Watchguard Firebox T45-CW Installation instructions

Firebox T45-CW Hardware Guide
WatchGuard Firebox is a comprehensive advanced network security platform that puts IT security professionals
back in charge of their networks with widely deployable, enterprise-grade security and threat visibility tools
suitable for any organization, regardless of budget, size, or complexity.
The Firebox T45-CW supports up to 20 users looking for intelligent network security appliances to secure small
environments such as a temporary site, branch office, or retail POS. The Firebox T45-CW features 5G cellular
and dual-band Wi-Fi 6 options built into the device that minimize disruptions to network activity.
Fireware OS
The Firebox T45-CW supports WatchGuard’s next generation UTM OS—Fireware® OS. Each Firebox appliance
includes Fireware OS and delivers exceptional protection against today's sophisticated threats to make sure
that your business stays connected. For more information on the features of Fireware OS, see Fireware Help.
Package Contents
Firebox T45-CW appliance
Quick Start Guide
1 RJ45 Ethernet cable
1 power adapter (100-240V)
1 power cord (US, AU, EU, UK)
4 external antennas
4 antenna terminal covers
About Your Hardware
Hardware Specifications
Processor NXP LS1043ASE7QQB, 1.6GHz, 4-Core
Memory DDR4 4GB
Storage M.2 SSD 16GB
Power Supply Input Ratings: 100-240V AC, 50-60Hz, 1.5A Max
Output Ratings: 12V DC, 4A, 48W
MTBF 477,304 hours
Dimensions D = 203.2 mm (8")
W = 215.9 mm (8.5")
H = 45.72 mm(1.8")
Weight 0.983 kg (2.17 lbs)
Interface Specifications
Network Interfaces 5 RJ45 connectors, 1000Base-TX (10/100/1000Mbps)
Cellular Interface 5G NR
Nano SIM card slot

Antennas 4 x SMA type external antennas (included)
Radio Type and Frequency Band 2x2 802.11ax Wi-Fi 6 dual band radios:
2.4 GHz: Data rates up to 573 Mbps
5 GHz: Data rates up to 1.2 Gbps
I/O Interfaces 1 USB 3.0, Type-A
1 RJ45 Serial Port
Environmental Requirements
To safely install your Firebox, we recommend that you:
Install it indoors.
Put it in a secure area, such as a locked room, to block the device from people who do not have
permission to use it.
Connect it to a conditioned power supply to prevent damage from sudden power changes.
Other environmental requirements:
Operating temperature: 0° to 40°C (32° to 104°F)
Operating humidity: 0% to 95% non-condensing
Non-operating temperature: –25° to 75°C (-13° to 167°F)
Non-operating humidity: 0% to 95% non-condensing

Hardware Description
Front View
Front view of the Firebox:
Failover
The Failover indicator is lit when there is a WAN failover from the primary external interface to the
backup interface. After the external interface connection fails back to the primary external interface, the
indicator is not lit.
5G
The 5G indicator is lit when a cellular connection is active.
The indicator is green when a 5Gconnection is active.
The indicator is yellow when a 4G LTEconnection is active.
Signal Strength ( )
Indicates the signal strength of the cellular connection.
2.4GHz and 5GHz
The 2.4 GHz and 5 GHz wireless radio indicators are lit when the wireless interface is enabled. The light
blinks when data is sent and received. The speed of the blink increases as the data flow increases.

Network Interface Status Indicators
The Firebox T45-CW has five network interfaces. There are two status indicators for each interface.
1000
Yellow
On Link speed: 1000 Mbps
Blinks (speed of blink increases as the data flow increases) Data sent and received
10/100
Green
On Link speed: 10 Mbps or 100 Mbps
Blinks (speed of blink increases as the data flow increases) Data sent and received
Status
The Status indicator is lit when there is a management connection to the device. The Status indicator is lit
for 30 seconds after you connect to the device with the Fireware Web UI or the command line interface.
It is also lit when the device is polled by WatchGuard System Manager.
Mode
The Mode indicator shows the status of the external network connection. If the device can connect to the
external network and send traffic, the indicator is green. The indicator flashes if the device cannot send
traffic to the external network.
Attn
The Attn indicator is yellow when you start the device with the Reset button pressed. For more
information, see Restore Factory-Default Settings.
Power ( )
The Power indicator shows the power status. It is green when the Firebox is powered on.
Indicator Indicator Color Interface Status

Rear View
Rear view of the Firebox:
Reset Button
This resets the device. For instructions on how to restore the device to factory-default settings, go to
Restore Factory-Default Settings.
SIMCard Slot
To enable a cellular connection as an external interface, insert an activated Nano SIMcard. For more
information, go to SIMCard Installation.
Serial Port (Console)
The leftmost port is an RJ45 serial console port. An RJ45 serial cable is not included with the device. For
information on how to connect to the Fireware CLI (Command Line Interface) with the serial port, go to
the FirewareCLIReference Guide.
USB Interface
The device includes one USB 3.0 interface. Connect a USB storage device for USB backup and restore, or
to store a support snapshot. For more information, go to Use a USBDrive for System Backup and
Restore in Fireware Help .
Network Interfaces
The Ethernet interfaces have standard RJ45 connectors and support link speeds of 10, 100, or 1000
Mbps.
The Firebox T45-CW has five network interfaces. These interfaces are labeled 0/WAN, 1/LAN, 2, 3, 4.
Interfaces 1 to 4 only support full duplex connections. Make sure the Firebox interfaces and
network devices you connect to these ports are set to auto-negotiation or full duplex.
Interface 0 supports both half and full duplex connections.
Power Switch
Controls the power supplied to the device. Move the switch to position 1 to power on the device, or
position 0 to power it off.
Power Input
An AC power adapter is included with your device. Connect the AC adapter to the device and to a power
source. Use only the supplied AC power adapter.
Antenna Connectors
Connect the antennas to the SMA-type antenna connectors on the rear of the device. For more
information, go to Antenna Installation.

Antenna Installation
4 SMA-type external antennas for 5G cellular are included with the device.
4 rubber antenna terminal covers are also included to protect the antenna connection.
1. Remove the protective caps from the antenna connectors on the rear of the Firebox.
2. Before you attach the antennas, slide the rubber antenna terminal cover over the end of the antenna,
and leave the screw cap exposed.
3. Insert the antennas into the connecter on the Firebox, then turn the screw cap clockwise to tighten.

4. Slide the rubber antenna terminal cover forward to fully cover the connector.

SIMCard Installation
To install a SIMcard to enable a cellular connection as an external interface on the Firebox:
1. Power off the Firebox.
2. Insert a SIMcard tool or paper clip into the hole to eject the SIM card tray.
3. Insert an activated Nano SIM card into the SIMcard tray.
Align the direction of the SIM card and the placement of the diagonal edge based on the diagram under the SIM card tray.
4. Insert the SIMcard tray into the Firebox.
5. Power on the Firebox.

Verizon is currently not supported for cellular connectivity with the 5Gmodem on the T45-
CW.
IMEI Number Information
The IMEI(International Mobile Equipment Identity) number of the cellular modem interface is located on a
sticker on the bottom of the Firebox.

AC Power Adapter
The AC power adapter supplies power for the Firebox. The power supply connector has a screw-type retention
mechanism. To prevent a disruption in the power supply, tighten the screw on the connector.
Before you connect the adapter, verify that the color band on the cord matches the color ring around the
power plug on the Firebox.
To safely connect the power supply:
Insert the silver connector on the power cord into the power port on the Firebox. Tighten the screw
until the connector is securely attached to the Firebox.
A Firebox T45-CW shipped outside the United States has a power adapter with blades, and includes four power
plugs to connect to the AC power adapter. Use the correct power plug for the power source used in your
country.
The AC power cord is only for WatchGuard products, and not usable for other equipment.
Cooling Fan
The Firebox T45-CW has an internal cooling fan to decrease the internal temperature of the device.
The fan is designed to start at boot time and run continuously at low speed to maintain an optimal
temperature.
When the temperature rises, and the CPU temperature exceeds 85°C, the fan switches to high speed.
When the CPU temperature drops to 75°C, the fan speed decreases to low speed.
The Firebox shuts down if the CPU temperature is greater than 100°C.
Wall Mount the Firebox
In some environments, you might want to mount the Firebox on a wall to improve the wireless range.
You can use the holes on the bottom of the Firebox to mount the device to a wall with appropriate screws and
anchors (not included).
(Maximum screw head diameter 8mm / 0.315in, maximum thread diameter 3.8mm / 0.15in)

1. Determine where the Firebox will be placed and mark the location for the two mounting holes (109mm
/ 4.3in apart).
2. Drill the two mounting holes and hammer the anchors into the holes.
3. Insert and tighten the screws into the anchors. Leave part of the screw exposed so you can place the
Firebox on the screws.
4. Align the screws with the holes on the bottom of the Firebox and place the Firebox on the screws.
5. Slide the Firebox to secure the screws in the slots of the mounting holes.
6. Adjust the screws as necessary to make sure the Firebox is safely secured to the wall.
Restore Factory-Default Settings
If you have a problem in your configuration file that you cannot correct, you can restore the factory-default
settings and start from a new configuration file. For example, if you do not know the administrator account
passphrase, or if a power interruption causes damage to the Fireware OS, you can restore the Firebox to the
factory-default settings and build your configuration again.
To reset the Firebox to factory-default settings:
1. Power off the Firebox.
2. Press and hold the Reset button on the back of the Firebox.
3. Power on the Firebox while you continue to hold the Reset button.
4. Continue to hold the Reset button until the Attn indicator on the front of the Firebox begins to flash.
5. Release the Reset button.
6. Wait until the Attn indicator stays lit and does not flash.
7. Power off the Firebox.
8. Power on the Firebox.
The Firebox restarts with factory-default settings.

Notices
All WatchGuard products are designed and tested to meet strict safety requirements. These requirements
include product safety approvals and other global compliance standards. Please read the following instructions
carefully before operating the product, and refer to them as needed to ensure the continued safe operation of
your product.
Product Safety Certification
The WatchGuard product is safety certified under the following standards:
CAN/CSA C22.2 No.60950-1-07, Second Edition 2014-10
UL 60950-1, Second Edition 2014-10-14
IEC 60950-1, 2005+A1:2009+A2:2013
IEC 62368-1: 2014 2nd edition
EN 60950-1:2006+A11:2009+A1:2010+A12:2011+A2:2013
Safety Warning
The AC power cord is only for WatchGuard products, and not usable for other equipment.
本コードは本製品専用です。他の機器には使用しないでください。
Do not place objects on the power cord.
Do not obstruct the ventilation openings. These openings prevent overheating of the machine.
Never push objects of any kind into slots or openings on this equipment. Making a contact with a voltage
point or shorting out a part may result in fire or electrical shock.
When removing or installing an appliance, follow the general installation safety instructions.
You must disconnect the AC power cord from the Firebox before you remove the cover of the Firebox for
any reason.
There is risk of explosion if the battery is replaced by an incorrect type. Dispose of used batteries
according to the manufacturer’s instructions.
警示 本電池如果更換不正確會有爆炸的危險，請勿自行更換電池。
Disclaimer
WatchGuard shall not be held liable if the end user alters, modifies, or repairs any WatchGuard hardware
appliance.
Avis
Tous les produits WatchGuard sont conçus et testés pour répondre à des exigences de sécurité strictes. Ces
exigences comprennent les approbations de sécurité des produits et d'autres normes de conformité
mondiales. Veuillez lire attentivement ces instructions avant d'utiliser le produit, et consultez-les si nécessaire
pour assurer le fonctionnement continu et sûr de votre produit.
CAN/CSA C22.2 No.60950-1-07, Second Edition 2014-10
UL 60950-1, Second Edition 2014-10-14
IEC 60950-1, 2005+A1:2009+A2:2013
IEC 62368-1: 2014 2nd edition
EN 60950-1:2006+A11:2009+A1:2010+A12:2011+A2:2013
Remarques sur la sécurité
Le cordon d'alimentation secteur est uniquement destiné aux produits WatchGuard et ne peut pas être
utilisé pour d'autres équipements.
Ne placez pas d'objets sur le cordon d'alimentation.
Ne pas obstruer les ouvertures de ventilation. Ces ouvertures évitent la surchauffe de la machine.

N'introduisez jamais d'objets d'aucune sorte dans les fentes ou les ouvertures de cet équipement. Établir
un contact avec un point de tension ou court-circuiter une pièce peut entraîner un incendie ou un choc
électrique.
Lors de la dépose ou de l'installation d'un appareil, respectez les consignes générales de sécurité
d'installation.
Vous devez débrancher le cordon d'alimentation CA du Firebox avant de retirer le couvercle du Firebox
pour quelque raison que ce soit.
Il y a un risque d'explosion si la batterie est remplacée par un type incorrect. Jetez les piles usagées
conformément aux instructions du fabricant.
Clause de non-responsabilité
WatchGuard décline toute responsabilité si l'utilisateur final altère, modifie ou répare tout appareil matériel
WatchGuard.
Hinweise Zur Sicherheit
Alle WatchGuard Produkte werden entwickelt und getestet, um strenge Sicherheitsanforderungen zu erfüllen.
Diese Anforderungen umfassen Produktsicherheit Zulassungen und andere globale Compliance-Standards.
Bitte lesen Sie die folgenden Anweisungen sorgfältig, bevor Sie das Produkt, und bezeichnen sie als notwendig,
um den sicheren Betrieb des Geräts zu gewährleisten. Weitere Informationen finden Sie in der elektronischen
Hardware Guide.
Die WatchGuard Produkt ist Sicherheit unter den folgenden Normen zertifiziert
CAN/CSA C22.2 No.60950-1-07, Second Edition 2014-10
UL 60950-1, Second Edition 2014-10-14
IEC 60950-1:2005+A1:2009+A2:2013
IEC 62368-1: 2014 2nd edition
EN 60950-1:2006+A11:2009+A1:2010+A12:2011+A2:2013
Sicherheitshinweis
Das Netzkabel ist nur für WatchGuard-Produkte und nicht für andere Geräte geeignet.
Legen Sie keine Gegenstände auf das Netzkabel.
Verdecken Sie nicht die Lüftungsöffnungen. Diese Öffnungen verhindern eine Überhitzung der Maschine.
Stecken Sie niemals Gegenstände jeglicher Art in die Schlitze oder Öffnungen des Geräts stecken. Der
Kontakt mit einem spannungsführenden Punkt oder das Kurzschließen eines Bauteils kann zu einem
Brand oder elektrischen Schlag führen.
Beim Entfernen oder Installieren eines Gerätes, nach den allgemeinen Installation Sicherheitshinweise.
Sie müssen das Netzkabel von der Firebox trennen, bevor Sie die Abdeckung der Firebox aus irgendeinem
Grund entfernen.
Es besteht Explosionsgefahr, wenn die Batterie durch einen falschen Typ ersetzt wird. Entsorgen Sie
gebrauchte Batterien gemäß den Anweisungen des Herstellers.
Haftungsausschluss
WatchGuard haftet nicht, wenn der Endbenutzer eine Hardware-Appliance von WatchGuard ändert, modifiziert
oder repariert.
Aviso De Seguridad
Todos los productos WatchGuard están diseñados y probados para satisfacer estrictos requisitos de seguridad.
Estos requisitos incluyen la homologación de productos de seguridad y otras normas de cumplimiento global.
Por favor, lea atentamente las siguientes instrucciones antes de utilizar el producto, y se refieren a ellos como
sea necesario para garantizar el funcionamiento seguro y continuo de su producto. Información adicional se
puede encontrar en la Guía del usuario electrónica.

Certificación de seguridad del producto
El producto tiene certificación de seguridad WatchGuard bajo las siguientes normas:
CAN/CSA C22.2 No.60950-1-07, Second Edition 2014-10
UL 60950-1, Second Edition 2014-10-14
IEC 60950-1:2005+A1:2009+A2:2013
IEC 62368-1: 2014 2nd edition
EN 60950-1:2006+A11:2009+A1:2010+A12:2011+A2:2013
Advertencia de seguridad
El cable de alimentación de CA es solo para productos WatchGuard y no se puede usar para otros
equipos.
No coloque objetos sobre el cable de alimentación.
No obstruya las aberturas de ventilación. Estas aberturas evitan el sobrecalentamiento de la máquina.
Nunca introduzca objetos de ningún tipo en las ranuras o aberturas del equipo. El contacto con puntos de
voltaje o el cortocircuito de una pieza podría provocar un incendio o una descarga eléctrica.
Al extraer o instalar un electrodoméstico, siga las instrucciones generales de instalación de seguridad.
Debe desconectar el cable de alimentación de CA del Firebox antes de quitar la tapa del Firebox por
cualquier motivo.
Existe riesgo de explosión si la batería se reemplaza por una del tipo incorrecto. Deseche las baterías
usadas de acuerdo con las instrucciones del fabricante.
Descargo de responsabilidad
WatchGuard no será responsable si el usuario final altera, modifica o repara cualquier dispositivo de hardware
de WatchGuard.
Federal Communications Commission (USA)Statement
Operations in the 5.15-5.25GHz band are restricted to indoor usage only. This equipment has been tested and
found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits
are designed to provide reasonable protection against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance
with the instructions, may cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by turning the equipment off and on,
the user is encouraged to try to correct the interference by one of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
FCC Caution: Any changes or modifications not expressly approved by the party responsible for compliance
could void the user’s authority to operate this equipment.
This device complies with Part 15 of the FCCRules. Operation is subject to the following two conditions:
1. This device may not cause harmful interference, and
2. this device must accept any interference received, including interference that may cause undesired
operation.
This device and its antenna(s) must not be co-located or operating in conjunction with any other antenna or
transmitter.
For product available in the USA/Canada market, only channel 1-11 can be operated. Selection of other
channels is not possible.

This device is restricted to indoor use.
FCC Radiation Exposure Statement: (Wireless)
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This
equipment should be installed and operated with minimum distance 20cm between the radiator & your body.
This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter.
This radio transmitter [FCC ID: Q6G-BS4AE5CW] has been approved by FCC to operate with the antenna types
listed below, with the maximum permissible gain indicated. Antenna types not included in this list that have a
gain greater than the maximum gain indicated for any type listed are strictly prohibited for use with this device.
7102A0608000 PCB 2.4/5 GHz 3.16 (2.4 GHz)
5.05 (5 GHz)
7102A0608000 PCB 2.4/5 GHz 3.01 (2.4 GHz)
5.11 (5 GHz)
7102A0499000 Dipole WWAN 1.17 (LB, band 5,8,12,13,14,17,18,19,20,26,28,29,71)
2.97 (MHB, band 1,2,3,4,7,25,30,32,34,38,39,40,41,66)
2.96 (UHB, band 42,48)
1.96 (LAA, Band 46)
7102A0499000 Dipole WWAN 1.17 (LB, band 5,8,12,13,14,17,18,19,20,26,28,29,71)
2.97 (MHB, band 1,2,3,4,7,25,30,32,34,38,39,40,41,66)
2.96 (UHB, band 42,48)
1.96 (LAA, Band 46)
7102A0499000 Dipole WWAN 1.17 (LB, band 5,8,12,13,14,17,18,19,20,26,28,29,71)
2.97 (MHB, band 1,2,3,4,7,25,30,32,34,38,39,40,41,66)
2.96 (UHB, band 42,48)
1.96 (LAA, Band 46)
7102A0499000 Dipole WWAN 1.17 (LB, band 5,8,12,13,14,17,18,19,20,26,28,29,71)
2.97 (MHB, band 1,2,3,4,7,25,30,32,34,38,39,40,41,66)
2.96 (UHB, band 42,48)
1.96 (LAA, Band 46)
CE (European Union) Radiation Exposure Statement
This equipment complies with CE radiation exposure limits set forth for an uncontrolled environment. This
equipment should be installed and operated with greater than 24cm between the radiator & your body.
ISED (Canada) Statement
This device contains licence-exempt transmitter(s)/receiver(s) that comply with Innovation, Science and
Economic Development Canada’s licence-exempt RSS(s). Operation is subject to the following two conditions:
1. This device may not cause interference.
2. This device must accept any interference, including interference that may cause undesired operation
of the device.
L’émetteur/récepteur exempt de licence contenu dans le présent appareil est conforme aux CNR d’Innovation,
Sciences et Développement économique Canada applicables aux appareils radio exempts de licence.
L’exploitation est autorisée aux deux conditions suivantes :
1. L’appareil ne doit pas produire de brouillage;
Model Name Ant. Type Support Max Peak Gain

2. L’appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d’en
compromettre le fonctionnement.
The device for operation in the band 5150-5250 MHz is only for indoor use to reduce the potential for harmful
interference to co-channel mobile satellite systems.
Les dispositifs fonctionnant dans la bande 5150-5 250 MHz sont réservés uniquement pour une utilisation à
l’intérieur afin de réduire les risques de brouillage préjudiciable aux systèmes de satellites mobiles utilisant les
mêmes canaux.
IC Radiation Exposure Statement:
This equipment complies with IC RSS-102 radiation exposure limits set forth for an uncontrolled environment.
This equipment should be installed and operated with minimum distance 24cm between the radiator & your
body.
Cet équipement est conforme aux limites d’exposition aux rayonnements IC établies pour un environnement
non contrôlé. Cet équipement doit être installé et utilisé avec un minimum de 24cm de distance entre la source
de rayonnement et votre corps
The transmitter module may not be co-located with any other transmitter or antenna.
Le module émetteur peut ne pas être coïmplanté avec un autre émetteur ou antenne.
CAN ICES-003 (B)/NMB-003(B) (Canada)
The Country Code Selection feature is disabled for products marketed in the US/Canada.
For product available in the USA/Canada market, only channel 1-11 can be operated. Selection of other
channels is not possible.
Pour les produits disponibles aux États-Unis / Canada du marché, seul le canal 1 à 11 peuvent être exploités.
Sélection d'autres canaux n'est pas possible.
This radio transmitter [IC: 4657A-BS4AE5CW] has been approved by Innovation, Science and Economic
Development Canada to operate with the antenna types listed below, with the maximum permissible gain
indicated. Antenna types not included in this list that have a gain greater than the maximum gain indicated for
any type listed are strictly prohibited for use with this device.
Le présent émetteur radio [IC: 4657A-BS4AE5CW] a été approuvé par Innovation, Sciences et Développement
économique Canada pour fonctionner avec les types d'antenne énumérés ci dessous et ayant un gain
admissible maximal. Les types d'antenne non inclus dans cette liste, et dont le gain est supérieur au gain
maximal indiqué pour tout type figurant sur la liste, sont strictement interdits pour l'exploitation de l'émetteur.
7102A0608000 PCB 2.4/5 GHz 3.16 (2.4 GHz)
5.05 (5 GHz)
7102A0608000 PCB 2.4/5 GHz 3.01 (2.4 GHz)
5.11 (5 GHz)
7102A0499000 Dipole WWAN 1.17 (LB, band 5,8,12,13,14,17,18,19,20,26,28,29,71)
2.97 (MHB, band 1,2,3,4,7,25,30,32,34,38,39,40,41,66)
2.96 (UHB, band 42,48)
1.96 (LAA, Band 46)
7102A0499000 Dipole WWAN 1.17 (LB, band 5,8,12,13,14,17,18,19,20,26,28,29,71)
2.97 (MHB, band 1,2,3,4,7,25,30,32,34,38,39,40,41,66)
2.96 (UHB, band 42,48)
1.96 (LAA, Band 46)
7102A0499000 Dipole WWAN 1.17 (LB, band 5,8,12,13,14,17,18,19,20,26,28,29,71)
2.97 (MHB, band 1,2,3,4,7,25,30,32,34,38,39,40,41,66)
2.96 (UHB, band 42,48)
Model Name Ant. Type Support Max Peak Gain

1.96 (LAA, Band 46)
7102A0499000 Dipole WWAN 1.17 (LB, band 5,8,12,13,14,17,18,19,20,26,28,29,71)
2.97 (MHB, band 1,2,3,4,7,25,30,32,34,38,39,40,41,66)
2.96 (UHB, band 42,48)
1.96 (LAA, Band 46)
Declaration of Conformity (EU) (Wireless)
This device complies with the essential requirements of the RED 2014/53/EU. The following test methods have
been applied in order to prove presumption of conformity with the essential requirements of the RED
2014/53/EU:
EN 60950-1: 2006+A11:2009+A1:2010+A12:2011+A2:2013
This standard is applicable to mains-powered or battery-powered information technology equipment,
including electrical business equipment and associated equipment, with a rated voltage not exceeding
600 V.
EN 62368-1:2014+A11:2017
Safety standard that classifies energy sources, prescribes safeguards against those energy sources, and
provides guidance on the application of, and requirements for, those safeguards.
EN 55032:2015/AC:2016-07
Electromagnetic compatibility of multimedia equipment. Emission requirements.
EN 55024:2010/A1:2015
Information technology equipment - Immunity characteristics - Limits and methods of measurement
EN 55035:2017
Electromagnetic compatibility of multimedia equipment. Immunity requirements.
EN 300 386 V2.1.1 (2016-07)
Telecommunication network equipment; Harmonised Standard for ElectroMagnetic Compatibility (EMC)
requirements.
EN 61000-3-2:2019
Limits for harmonic current emissions (equipment input current ≤16 A per phase).
EN 61000-3-3:2013/A1:2019
Electromagnetic compatibility (EMC) Limits. Limitation of voltage changes, voltage fluctuations and flicker
in public low-voltage supply systems, for equipment with rated current ≤1616 A per phase and not
subject to conditional connection.
EN 61000-4-2 Edition 2.0 2008-12
Electromagnetic compatibility (EMC) Testing and measurement techniques. Electrostatic discharge
immunity test.
EN 61000-4-3 Edition 3.2 2010-04
Electromagnetic compatibility (EMC) Testing and measurement techniques. Radiated, radio-frequency,
electromagnetic field immunity test.
EN 61000-4-4 Edition 3.0 2012-04
Electromagnetic compatibility (EMC) Testing and measurement techniques. Electrical fast transient/burst
immunity test.
EN 61000-4-5 Edition 3.1 2017-08
Electromagnetic compatibility (EMC) Testing and measurement techniques. Surge immunity test.
EN 61000-4-6 Edition 4.0 2013-10
Electromagnetic compatibility (EMC) Testing and measurement techniques. Immunity to conducted
disturbances, induced by radio-frequency fields.
Model Name Ant. Type Support Max Peak Gain

EN 61000-4-11 Edition 2.1 2017-05
Electromagnetic compatibility (EMC) Testing and measurement techniques. Voltage dips, short
interruptions and voltage variations immunity tests for equipment with input current up to 16 A per
phase.
EN 301 489-1 v2.1.1 (2017-03)
Electromagnetic compatibility and Radio Spectrum Matters (ERM); ElectroMagnetic Compatibility (EMC)
standard for radio equipment and services; Part 1: Common technical requirements
EN 301 489-17 v3.1.1 (2017-02)
Electromagnetic compatibility and Radio spectrum Matters (ERM); ElectroMagnetic Compatibility (EMC)
standard for radio equipment and services; Part 17: Specific conditions for 2.4 GHz wideband
transmission systems and 5 GHz high performance RLAN equipment
EN 300 328 V2.2.2 (2019-11)
Electromagnetic compatibility and Radio spectrum Matters (ERM); Wideband Transmission systems; Data
transmission equipment operating in the 2,4 GHz ISM band and using spread spectrum modulation
techniques; Harmonized EN covering essential requirements under article 3.2 of the RED Directive
EN 301 893 v2.1.1 (2017-05)
Broadband Radio Access Networks (BRAN); 5 GHz high performance RLAN; Harmonized EN covering
essential requirements of article 3.2 of the RED Directive
EN 301 908-1 V13.1.1 (2019-11)
IMT cellular networks - Harmonised Standard for access to radio spectrum.
This device has software that cannot affect compliance with the Radio Equipment Directive (RED) 2014/53/EU,
even if the software is changed or replaced.
This device is a 5GHz wideband transmission system (transceiver), intended for use in all EU member states
and EFTA countries, except in France and Italy where restrictive use applies.
This device is restricted to indoor use when operating in the 5150 to 5350 MHz frequency range in these
countries:
2412 - 2472 MHz 19.95 dBm
5180 - 5240 MHz 22.90 dBm
In Italy the end-user should apply for a license at the national spectrum authorities in order to obtain
authorization to use the device for setting up outdoor radio links and/or for supplying public access to
telecommunications and/or network services.
Frequency Range Maximum Output Power (EIRP)

Restrictions: France (i) les dispositifs fonctionnant dans la bande 5150-5250 MHz sont réservés uniquement
pour une utilisation à l’intérieur afin de réduire les risques de brouillage préjudiciable aux systèmes de
satellites mobiles utilisant les mêmes canaux; (ii) De plus, les utilisateurs devraient aussi être avisés que les
utilisateurs de radars de haute puissance sont désignés utilisateurs principaux (c.-à-d., qu’ils ont la priorité)
pour les bandes 5 250-5 350 MHz et 5 650-5 850 MHz et que ces radars pourraient causer du brouillage et/ou
des dommages aux dispositifs LAN-EL.
Dieses Gerät verfügt über Software, die die Einhaltung der Richtlinie über Funkanlagen (RED) 2014/53/EU nicht
beeinträchtigen kann, selbst wenn die Software geändert oder ersetzt wird.
Die oben genannten Gerät entspricht den grundlegenden Anforderungen und anderen relevanten
Bestimmungen der Richtlinie 2014/53/EU, wenn für den vorgesehenen Zweck verwendet werden. Dieses Gerät
ist für die Verwendung in den USA, Kanada, and Europäische Union.
Einschränkungen: Frankreich –(i)-Geräte, die im Band 5150-5250 MHz ist nur für den Innenbereich, um das
Risiko von Störungen des mobilen Satelliten-Systeme, die die gleichen Kanäle (ii) Darüber hinaus reduzieren
vorbehalten, sollten Benutzer auch darauf hingewiesen werden, dass die Nutzer von Hochleistungs-Radare
bezeichnet werden primäre Benutzer (dh d. sie haben Priorität) der Bänder 5 250-5 350 MHz und 5 650-5 850
MHz und dass diese Radargeräte können Störungen und / oder Schäden an LE-LAN-Geräten verursachen.
CENotice
The symbol on your WatchGuard Technologies equipment indicates that it is in compliance with the
Electromagnetic Compatibility (EMC) directive and the Low Voltage Directive (LVD) of the European Union (EU).
Български Този продукт е в съответствие с Директива 2014/53/ЕС.
Česky Tento produkt je v souladu se směrnicí 2014/53/EU.
Dansk Dette produkt er i overensstemmelse med direktiv 2014/53/EU.
Deutsch Dieses Produkt entspricht der Richtlinie 2014/53/EU.
Eesti See toode vastab direktiivile 2014/53/EL.
English This product is in compliance with Directive 2014/53/EU.
Español Este producto cumple con la Directiva 2014/53/UE.
Ελληνική Το προϊόν αυτό συμμορφώνεται με την Οδηγία 2014/53/ΕΕ.
Français Ce produit est conforme à la Directive 2014/53/UE.
Hrvatski Ovaj proizvod je u skladu s Direktivom 2014/53/EU.
Italiano Questo prodotto è conforme alla Direttiva 2014/53/EU.
Latviski Šis produkts atbilst Direktīvai 2014/53/EU.
Lietuvių Šis gaminys atitinka direktyvą 2014/53/ES.
Malti Dan il-prodott huwa konformi mad-Direttiva 2014/53/UE.
Magyar Ez za termék megfelel a 2014/53/EU irányelvnek.
Nederlands Dit product is in overeenstemming met Richtlijn 2014/53/EU.
Norsk Dette produktet er i samsvar med direktiv 2014/53/EU.
Polski Ten produkt jest zgodny z dyrektywą 2014/53/UE.
Português Este produto está em conformidade com a Diretiva 2014/53/UE.


Rumunski Acest produs este în conformitate cu Directiva 2014/53/UE.
Slovensky Tento produkt je v súlade so smernicou 2014/53/EÚ.
Slovensko Ta izdelek je v skladu z Direktivo 2014/53/EU.
Suomi Tämä tuote on direktiivin 2014/53/EU mukainen.
Svenska Denna produkt överensstämmer med direktiv 2014/53/EU.
RoHS Statement
The Restriction of Hazardous Substances 2.0 (RoHS 2.0) in Electrical and Electronic Equipment Directive was
passed into law by the European Union (EU). It affects manufacturers, sellers, distributors and recyclers of
electrical and electronic equipment containing lead, cadmium, mercury, hexavalent chrome, polybrominated
diphenylether (PBDE), polybrominated biphenyl (PBB), Bis (2-ethylhexyl) phthalate (DEHP), Butyl benzyl

