WaterLogic WL250 Operating instructions

WL250Manual Page53‐Revision:12‐12‐2018
POWERTROUBLESHOOTINGINDEX


1. RedHeaterandCompressorPowerSwitchwon'tlight,andtheRedLEDon
theFrontwon'tlight

2. RedPowerSwitchislitbuttheredLEDontheFrontisnotlit

3. CompressorRunsbutdoesNotChill

4. CompressorisNotRunning


1. RedHeaterandCompressorPowerSwitchwon’tlightandtheRedLEDon
theFrontwon’tlight


PossibleReason Solution
CircuitBreaker ChecktheCircuitBreaker
FuseisBlown ReplaceFuse
Defective/LoosePowerCord Checkthatpowercordisproperlypluggedin.Ifitisproperly
pluggedin,useadifferentpowercordtoverify.
FailedPowerLineNoiseFilter,
ElectroMagneticInterference
filter(EMI)
ReplacePowerLineNoiseFilter,ElectroMagneticInterference
filter(EMI)
DefectiveRedHeater/
CompressorSwitch ReplaceRedHeater/CompressorSwitch






WL250Manual Page54‐Revision:12‐12‐2018
2. RedPowerSwitchislitbuttheRedLEDontheFrontisnotlit
PossibleReason Solution
BadTransformer ReplaceTransformer
BlackPowerConnectortothe
PCBisnotproperlyconnected Properlyconnect.
BadFrontPCB
ReplaceFrontPCB
HotandCold–P/NEN‐6085WLCPPN12‐8103
ColdOnly–P/NEN‐6086WLCPPN12‐8615
DefectiveRedHeater/
CompressorSwitch ReplaceRedHeater/CompressorSwitch

3. CompressorRunsbutDoesNotChill
PossibleReason Solution
Condenserisdirty Cleanthecondensingcoilofanyobstructionsordust.
Reductionofairflowintounit. Makesureunitisnotunderminimumventilationrequirements(2
to4inches).
Compressorisrunningvery
hot. Loworlostrefrigerant.Refrigerantrechargerequired.

4. CompressorisNotRunning
PossibleReason Solution
RedHeaterandCompressor
Switchbuttononunitisinthe
offposition


TurnRedHeaterandCompressorSwitchon.
I=ON

CompressorStartingCircuit
TurnRedHeaterandCompressorSwitchoff.O=OFF.

Removethecompressorcaponsideofthecompressor;

Disconnecttheblackandredterminalconnectors;

Inspectthestarterandoverloadrelayforanydefects.

Replacecomponents(s)asneeded.

TurnRedHeaterandCompressorSwitchonI=ONandretest
compressoroperation.
