WaterLogic WL500 - Sparkling Manual

WL500 – Sparkling
OPERATING, INSTALLATION, AND SERVICE MANUAL
Waterlogic Commercial Products, LLC
11710 Stonegate Circle
Omaha, NE 68164
[phone]
www.waterlogic.us

WL500 OPERATING, INSTALLATION, AND SERVICE MANUAL
Congratulations on your choice of the Waterlogic WL500 water treatment system. The WL500 is a fully
programmable self-contained model that dispenses cold, hot, extra-hot, and premium sparkling water.
Every WL500 includes:
High Performance Multi-Stage Filtration
Bio-Cote® Anti-Microbial Protection
Advanced In-Tank Ultraviolet (UV) Purification
The Waterlogic WL500 provides exceptional quality and great tasting water with every use.
TABLE OF CONTENTS
•Features and Benefits..................................................................3
•Certifications ...............................................................................5
•Introduction.................................................................................6
•Safety Alert Symbols....................................................................6
•Safety Precautions.......................................................................7
•Model and Part Designations ......................................................8
•Specifications...............................................................................8
•Operating Instructions.................................................................9
•Principles of Operation..............................................................10
•Flow Diagram.............................................................................13
•Programming Menu and Instructions .......................................14
•Quick Start Guide………………………………………… ..........................16
•Pre-Installation Procedures.......................................................17
•Draining Procedure....................................................................21
•Installation Procedures..............................................................24
•Service Requirements................................................................27
•Replacement Components........................................................29
•Hot Tank Descaling Instructions ...............................................30
•Layout Drawing and Part Numbers…………………… .....................32
•Main Parts Drawing and Part Numbers.....................................33
•Wetted Parts Drawing and Part Numbers.................................36
•Electrical Diagram......................................................................39
•Fault Codes and Troubleshooting .............................................40
•Base Cabinet & Cup Dispenser Instructions..............................49
•Warranty ...................................................................................53
WL500 Operating, Installation, and Service Manual Page 2 - Revision: 5-29-2015

WL500 FEATURES AND BENEFITS
Premium Sparkling Water
Unlimited Premium Sparkling Water produced through innovative Mizzling Technology.
Cold, Hot, and Extra Hot Water
Pressure Fed Cold, Hot, and Extra Hot Selections to meet a wide range of customer demands.
High Volume Storage and Water Capacity
3 liters of Cold, 1 liter of Sparkling, and 1.6 liters of Hot Water Storage.
BioCote®Anti-Microbial Protection
Plastic surfaces surrounding dispensing areas and drip tray are infused with an
exclusive silver additive called BioCote®. Silver is a natural anti-microbial that
inhibits the growth of microorganisms providing additional surface protection.
Large Dispense Area with Recessed Faucet
6-3/4 inch dispense height with BioCote® recessed faucet to protect from cross-contamination.
Drip Tray with Sensor and Alarm
Two-piece BioCote® drip tray for easy cleaning. Drip Tray Sensor and Drip Tray Full Fault Mode that
halts supply to prevent overflow and sounds alarm to reduce accident potential.
Child Safeguard
WL500 requires selection followed by main dispense and defaults back to cold/sparkling water selection
after 3 seconds of inactivity to prevent accidental dispensing of hot water.
Digital Display
WL500 has an innovative user interface utilizing a LCD display for easy use and programming.
Advanced Programming
Customizable settings for optimizing each WL500 including; Cold Temp Set Point, Hot Temp Set Point,
Static or Ranging Temperature Display, UV Timer, F/C Display, Multiple Languages, Filter Timer Setting,
Filter Life Monitor, Sleep Mode, and Default Selection Mode.
Energy Saving Sleep Mode
Energy saving Sleep Mode can be programmed to turn off heater after 3 hours of inactivity.
In-Tank UV Purification
Industry leading In-Tank UV Purification sterilizes water within Stainless Steel Cold Tank. UV Indicator
and Fault Mode Protection to alert user and stop water supply.
Add-On Base Cabinet with Optional Cup Holder
Matching base cabinet with optional cup holder provides the flexibility to meet
all installation requirements while minimizing inventory costs.
WL500 Operating, Installation, and Service Manual Page 3 - Revision: 5-29-2015

WATERLOGIC WL500 PREMIUM SPARKLING OVERVIEW
Waterlogic WL500 produces Premium Sparkling Water which is made in a batch and contains a fine,
dense carbonation as compared to other “soda water” products in the market. Optimum sparkling
water is generated in the WL500 with 41°F cold water and food grade CO2at 42.5 psi (3 Bar).
Please ensure customer’s carbonation expectations are clear before installing a WL500. Waterlogic
Premium Sparkling Water is very similar to Perrier and Pellegrino.
The premium fine dense sparkling water produced by the WL500 may not meet user's expectations if
they are looking for large bubble soda stream type of carbonation.
A blind taste test using Pellegrino/Perrier is a great way to demonstrate the expectations and quality of
the Waterlogic Premium Sparkling Water. Open two bottles and empty one and fill with Premium
Waterlogic Sparkling Water from a freshly regenerated tank operating at optimum conditions (41°F / 43
psi). Recap both and mark the bottles accordingly. Ensure the bottles are sampled at the same
temperature by refrigerating if necessary for later use and comparison. Most users will prefer the great
taste of the Waterlogic Premium Sparkling Water at a fraction of the cost of the bottled counterparts.
You may purchase a carbonation tester from a company such as Taprite to measure the level of
carbonation if you wish to quantify the results and check the output of the WL500. The level of
carbonation is very consistent as long the test conditions are repeatable and proper testing procedures
are followed.
Temperature of the water in the WL500 has the largest impact on the taste and carbonation levels and
the cold tank must below 46°F (prefer 41°F) before injecting water into the sparkling chamber
(carbonator) to produce proper results.
The temperature inside the cold tank can be displayed on the LDC screen by setting the temp display
function to "Ranging" mode. See the programming section to adjust this setting.
Allow a minimum of an hour for the WL500 to chill the cold circuit to the 41°F set point temperature
before sampling the sparkling water. Once the water is chilled, the sparkling tank should be
"Regenerated" by completely and continuously dispensing the initial batch (0.8 liters) of product from
the carbonator until only Co2 gas is dispensing from the faucet. The initial batch of sparkling product
will be flat because it was injected into the carbonator at ambient temperature when initiating the
WL500. Always remember that the water must be below 46° F to make premium sparkling water.
Do not set the cold temperature set point below 41°F or you increase the risk of freezing the sparkling
tank. The thermistor that controls the refrigeration system is located in the well in the UV cold tank
and does not monitor water temperature in the sparkling tank (carbonator). The refrigeration system
chills both tanks simultaneously and is either on/off based up on feedback from the thermistor.
Frequent or continuous use of the cold still water results in refrigeration system running and
continuously chilling the sparkling product in the carbonator below freezing point. This can result in a
frozen sparkling tank and sparkling product will not be dispensed even with proper gas supply.
WL500 Operating, Installation, and Service Manual Page 4 - Revision: 5-29-2015

WL500 CERTIFICATIONS
Waterlogic water treatment systems have been tested, and certified to rigorous NSF and UL Standards.
We believe that performance testing and certifications validate Waterlogic as a world-leader in water
treatment systems.
WL500 Certifications Include
UL399 – Certified Drinking Water Cooler
Intertek Labs (ETL) Certified the WL500 to ANSI/UL 399 Standard for Drinking Water
Coolers.
BPA Free - Waterlogic tests for BPA and declares that all of its products are Bisphenol-A
FREE and contain no harmful BPA plastics.
Waterlogic is certified to ISO 9001 – Quality Management Systems (certified by
Moody International). ISO 9001 is the internationally accepted standard for
well managed organizations that have adopted the key quality management
principles to its operations to bring consistent quality products and a culture of
continuous improvement.
Safe Drinking Water Act
Waterlogic water treatment systems conform to the Safe Drinking
Water Act (SWDA) “lead-free” amendment effective January 4, 2014.
WL500 Operating, Installation, and Service Manual Page 5 - Revision: 5-29-2015

INTRODUCTION
Carefully read and follow all instructions to ensure proper and efficient operation of your WL500.
Contact Waterlogic or an Authorized Waterlogic Dealer if you have any questions.
Waterlogic and Authorized Waterlogic Dealers employ trained service personnel who are experienced
in the installation, function and repair of Waterlogic equipment. This publication is written for use by
these qualified individuals. Waterlogic encourages users to learn about products, however, we believe
that product knowledge and service is best obtained by consulting Waterlogic or an Authorized
Waterlogic Dealer.
Waterlogic water treatment systems should be combined with selected water treatment components
to create a system specifically tailored for each application by trained and qualified personnel.
Products manufactured and marketed by Waterlogic and its affiliates are protected by patents issued or
pending in the United States and other countries.
Waterlogic reserves the right to change the specifications referred to in this literature at any time,
without prior notice. Changes or modifications not expressly approved by Waterlogic could void the
warranty and user’s authority to operate the equipment.
SAFETY ALERT SYMBOLS
Read and follow all safety information carefully. The signal words used in this manual are selected as
shown below and based on an assessment of the degree of potential injury or damage (severe or minor)
and the occurrence of injury (definitely occurs or has the potential to occur) when the warning is
ignored:
DANGER!
Indicates a situation which, when not avoided, results in death or severe injury.
WARNING!
Indicates a situation which, when not avoided, has the potential to result in death or severe
injury; and/or severe property damage.
CAUTION!
Indicates a situation which, when not avoided, results or has the potential to result in minor
injury; and/or minor property damage.
WL500 Operating, Installation, and Service Manual Page 6 - Revision: 5-29-2015

SAFETY PRECAUTIONS
Basic safety precautions should be followed, including the following:
DANGER!If incorrectly installed, operated or maintained, this product can cause death or severe
injury. Those who install, operate, or maintain this product should be trained in its proper use, warned of
its dangers, and should read the entire manual before attempting to install, operate, or maintain this
product.
WARNING! Unit is to be used for its intended purpose as described in this manual, and untrained
individuals who use this manual assume the risk of any resulting property damage or personal injury.
WARNING!HOT WATER. Unit produces Very Hot Water up to 203oF. Water above 125oF can cause
severe burns or scalding. Keep unauthorized people and children away from the unit to avoid accidental
dispensing of hot water. Children should not use without supervision.
DANGER! ELECTRICAL SHOCK HAZARD. Always unplug from power supply prior to servicing
equipment to prevent electrical shock.
WARNING! This system to be used for water only and is not intended for use where water is
microbiologically unsafe or with water of unknown quality without adequate disinfection before or
after the system. The system is designed for the supplemental bactericidal treatment of either treated
and disinfected public drinking water, or other drinking water, which has been tested and deemed
acceptable for human consumption by the state or local health agency having jurisdiction. The system is
designed to reduce normally occurring non-pathogenic or nuisance microorganisms only. System is not
intended for treatment of contaminated water.
WARNING! Dispenser Could Tip or Fall causing serious injury. Always install unit on a firm, flat, and
level surface and secure the WL500 to the base cabinet with the screw provided to lock the components
together. Never place heavy items on top of unit and never climb, stand, or hang on unit or storage
cabinet to prevent injury and damage.
DANGER!HIGH PRESSURE CO2GAS. CO2cylinders (tanks) contain high pressure compressed gas.
Always use caution when handling and use a proper pressure regulator. Never expose tanks to
temperature over 125 F and always secure the cylinder vertically. Follow all local and state
transportation and safety standards. Always ensure proper ventilation.
CAUTION! INDOOR USE ONLY.Do not install outdoors or where unit is in direct sunlight. Do not
install where ambient temperature goes below 50F or above 97F. Avoid high humidity and moisture.
Product life and performance will be impacted and warranty could be voided.
WL500 Operating, Installation, and Service Manual Page 7 - Revision: 5-29-2015

MODEL/PART DESIGNATIONS
BRAND NAME DESCRIPTION MODEL – PART NUMBER
WL500 Waterlogic WL500 - Cold, Sparkling, Hot, Extra Hot 10-VMHCS3
F-6004-M-HCS-DT-CS-INN
AK-0005 Optional Base Cabinet for Waterlogic WL500 10-7000
AK-0007 Optional Cup Dispenser for Base Cabinet 10-7001
SPECIFICATIONS
ITEM
WL500 (w/o BASE CABINET)
WL500 (with BASE CABINET)
Water & CO2Connection
¼” Quick Connect
Cold Water Temperature
Cold Water Temperature – Factory Set Point 41° - 5°C
(Adjustable) 34° - 54° F. (1.1°- 12.2°C)
Hot Water Temperature
158
°
- 203
°
F (70
°
- 95
°
C) Programmable
Recommended Service Pressure
40-60 psi (275-414 kPa) – Use Pressure Regulator
Maximum Working Pressure
60 psi (414 kPa) – Use Pressure Regulator
CO2Supply Requirement
(400 Glasses/ 1lb CO
2
)^ Food Grade CO2- Regulated to 35-45 psi
Environmental Temperature
35°- 100°F (2°- 37°C)
Refrigerant Gas R134a – 2.29 oz. (65 grams) - Hi (280 psi) Low (90 psi)
R134a Pressures High (230 psi), Low (90 psi)
SHIPPING SPECIFICATIONS
ITEM
WL500 (w/o BASE CABINET)
WL500 (with BASE CABINET)
Width/Depth/Height
#
17 in. x 18 in. x 18.5 in.
#
17 in. x 18 in. x 49.25 in.
Weight – Dry (w/o packaging) 65 lb. (29.5 kg) 100 lb. (45.4 kg)
Shipping Information
(length x width x height)
20 in. x 22 in. x 22 in.
8 units per pallet
AK-0005 33 in. x 18 in. x 10 in.
AK-0007 32 in. x 12 in. x 7 in.
Shipping Weight – Dry 70 lb. (32 kg) AK-0005 35 lb. / AK-0007 9 lb.
ELECTRICAL SPECIFICATIONS
ELECTRICAL SUPPLY 120V/60Hz 15 Amp Service
+
COMPONENT POWER (approximate) AMP DRAW (approximate)
Heater 500 Watts 4.2 Amps
Compressor 210 Watts 1.75 Amps
Fan Motor 18 Watts 0.15 Amps
UV Lamp System 18 Watts 0.15 Amps
Pump 26 Watts 0.22 Amps
WL500 TOTAL 772 Watts 6.47 Amps
#WL500 is 18.5 in. tall and may not fit between countertops and cabinets - Check installation to ensure adequate clearance.
^400 12oz Cups of Premium Sparkling Water per pound of CO2under normal conditions. +G F I recommended - See Installation Instructions.
WL500 Operating, Installation, and Service Manual Page 8 - Revision: 5-29-2015

OPERATING INSTRUCTIONS
The above picture shows front LCD display and control panel for the Waterlogic WL500 .
Button Operational Use Programming Mode
1 Select Cold Water Scroll the Menu Down
2 Select Sparkling Water Scroll the Menu Up
3 Select Hot Water
Enter (select) an Option
on the Menu
4 Select Extra Hot water
Escape to Main Menu/Exit
Programming Mode
Main Dispense Button
(larger -not shown above) Dispense Selection N/A
For Cold Water: Press Cold (Button 1) followed by the Main Dispense Button.
For Sparkling Water: Press Sparkling (Button 2) followed by the Main Dispense Button.
For Hot Water: Press Hot (Button 3) followed by the Main Dispensing Button.
For Extra Hot Water: Press Extra Hot (Button 4), wait approximately 30 seconds. Then press Hot
(Button 3) and the Main Dispensing Button. This procedure will raise the hot
water temperature approximately 2oF. Repeating the process over again will
raise the temperature about 2oF more until the desired temperature is reached
up to a maximum limit of 203oF.
NOTE: Default selection mode is Cold Water. Selection will return to default after 3 seconds of
inactivity. The default selection can be programmed to Cold or Sparkling. See Programming section of
this manual.
WL500 Operating, Installation, and Service Manual Page 9 - Revision: 5-29-2015

WL500 PRINCIPLES of OPERATION
It will take the WL500 approximately 10 minutes to heat 1.6 liters of water in the hot circuit and 45
minutes to chill the 4 liters of water in the cold circuit to set point temperatures after all tanks have
been properly filled. The WL500 has two cold tanks; a 2 liter UV Cold Tank and a 2 liter Sparkling Cold
Tank which is separated by a baffle/divider plate that isolates a 1 liter Sparkling Water Chamber from a
1 liter Pre-Chill Chamber within.
WL500 PRINCIPLES of OPERATION LAYOUT
Dispensing Cold Still Water from the WL500
The WL500 defaults to cold water selection when idle. “COLD” will appear on the display and cold
water will be dispensed when the Main Dispense Button is pressed. Selecting COLD (Button 1) and then
pressing the Main Dispense Button opens Solenoids 2 and 4, which allows supply water to push into the
Pre-Chill Chamber of the Sparkling Cold Tank. Pressurize feed water pushes into the bottom of the pre-
chill chamber and forces pre-chilled water through the tall draw tube into the bottom of the UV Cold
Tank. UV treated, cold, still water is forced out through the tall draw tube, through Solenoid 4, out the
faucet of the dispenser. When the main dispense button is released, both Solenoid 2 and 4 will close,
thus stopping cold, still water output.The WL500 is a pressure fed unit and output is dependent on
supply.
Sparkling Cold Tank
UV Cold Tank
Sparkling
Chamber
Pre-Chill
Chamber
1 Liter
UV
Chamber
2 Liter
1 Liter
Pump Drain
WL500 Operating, Installation, and Service Manual Page 10 - Revision: 5-29-2015

Dispensing Hot Water from the WL500
To dispense hot water, select the small HOT (Button 3) and release. HOT will appear in the display, and
press the Main Dispense Button. This will open the hot input solenoid (Solenoid 1– not shown above)
and allow hot water to dispense through the faucet. The WL500 can be programmed to default back to
COLD or Sparkling after 3 seconds of inactivity as a safety feature to prevent accidental dispensing of
hot water.
Dispensing Extra Hot Water from the WL500
Typically, the WL500 hot water temperature is set to 189oF. In some cases, extra hot water is desired
for making soups and teas. To temporarily raise the hot water temperature, users can depress and
release the EXTRA HOT select button (button 4). The word HEATING will appear in the display for 10-
seconds, which will raise the hot water temperature about 2 degrees. If the user presses the EXTRA
HOT select button again after 30-seconds have expired, the word HEATING will appear in the display,
and the temperature in the hot tank will be raised another 2oF. Eventually, as the process is repeated,
the hot tank temperature will reach up to 203oF, and the extra heating will be disabled. At this point,
203oF hot water can be dispensed from the WL500, which is a desired temperature for soups/teas. The
WL500 will return to the hot temperature set point after the extra hot water is dispensed.
Dispensing Premium Sparkling Water from the WL500
To dispense sparkling water, press and release Sparkling (Button 2). SPARKLING will appear in the
display. From this point, the user has 3-seconds to press the Main Dispensing Button for Premium
Sparkling Water. The unit will default back to COLD water after 3 seconds unless the Default Set is
changed to Sparkling. (See Programming Section)
When the Main Dispensing Button is pressed, Solenoid 5 will open, and the CO2gas supply from the
bottle will push sparkling water out of the sparkling water chamber to the faucet. The CO2supply is
what forces sparkling water out of the sparkling chamber. The sparkling water chamber is 1 liter in size
and a maximum of 1 liter of sparkling water can be dispensed to the glass at a time. Once the sparkling
tank empties of sparkling water, only CO2 gas will dispense to the glass. At this point, the main
dispensing button must be released to allow the WL500 to make another batch of Premium Sparkling
Water.
When the Main Dispensing Button is released, Solenoid 2 and 3 will open, and the Booster Pump will
start the Mizzling Process. The Booster Pump will draw cold, still water from the Cold Tank, forcing that
water through Solenoid 3 and the check valve into the spray header inside of the sparkling chamber.
The spray will enter the sparkling chamber as a fine mist that will absorb the CO2gas that is present in
the chamber. Once the sparkling tank fills with water, the level probe mounted in the top of the
sparkling tank will detect the water and signal the PCB to shut down the booster pump, as well as close
Solenoid 2 and 3. Note that the booster pump can supply this spray up to approximately 70 psi, and if
the CO2gas pressure is too high, the booster pump will not be able to overcome the gas pressure, and
will “dead-head”. If the booster pump runs for 10 minutes without a signal from the level sensor, the
PCB will shut down the sparkling water process and signal a NO WATER SUPPLY FAULT will be displayed.
WL500 Operating, Installation, and Service Manual Page 11 - Revision: 5-29-2015

Once the level sensor detects the tank is full of water, the PCB will shut down sparkling water
generation (Mizzling Process). The WL500 will return to the COLD default selection after 3 seconds.
Cold and Hot water can be dispensed while sparkling water is being generated. The sparkling water
generation will stop as soon as sparkling water is dispensed or the chamber fills. The WL500 will make 1
liter (34 ounces) of sparkling water in approximately 1 minute, 20 seconds. Typically, users will only
dispense up to ½ liter (17 ounces) of sparkling water at a time, and the WL500 takes about 40 seconds
to regenerate sparkling water tank accordingly.
Waterlogic WL500 produces Premium Sparkling Water
which is made in a batch and contains a fine, dense
carbonation as compared to some “soda water” products.
Optimal sparkling water is generated with cold water under
46oF.
WL500 Sparkling Level Sensor Probe requires inspection
and service. See Service Section.
WL500 Sleep Mode
The WL500 has programmable sleep mode. When sleep
mode is ON the WL500 will shut down the heater circuit to
conserve energy after the machine is idle for 3 hours. The
heater circuit will awake once any button is depressed and
it will reheat the hot tank to set point temperature. “SLEEP
MODE” will be displayed. Always check Sleep Mode setting
if unit does not produce hot water as expected.
WL500 UV Protection
The Waterlogic WL500 contains a germicidal ultraviolet
(UV) lamp that sterilizes water in the cold tank and requires
annual replacement.
The WL500 has a UV CDS Sensor located in the Cap of the
UV Tank. UV Fault Mode Protection will alert the user with
a 20 second audible alarm and display UV FAULT on screen
when UV light is not detected. UV Fault Mode Protection
will shut off cold/sparkling water to avoid potentially
dispensing unsafe water.
WL500 Operating, Installation, and Service Manual Page 12 - Revision: 5-29-2015

WL500 FLOW DIAGRAM
Water In
1 Liter Pre-Chill Tank
WL500 Operating, Installation, and Service Manual Page 13 - Revision: 5-29-2015

PROGRAMING MENU AND INSTRUCTIONS
Menu
Options
Brief Description
Cold Temp
Set
3° - 12°C The cold temperature can be set between 3°C and 12°C or 37°F and 54°F, depending on
which units are selected (°C or °F) in the F/C option.
37° - 54°F Recommended/Default Setting is 5°C/41°F.
Hot Temp
Set
70°C - 95°C The hot temperature can be set between 70°C and 95°C or 158°F and 203°F, depending
on which units are selected (°C or °F) in the F/C option.
158°F - 203°F Recommended/Default Setting is 87°C/189°F.
Temp
Display
Static The display indicates the STATIC (SET POINT) temperature. Default
Ranging The display indicates the ACTUAL tank temperature
UV Timer
3 minutes
The UV lamp lights every time you take a drink of cold water, and stays on for 3 minutes.
Recommended/Default Setting is 3 minutes
10 minutes The UV lamp lights every time you take a drink of cold water, and stays on for 10 minutes.
Constant The UV lamp stays on when power is on. Not Recommended
F/C
°
F Temperatures are displayed in degrees Fahrenheit. Default is
o
F
°C Temperatures are displayed in degrees Centigrade.
Language
English The display will read in English. Default is English
Spanish The display will read in Spanish
French, Etc… The display will read in French, and many others…
Flow
Counter
Liters
(4000-9000) DO NOT USE. “NO WATER SUPPY” Fault will occur. Use Filter Timer Instead.
Gallons (1000-
3000) DO NOT USE.“NO WATER SUPPY” Fault will occur. Use Filter Timer Instead.
Filter Timer
3 months Timer for Filter Life set at 3 months. Displays “Change Filter” after 3 months
6 months Timer for Filter Life set at 6 months. Displays “Change Filter” after 6 months
9 months Timer for Filter Life set at 9 months. Displays “Change Filter” after 9 months
None Timer for Filter Life is turned off. Default is None
Filter Life 00 DAYS
Indicates amount of water flowed(gal/liters) or days elapsed since last reset
Ensure Filter Timer is enabled and Filter Life indicates DAYS
Sleep Mode On Shuts heater down (hot water) if not used in 3 hours. – Default Sleep is ON
Off Hot water remains powered indefinitely.
Default Set Cold Defaults Display & Dispense Selection to Cold after 3 seconds. Default is Cold
Sparkling Defaults Display & Dispense Selection to Sparkling after 3 seconds.
Reset OK? Resets the Filter Life to zero. Confirm by selecting Button 3 (Hot) to Save and Exit. This
resets the timer.
WL500 Operating, Installation, and Service Manual Page 14 - Revision: 5-29-2015

PROGRAMMING INSTRUCTIONS
Access the programming menu by depressing Buttons No. 1 and No. 2 simultaneously for three seconds
until the Password Message appears on the display: Password * * * *
PASSWORD IS: 1 1 1 1
Press Button No. 1 until the number 1 is displayed
Press Button No. 2 to move to next field
Press Button No. 1 until the number 1 is displayed
Press Button No. 2 to move to next field and continue…until all 4 fields display 1 1 1 1
Press Button No. 3 to enter the password and access the programming mode.
Note: Unit will exit programming mode if no buttons are pressed within 5 seconds and return to display
mode.
Programming Example: Change Language
1. Press Buttons No. 1 and No. 2 for three seconds until “Password ****” appears on the
display. Enter 1 1 1 1 Password as shown above.
2. Press Button No. 2 repeatedly to scroll through the menu until the option “Language”
appears on the display.
3. Press Button No. 3 to select the Language option.
4. Press Button No. 2 repeatedly to scroll down through the languages until Spanish is
displayed).
5. Press Button No. 3 to select “Spanish.” This saves the selection.
6. Press Button No. 4 to exit programming mode.
Programming Example: Change Language and Lower Cold Temp
1. Press Buttons No. 1 and No. 2 for three seconds until “Password ****” appears on the
display. Enter 1 1 1 1 Password as shown above.
2. Press Button No. 2 repeatedly until the menu scrolls to the option “Language” on the
display.
3. Press Button No. 3 to select the Language option.
4. Press Button No. 1 repeatedly to scroll up through the language. (Spanish, French, English,
and others).
5. Press Button No. 3 to select “English.”
6. Press Button No. 1 repeatedly until the menu scrolls up to the option “Cold Temp Set” on
the display.
7. Press Button No. 3 to select the “Cold Temp Set” option.
8. Press Button No. 1 repeatedly until “39F” is displayed.
9. Press Button No. 3 to select “39F.”
10. Press Button No. 4 to exit Programming mode.
WL500 Operating, Installation, and Service Manual Page 15 - Revision: 5-29-2015

Mounting Bolt Here
WL500 QUICK START GUIDE
Critical Requirements
Establish Food Grade CO2Supply and regulate to 35-45 psi.This will produce optimum sparkling water
and CO2 concentration when combined with 46 F degree or cooler water. Regulate the Water Supply to
40–60 psi.ALWAYS use a pressure regulator.
1) Prior to setting the WL500 machine, open the knock-out on the back panel of the base cabinet to
allow running the CO2 pipe from the base cabinet to the WL500 machine.
2) Unpack the WL500 and set on top of base cabinet so that the side panels of the machine align with
the side panels of the base cabinet.
3) Secure the WL500 to the base cabinet using the bolt provided in the
base cabinet. Note that the connection point is accessed from the
underside of the base cabinet. The bolt threads into the WL500 base
plate and locks the unit together.
4) Install a regulator onto a 5lb or 10lb food grade CO2bottle and purge
some gas from the bottle. Regulate output to 35-45 psi. Close the
regulator outlet valve, and secure in the base cabinet.
5) Route a ¼-inch pipe from the outlet fitting of the CO2 regulator
through the knock-out up to the CO2IN bulkhead fitting on the back of the WL500.
6) Slowly open and supply CO2 to the WL500 prior to establishing water supply and power.
7) Establish 40–60 psi 0.5 gal/min or greater potable water supply. Leak Protection is recommended.
8) Supply power to the WL500, and turn on the RED power switch (GREEN power switch MUST remain
OFF until the WL500 tanks are filled or hot tank overload will trip).
9) Fill the hot, cold, and sparkling tanks by dispensing until water flows from each. The sparkling tank
will self-fill after the cold tank is filled. Once tanks are full, turn on the green power switch to allow
the heating and chilling systems to function.
10) Regenerate the sparkling tank by dispensing the initial batch of 1 liter from the chamber. Remember
that the water in the cold tank needs to be cold (below 46 F) to make premium tasting sparkling
water.
WL500 Operating, Installation, and Service Manual Page 16 - Revision: 5-29-2015

PRE-INSTALLATION PROCEDURES
DANGER! ELECTRICAL SHOCK HAZARD.
Only qualified personnel who have read and understand this entire manual should attempt to install, or
service this unit, failure to do so could result in death or serious injury. DO NOT plug into an electrical
supply until specifically instructed.
WARNING! ALWAYS SANITIZE BEFORE USE.
Sanitize before use to eliminate any potential microbiological contaminates.
Materials Needed:
•Personal Protective Equipment. Rubber or Nitrile Safety Gloves and Protective Eyewear
•Phillips Screwdriver. Temperature Gauge.
•Water Pitcher or Container to collect water from the faucet
•5 gallon container or drain basin
•Sanitizer - Household Bleach (5.25% Sodium Hypochlorite) or Citric Acid Based Cleaner
•¼” Plastic Tubing, at least 4 feet in length, and assorted ¼” quick connect fittings.
•TDS Meter and Test Strips for measuring chlorine. - Optional
•1/8 NPT Female Thread to ¼” Compression Fitting (Used to connect hose to drain fittings)
1. Unpack the Waterlogic WL500 and check exterior for damage.
WARNING! WL500 IS HEAVY.
Use proper lifting aids and handling techniques to avoid injury. Use assistance as single person lift
could cause injury. Always drain before handling and transporting and handling to reduce the weight
of the unit.
2. Remove the Retaining Screw that is located directly in front of
the faucet nipple. Refer to Figure 1. Removing this screw will
allow access to the inside serviceable components (filters and
UV lamp).
3. Open the front hatch cover by lifting up and hinging outward.
Front hatch cover can be removed by carefully squeezing panel
base and pulling over hinge pins.
Flush Filters
CAUTION! FILTER FLUSH REQUIRED.
WL350’s are not supplied with filters. Filters should be configured to optimize your system. Filters
need to be configured and specified to do the job given the local water conditions, usage,
maintenance schedule, and placement restrictions.
In order for our filters to perform as represented and to provide the best quality water possible, it is
essential that filters be replaced periodically. The frequency of filter changes depends upon your
water quality and your water usage. For example, if there is a lot of sediment and/or particles in
your water, then you will have to change your filters more frequently than a location with little to no
sediment. Be sure to replace your filters whenever you notice a decline in the performance, whether
it is a drop in flow rate and/or pressure or an unusual taste in the water.
WL500 Operating, Installation, and Service Manual Page 17 - Revision: 5-29-2015

4. Flush thoroughly per filter manufacturers’ recommendation with fresh water to drain.
5. Once flushed, install the filters. Following the flow direction on the filter.
NOTE: Filters should not be flushed prior to 24 hours before installation to limit Microbial Growth.
Sanitizing
Sanitize using a household bleach solution or other approved cleaner throughout the cold and sparkling
water circuits. Follow all instructions on the sanitizer and flush with fresh water through the faucet
until odor and taste is acceptable.
WARNING! USE PROPER PERSONAL PROTECTIVE EQUIPMENT
Always ensure proper ventilation and use proper personal protective equipment such as gloves and eye
protection when using chemicals. Refer to Material Safety Data Sheet for specific requirements of each
chemical product. Take all necessary precautions to prevent sanitizer from contacting eyes, clothing, and
any other surfaces in could damage (carpets).
6. Remove the UV Cover Plate and set aside – 2 Screws.
7. Disconnect the UV Lamp harness and carefully remove the UV Lamp from the quartz sleeve.
CAUTION! UV SYSTEM IS FRAGILE. Never handle the UV System with bare hands. UV Lamp and
quartz sleeve must be free of oils and contaminants to ensure proper operation.
8. Remove UV Sensor from the side of the cold tank/quartz sleeve retaining cap.
9. Unscrew cold tank/quartz sleeve retaining cap and remove the quartz sleeve. This may require top
cover to be removed to access properly and facilitate removal.
10. Mix ½ gallon of sanitizer per directions or use Bleach Solution (1 teaspoon = 1/6 oz. = 5 ml = ½ cap
full) of household bleach (Sodium Hypochlorite 5 - 10% Concentration) with 1/2 gallon of water.
Always ensure sanitizer is compatible with stainless steel and acetal plastic.
11. Pour sanitizer solution into cold tank thru funnel or spout. You may add concentrated sanitizer (½
cap bleach) directly into empty cold tank instead of premixing.
12. Inspect and clean quartz sleeve and O-ring. Reinstall the quartz sleeve and quartz sleeve retaining
nut. Tighten firmly to ensure proper seal. Over-tightening can cause damage.
13. Reinstall the UV Lamp and UV Sensor. Take care not to touch with fingers.
14. Connect 40-60 psi regulated, potable water supply to the water inlet bulkhead fitting located on the
back of the unit. Turn on water supply and check for leaks.
15. Connect CO2gas line to WL500 bulkhead inlet fitting. Regulate to 35-45 psi. Turn on CO2.
WARNING! HIGH PRESSURE CO2GAS. Use/Handle in accordance with all safety standards.
DANGER! ELECTRICAL SHOCK HAZARD.
WL500 Operating, Installation, and Service Manual Page 18 - Revision: 5-29-2015

Do not plug in unit unless qualified. Only qualified personnel who have read and understand this
entire manual should attempt to install or service this unit.
16. Connect WL500 to power, and turn I=ON the Red Power Switch.
CAUTION! NEVER TURN ON HEATER BEFORE FILLING HOT TANK.
Green Compressor/Heater Switch must be in the O=OFF position while the hot tank is empty.
Damage could occur within one minute and the overload (high limit) will require manual reset if
heater is turned on with an empty hot tank.
Fill the Cold Circuit with Sanitizer
17. Wait 10 seconds for the unit to perform its diagnostics checks, depress the main dispensing button
on the front control panel until cold water/sanitizing solution comes out the faucet. NOTE:
Container and drain basin will be required to catch the water from the faucet.
WARNING! Use Personal Protective Equipment. Gloves and Eye Protection Required. The first 2
or 3 gallons of water will contain concentrated sanitizer. Use extreme care!
Fill the Sparkling Chamber with Sanitizer
18. The sanitizer solution will be injected into the sparkling tank by the booster pump once unit is
turned on and the cold tank is full. Dispense 1 liter of sparkling water into container and let
sparkling chamber regenerate to ensure the sparkling tank is full of sanitizer.
CAUTION! USE SANITIZER COMPATIBLE WITH STAINLESS STEEL AND ACETAL PLASTIC.
Do not allow the sanitizer solution to remain in the system for more then 10-15 minutes unless
otherwise directed by the sanitizer manufacturer.
Flushing the Sanitizer from the Machine
19. Place a pitcher, catch basin, or other container under the faucet of the WL500.
20. Flush the Cold Tank. Run several gallons of water through the faucet by dispensing cold water to
dilute and remove the sanitizer from the cold circuit. You can use chlorine test strips to evaluate the
water. Once the sanitizer odor/taste has been flushed out of the cold side of the machine, move to
the sparkling circuit.
21. Flush the Sparkling Chamber. Dispense sparkling water until only gas comes out. Let the sparkling
tank regenerate. This should take approximately 1 minute, 20 seconds. Listen for the booster pump
to turn off. Repeat the sparkling water regeneration until the sanitizer odor/taste has been flushed
out.
22. The sanitization process for the Cold and Sparkling Circuits is now complete.
WL500 Operating, Installation, and Service Manual Page 19 - Revision: 5-29-2015

Fill the Hot Tank
23. Press the Hot Button (Button 3), followed by the main dispensing button to fill the hot tank. Water
will dispense from the faucet once the hot tank is full. Flush until water is clear.
WARNING! HOT CIRCUIT IS NOT SANITIZED. WATER MUST EXCEED 171oF
Water in the hot circuit is not sanitary until the temperature over 171oF for 5 minutes.
Do Not Ingest and avoid contact until heater is turned on for at least 5 minutes.
UV System Functional Test
WARNING! ULTRAVIOLET RADIATION. Protect your skin and eyes against ultraviolet rays.
Never look directly at an operating UV light. Disconnect before removing.
24. Dim or shield the overhead lights and peer into the machine, on top of the cold tank, at the UV
connector and retaining cap. The blue glow indicates that the lamp is lit.
25. Find the white wires delivering power to the top of the lamp assembly. Follow the wires back until
the electrical connector is found. Disconnect the electrical connector and verify that the UV lamp
alarm annunciates.
26. Reconnect the UV lamp wire connector, and cycle the red power switch to clear the alarm.
Compressor Test
27. Switch on the green power switch (turns on the compressor and heater). Always ensure tanks are
full of water before turning on the heater or the overload (high limit) will open and require manual
reset. Once the compressor starts, the fan condenser also will start. Verify the fan has started by
feeling for the discharge of air at the rear grill of the machine. Heat exchange is a signal that the
refrigeration system is working.
28. Monitor the cold tank temperature on the front display of the unit by changing the Temp Display to
RANGING. It will take about 45 minutes for the unit to chill down to the default set point
temperature of 41°F assuming ambient inlet water of 75oF.
29. Once the machine reaches its target temperature, the compressor and fan will shut off. Draw a
glass of cold water and verify it is has been chilled to proper temperature.
Heater Test
30. Always ensure tanks are full of water before turning on the heater or the overload (high limit) will
open and require manual reset. It will take the heater approximately 10 minutes to heat the water
from ambient 75°F to the factory set point of 189°F. You can monitor the hot tank temperature by
selecting the hot button when the Temp Display is RANGING. Dispense a cup of hot water to ensure
the temperature/odor/taste is acceptable.
WARNING! VERY HOT WATER CAN BURN OR SCALD.
Hot water should be dispensed carefully into insulated container to avoid injury.
Drain the WL500 for Transport
31. Drain the WL500 for transportation per the Draining Instructions in this manual.
WARNING! STORE UNIT EMPTY.ALWAYS SANITIZE BEFORE REUSE.
The unit must be completely drained and sealed before storing to avoid stagnation and reduce
microbiological contamination (potential bacterial growth).
WL500 Operating, Installation, and Service Manual Page 20 - Revision: 5-29-2015
