WaterLogic CUBE User manual

CUBEManual Page13–Revision10‐8‐2018

PCBLEDCODES




EnergySavingSleepMode
Active
WhiteDispenseBacklight
indicatesCubeisinEnergy
SavingSleepMode.

NoDispenseBacklight
indicatesCubeisNOTin
EnergySavingSleepMode.
UVDosageisadequatewhen
illuminated
UVPurificationAlert
ReplaceUVLamp

ColdandAmbientwaterwillnotdispense
withoutproperlyfunctioningFIREWALL™
UVpurificationthatensuresthesafetyof
thewater.
FilterService
Needed
ReplaceFilter
Cartridge Leakhasbeen
detected
InstructionstoReplacetheUVlamp,ReplaceFilterCartridgeandcorrectinganyleakselsewhere
inthisManual.

CUBEManual Page14–Revision10‐8‐2018

CONSUMABLECOMPONENTS

Component WLCPPartNo. FrequencyofReplacement
13WUVLampAssembly 10‐8075 Every12months,orasrequired
FactoryPN:CT‐2090‐C
Sediment20MicronFilter
Click‐In‐Click‐OutHousing
Assembly

NSF/ANSI53Certified
FT‐0003‐L00‐WLT

ReplacementElement
P/NFT‐0055‐WLT
Every12months.Localwaterconditions
willdetermineproperfiltertypeand
maintenanceschedule.
HotTank1.3Liter
120V/500W HT‐0001‐I00 Every3‐5years,dependingonusage.



CAUTION!UseonlyWaterlogicReplacementpartsthatcanbeobtainedfromWaterlogicoran
AuthorizedWaterlogicDealer,failuretodosowillvoidtheWarranty.

SeeInstallationandServiceManualforadditionalinformation.

HotTankHT‐0001‐I00Service
HotTanks(withcontrols)mustbereplacedatleastevery3‐5yearsdependingonusage.Descaling
hottankmayberequiredonaregularbasisdependinguponfiltrationandlocalwaterconditions.
SeeInstallationandServiceManualforfurtherdetails.


DISPOSAL
EndofLife
Attheendofthisproduct’slife,ensurethatitisdisposedofinanenvironmentallyfriendlymanner
whichisfullycompliantwithallFederal/State/LocalRequirementsandGuidelines.Donotdispose
ofthisappliancewithnormalhouseholdorbusinesswaste.



CUBEManual Page15–Revision10‐8‐2018

SERVICEREQUIREMENTS

WARNING!Readandunderstandthecontentsofthismanualbeforeattemptingtoservice
CUBE.Failuretofollowtheinstructionsinthismanualcouldresultindeath,seriouspersonal
injury,orseverepropertydamage.Onlytrainedandqualifiedtechniciansshouldattemptto
install,maintain,orserviceWaterlogicEquipment.

MaterialsNeeded:
 PersonalProtectiveEquipment.RubberorNitrileSafetyGlovesandProtectiveEyewear
 PhillipsScrewdriver.
 Replacementfiltercartridge(s)
 New13‐WattUVlamp
 WaterPitcherorContainertocollectwaterfromthefaucet
 5‐galloncontainerordrainbasin
 Sanitizer‐HouseholdBleach(5.25%SodiumHypochlorite)orCitricAcidBasedCleaner

1. WARNING!HIGHVOLTAGEELECTRICALHAZARD.Unplugbeforeinspectionandservice.

1. Visuallyinspectallelectricalandwaterconnectionsforsignsofwearordamage.
2. WaterlogicrecommendschangingtheUVLampevery12months.
WARNING!ULTRAVIOLETRADIATION.Protectyourskinandeyesagainstultravioletrays.
NeverlookdirectlyatanoperatingUVlight.DisconnectbeforeremovingUVLamp.

CAUTION!UVLAMPSAREHAZARDOUS.LampsareconsideredHazardousWasteandmustbe
disposedofaccordingly.RefertoProductMSDSsheetfordetails.

CAUTION!UVSYSTEMISFRAGILE.NeverhandletheUVLamporQuartzSleevewithbarehands.
UVLampandQuartzSleevemustbefreeofoilsandcontaminantstoensureproperoperation.
Useasoftnon‐abrasiveclothtoclean.

3. Ensurethereisadequate(minimumof2”)clearancearoundtheCubeWaterTreatmentSystem
andcleanthecondensergrillandcompressorfantoprovideefficientcoolingsystemoperation.
4. Sanitizethecoldtankperinstructionsinthepre‐installationprocedures.
CleanandsanitizeexternalsurfacesoftheCubeWaterTreatmentSystem.Usesoapandwateror
chemicalsthatarecompatiblewithABSplasticandwillnotdamageordegradetheproductsurfaces.
Removeandcleanthefaucet.Replaceasneeded.
WARNING!SANITIZERMAYCONTAINHAZARDOUSCHEMICALS.Useofproperpersonal
protectiveequipmentsuchasrubberglovesandeyeprotectionisrequired.

CUBEManual Page16–Revision10‐8‐2018

HOTTANKPRINCIPLESOFOPERATION


AllWaterlogicHotTankshaveabuilt‐inVentor
ExpansionChamberinthetopofthetankexceptfor
WL270(GF)units.

TheVentChamberallowsforexpansionofthewater
whenitisheated.

Thechambersareseparatedbyawelded‐intank
baffle.

Wateralwaysflowsintothebottomofthetankand
outthetoptothefaucet.

TheHotTankoutlettubehasarestrictorinitsbase.
Thisensuresthereservoirisalwaysfullbyallowing
morewaterinthanout.

Thereisasmallholeinthesideofthetankoutlettube
thatallowsairandwatertopassintothevent
chamberasitisheated.

Waterintheventchamberissuctionedbackthrough
theoutlettubeventholewhenwaterisdispensed.

Expansionofwaterasitisheatedinthereservoirwill
pushthewateroutthefaucetwhentheoutlettube
ventholebecomespluggedwithdebrisorscale.

ThesmallOutletVentHoleissusceptibletoscalebuild
upandisakeyindicatorthatdescalingisrequired.

ItiscriticaltodescaletheHotTankthroughthevent
lineandoutletlineonaregularbasistopreventthis
problem.

Descalingthroughtheinletand/oroutletlinesonly
willnotcleantheventchamberandoutletventhole
properly.



CUBEManual Page17–Revision10‐8‐2018

RESETTINGTHEHOTTANKOVERLOAD(HIGHLIMIT)SAFETY

1. TurnoffboththeGreenHeater/Compressor
SwitchandtheRedPowerSwitcheslocatedon
backofunit

O=OFF
2. Unplugpowertounit.




3.  WithaPhillipsHeadScrewdriver,removethe
twoscrewsatbackoftheTopCoverifinstalled.


4. RemoveTopCoverbyplacingyourhands
onthetopandpushingtheTopCover
towardstherear.

Liftandremove.
5.  WithaPhillipsHeadScrewdriver,RemovethetwoscrewsontheRight‐SidePanel

RemoveRightSidePanel.


CUBEManual Page18–Revision10‐8‐2018

6.  ReachupbehindtheHotTankandtakeholdoftheprotectivemetalboxcoveringthe
overloadsontheHotTank.TherearenutsthatsecurethemetalboxtotheHotTank,
howeverthenutsarelooseenoughtoremovethemmetalbox.
7.  PressRedButtononeachoverloadtoreset(therearetworesetbuttons)

















8.  Reassembleunitbyusingtheseinstructionsinreverse.

Locationofthetwo
HotTankOverload
Buttons

CUBEManual Page19–Revision10‐8‐2018

HOTTANKDESCALING

TheHotTankrequiresremovalofmineraldeposits(descaling)onaregularbasis,dependingupon
filtrationandlocalwaterconditions.Descalingisanimportantprocessthatremovescalcium
deposits,orscale,thatcanbuildupinsideatankovertime.Calciumandscaleisnon‐toxicbutleft
unattended,itwillhinderyourunit’sperformance.

HotTankTroubleshooting:Hotwaterintermittentlyforcedoutthroughthefaucetisanindicator
thatdescalingisneeded.ThisoccurswhenscalehasdepositedontheexpansionslotinsidetheHot
Tankventchamberandblocksthenormalpathforwatertoexpand.

Descalingshouldtakeplaceevery6to12monthstopreservethelong‐termhealthofyourunit.Use
non‐toxiccleanersuchasScaleKleen,DEZCAL,20%CitricAcidSolution,orUndilutedVinegar
Solutiontoremovemineraldepositsasdirectedbythemanufacturer.

WARNING!PERSONALPROTECTIVEEQUIPMENTREQUIRED.Alwaysensureproperventilation
anduserubberornitrileglovesandeyeprotectionwhenusingchemicals.RefertoMaterial
SafetyDataSheetforspecificrequirementsofeachproduct.

CAUTION!STAINLESSSTEELTANKDESCALING.
TheHotTankismadefromstainlesssteel.Ensuredescalingsolutioniscompatiblewithstainless
andalwaysflushtheunitcompletely.Disposeinanenvironmentallysafemanner.

SeeHotTankDescalingVideoandtrainingprocedurelocatedonthePartnerAreaoftheWaterlogic
Websiteformoredetailedinstructions.www.waterlogic.us

MaterialsNeeded:
 PersonalProtectiveEquipment.RubberorNitrileSafetyGlovesandProtectiveEyewear
 PhillipsScrewdriver
 TemperatureGauge
 WaterPitcherorContainertocollectwaterfromthefaucet
 5‐galloncontainerordrainbasin
 CitricAcidBasedCleaner
 ¼”PlasticTubing,atleast4feetinlength,andassorted¼”quickconnectfittings
 SanitizingCartridge
 FoodColoring

1.  Turnofftheincomingwatersupplyattheisolationpoint 

2.  Selectthecold‐watericonandthenselecttheDispenseButton,when
thewaterstopsflowingreleasethebutton. 

CUBEManual Page20–Revision10‐8‐2018

3.  SwitchofftheRedPowerandtheGreenHeater/CompressorSwitchesO=OFFattherearof
themachineandremovethepowerleadfromtheunit.

4.  UseaPhillips‐headscrewdrivertoremovethetwoscrewsatthe
rearofthemachinethatsecuretheTopCoverifinstalled.

5.  RemovetheTopCoverbyplacingyourhands
ontheTop,andpushittowardstherearof
theCUBEthenlifttoremove.
6.  Next,removetheFilterclosesttothefrontof
themachine.

Insertyourfingerintotheroundholeofthe
lever,andpulltheleveruptothevertical
position. 

7.  Pulltheleverstraightuptoremovethefilterassembly(someslight
forcemayberequired).
Verifythefilterremovedisthe10‐inchCBCfilter.Ifthefilteris
labeleddifferently,call1‐800‐288‐1891TechnicalAssistance.
8.  Unscrewthefilterbodyfromthefilterheadbyturningthebaseinaclockwisedirection.

9.  Pourawaytheexcesswater.

CUBEManual Page21–Revision10‐8‐2018

10.  RemovetheFilterCartridgefromthefilterheadbyturningthebasein
aclockwisedirection.

11.  RemovetheHotDrainValveCapatthebackoftheCUBEuntilall
waterhasbeenremoved.
12.  AddDescalingSolution(minimum2ouncesofdescalingpowder)toEmptyFilterBody.

13.  ScrewtheFilterBodytothefilterheadinacounter‐clockwisemotion,
itmustbesecurelytightened.
14. a. InserttheFilter
Assemblybackinto
itscradle,aligning
thetwomaleports
withthefemaleholes
inthecradle
b. Pushitfirmlyuntil
theFilterissecurely
inplaceandisflush
withthecradletop
surface.
c. Lockthefilterby
closingthelocking
leveruntilit‘clicks’
intoplace.
15.  Turnonthewatersupplyattheisolationpoint

CUBEManual Page22–Revision10‐8‐2018

16.  Reconnectthepowerleadandinsertitintotherearofthemachine.
TurnONtheRedPowerSwitch.I=ON
17.  Placeacontainerunderthedispensearea.SelecttheHot
WaterIconandthentheDispensebutton.

Dispense2quartsofwater.




18.  TurnonGreenHeater/CompressorSwitchatrearofmachine.I=
ON

19.  LeavethedescalesolutionfluidtostandintheHotTankfor20minutes.

After20minutes,selecttheHotWaterIcon,selecttheDispensebuttonandflush3gallons
ofHotwaterthroughtheCUBE.
20.  Turnoffthewatersupplyattheisolationpoint.
21.  SelecttheCold‐WaterIcon,thentheDispenseButtonuntilno
waterdispensesfromtheCUBE.
22.  SwitchOfftheRedPowerandGreenHeater/CompressorSwitchatthe
rearofthemachine.O=OFF
23.  RemovethePowerLeadfromtheunit.
24.  Insertyourfingerintotheroundholeofthelever,
andpulltheleveruptotheverticalposition.
NOTE:MakesurethefrontFilterwithdescaling
solutionsistheoneremoved.


CUBEManual Page23–Revision10‐8‐2018

25.  Pulltheleverstraightuptoremovethefilterassembly(someslight
forcemayberequired)
26.  Unscrewthefilterbodyfromthefilterheadbyturningthebasein
clockwisedirection.

27.  Pourawaytheexcesswater,ensureanyremnantsofdecalingsolutionhavebeenflushed.
28.  RemovetheFilterCartridgefromthefilterhead. 
29.  ScrewtheFilterBodytotheFilterHeadbyturningthebaseinacounter‐
clockwisedirection.Ensureitissecurelytightened.
30.  FittheFilterAssemblyintothemachineasfollows:

CUBEManual Page24–Revision10‐8‐2018

a. InserttheFilter
Assemblybackinto
itscradle,aligning
thetwomalespigots
withthefemaleholes
inthecradle
b. Pushitfirmlyuntil
theFilterissecurely
inplaceandisflush
withthecradletop
surface.
c. Lockthefilterby
closingthelocking
leveruntilit‘clicks’
intoplace.
31.  UseaPhillips‐headscrewdrivertoreinstallthetwoscrewsat
therearofthemachinethatsecuretheTopCoverifscrews
wereremovedinStep4.
32.  Turnonthewatersupplyattheisolationpoint.
33.  Reconnectthepowerleadandinsertitintotherearofthemachine.
TurnontheRedPowerSwitchI=ON



34.  TheGreenHeater/Compressorswitchcannowbeturnedon.I=ON

AllowtheCUBEtoheatandcoolthewater.


35.  Cleantheoutsideofthemachinewiththenon‐abrasiveanti‐bacterialwipeorcloth.
36.  Tastethewateronefinaltime,ifyoudetecthintoftaste,flush3moregallonsofwater
throughtheHotTank.


CUBEManual Page25–Revision10‐8‐2018

WARNING!HOTWATERHAZARD.UnitProducesVeryHotWaterandSteam.Alwaysuse
insulatedandchemicallycompatiblecontainersandletunitcooldownbeforedrainingtheHot
Tanktoavoidinjury.


CAUTION!REPLACEHOTTANKEVERY3‐5YEARS.TheHotTankanditscontrolsshouldbe
replacedaminimumofeverythreetofiveyearstoensureefficientoperation.


WARNING!REINSTALLALLPANELSANDCOVERS.Alwaysreinstallallpanels,protectivecovers,
andfastenersafterservicingequipment.Failuretodosocouldresultinseverepersonalinjury
andwillvoidthecertificationsandwarrantyoftheequipment.


CUBEManual Page26–Revision10‐8‐2018

FILTERREPLACEMENT

Filtersshouldbeconfiguredtooptimizeyoursystem.Filtersneedtobeconfiguredandspecifiedto
dothejobgiventhelocalwaterconditions,usage,maintenanceschedule,andplacement
restrictions.

Inorderforourfilterstoperformasrepresentedandtoprovidethebestqualitywaterpossible,itis
essentialthatfiltersbereplacedperiodically.Thefrequencyoffilterchangesdependsonyourwater
qualityandyourwaterusage.Forexample,ifthereisalotofsedimentand/orparticlesinyour
water,thenyouwillhavetochangeyourfiltersmorefrequentlythanalocationwithlittletono
sediment.Besuretoreplaceyourfilterswheneveryounoticeadeclineintheperformance,whether
itisadrop‐inflowrateand/orpressureoranunusualtasteinthewater.


WARNING!Readandunderstandthecontentsofthismanualbeforeattemptingtoservice
CUBE.Failuretofollowtheinstructionsinthismanualcouldresultindeath,seriouspersonal
injury,orseverepropertydamage.Onlytrainedandqualifiedtechniciansshouldattemptto
install,maintain,orserviceWaterlogicEquipment.

MaterialsNeeded:
 PhillipsScrewdriver.
 Replacementfiltercartridge(s)
 WaterPitcherorContainertocollectwaterfromthefaucet
 5‐galloncontainerordrainbasin

1. Turnofftheincomingwatersupplyattheisolationpoint.

2. Selectthecold‐watericonandthenselectthedispensebutton.Whenthewater
stopsflowingreleasethebutton



3. SwitchOfftheRedPowerSwitchandtheGreenHeater/Compressorswitchesat
therearofthemachineO=OFFandremovethepowerleadfromtheCUBE
WaterTreatmentSystem.

4. RemovethetwoscrewsattherearofthemachinethatholdtheTopCoverin
place







CUBEManual Page27–Revision10‐8‐2018


5. RemovetheTopCoverbyplacingyourhandsontheTopinthepicture
andpushitbackwardsandthenliftituptoremove.





6. ReplacetheCarbonBlockFilter.Insertyourfingerintothetopofthe
carbonblockfilter(thefilterthatisclosertothefrontofthemachine)
andpulltheleveruptotheverticalposition.



7. Pulltheleverstraightuptoremovethefilterassembly(slightforcemayberequired).






8. RemovetheFilterBodyfromthefilterheadbyturningthebaseina
clockwisedirection.







9. RemovetheFilterCartridgefromtheFilterHeadbypullingitout.






10. RemovethenewFilterCartridgefromthepackagingandfititbyfirmlypushingitintothe
FilterHead,makingsureitisfirmlyandsecurelyfitted.






CUBEManual Page28–Revision10‐8‐2018

11. ScrewtheFilterBodytothefilterheadbyturningthebaseinaclockwise
direction.Ensureitissecurelytightened.



12. Fitthefilterassemblyintothemachine:

a. Insertthefilterassembly
backintoitscradle,
aligningthetwomale
spigotswiththefemale
holesinthecradle


b. Pushitfirmlyuntilthe
filtersitssnuglyandis
flushwiththecradle
topsurface



c. Lockthefilterby
closingthelocking
leveruntilit‘clicks’
intoplace




13. ReplaceTopCoverandScrews.

14. TurnontheWaterSupply.

15. TurnonRedPowerSwitchI=ON

*DonotturnonGreenHeater/CompressorSwitchuntilinstructedtodoso.

16. SelectColdWateranddispenseuntilwaterflowsclear.Thisstepflushesthe
carbonfinesfromthefilter.

17. Resetfilterservicetimer.Resetbyselectingthehotandcoldiconssimultaneouslyandholding
themfor10seconds.Theunitwillbeepandthefilterserviceindicatorlightwillturnoffonce
resetiscomplete.

18. TurnonGreenHeater/CompressorSwitch.I=ON






CUBEManual Page29–Revision10‐8‐2018

UVLAMPREPLACEMENT

1.  RemovetheUVLampProtectiveCoverfromthefront
right‐handsideoftheCUBEbyremovingthefixing
screwandliftingthecoverup
2.  DisconnecttheUVLampConnectorbypressinginthe
cliponthesideofthemachine.

Pulltheconnectortowardsthefrontofthemachine.


3.  FirmlypulltheoldUVLampupandoutoftheCUBE.

Donotpullthelampoutanangleasitmaybreakor
damagetheinternalpartsoftheCUBE.
4.  InsertthenewUVLampwhileholdingthewhiteend
capsonly.

InserttheUVLamp,ensuringyouhavepusheditall
thewaydownuntilitcannotgoanyfurther.

ReconnecttheUVlampConnector,makingsurethe
connectorsarelinedupcorrectlyastheywillonlyfit
whencorrectlyaligned.

5.  ReinstalltheUVLampProtectiveCoverandSecureit
inplacewiththefixingscrew.
6.  InstalltheTopCoverontothemachinebyplacing
coverintoposition.Ensurethetwofixinglogsatthe
frontarelinedupwiththegrooves,thenpullingthe
coverfirmlytowardsyourselfuntilitclicksintoplace.

CUBEManual Page30–Revision10‐8‐2018

7.  Reconnectthepowerleadintothebackofthe
machineandplugintopowersource.
8.  TurnonRedPowerSwitchtotheOnPositionI=On
9.  VisuallyverifythattheUVLampisworkingcorrectlyby
checkingthePCBLED.Thereshouldbenowarning
iconsflashing.


Note:UVLampSensoristemperaturesensitive.Duringextendedperiodsofuse,especially
whenfillingordrainingtheunit,whenwaterisnotbeingdispensedUVLampSensorcan
overheat,initiatingaUVFault.Ifthisoccurs,turnofftheunitfor5minutesandallow
sensortocoolbeforeresumingoperation.


CUBEManual Page31–Revision10‐8‐2018

QUARTZSPIRALREPLACEMENT

1.  TurnoffboththeGreenHeater/CompressorSwitchandtheRedPowerSwitcheslocatedon
backofunit

O=OFF
Unplugpowertounit.
2.  WithaPhillipsHeadScrewdriver,removethetwo
screwsatbackoftheTopCoverifinstalled.


3.  RemoveTopCoverbyplacingyourhandsonthe
topandpushingtheTopCovertowardstherear.

Liftandremove.




4.  WithaPhillipsHeadScrewdriver,removethetwo
screwsontheLeftSidePanel.RemoveLeft
SidePanel.

RemovethetwoscrewsontheRight‐SidePanel.

RemoveRightSidePanel.

CUBEManual Page32–Revision10‐8‐2018

5.  WithaPhillipsHeadScrewdriver,removethefive
screwsontheelectricalcoverplate.

RemovetheElectricalCoverPlate.

6.  WithaPhillipsHeadScrewdriver,removethefour
screwsthatattachtheSelection‐DispensePCBto
theMainframe.

RemovetheSelection‐DispensePCB.

7.  WithaPhillipsHeadScrewdriver,removethetwo
screwsfromthefaucetplate.

RemoveFaucetPlate.

8.  WithaPhillipsHeadScrewdriver,removethefour
screwsthatattachtheFrontPaneltothe
mainframe.

RemoveFrontPanel.

