Wasp Cycle Cadence Sensor User manual

Cycle Cadence Sensor
User Manual
Cycle Cadence Sensor User Manual
Cycle Cadence Sensor User Manual
Congratulations on purchasing our WASP cycle cadence sensor.
This device supports both Bluetooth LE 4.0 and ANT+ real-time
monitoring of cadence. Information is transmitted wirelessly from
the sensor to your smart phone app or sports watch. This user
manual will help you to use the product better, so please keep
it for reference.
Product Overview
1 x Speed/cadence Sensor 2 x Rubber mat (flat, curved)
User Manual
2 x Band (large, small)
Caring for your device
Please follow these caring instructions to ensure reliable
operation of the cycle cadence sensor and to maximize life span.
Detach the sensor from the bike after use, and clean and dry with
a soft towel. Do not use cleaning chemicals.
Disclaimer
The information contained in this manual is for reference only.
The product described may be subject to alteration owing to the
manufacturer’s continuing research and development plans, without
making an announcement in advance. We shall not make any
statement or warranty about this manual or the contained product.
We shall not bear any legal responsibility for any direct or indirect,
accidental or special damages, losses and expenses arising from or
in connection with this manual or the contained product.
For more information visit www.thewaspworks.com
Cadence Sensor User Manual Fin Art.indd 1 12/11/18 3:08 pm

Compatibility
iOS7.0 system version
above, iPhone 4s or later.
For compatible ANT+ devices that support
the Heart Rate Profile (HRP), please go to
https://www.thisisant.com/directory.
Any Bluetooth 4.0 enabled Android
device with Android 4.4 or later.
Compatible with most popular apps such as
MooFit/Endomondo/Strava/Sports Tracker/
Runtastic/Wahoo Fitness/WASP
Battery
This device comes with a CR2032 battery already installed.
Battery replacement
Using a coin, twist the battery door counter clockwise until
it clicks out of place.
Remove the battery and
replace with (+) side up.
Use a coin to twist the
battery door back into
place clockwise.
Keep batteries
away from children.
Dispose of used
battery according
to local regulations.
Cycle cadence sensor specifications
Measurement Range 300rpm (or 120km/h for speed)
Working temperature -20℃ + 60℃
Communication Bluetooth LE 20m: ANT+ 10m
Battery Life 300 hours for cadence mode
500 hours for speed mode.
Waterproof grade IP67
Product size 36 x 30 x 13.8 mm
Weight 9g
Specifications are subject to change without notice.
Take out the
insulating sheet
Function and operation
This product has two modes of operation, cadence or speed
monitoring. The mode switches from speed to cadence monitoring
and back each time the battery is removed and replaced. After
inserting the battery, a light on the front of the product will glow
either red or blue for a few seconds.
Mode switching
Twist the battery door with a coin in the OPEN direction, open the
battery door, remove the battery and then re-insert the battery
again. Close the battery door by twisting in the CLOSE direction.
After the battery is re-inserted there will be a light on.
RED indicates speed mode
BLUE indicates cadence mode
Installation for cadence mode
Buckle the flat rubber mat onto the back of the sensor, then
bind the sensor with the large rubber band onto the pedal crank.
Installation for speed mode
Buckle the curved rubber mat onto the back of the sensor, then
bind the sensor with the large rubber band onto the wheel axle.
