Firebox®X Peak
Hardware Guide
Firebox® X5000, Firebox® X6000, Firebox® X8000

Limited Hardware Warranty
Firebox X Peak Hardware Guide 2
Copyright and Patent Information
Copyright© 1998 - 2005 WatchGuard Technologies, Inc. All rights reserved.
WatchGuard, the WatchGuard logo, Firebox, LiveSecurity, and any other mark listed as a
trademark in the “Terms of Use” portion of the WatchGuard Web site that is used herein are
either registered trademarks or trademarks of WatchGuard Technologies, Inc. and/or it’s
subsidiaries in the United States and/or other countries. All other trademarks are the
property of their respective owners.
Printed in the United States of America.
Publication ID: 1311-001
Text ID: 1311-000
Doc Version: 8.0
U.S. Patent Nos. 6,493,752; 6,597,661; D473,879. Other Patents Pending.
Notice to Users
Information in this guide is subject to change without notice. Companies, names, and data
used in examples herein are fictitious unless otherwise noted. No part of this guide may be
reproduced or transmitted in any form or by any means, electronic or mechanical, for any
purpose, without the express written permission of WatchGuard Technologies, Inc.
Limited Hardware Warranty
This Limited Hardware Warranty (the “Warranty”) applies to the enclosed Firebox hardware
product, not including any associated software which is licensed pursuant to a separate end-
user license agreement and warranty (the “Product”). BY USING THE PRODUCT, YOU (either
an individual or a single entity) AGREE TO THE TERMS HEREOF. If you do not agree to these
terms, please return this package, along with proof of purchase, to the authorized dealer
from which you purchased it for a full refund. WatchGuard Technologies, Inc. (“WatchGuard”)
and you agree as set forth below or on the reverse side of this card, as applicable:
1. LIMITED WARRANTY. WatchGuard warrants that upon delivery and for one (1) year
thereafter (the “Warranty Period”): (a) the Product will be free from material defects in
materials and workmanship, and (b) the Product, when properly installed and used for its
Complete copyright, trademark, patent, and licensing
information can be found in the WatchGuard System
Manager User Guide. A copy of this book is automatically
installed into a folder of the installation directory called
Documentation. You can also find it online at:
http://www.watchguard.com/help/documentation/

Limited Hardware Warranty
Firebox X Peak Hardware Guide 3
intended purpose and in its intended operating environment, will perform substantially in
accordance with WatchGuard applicable specifications.
This warranty does not apply to any Product that has been: (i) altered, repaired or modified by
any party other than WatchGuard except for the replacement or inclusion of specified
components authorized in and performed in strict accordance with documentation provided
by WatchGuard; or (ii) damaged or destroyed by accidents, power spikes or similar events or
by any intentional, reckless or negligent acts or omissions of any party. You may have
additional warranties with respect to the Product from the manufacturers of Product
components. However, you agree not to look to WatchGuard for, and hereby release
WatchGuard from any liability for, performance of, enforcement of, or damages or other relief
on account of, any such warranties or any breach thereof.
2. REMEDIES. If any Product does not comply with the WatchGuard warranties set forth in
Section 1 above, WatchGuard will, following receipt of the product you claim is defective and
at its option, either (a) repair the Product, or (b) replace the Product; provided, that you will
be responsible for returning the Product and for all costs of shipping and handling. Repair or
replacement of the Product shall not extend the Warranty Period. Any Product, component,
part or other item replaced by WatchGuard becomes the property of WatchGuard.
WatchGuard shall not be responsible for return of or damage to any software, firmware,
information or data contained in, stored on, or integrated with any returned Products.
3. DISCLAIMER AND RELEASE. THE WARRANTIES, OBLIGATIONS AND LIABILITIES OF
WATCHGUARD, AND YOUR REMEDIES, SET FORTH IN PARAGRAPHS 1 AND 2 ABOVE ARE
EXCLUSIVE AND IN SUBSTITUTION FOR, AND YOU HEREBY WAIVE, DISCLAIM AND RELEASE
ANY AND ALL OTHER WARRANTIES, OBLIGATIONS AND LIABILITIES OF WATCHGUARD AND
ALL OTHER RIGHTS, CLAIMS AND REMEDIES YOU MAY HAVE AGAINST WATCHGUARD,
EXPRESS OR IMPLIED, ARISING BY LAW OR OTHERWISE, WITH RESPECT TO ANY
NONCONFORMANCE OR DEFECT IN THE PRODUCT (INCLUDING, BUT NOT LIMITED TO, ANY
IMPLIED WARRANTY OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE, ANY
IMPLIED WARRANTY ARISING FROM COURSE OF PERFORMANCE, COURSE OF DEALING, OR
USAGE OF TRADE, ANY WARRANTY OF NONINFRINGEMENT, ANY WARRANTY OF
UNINTERRUPTED OR ERROR-FREE OPERATION, ANY OBLIGATION, LIABILITY, RIGHT, CLAIM OR
REMEDY IN TORT, WHETHER OR NOT ARISING FROM THE NEGLIGENCE (WHETHER ACTIVE,
PASSIVE OR IMPUTED) OR FAULT OF WATCHGUARD OR FROM PRODUCT LIABILITY, STRICT
LIABILITY OR OTHER THEORY, AND ANY OBLIGATION, LIABILITY, RIGHT, CLAIM OR REMEDY
FOR LOSS OR DAMAGE TO, OR CAUSED BY OR CONTRIBUTED TO BY, THE PRODUCT).
4. LIMITATION AND LIABILITY. WATCHGUARD’S LIABILITY (WHETHER ARISING IN CONTRACT
(INCLUDING WARRANTY), TORT (INCLUDING ACTIVE, PASSIVE OR IMPUTED NEGLIGENCE AND
STRICT LIABILITY AND FAULT) OR OTHER THEORY) WITH REGARD TO ANY PRODUCT WILL IN
NO EVENT EXCEED THE PURCHASE PRICE PAID BY YOU FOR SUCH PRODUCT. THIS SHALL BE
TRUE EVEN IN THE EVENT OF THE FAILURE OF ANY AGREED REMEDY. IN NO EVENT WILL
WATCHGUARD BE LIABLE TO YOU OR ANY THIRD PARTY (WHETHER ARISING IN CONTRACT
(INCLUDING WARRANTY), TORT (INCLUDING ACTIVE, PASSIVE OR IMPUTED NEGLIGENCE AND
STRICT LIABILITY AND FAULT) OR OTHER THEORY) FOR COST OF COVER OR FOR ANY
INDIRECT, SPECIAL, INCIDENTAL, OR CONSEQUENTIAL DAMAGES (INCLUDING WITHOUT
LIMITATION LOSS OF PROFITS, BUSINESS, OR DATA) ARISING OUT OF OR IN CONNECTION
WITH THIS WARRANTY OR THE USE OF OR INABILITY TO USE THE PRODUCT, EVEN IF

Limited Hardware Warranty
Firebox X Peak Hardware Guide 4
WATCHGUARD HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES. THIS SHALL BE
TRUE EVEN IN THE EVENT OF THE FAILURE OF ANY AGREED REMEDY.
5. MISCELLANEOUS PROVISIONS. This Warranty will be governed by the laws of the state of
Washington, U.S.A., without reference to its choice of law rules. The provisions of the 1980
United Nations Convention on Contracts for the International Sales of Goods, as amended,
shall not apply. You agree not to directly or indirectly transfer the Product or associated
documentation to any country to which such transfer would be prohibited by the U.S. Export
laws and regulations. If any provision of this Warranty is found to be invalid or unenforceable,
then the remainder shall have full force and effect and the invalid provision shall be modified
or partially enforced to the maximum extent permitted by law to effectuate the purpose of
this Warranty. This is the entire agreement between WatchGuard and you relating to the
Product, and supersedes any prior purchase order, communications, advertising or
representations concerning the Product AND BY USING THE PRODUCT YOU AGREE TO THESE
TERMS. IF THE PRODUCT IS BEING USED BY AN ENTITY, THE INDIVIDUAL INDICATING
AGREEMENT TO THESE TERMS BY USING THE PRODUCT REPRESENTS AND WARRANTS THAT
(A) SUCH INDIVIDUAL IS DULY AUTHORIZED TO ACCEPT THE WARRANTY ON BEHALF OF THE
ENTITY AND TO BIND THE ENTITY TO THE TERMS OF THIS WARRANTY; (B) THE ENTITY HAS
THE FULL POWER, CORPORATE OR OTHERWISE, TO ENTER INTO THE WARRANTY AND
PERFORM ITS OBLIGATIONS UNDER THE WARRANTY AND; (C) THE WARRANTY AND THE
PERFORMANCE OF THE ENTITY’S OBLIGATIONS UNDER THE WARRANTY DO NOT VIOLATE
ANY THIRD-PARTY AGREEMENT TO WHICH THE ENTITY IS A PARTY. No change or modification
of the Warranty will be valid unless it is in writing and is signed by WatchGuard.

Limited Hardware Warranty
Firebox X Peak Hardware Guide 5
Declaration of Conformity

Limited Hardware Warranty
Firebox X Peak Hardware Guide 6
FCC Certification
This device has been tested and found to comply with limits for a Class A
digital device, pursuant to Part 15 of the FCC Rules. Operation is subject to
the following two conditions:
This device may not cause harmful interference.
This device must accept any interference received, including interference
that may cause undesired operation.
CE Notice
The CE symbol on your WatchGuard Technologies equipment indicates that
it is in compliance with the Electromagnetic Compatibility (EMC) directive
and the Low Voltage Directive (LVD) of the European Union (EU).
Industry Canada
This Class A digital apparatus meets all requirements of the Canadian Inter-
ference-Causing Equipment Regulations.
Cet appareil numerique de la classe A respecte toutes les exigences du
Reglement sur le materiel broulleur du Canada.
VCCI Notice Class A ITE

Limited Hardware Warranty
Firebox X Peak Hardware Guide 7
CAUTION: DANGER OF EXPLOSION IF BATTERY IS INCORRECTLY
REPLACED. REPLACE ONLY WITH THE SAME OR EQUIVALENT TYPE REC-
OMMENDED BY THE MANUFACTURER. DISPOSE OF USED BATTERIES
ACCORDING TO THE MANUFACTURER’S INSTRUCTIONS.
ATTENTION: IL Y A DANGER D’EXPLOSION S’IL Y A REMPLACEMENT
INCORRECT DE LA BATTERIE, REMPLACER UNIQUEMENT AVEC UNE BAT-
TERIE DU MÊME TYPE OU D’UN TYPE ÉQUIVALENT RECOMMANDÉ PAR
LE CONSTRUCTEUR. METTRE AU REBUT LES BATTERIES USAGÉES CON-
FORMÉMENT AUX INSTRUCTIONS DU FABRICANT.

Firebox X Peak Hardware Guide 8
Contents
Limited Hardware Warranty ............................................2
Package Contents ............................................................2
Hardware Specifications .................................................3
Interface Specifications ..................................................3
Environmental Requirements .........................................3
Hardware Description ......................................................4
Firebox X front ......................................................... 4
Firebox X rear .......................................................... 7

Firebox X Peak Hardware Guide 1
Firebox X Peak
Hardware Guide
The Firebox® X Peak is a line of model-upgradeable, integrated
security devices designed to deliver superior security with opti-
mized performance for your network-intensive enterprise or
data center. Each appliance includes these features for compre-
hensive protection of your network:
• Stateful firewall
• Gateway antivirus
• Behavioral and signature-based intrusion prevention
• Deep application inspection
• Web content filtering
• Virtual private networking
• Authentication
The Firebox X Peak features an Intelligent Layered Security
architecture that identifies and blocks threats at many layers.
This cooperative protection keeps your network safe from
threats which come from the outside and inside your network.
Firebox X Peak devices ship with WatchGuard’s next generation
operating system — Fireware Pro. Some features Fireware Pro
provides include:
• Advanced networking features

2
• High availability
• Quality of service
• Dynamic routing protocol support
• AES VPN encryption
The WatchGuard® System Manager management software is an
intuitive interface to configure, manage and monitor all the
Firebox X devices on your network.
The Firebox X Peak model line also includes high port density
and gigabit throughput capacity to accommodate your network
intensive requirements. The device is packaged in a 1U rack-
mountable form factor for space-saving installation.
For information on installing the Firebox X Peak device, see the
Firebox X Peak QuickStart Guide or the “Getting Started” chap-
ter in the WatchGuard System Manager User Guide. Thank you
for selecting the Firebox X Peak to protect your network. We
look forward to meeting your security requirements in these
dynamic times.
Package Contents
The package contains this Hardware Guide and:
•QuickStartGuide
• Firebox® X Peak device
• 3 straight-through Ethernet cables (green)
• 1 crossover Ethernet cable (red)
• 1 serial cable (blue)
• 1 DB9 adapter
• 1 rack-mounting kit
• WatchGuard® System Manager CD-ROM
• LiveSecurity®Service activation card
• License key
• Warranty card
• 4 rubber pads for the bottom of the appliance

Hardware Specifications
Firebox X Peak Hardware Guide 3
Hardware Specifications
This table shows the hardware specifications for the Firebox® X
Peak.
Interface Specifications
This table shows the interface specifications for the Firebox® X
Peak.
Environmental Requirements
We recommend that you uses these guidelines to install your
Firebox® X Peak device safely:
• Install in a network rack
Processor 2.8 GHz Intel based Processor
Memory - Flash 128 MB
Memory - RAM 512 MB
Cache 512 KB Level 2
Power supply 100-240 VAC
Autosensing
System Bus PCI-X 64-bit, 66Mhz and
PCI 32-bit, 33Mhz
Dimensions D=13.5” (34.29 cm)
W=16.75” (42.55 cm)
H=1.75” (4.45 cm)
Weight 12 lbs (5.44 Kg)
Current 1.2Amps @ 115VAC
Heat dissipation 471 BTU/hour
Network interfaces 7 x 10/100 Mbps Fast Ethernet
auto-negotiate (half/full duplex) RJ-45
3 x 10/100/1000 Gigabit Ethernet,
auto-negotiate (half/full duplex), RJ-45
Serial ports 2 DB9 (1 front, 1 rear)
USB ports 1 USB 2.0

4
• Put in a secure area, such as a locked room, to block
personnel from physical access to the device who do not
have permission
• Connect to a conditioned power supply to prevent damage
which a sudden power change can cause
This table shows environmental requirements:
Hardware Description
Firebox X front
This photograph shows the front panel the Firebox® X Peak.
Operating
temperature 0 – 45 degrees Celsius (32 – 113 degrees Fahrenheit)
Operating
humidity 10% - 85%
Non-operating
temperature -40 – 70 degrees Celsius (-40 – 158 degrees Fahrenheit)
Non-operating
humidity 10% – 95% Non-condensing at 55 degrees Celsius
(131 degrees Fahrenheit)
Non-operating
random vibration 7 – 28 Hz 0.001 to 0.01 G2 per Hz
Acoustic noise 57 dBA at 20° - 25°C
Operating
mechanical shock 20.0 G with 11 Msec duration 1/2 sine wave

Hardware Description
Firebox X Peak Hardware Guide 5
The photograph below is a close-up of the left side of the
Firebox® X Peak. It shows the LCD indicator panel. For more
information, see the “LCD Display” appendix of the Fireware
Configuration Guide.
From the left, the indicators are as follows:
Front Panel Display
The LCD screen shows Firebox X Peak status
information. Use the buttons to change the
information that appears.
LCD Console Buttons
Use the LCD Console buttons to see or edit the Firebox
X Peak status and configuration.
Reset
Use the Reset button to reset the Firebox.
Power
An amber LED (light-emitting diode) indicates that the
power is on.
Storage
A green LED indicates that the Firebox is writing to or
reading from the compact flash card or the hard drive
disk (if installed).
Arm/Disarm
A green LED indicates the Firebox is armed. A red LED
indicates the Firebox is disarmed.
DB9 Serial Port (Console)
A DB9 connector for the serial port. This serial port has
a door that it is necessary to remove to use the serial
port.

6
USB Port
The USB port is not currently used. This feature is
reserved for possible future use.
The photograph below shows a close-up of the right side of the
Firebox X Peak. From the left, the indicators and connections
are as follows.
Ethernet interfaces
All ethernet interfaces have standard RJ45 connectors.
The maximum speed for each interface depends on the
Firebox X model you purchased.
The first three interfaces have a label to identify them
as 0, 1, and 2. The label also shows the maximum speed
with the text 10/100/1000.
The subsequent seven interfaces have a label to identify
them as 3 - 9. The label also shows the maximum speed
with the text 10/100.
LEDs (Interfaces 0–2)
There are three rows of LEDs above the first three
interfaces. They show the speed of the interfaces. The
LED columns have a label with the text 0, 1, and 2. The
labels also show the speed with the text 10 Mbps,
100Mbps, and 1000 Mbps. When an LED comes on, it
shows the current speed of the specified interface.
Firebox X
Model 10/100/1000 interfaces 10/100 Interfaces
X5000 none interface 0–9
X6000 interface 0 interface 1–9
X8000 interface 0, 1, 2 interface 3–9

Hardware Description
Firebox X Peak Hardware Guide 7
LEDs (Interfaces 3–9)
LEDs are assembled into the interfaces 3 through 9. The
left LED comes on when the interface transmits traffic
at 100 Mbps. The right LED comes on when the
interface transmits traffic at 10 Mbps.
Firebox X rear
The rear of the Firebox® X Peak has the AC power receptacle,
power button, a second DB9 serial port, and two panels which
you can remove.
Left Panel (Hard Disk Drive)
You can open the panel on the lower left side. Remove
the two screws. This panel gives access to an optional
hard disk drive. This feature is reserved for possible
future use.
DB9 Serial Port (Aux)
This serial port is reserved for possible future use.
Fan Assembly
The fan assembly has three fans that decrease the
internal temperature of the Firebox X Peak.
Power Switch
This switch starts the Firebox X Peak.
AC Receptacle
Accepts the detachable, AC power cable supplied with
the Firebox X. The power supply for the Firebox X Peak
is a WatchGuard standard auto-sensing AC power
supply.

8
