blade Guard Lock.
2. Make sure Blade Guard is fully engaged, aligned
properly and does not contact the Blade.
3. Adjust Blade Guard to prevent
contact with Saw Blade.
QFKMLMRl%%GI%JK6!6MG%E6KLIPE%LMkPKH-
The Blade Guard must be removed for making
non-through cuts and must be reinstalled
after making non-through cuts.
S7,9*%
R',(9%
T&4X
K"W"83%
Y8"2*
L8#$,77%K"/%;*84*
QFKMLMRl GI%JK6!6MG%E6KLIPE%LMkPKH-
G&%/(*W*8$%X"4X+,4X=%5,X*%#'(*%K"/%;*84*%"#%/,(,77*7%$&%$.*%+7,9*%,89%7&4X*9%"8%/7,4*1%%%
U&%8&$%'#*%K"/%;*84*%).*8%4'$$"83%,4(&##%)&&9%3(,"8%[4(&##4'$$"83\1
M&$*- The Rip Fence can be installed
on either side of Blade.
1. Raise Rip Fence Lock.
2. Place Rip Fence on Work Table, then side to
desired location using Scale if necessary.
3. Lower Rip Fence Lock.
K"/%
;*84*%
T&4X
U'#$%6Z$(,4$"&8%E*$'/
Attach dust collection system to Dust Port on back of Table Saw.

Page 12 ;&(%$*4.8"4,7%<'*#$"&8#=%/7*,#*%4,77%>?@@@?@AA?BCDC1 Item 57342
EF;6GH IJ6KFGLIM NFLMG6MFMO6E6GPJ
6##*8$",7%E$(,"3.$%J'#.?#$"4X%;*,$'(*#%,89%;'84$"&8#
M&$*- Straight style (traditional) stick shown. A different stick design
may be used if it properly protects against all hazards.
U",3(,5%8&$%$&%#4,7*1
• Push sticks must be made from sturdy, defect-free, plywood or
normal wood to prevent unexpected breakage. Material must
be at least 1/4″ thick, but no thicker than the finished wood.
• Inspect push stick before use and do not use
a damaged or deteriorated push stick.
• Push stick dimensions will vary depending
on the application and user.
_,897*%M&$4.
• Must be far
enough down
the stick to allow
a comfortable
and firm grip.
• Must be deep
enough to prevent
hand from slipping
down the stick.
• Do not cut more than
halfway into the stick
to prevent weakening.
• Corners may
be rounded to
increase comfort.
E$"4X%T*83$.
• Must be long enough
to keep hand
clear of blade.
• At least 6″ from end
of handle to closest
part of notch.
M&$4.
• Must be right (90°) angle, cut at 30°-40° from the angle
of the stick to keep hands out of the line of the blade.
• The lower lip of the notch must be no
longer than the workpiece is thick.
At Least 6″
T*##%$.,8%
)&(X/"*4*%
$."4X8*##
MIG%GI%EOFT61MIG%GI%EOFT61
Dfm
nfm?gfmnfm?gfm

Page 13;&(%$*4.8"4,7%<'*#$"&8#=%/7*,#*%4,77%>?@@@?@AA?BCDC1Item 57342
EF;6GHIJ6KFGLIMNFLMG6MFMO6 E6GPJ
I/*(,$"83%L8#$('4$"&8#
%K*,9%$.*%6MGLK6%LNJIKGFMG%EF;6GH%LM;IKNFGLIM%#*4$"&8%,$%$.*%+*3"88"83%&2%$."#%
5,8',7%"847'9"83%,77%$*Z$%'89*(%#'+.*,9"83#%$.*(*"8%+*2&(*%#*$%'/%&(%'#*%&2%$."#%/(&9'4$1
GI%JK6!6MG%E6KLIPE%LMkPKH-%
Q*,(%FMEL?,//(&W*9%#,2*$V%3&337*#%,89%.*,("83%/(&$*4$"&8%9'("83%&/*(,$"&81%%
Q*,(%.*,WV?9'$V%)&(X%37&W*#%).*8%.,897"83%#,)%+7,9*#1
QFKMLMRl%%GI%JK6!6MG%E6KLIPE%LMkPKH%;KIN%FOOLU6MGFT%IJ6KFGLIM-%
N,X*%#'(*%$.,$%$.*%G("33*(%"#%"8%$.*%&22?/&#"$"&8%,89%'8/7'3%$.*%$&&7%2(&5%"$#%
*7*4$("4,7%&'$7*$%+*2&(*%/*(2&(5"83%,8V%/(&4*9'(*%"8%$."#%#*4$"&81
S7,9*%O.,83"83
QFKMLMRl%%GI%JK6!6MG%E6KLIPE%LMkPKH-%%N,X*%#'(*%$.,$%$.*%#,)%+7,9*%"#%"8#$,77*9%$&%(&$,$*%"8%$.*%
/(&/*(%9"(*4$"&81%U&%8&$%'#*%3("89"83%).**7#=%)"(*%+('#.*#=%&(%,+(,#"W*%).**7#%&8%,%$,+7*%#,)1%L5/(&/*(%
#,)%+7,9*%"8#$,77,$"&8%&(%'#*%&2%,44*##&("*#%8&$%(*4&55*89*9%5,V%4,'#*%#*("&'#%"8]'(V1%
Only use a 10″ saw blade with a 5/8″ diamond arbor, rated to at
7*,#$%g=bBf%KJN%,89%"8$*89*9%2&(%)&&94'$$"831%%
M&$*- Saw Blade sold separately.
1. Turn Power Switch off and unplug
the tool from its power source.
2. Loosen Lock Knob, then move Blade Height
Handle to 0°. Tighten Lock Lever.
3. Turn Blade Height Handle to lower
the Blade completely.
S7,9*%
_*"3.$%
_,897*
T&4X%
Y8&+
4. Raise Blade Guard Lock, then remove Blade Guard.
S7,9*%
R',(9%
T&4X
5. Remove Table Insert, pull up by using hole.
G,+7*%
L8#*($
6. Raise Blade completely, then move
Blade Height Handle to 15°.
7. Use two included wrenches, one to hold the
Inner Flange and the other to loosen the Blade Nut.
8. Remove Blade Nut, Outer Flange and Blade.
S7,9*%
M'$
I'$*(%
;7,83*%
L88*(%
;7,83*
9. Install new Blade with teeth pointing forward.
Replace Outer Flange and Blade Nut, then,
tighten Blade Nut. DO NOT overtighten.
10. Move Blade Height Handle to 0°. Lower
Saw blade completely, then replace
Table Insert and Blade Guard.

Page 14 ;&(%$*4.8"4,7%<'*#$"&8#=%/7*,#*%4,77%>?@@@?@AA?BCDC1 Item 57342
EF;6GH IJ6KFGLIM NFLMG6MFMO6E6GPJ
Q&(X/"*4*%,89%Q&(X%F(*,%E*$%P/
1. Designate a work area that is clean and well lit.
The work area must not allow access by children
or pets to prevent distraction and injury.
2. Route the power cord along a safe route to reach
the work area without creating a tripping hazard or
exposing the power cord to possible damage. The
power cord must reach the work area with enough
extra length to allow free movement while working.
3. There must not be objects, such as utility lines,
nearby that will present a hazard while working.
4. Cut only the following materials:
Dimensional lumber, plywood, particle board.
M&$*- Use caution to avoid overheating the cutting tips.
5. Use an auxiliary fence to be in contact with
the table top when cutting thin workpieces;
6. Allow room on both sides of saw
for extended workpieces.
7. Use additional supports if needed to ensure
the stability of the workpiece. Mount the Saw
so that the surface is level to the ground, and
additional supports to provide a surface on the
same level as the saw table. If the work surface
and any workpiece supports are not level, and
on the same level, unwanted bevel angles will
appear in the cuts resulting in poor joinery.
R*8*(,7%L8#$('4$"&8#%2&(%P#*
%
EFQE%OFM%oPLOYTH%FNJPGFG6%;LMR6KE%L;%NLEPE6U1%%%
Y**/%.,89#%)*77%47*,(%&2%4'$$"83%,(*,1%
UI%MIG%IJ6KFG6%QLG_%FMH%RPFKU%ULEFST6U=%UFNFR6U=%IK%K6NI!6U1%%%
N&W"83%3',(9#%5'#$%5&W*%2(**7V%,89%47&#*%"8#$,8$7V1%%
LMEGFTT%RPFKU%S6;IK6%PE61
J(&/*(%J7,4*5*8$%I2%_,89#%U'("83%$.*%O'$$"83%J(&4*##
1. Review Safety warnings at the beginning of the
manual before performing any cutting procedure.
Keep all guards in place and in working order.
2. Do not pass hands directly over the Saw Blade
when cutting the workpiece. Push the workpiece
into the Saw Blade using a Push-stick, push-block or
by holding the workpiece against the Miter Gauge.
QFKMLMRl%%EF;6%OPGGLMR%JKIO6UPK6E%!FKH%U6J6MULMR%IM%G_6%GHJ6%I;%OPG1%%%
GI%JK6!6MG%E6KLIPE%LMkPKH%;KIN%YLOYSFOY-
P#*%;*84*%2&(%*W*(V%K"/%O'$%%
[4'$%,7&83%)"$.%$.*%3(,"8\1
K"/%O'$#
1. Rip cuts are straight cuts made parallel
to (along with) the grain of the wood by
sliding the workpiece along the Fence.
2. For pieces wider than 6″, hold the workpiece,
staying clear of the Saw Blade. For pieces
between 2″ and 6″, use the included Push-
stick or make a push-stick as described in the
Safety section of this manual. Use a Push-block
(not included) when ripping widths under 2″.
3. When ripping, always use the Rip Fence.
This improves the accuracy of the cut, and
reduces the chance for Saw Blade binding.
U&%8&$%'#*%;*84*%2&(%,8V%4(&##4'$%%
[4'$%,3,"8#$%$.*%3(,"8\1
O(&##4'$#0N"$*(%O'$#
Blade Guard Saw Blade
Miter
Gauge Workpiece
Clamp
Scrap Wood
Cut Line
1. Adjust the Miter Gauge to the needed angle and
place it in the right or left slot on the Table.
2. Hold the workpiece against the Miter Gauge,
and slide them together to make the cut.
Clamp smaller pieces to a piece of scrap wood
that can reach beyond the Miter Gauge and
hold the scrap against the Gauge while making
the cut. Keep the clamp clear of the Saw Blade.
SPG

Page 15;&(%$*4.8"4,7%<'*#$"&8#=%/7*,#*%4,77%>?@@@?@AA?BCDC1Item 57342
EF;6GHIJ6KFGLIMNFLMG6MFMO6 E6GPJ
N,X"83%,%O'$
1. After adjusting the width and/or angle of the cut,
plug the Table Saw into a grounded 120V outlet.
2. Turn the Power Switch on.
QFKMLMRl Avoid bevel ripping on
bevelling side of the saw blade.
QFKMLMRl%%GI%JK6!6MG%E6KLIPE%LMkPKH-
The tool will restart automatically if stalled.
3. At the start of the cut, the left hand holds
the workpiece firmly on the Work Table
(and against the Fence, if used), and the right
hand, with the aid of a Push-stick, pushes
the workpiece toward the turning Saw Blade.
Keep both hands out of the path of the Saw Blade.
QFKMLMRl%%GI%JK6!6MG%E6KLIPE%LMkPKH-
Throughout the cut, keep all body parts a
safe distance from the spinning Blade.
4. After the cut is under way, use the Push Stick
to continue guiding the workpiece forward.
Just before the cut is completed, move the left hand
safely farther away from the workpiece and the Saw
Blade. Continue pushing the workpiece into the Saw
Blade with the Push Stick until the cut is complete.
5. Once the cut is complete, continue to maintain
control of the workpiece. Turn the Switch off.
Then, wait until the Saw Blade completely stops
rotating before removing the workpiece.
6. To prevent accidents, turn off the Table Saw,
and unplug it after use. Clean, then cover and
store the Saw indoors out of children’s reach.
N,X"83%,%M&8?G.(&'3.%O'$
1. Unplug saw and remove Blade Guard.
2. Place Riving Knife in Non-Through Cut position.
[E**%+1%M&8?G.(&'3.%O'$%&8%/,3*%>f\1
3. Unlock Bevel Lock and set the bevel
angle to 0°, then secure Bevel Lock.
4. Set the blade to the correct depth for the workpiece.
5. Use either the Rip Fence or Miter Gauge,
depending on the shape and size of the wood.
6. Plug the saw back in and turn Power on.
7. Allow the blade to reach full speed before
moving the workpiece into the blade.
QFKMLMR- Always use Push Blocks, Push Sticks,
and/or Featherboards appropriately when making
non-through cuts to reduce the risk of serious injury.
8. After the cut has been made, turn saw off.
Allow the blade to come to a complete
stop before removing the workpiece.
9. QFKMLMRl%%GI%JK6!6MG%E6KLIPE%LMkPKH-
Reposition Riving Knife and reinstall Blade Guard
before doing any other type of cut and after use,
even if you intend to do more non-through cuts at
another time. The Blade Guard is a critical safety
component and must be used whenever practical.
N,X"83%,89%P#"83%,%k"3%
M&$*- A jig is used for all tapered cuts.
1. Use recessed screws to secure a handle
to a long, straight piece of wood.
2. Cut an L-shaped stop in the left side of the jig.
3. Position the workpiece flat on the table with the edge
flush against the jig and against the L-shaped stop.
4. Hold jig handle and use a push block
(sold separately) while making a tapered cut.
N,X"83%,89%P#"83%,8%F'Z"7",(V%;*84*
M&$*- An auxiliary fence is used for
rip cutting thin workpieces.
1. Use a piece of wood that is 3/4″ thick,
3-1/2″ wide, and 18-1/2″ long.
2. Place the wood piece against left side of rip
fence and rest firmly on the saw table.
3. Secure wood piece to the fence
using 1-1/2″ wood screws.

Page 16 ;&(%$*4.8"4,7%<'*#$"&8#=%/7*,#*%4,77%>?@@@?@AA?BCDC1 Item 57342
EF;6GH IJ6KFGLIM NFLMG6MFMO6E6GPJ
N,"8$*8,84*%,89%E*(W"4"83%L8#$('4$"&8#
%J(&4*9'(*#%8&$%#/*4"2"4,77V%*Z/7,"8*9%"8%$."#%5,8',7%5'#$%
+*%/*(2&(5*9%&87V%+V%,%<',7"2"*9%$*4.8"4",81
GI%JK6!6MG%E6KLIPE%LMkPKH%;KIN%FOOLU6MGFT%IJ6KFGLIM-%
N,X*%#'(*%$.,$%$.*%G("33*(%"#%"8%$.*%&22?/&#"$"&8%,89%'8/7'3%$.*%$&&7%2(&5%"$#%
*7*4$("4,7%&'$7*$%+*2&(*%/*(2&(5"83%,8V%/(&4*9'(*%"8%$."#%#*4$"&81
GI%JK6!6MG%E6KLIPE%LMkPKH%;KIN%GIIT%;FLTPK6-%
U&%8&$%'#*%9,5,3*9%*<'"/5*8$1%%L2%,+8&(5,7%8&"#*%&(%W"+(,$"&8%
&44'(#=%.,W*%$.*%/(&+7*5%4&((*4$*9%+*2&(*%2'($.*(%'#*1
O7*,8"83=%N,"8$*8,84*=%,89%T'+("4,$"&8
1. S6;IK6%6FO_%PE6= inspect the general
condition of the tool. Check for:
• loose hardware,
• misalignment or binding of moving parts,
• damaged cord/electrical wiring,
• cracked or broken parts, and
• any other condition that may
affect its safe operation.
2. F;G6K%PE6= wipe external surfaces
of the tool with clean cloth.
3. K*5&W*%4'$?&22%/"*4*#%,89%#4(,/#%2(&5%$.*%G,+7*%
+*2&(*%#$,($"83%$.*%G,+7*%E,)1%%Switch off the tool.
While the Saw Blade is completely stopped; unplug
the machine, remove the Blade, and remove all
debris. With a brush, soft cloth, or vacuum, remove
all sawdust from the Table Saw.
F77&)"83%#,)9'#$=%#4(,/#=%&(%&$.*(%9*+("#%
$&%,44'5'7,$*%4,8%4,'#*%,%2"(*=%(*#'7$"83%"8%
#*W*(*%/*(#&8,7%"8]'(V%&(%/(&/*($V%9,5,3*1
4. Do not use solvents to wipe off the Table Saw, as
damage may result. If necessary, wipe with a damp
cloth. You may use a mild detergent.
U&%8&$%"8$(&9'4*%),$*(%"8$&%$.*%*7*4$("4%
5&$&(%$.(&'3.%$.*%5&$&(%W*8$#1
5. Once clean, lubricate all moving parts with a light oil.
6. When storing, keep the Table Saw
covered with a cloth cover.
7. QFKMLMRl%%GI%JK6!6MG%E6KLIPE%
LMkPKH-%%L2%$.*%/7'3%&(%$.*%#'//7V%4&(9%&2%$."#%
/&)*(%$&&7%"#%9,5,3*9=%"$%5'#$%+*%(*/7,4*9%
&87V%+V%,%<',7"2"*9%#*(W"4*%$*4.8"4",81

Page 17;&(%$*4.8"4,7%<'*#$"&8#=%/7*,#*%4,77%>?@@@?@AA?BCDC1Item 57342
EF;6GHIJ6KFGLIMNFLMG6MFMO6 E6GPJ
G(&'+7*#.&&$"83
J(&+7*5 J&##"+7*%O,'#*# T"X*7V%E&7'$"&8#
Tool will not start. 1. Cord not connected.
2. No power at outlet.
3. Tool’s thermal reset breaker
tripped (if equipped).
4. Internal damage or wear.
(Carbon brushes or
Trigger, for example.)
1. Check that cord is plugged in.
2. Check power at outlet. If outlet is unpowered,
turn off tool and check circuit breaker.
If breaker is tripped, make sure circuit is right
capacity for tool and circuit has no other loads.
3. Turn off tool and allow to cool.
Press reset button on tool.
4. Have technician service tool.
Tool operates slowly. 1. Forcing tool to work too fast.
2. Extension cord too long or cord
diameter too small.
1. Allow tool to work at its own rate.
2. Eliminate use of extension cord. If an extension
cord is needed, use one with the proper diameter
for its length and load. See Extension Cords
in Grounding section on page 6.
Performance
decreases over time.
Carbon brushes worn
or damaged.
Have qualified technician replace brushes.
Excessive noise
or rattling.
Internal damage or wear. (Carbon
brushes or bearings, for example.)
Have technician service tool.
Overheating. 1. Forcing tool to work too fast.
2. Blocked motor housing vents.
3. Motor being strained by long or
small diameter extension cord.
1. Allow tool to work at its own rate.
2. Wear ANSI-approved safety goggles and
NIOSH-approved dust mask/respirator while
blowing dust out of motor using compressed air.
3. Eliminate use of extension cord. If an extension
cord is needed, use one with the proper diameter
for its length and load. See Extension Cords
in Grounding section on page 6.
% ;&77&)%,77%#,2*$V%/(*4,'$"&8#%).*8*W*(%9",38&#"83%&(%#*(W"4"83%$.*%$&&71%%%
U"#4&88*4$%/&)*(%#'//7V%+*2&(*%#*(W"4*1

Page 18 ;&(%$*4.8"4,7%<'*#$"&8#=%/7*,#*%4,77%>?@@@?@AA?BCDC1 Item 57342
EF;6GH IJ6KFGLIM NFLMG6MFMO6E6GPJ
JT6FE6%K6FU%G_6%;ITTIQLMR%OFK6;PTTH
THE MANUFACTURER AND/OR DISTRIBUTOR HAS PROVIDED THE PARTS LIST AND ASSEMBLY DIAGRAM
IN THIS MANUAL AS A REFERENCE TOOL ONLY. NEITHER THE MANUFACTURER OR DISTRIBUTOR
MAKES ANY REPRESENTATION OR WARRANTY OF ANY KIND TO THE BUYER THAT HE OR SHE IS
QUALIFIED TO MAKE ANY REPAIRS TO THE PRODUCT, OR THAT HE OR SHE IS QUALIFIED TO REPLACE
ANY PARTS OF THE PRODUCT. IN FACT, THE MANUFACTURER AND/OR DISTRIBUTOR EXPRESSLY
STATES THAT ALL REPAIRS AND PARTS REPLACEMENTS SHOULD BE UNDERTAKEN BY CERTIFIED AND
LICENSED TECHNICIANS, AND NOT BY THE BUYER. THE BUYER ASSUMES ALL RISK AND LIABILITY
ARISING OUT OF HIS OR HER REPAIRS TO THE ORIGINAL PRODUCT OR REPLACEMENT PARTS
THERETO, OR ARISING OUT OF HIS OR HER INSTALLATION OF REPLACEMENT PARTS THERETO.

Page 19;&(%$*4.8"4,7%<'*#$"&8#=%/7*,#*%4,77%>?@@@?@AA?BCDC1Item 57342
EF;6GHIJ6KFGLIMNFLMG6MFMO6 E6GPJ
K*4&(9%J(&9'4$^#%E*(",7%M'5+*(%_*(*-%
M&$*-%L2%/(&9'4$%.,#%8&%#*(",7%8'5+*(=%(*4&(9%5&8$.%,89%V*,(%&2%/'(4.,#*%"8#$*,91
M&$*- Some parts are listed and shown for illustration purposes only,
and are not available individually as replacement parts.

Page 20 ;&(%$*4.8"4,7%<'*#$"&8#=%/7*,#*%4,77%>?@@@?@AA?BCDC1 Item 57342
EF;6GH IJ6KFGLIM NFLMG6MFMO6E6GPJ
J,($#%T"#$%,89%U",3(,5
J,($#%T"#$
J,($ U*#4("/$"&8 o$V
1 Cap 1
2 Nut M6 2
3 Spring 1
4 Plate 1
5 Cap 1
6 Fence Draw Bar 1
7 Fence 1
8 Hex Bolt M6x12, Spring Washer, Washer 2
9 Knob 5
10 Screw M4x10, Spring Washer, Washer 4
11 Rip Fence Indicator 1
12 Fence Seat 1
13 Fence Lock 1
14 Set Screw 1
15 Screw M5x10 2
16 Locking Plate 2
17 Cap 1
18 Sliding Fence 1
19 Bolt M6×50 2
20 Cap 1
21 Locking Plate 1
22 Blade Guard Bracket 1
23 Screw M5x10, Spring Washer, Washer 2
24 Bolt M6×16 4
25 Cap 1
26 Scale Base 1
27 Rip Fence Scale 1
28 Fixed Plate 4
29 Washer Ø6x12x0.8 7
30 Spring Washer 4
31 Cap 1
32 Nut M6 4
33 Hex Bolt M6x25, Spring Washer, Washer 4
34 Rotating Base 1
35 Rotating Friction Plate 1
J,($ U*#4("/$"&8 o$V
36 Bracket 2
37 Gasket 2
38 Screw ST4.2x10 6
39 Angle Guard Plate 1
40 Angle Guard 1
41 Angle Guard Spring 1
42 Hex Bolt M6x16, Spring Washer, Washer 6
43 Washer Ø6x18x1.5 6
44 Handle 2
45 Main Table 1
46 Table Insert 1
47 Screw M4x 5 6
48 Blade Guard Spring Clip 2
49 Screw 4
50 Blade Guard (Left) 1
51 Nut M5 6
52 Washer Ø5x14x1 1
53 Blade Guard Lock 1
54 Blade Guard Bracket 1
55 Riving Knife 1
56 Spring 1
57 Bracket Fixed Pin 1
58 Locking Screw 1
59 Riving Knife Pin 5 X 32 1
60 Blade Guard (Right) 1
61 Lifting Friction Pad 1
62 Riving Knife Bracket 1
63 Hex Bolt M6x20 2
64 Pin 8x16 2
65 Riving Knife Plate 1
66 Spring 1
67 Pin 5x32 1
68 Cylindrical Pin 8x16 1
69 Riving Knife Handle 1
70 Spring 1
