Waterco MULTI CYCLONE 70XL User manual

Waterco Limited ABN 62 002 070 733
www.waterco.com
Notice to Installer
This manual contains important information about the installation, operation
and safe use of this product. Once the product has been installed this manual
must be given to the owner / operator of this equipment.
This equipment must be installed and serviced by a qualified technician.
Improper installation can create electrical hazards which could result in property
damage, serious injury or death. Improper installation will void the warranty.
WARNING
!
(W99303) 09/2014
70XL
OFFICES - AUSTRALIA
NSW - SYDNEY
(HEAD OFFICE)
Tel: [phone]
QLD - BRISBANE
Tel: [phone]
VIC/TAS - MELBOURNE
Tel: [phone]
WA - PERTH
Tel: [phone]
SA/NT - ADELAIDE
Tel: [phone]
ACT DISTRIBUTION
Tel: [phone]
OFFICES
WATERCO (EUROPE) LIMITED
Sittingbourne, Kent, UK
Tel: [phone]
WATERCO FRANCE
Saint Priest, France
Tel: [phone]
WATERCO USA
Augusta, GA, USA
Tel: [phone]
WATERCO CANADA
Longueuil, Quebec, Canada
Tel: [phone]
WATERCO (NZ) LIMITED
Auckland, New Zealand
Tel: [phone]
WATERCO © LIMITED
Guangzhou, China
Tel: [phone]
WATERCO (FAR EAST) SDN BHD
Selangor, Malaysia
Tel: [phone]
PT WATERCO INDONESIA
Jakarta, Indonesia
Tel: [phone]
WATERCO SINGAPORE INTL PTE LTD
Nehsons Building, Singapore
Tel: [phone]
Manual

Table of
Waterco Multicyclone 70XL
SAFETY INFORMATION ------------------------------------------- 00
INTRODUCTION -------------------------------------------------- 01
INSTALLATION ---------------------------------------------------- 02
PLUMBING CONNECTION --------------------------------------- 02
FILTER MAINTENANCE ------------------------------------------- 03
FLUSHING OUT THE SEDIMENT CHAMBER ------------------- 03
WARRANTY -------------------------------------------------------- 03
TECHNICAL SPECIFICATION ------------------------------------- 04
DIMENSIONS ------------------------------------------------------ 04
EXPLODED DIAGRAM -------------------------------------------- 05
I pg 01
SAFETY INFORMATION
1. MultiCyclone 70XL is designed to work with water at temperatures greater than 32ºF and less
than 113ºF. The lter should never be operated outside of these temperatures or damage may
occur.
2. The installation should be carried out in accordance to the safety and the specic instructions for
each facility.
3. Any modication of the lter requires the prior consent from Waterco. Original replacement
parts and accessories authorized by the manufacturer ensure a high level of safety. Waterco
assumes no liability for the damage and injuries caused by unauthorised replacement parts and
accessories.
4. The user should make sure that the installation is carried out by qualied authorised persons and
that these persons have rst carefully read the following instructions.
5. The operating safety of the lter is only guaranteed if the installation and operation instructions
are correctly followed.
6. In the event of defective operation or fault, contact Waterco or its nearest authorised service
agent.
7. To reduce the risk of injury, do not permit children to use this product unless they are closely
supervised at all times.
8. Incorrectly installed equipment may fail, causing severe injury or property damage.
INTRODUCTION
MultiCyclone 70XL is capable of saving water and reducing lter maintenance.
The MultiCyclone 70XL works on the basis of centrifugal water ltration. There are no moving parts
to wear and tear, and no lter media to clean or replace.
EXIT PIPE
CYCLONE RH
CYCLONE LH
TOP SHELL
WATER OUTLET 4” PORT
MAINFOLD PLATE
CYCLONE HOLDER
BOTTOM SHELL
WATER INLET 4” PORT
CLEAR PIPE
STAND
DRAIN / FLUSH VALVE
Incoming water is guided by a diverter plate so that it enters multiple hydro cyclones tangentially
generating a strong centrifugal effect. This spins the sediment out to the hydro cyclone’s wall and
then spirals it down to the sediment chamber, while the cleansed water spirals upwards.

Waterco Multicyclone 70XL I pg 03
The accumulation of sediment can be visibly monitored through the MultiCyclone 70XL’s clear pipe.
The MultiCyclone 70XL is cleaned by simply opening the purge valve.
MultiCyclone 70XL is ideal as a pre-lter to extend the life of your existing lter.
• Save Water
• Reduce backwash frequency.
Please Note: The MultiCyclone 70XL is designed to filter sediment that is heavier than water; floating
debris cannot be filtered out by centrifugal filtration.
INSTALLATION
Be sure to comply with the local plumbing codes. The lter may be plumbed into a drinking water
system and would, therefore be subject to whichever local regulations that may apply.
Be sure that all provisions for wastewater disposal meet local, state or national codes. Do not
discharge water where it will cause ooding or damage.
If the incoming water pressure is higher than the maximum operating pressure of 350kPa /3.5Bar
/50psi, a Pressure Regulating Valve (PRV) must be installed upstream of the lter inlet.
The PRV should be set to 90% of the maximum operating pressure of the tank.
If the incoming water ow is less than the lter’s minimum ow requirements, the lter’s ltration
efciency will be affected, please consult Waterco.
MultiCyclone 70XL Recommended Operational Flow Rates
Minimum ow rate: 36m3/hr (158.5 GPM)
Maximum ow rate: 96m3/hr (422.3 GPM)
PLUMBING CONNECTION
1. Connect the outlet from your pump to the inlet of the MultiCyclone 70XL.
Glue the plumbing to the Barrel unions and Allow 24 hours for glue (solvent) to set. Ensure
solvents are not excessively applied to ttings as this could run into o-rings and create sealing
problems. Screw the barrel union on to the inlet of your MultiCyclone 70XL and hand tighten.
2. Connect from the outlet of the MultiCyclone 70XL to the inlet of your
filter.
Glue the plumbing to the Barrel unions and Allow 24 hours for glue (solvent) to set. Ensure
solvents are not excessively applied to ttings as this could run into o-rings and create sealing
problems. Screw the barrel union on to the outlet of your MultiCyclone 70XL and hand tighten.
3. Connect to Waste Line.
Glue the plumbing from the Sediment Purge Valve to your waste line.
4. Turn on pump.
Be sure to check that there are no leaks from the connectors. If required, tighten by hand.
FILTER MAINTENANCE
Filter maintenance determined by the following conditions:
1. The ow rate through the MultiCyclone 70XL is insufcient to meet the demand.
The accumulation of sediment can be visibly monitored through the MultiCyclone 70XL’s clear pipe.
The MultiCyclone 70XL is cleaned when the clear pipe is ¾ full of sediment.
FLUSHING OUT THE SEDIMENT CHAMBER
Procedure to purge the Multicyclone 70XL:
1. Open 2 way valve whilst pump running
2. Allow sediments to be ush out from sediment chamber
3. Visually inspect clear pipe
4. If clear pipe is free of debris close 2 way valve.
WARRANTY
MultiCyclone 70XL is covered by a 2 years warranty.
For more information please refer to the Waterco “Warranty Terms & Conditions” booklet. With our
on going commitment to quality products and service Waterco Limited reserves the right to alter the
product in any manner and at any time without prior warning.
This information is to the best of our knowledge, accurate at the time of printing. Any recommendations
or suggestions are made without warranty and without prejudice, since the use of our product is
beyond our control.

0
2
4
6
8
10
12
14
16
18
0 50 100 150 200 250 300 350 400 450
Head Loss (psi)
Flow Rate (gpm)
Head Loss For Mulcyclone XL70 Commercial
Waterco Multicyclone 70XL I pg 05
TECHNICAL SPECIFICATION
Pressure Rating: 350kPa / 3.5bar /50psi
Minimum Flow Rate: 36m3/hr (158.5 GPM)
Maximum Flow Rate: 96m3/hr (422.3 GPM)
DIMENSIONS
EXPLODED DIAGRAM
NO DESCRIPTION CODE QTY
40 BUTYL TAPE W01285 11.8”
(30cm)
39 ORING JOINTED 4”M/CYCLONE L1900 W44058 1
38 BASE MULTICYCLONE 4” W22509 1
37 WATERCO 2”/2 1/2” (50/65mm) 2 Way Valve 14856 1
36 PIPE PVC CLEAR 2” SCH40 LENGTH 20” (NSF) W22749 1
35 ELBOW 90DEG 2” CLEAR PVC SCH40 (NSF) W22752 1
34 PIPE 2” SCH80 NSF W22745 6.5cm
33 B/U P/END SLIP/SLIP 2”(50mm) BLACK W02081BLK 1
32 T/L LOCK NUT 2”(50mm) NEW BLACK W02647BLK 1
31 B/U THREADED END THRD/ THRD
2”(50mm) BLACK W02154BLK 1
30 O-RING 2”(50mm) B/U NITRILE W02280 2
29 AIR RELIEF VALVE NEW STYLE BLK 620221 1
28 O-RING 4”(100mm) B/U NITRILE W02553 2
27 NUT HEX LONG M10x45mm SS304 W22751 48
26 SPRING WASHER M10 SS304 W22414 48
25 WASHER M10 OD=30 THICKNESS 2.5 SS304 W22651 96
24 SCREW HEX M10x110mm SS304 W22750 48
23 HEXAGON BOLT M6 35 SS304 W22654 60
22 WASHER M6 FLAT SS304 W12782 60
21 O-RING 20 2.0 W22626 70
20 O-RING BS009 W22628 60
19 O-RING 27 2.0 W22627 140
18 O-RING BS392 W22629 1
17 SPIGOT MULTI CYCLONE 4” W22508 70
16 O-RING JOINTED DIA9 4”M/CYCLONE W44059 2
15 BULKHEAD LOCK NUT 4”(100mm) BLACK 12221006 1
14 LOCKING NUT 100mm 4”M/CYCLONE W44060 2
13 BARREL UNION PLAIN END 100mm BLACK 12221011 2
12 RUBBER WASHER 4” CYCLONE W22544 1
11 MALE VALVE SOCKET 4” BSPT 11TPI
ASTM (NSF) W22748 1
10 ELBOW 100mm BLACK BS W34026 1
9PIPE 4” ANSI SCH80 NSF W22556 14.57”
(37cm)
8BBULKHEAD BODY 4”(100mm)
4” L=3.66” (93mm) W22648 1
7GASKET 4”(100mm) BULKHEAD W02539 2
6CONE CYCLONE STANDARD RH W22504 20
5CONE CYCLONE STANDARD LH W22505 50
4MANIFOLD PLATE MULTICYCLONE 4” W22503 1
3BOTTOM SHELL MULTICYCLONE 4” G W22730 1
2CYCLONE PLATE MULTICYCLONE 4” G W22732 1
1TOP SHELL MULTICYCLONE 4” G W22729 1
