WaterLogic WL500 - Sparkling Manual

Waterlogic Commercial Products, LLC
11710 Stonegate Circle
Omaha, NE 68164
[phone]
www.waterlogic.us
WL500 –Sparkling
OPERATING, INSTALLATION, AND SERVICE MANUAL

Revision 1.1 Page 2
WL500 OPERATING, INSTALLATION, AND SERVICE MANUAL
Congratulations on your choice of the Waterlogic WL500 water treatment system. The WL500
is a fully programmable self-contained model that dispenses cold, hot, extra-hot, and premium
sparkling water. Every WL500 includes:
High Performance Multi-Stage Filtration
Bio-Cote Anti-Microbial Protection
Advanced In-Tank Ultraviolet (UV) Purification
The Waterlogic WL500 provides exceptional quality and great tasting water with every use.
TABLE OF CONTENTS
Features and Benefits ................................................................. 3
Certifications............................................................................... 4
Introduction ................................................................................ 5
Safety Alert Symbols ................................................................... 5
Safety Precautions ...................................................................... 6
Warranty .................................................................................... 7
Model and Part Designations...................................................... 8
Specifications .............................................................................. 8
Layout Drawing and Part Numbers……………………....................... 9
Operating Instructions .............................................................. 10
Flow Diagram ............................................................................ 11
Principles of Operation ............................................................. 12
Programming Menu and Instructions....................................... 15
Quick Start Guide………………………………………….......................... 17
Pre-Installation Procedures ...................................................... 18
Draining Procedure ................................................................... 22
Installation Procedures ............................................................. 24
Service Requirements ............................................................... 27
Hot Tank Descaling Instructions ............................................... 28
Replacement Components ....................................................... 29
Main Parts Drawing................................................................... 30
Main Parts List........................................................................... 31
Wetted Parts Drawing............................................................... 33
Wetted Parts List....................................................................... 34
Fault Codes and Troubleshooting ............................................. 36
Electrical Schematic .................................................................. 37
Base Cabinet & Cup Dispenser Instructions ............................. 38

Revision 1.1 Page 3
WL500 FEATURES AND BENEFITS
Advanced Multi-Stage Filtration
Pre-Installed Filters in each WL500 to remove contaminants and provide great taste.
Premium Sparkling Water
Unlimited Premium Sparkling Water produced through innovative Mizzling Technology.
Cold, Hot, and Extra Hot Water
Pressure Fed Cold, Hot, and Extra Hot Selections to meet a wide range of customer demands.
High Volume Storage and Water Capacity
3 liters of Cold, 1 liter of Sparkling, and 1.6 liters of Hot Water Storage.
BioCote®Anti-Microbial Protection
Plastic surfaces surrounding dispensing areas and drip tray are infused with an
exclusive silver additive called BioCote®. Silver is a natural anti-microbial that
inhibits the growth of microorganisms providing additional surface protection.
Large Dispense Area with Recessed Faucet
6-3/4 in. dispense height with BioCote® recessed faucet to protect from cross-contamination.
Drip Tray with Sensor and Alarm
Two-piece BioCote® drip tray for easy cleaning. Drip Tray Sensor and Drip Tray Full Fault Mode
that halts supply to prevent overflow and sounds alarm to reduce accident potential.
Child Safeguard
WL500 requires selection followed by main dispense and defaults back to cold/sparkling water
selection after 3 seconds of inactivity to prevent accidental dispensing of hot water.
Digital Display
WL500 has an innovative user interface utilizing a LCD display for easy use and programming.
Advanced Programming
Customizable settings for optimizing each WL500 including; Cold Temp Set Point, Hot Temp Set
Point, Static or Ranging Temperature Display, UV Timer, F/C Display, Multiple Languages, Filter
Timer Setting, Filter Life Monitor, Sleep Mode, and Default Selection Mode.
Energy Saving Sleep Mode
Energy saving Sleep Mode can be programmed to turn off heater after 3 hours of inactivity.
In-Tank UV Purification
Industry leading In-Tank UV Purification sterilizes water within Stainless Steel Cold Tank. UV
Indicator and Fault Mode Protection to alert user and stop water supply.
Add-On Base Cabinet with Optional Cup Holder
Matching base cabinet with optional cup holder provides the flexibility to
meet all installation requirements while minimizing inventory costs.

Revision 1.1 Page 4
WL500 CERTIFICATIONS
Waterlogic water treatment systems have been tested, approved, and certified by the world’s
top standards bodies such as NSF and ANSI. These organizations set and regulate national
standards. We believe that performance testing and certifications validate Waterlogic as a
world-leader in water treatment systems.
WL500 Certifications Include
UL399 –Certified Drinking Water Cooler
Intertek Labs (ETL) Certified the WL500 to ANSI/UL 399 Standard for Drinking
Water Coolers.
BPA Free - Waterlogic tests for BPA and declares that all of its products are
Bisphenol-A FREE and contain no harmful BPA plastics.
Waterlogic is certified to ISO 9001 –Quality Management Systems
(certified by Moody International). ISO 9001 is the internationally
accepted standard for well managed organizations that have adopted
the key quality management principles to its operations to bring
consistent quality products and a culture of continuous improvement.
Safe Drinking Water Act
Waterlogic water treatment systems conform to the Safe
Drinking Water Act (SWDA) “lead-free” amendment effective
January 4, 2014.

Revision 1.1 Page 5
INTRODUCTION
Carefully read and follow all instructions to ensure proper and efficient operation of your
WL500. Contact Waterlogic or an Authorized Waterlogic Dealer if you have any questions.
Waterlogic and Authorized Waterlogic Dealers employ trained service personnel who are
experienced in the installation, function and repair of Waterlogic equipment. This publication
is written for use by these qualified individuals. Waterlogic encourages users to learn about
products, however, we believe that product knowledge and service is best obtained by
consulting Waterlogic or an Authorized Waterlogic Dealer.
Waterlogic water treatment systems should be combined with selected water treatment
components to create a system specifically tailored for each application by trained and qualified
personnel.
Products manufactured and marketed by Waterlogic and its affiliates are protected by patents
issued or pending in the United States and other countries.
Waterlogic reserves the right to change the specifications referred to in this literature at any
time, without prior notice. Changes or modifications not expressly approved by Waterlogic
could void the warranty and user’s authority to operate the equipment.
SAFETY ALERT SYMBOLS
Read and follow all safety information carefully. The signal words used in this manual are
selected as shown below and based on an assessment of the degree of potential injury or
damage (severe or minor) and the occurrence of injury (definitely occurs or has the potential to
occur) when the warning is ignored:
DANGER!
Indicates a situation which, when not avoided, results in death or severe injury.
WARNING!
Indicates a situation which, when not avoided, has the potential to result in death or
severe injury; and/or severe property damage.
CAUTION!
Indicates a situation which, when not avoided, results or has the potential to result in
minor injury; and/or minor property damage.

Revision 1.1 Page 6
SAFETY PRECAUTIONS
Basic safety precautions should be followed, including the following:
DANGER! If incorrectly installed, operated or maintained, this product can cause death or
severe injury. Those who install, operate, or maintain this product should be trained in its
proper use, warned of its dangers, and should read the entire manual before attempting to
install, operate, or maintain this product.
WARNING! Unit is to be used for its intended purpose as described in this manual, and
untrained individuals who use this manual assume the risk of any resulting property damage
or personal injury.
WARNING! HOT WATER. Unit produces Very Hot Water up to 203oF. Water above 125oF
can cause severe burns or scalding. Keep unauthorized people and children away from the unit
to avoid accidental dispensing of hot water. Children should not use without supervision.
DANGER! ELECTRICAL SHOCK HAZARD. Always unplug from power supply prior to servicing
equipment to prevent electrical shock.
WARNING! This system to be used for water only and is not intended for use where water
is microbiologically unsafe or with water of unknown quality without adequate disinfection
before or after the system. The system is designed for the supplemental bactericidal treatment
of either treated and disinfected public drinking water, or other drinking water, which has been
tested and deemed acceptable for human consumption by the state or local health agency
having jurisdiction. The system is designed to reduce normally occurring non-pathogenic or
nuisance microorganisms only. System is not intended for treatment of contaminated water.
WARNING! Dispenser Could Tip or Fall causing serious injury. Always install unit on a firm,
flat, and level surface and secure the WL500 to the base cabinet with the screw provided to lock
the components together. Never place heavy items on top of unit and never climb, stand, or
hang on unit or storage cabinet to prevent injury and damage.
DANGER! HIGH PRESSURE CO2GAS. CO2 cylinders (tanks) contain high pressure
compressed gas. Always use caution when handling and use a proper pressure regulator.
Never expose tanks to temperature over 125 F and always secure the cylinder vertically. Follow
all local and state transportation and safety standards. Always ensure proper ventilation.
CAUTION! INDOOR USE ONLY. Do not install outdoors or where unit is in direct sunlight.
Do not install where ambient temperature goes below 50F or above 97F. Avoid high humidity
and moisture. Product life and performance will be impacted and warranty could be voided.

Revision 1.1 Page 7
WATERLOGIC MANUFACTURED WATER TREATMENT SYSTEM LIMITED WARRANTY
UNITED STATES AND CANADA ONLY
Waterlogic water treatment systems are guaranteed to the original purchaser to be free of defects
in materials and workmanship for a period of three (3) years from the date of purchase, but in no
event longer than forty-eight (48) months from the date of manufacture. Waterlogic Commercial
Products, LLC (“Waterlogic”) based in the U.S.A. and its affiliated companies are not liable for any
cost of removal, installation, transportation, or any other charges which may arise in connection
with a warranty claim.
This warranty does not cover damage or wear to products caused by abnormal operating
conditions, accident, abuse, misuse, unauthorized or improper alteration or repair, damage caused
by or resulting from shipping or accident, damage caused by hot water, freezing, flood, fire, or acts
of God. The effects from chlorine corrosion, scaling and normal wear are specifically excluded from
this warranty. This warranty does not cover products used outside the country where the unit was
purchased, and does not cover products that were not installed in accordance with Waterlogic
printed installation and operating instructions obtained in training or from www.waterlogic.us.
Failure to follow all instructions for operation and maintenance voids the warranty. This warranty is
not transferable.
To obtain warranty repairs or replacement, you must obtain a Return Authorization from
Waterlogic. To obtain a Return Authorization, you must submit a Return Authorization form with
supporting documentation to Waterlogic for evaluation. The form is available at
www.waterlogic.us. Supporting documentation must include, but is not limited to; proof of
purchase, installation date, failure date, and supporting installation and maintenance data. After
you submit a Return Authorization form and supporting documentation, Waterlogic will determine
whether a reasonably apparent defect in materials or workmanship covered by this limited
warranty exists. If Waterlogic determines the claimed defect is covered by this warranty, Waterlogic
will, at its sole discretion, determine whether to correct the defect or replace the unit, free of
charge to you. If Waterlogic determines that the unit should be returned for warranty service,
Waterlogic will approve of return in writing and will issue a Return Authorization which you must
obtain prior to shipping the product. You are responsible for the cost of freight in to Waterlogic.
Waterlogic and its affiliated companies hereby limit the duration of any and all implied warranties
to a maximum period of three (3) years from the date of purchase including, but not limited to, the
implied warranties of merchantability and fitness for a particular purpose. Some states do not allow
limitations on how long an implied warranty lasts, so the above limitation may not apply to you.
Consequential and incidental damages are not recoverable under this warranty. Some states do not
allow the exclusion or limitation of incidental or consequential damages, so the above limitation or
exclusion may not apply to you.
This warranty gives you specific legal rights and you may also have other rights which may vary
from state to state.
Waterlogic Commercial Products, LLC Tel: [phone]
11710 Stonegate Circle
Omaha, NE 68164 Website: www.waterlogic.us

Revision 1.1 Page 8
MODEL/PART DESIGNATIONS
MODEL/PART NUMBER
DESCRIPTION
INN #
WL500
Waterlogic WL500 - Cold, Sparkling, Hot, Extra Hot
10-VMHCS3
F-6004-M-HCS-DT-CS-INN
AK-0005
Optional Base Cabinet for Waterlogic WL500
10-7000
AK-0007
Optional Cup Dispenser for Base Cabinet
10-7001
SPECIFICATIONS
ITEM
WL500 (w/o BASE CABINET)
WL500 (with BASE CABINET)
Width/Depth/Height #
17 in. x 18 in. x 18.5 in.#
17 in. x 18 in. x 49.25 in.
Weight –Dry (w/o packaging)
65 lb. (29.5 kg)
100 lb. (45.4 kg)
Cold Water Temperature
37- 54F (3- 12C )
Programmable
Same
Hot Water Temperature
158- 203F (70- 95C)
Programmable
Same
Water & CO2 Connection
1/4 in. tubing
Same
Recommended Service Pressure
40-60 psi (275-414 kPa)
Same
Max. Working Pressure
60 psi (414 kPa)
Same
CO2 Supply Requirement
(400 Glasses/ 1lb CO2)^
Food Grade CO2
Regulated to 35-45 psi
Same
Environment / Temperature
Indoor 50-95F (10-35C)
Same
Shipping Information
(length x width x height)
20 in. x 22 in. x 22 in.
8 units per pallet
AK-0005 33 in. x 18 in. x 10 in.
AK-0007 32 in. x 12 in. x 7 in.
Shipping Weight –Dry
70 lb. (32 kg)
AK-0005 35 lb. / AK-0007 9 lb.
Rated Service Flow†
Rated Capacity/Service Life
0.5 gpm (1.89 lpm)
2,000 Gallons, or 6-months
Same
NSF/ANSI Standard 53*
Installed in 1st Filter Head
Cyst Reduction –1 micron
Same
NSF/ANSI Standard 42*
Installed in 2nd Filter Head
Aesthetic Chlorine Reduction
Taste/Odor Reduction –10 micron
Same
Refrigerant
R134a –2.29 oz. (65 grams)
Hi (280 psi) Low (90 psi)
Same
ELECTRICAL SPECIFICATIONS
ELECTRICAL SUPPLY
120V/60Hz
15 Amp Service+
COMPONENT
POWER (approximate)
AMP DRAW (approximate)
Heater
500 Watts
4.2 Amps
Compressor
210 Watts
1.8 Amps
Fan Motor
18 Watts
0.15 Amps
UV Lamp System
18 Watts
0.15 Amps
Pump
26 Watts
0.22 Amps
WL500 TOTAL
776 Watts
6.47 Amps
†Limited to 0.5 gallons per minute (gpm) by the filter head installed on the carbon block filter.
*See Performance Data Sheet for NSF/ANSI 42, 53 Specifications
#WL500 is 18.5 in. tall and may not fit between countertops and cabinets - Check installation to ensure adequate clearance.
^400 12oz Cups of Premium Sparkling Water per pound of CO2 under normal conditions. +G F I recommended - See Installation Instructions.

Revision 1.1 Page 9
WL500 LAYOUT DRAWING with PART NUMBERS
No
Part No
Description
Remark
1
PL-1095
Top Cover Gray
10-7073
2
PL-1092
Front Hatch Panel Gray (BIOCOTE LOGO)
10-7070
3
PL-1102
LCD Lenses Insert Label Black (4 button holes)
10-7077
4
PL-1098
Dispense Silicon 4 Button Key Mat C&S&H&EX
10-7225
5
PL-1093
Front Panel for Drip Tray Insert Silver
10-7071
6
PL-1152
Drip Tray Grill –BICOTE
12-8150
7
PL-1127A
Drip Tray Body Only –BIOCOTE WL LOGO same as PL-1222
10-7074
8
PL-1094
Side Panel Silver Plastic LH/RH
10-7072
9
ST-8094-A
Back Metal Panel
10-7051
10
EL-5005
Switch - Heater/Compressor (Green) I=ON O=OFF
10-3009
11
EL-5004
Switch - Power (Red) I=ON O=OFF
10-3008
12
PU-4028
CO2 Inlet Bulkhead Connector 1/4"(JG#PI1208S)
10-3067
13
EL-5012
Fuse Holder & Fuse 120V/15A
10-3014
14
EL-5016
Socket with EMI Filter 120V/60Hz
10-4013
15
CT-2039-A
Drain with Cap - Cold Drain - Hot Drain
CT-2039-A
16
CT-2031-A
Drain –5/16” Cap –Pre Chill/Pump Drain
14-5011
17
ST-8016
Unit Adjustable Rubber Feet
10-3083
18
PU-4028
Water Inlet Bulkhead Connector 1/4" (JG#PI1208S)
10-3067

Revision 1.1 Page 10
OPERATING INSTRUCTIONS
The above picture shows front LCD display and control panel for the Waterlogic WL500 .
Button
Operational Use
Programming Mode
1
Select Cold Water
Scroll the Menu Down
2
Select Sparkling Water
Scroll the Menu Up
3
Select Hot Water
Enter (select) an Option
on the Menu
4
Select Extra Hot water
Escape to Main Menu/Exit
Programming Mode
Main Dispense Button
(larger -not shown above)
Dispense Selection
N/A
For Cold Water: Press Cold (Button 1) followed by the Main Dispense Button.
For Sparkling Water: Press Sparkling (Button 2) followed by the Main Dispense Button.
For Hot Water: Press Hot (Button 3) followed by the Main Dispensing Button.
For Extra Hot Water: Press Extra Hot (Button 4), wait approximately 30 seconds. Then press
Hot (Button 3) and the Main Dispensing Button. This procedure will raise
the hot water temperature approximately 2oF. Repeating the process
over again will raise the temperature about 2oF more until the desired
temperature is reached up to a maximum limit of 203oF.
NOTE: Default selection mode is Cold Water. Selection will return to default after 3 seconds of
inactivity. The default selection can be programmed to Cold or Sparkling. See Programming.

Revision 1.1 Page 11
WL500 FLOW DIAGRAM

Revision 1.1 Page 12
WL500 PRINCIPLES of OPERATION
It will take the WL500 approximately 10 minutes to heat 1.6 liters of water in the hot circuit and
45 minutes to chill the 4 liters of water in the cold circuit to set point temperatures after all
tanks have been properly filled. The WL500 has two cold tanks; a 2 liter UV Cold Tank and a 2
liter Sparkling Cold Tank which is separated by a baffle/divider plate that isolates a 1 liter
Sparkling Water Chamber from a 1 liter Pre-Chill Chamber within.
WL500 PRINCIPLES of OPERATION LAYOUT
Dispensing Cold Still Water from the WL500
The WL500 defaults to cold water selection when idle. “COLD”will appear on the display and
cold water will be dispensed when the Main Dispense Button is pressed. Selecting COLD
(Button 1) and then pressing the Main Dispense Button opens Solenoids 2 and 4, which allows
supply water to push into the Pre-Chill Chamber of the Sparkling Cold Tank. Pressurize feed
water pushes into the bottom of the pre-chill chamber and forces pre-chilled water through the
tall draw tube into the bottom of the UV Cold Tank. UV treated, cold, still water is forced out
through the tall draw tube, through Solenoid 4, out the faucet of the dispenser. When the main
dispense button is released, both Solenoid 2 and 4 will close, thus stopping cold, still water
output. The WL500 is a pressure fed unit and output is dependent on supply.
Sparkling Cold Tank
UV Cold Tank
Sparkling
Chamber
Pre-Chill
Chamber
1 Liter
UV
Chamber
2 Liter
1 Liter
Pump Drain

Revision 1.1 Page 13
Dispensing Hot Water from the WL500
To dispense hot water, select the small HOT (Button 3) and release. HOT will appear in the
display, and press the Main Dispense Button. This will open the hot input solenoid (Solenoid 1–
not shown above) and allow hot water to dispense through the faucet. The WL500 can be
programmed to default back to COLD or Sparkling after 3 seconds of inactivity as a safety
feature to prevent accidental dispensing of hot water.
Dispensing Extra Hot Water from the WL500
Typically, the WL500 hot water temperature is set to 189oF. In some cases, extra hot water is
desired for making soups and teas. To temporarily raise the hot water temperature, users can
depress and release the EXTRA HOT select button (button 4). The word HEATING will appear in
the display for 30-seconds, which will raise the hot water temperature about 2 degrees. If the
user presses the EXTRA HOT select button again after 30-seconds have expired, the word
HEATING will appear in the display, and the temperature in the hot tank will be raised another
2oF. Eventually, as the process is repeated, the hot tank temperature will reach up to 203oF,
and the extra heating will be disabled. At this point, 203oF hot water can be dispensed from
the WL500, which is a desired temperature for soups/teas. The WL500 will return to the hot
temperature set point after the extra hot water is dispensed.
Dispensing Premium Sparkling Water from the WL500
To dispense sparkling water, press and release Sparkling (Button 2). SPARKLING will appear in
the display. From this point, the user has 3-seconds to press the Main Dispensing Button for
Premium Sparkling Water. The unit will default back to COLD water after 3 seconds unless the
Default Set is changed to Sparkling. (See Programming Section)
When the Main Dispensing Button is pressed, Solenoid 5 will open, and the CO2gas supply from
the bottle will push sparkling water out of the sparkling water chamber to the faucet. The CO2
supply is what forces sparkling water out of the sparkling chamber. The sparkling water
chamber is 1 liter in size and a maximum of 1 liter of sparkling water can be dispensed to the
glass at a time. Once the sparkling tank empties of sparkling water, only CO2 gas will dispense
to the glass. At this point, the main dispensing button must be released to allow the WL500 to
make another batch of Premium Sparkling Water.
When the Main Dispensing Button is released, Solenoid 2 and 3 will open, and the Booster
Pump will start the Mizzling Process. The Booster Pump will draw cold, still water from the Cold
Tank, forcing that water through Solenoid 3 and the check valve into the spray header inside of
the sparkling chamber. The spray will enter the sparkling chamber as a fine mist that will
absorb the CO2gas that is present in the chamber. Once the sparkling tank fills with water, the
level probe mounted in the top of the sparkling tank will detect the water and signal the PCB to
shut down the booster pump, as well as close Solenoid 2 and 3. Note that the booster pump
can supply this spray up to approximately 70 psi, and if the CO2gas pressure is too high, the
booster pump will not be able to overcome the gas pressure, and will “dead-head”. If the
booster pump runs for 10 minutes without a signal from the level sensor, the PCB will shut
down the sparkling water process and signal a NO WATER SUPPLY FAULT will be displayed.

Revision 1.1 Page 14
Once the level sensor detects the tank is full of water, the PCB will shut down sparkling water
generation (Mizzling Process). The WL500 will return to the COLD default selection after 3
seconds. Cold and Hot water can be dispensed while sparkling water is being generated. The
sparkling water generation will stop as soon as sparkling water is dispensed or the chamber fills.
The WL500 will make 1 liter (34 ounces) of sparkling water in approximately 1 minute, 20
seconds. Typically, users will only dispense up to ½ liter (17 ounces) of sparkling water at a
time, and the WL500 takes about 40 seconds to regenerate sparkling water tank accordingly.
Waterlogic WL500 produces Premium Sparkling
Water which is made in a batch and contains a fine,
dense carbonation as compared to some “soda
water” products. Optimal sparkling water is
generated with cold water under 46oF.
WL500 Sparkling Level Sensor Probe requires
inspection and service. See Service Section.
WL500 Sleep Mode
The WL500 has programmable sleep mode. When
sleep mode is ON the WL500 will shut down the
heater circuit to conserve energy after the machine
is idle for 3 hours. The heater circuit will awake
once any button is depressed and it will reheat the
hot tank to set point temperature. “SLEEP MODE”
will be displayed. Always check Sleep Mode setting
if unit does not produce hot water as expected.
WL500 UV Protection
The Waterlogic WL500 contains a germicidal
ultraviolet (UV) lamp that sterilizes water in the
cold tank and requires annual replacement.
The WL500 has a UV CDS Sensor located in the Cap
of the UV Tank. UV Fault Mode Protection will
alert the user with a 20 second audible alarm and
display UV FAULT on screen when UV light is not
detected. UV Fault Mode Protection will shut off
cold/sparkling water to avoid potentially
dispensing unsafe water.

Revision 1.1 Page 15
PROGRAMING MENU
Menu
Options
Brief Description
Cold Temp
Set
3° - 12°C
The cold temperature can be set between 3°C and 12°C or 37°F and 54°F,
depending on which units are selected (°C or °F) in the F/C option.
37° - 54°F
Recommended/Default Setting is 5°C/41°F.
Hot Temp
Set
70°C - 95°C
The hot temperature can be set between 70°C and 95°C or 158°F and 203°F,
depending on which units are selected (°C or °F) in the F/C option.
158°F - 203°F
Recommended/Default Setting is 87°C/189°F.
Temp
Display
Static
The display indicates the STATIC (SET POINT) temperature. Default
Ranging
The display indicates the ACTUAL tank temperature
UV Timer
3 minutes
The UV lamp lights every time you take a drink of cold water, and stays on for 3
minutes.Recommended/Default Setting is 3 minutes
10 minutes
The UV lamp lights every time you take a drink of cold water, and stays on for 10
minutes.
Constant
The UV lamp stays on when power is on. Not Recommended
F/C
F
Temperatures are displayed in degrees Fahrenheit. Default is oF
C
Temperatures are displayed in degrees Centigrade.
Language
English
The display will read in English. Default is English
Spanish
The display will read in Spanish
French, Etc…
The display will read in French, and many others…
Flow
Counter
Liters
(4000-9000)
DO NOT USE. “NO WATER SUPPY” Fault will occur. Use Filter Timer Instead.
Gallons (1000-
3000)
DO NOT USE.“NO WATER SUPPY” Fault will occur. Use Filter Timer Instead.
Filter Timer
3 months
Timer for Filter Life set at 3 months. Displays “Change Filter” after 3 months
6 months
Timer for Filter Life set at 6 months. Displays “Change Filter” after 6 months
9 months
Timer for Filter Life set at 9 months. Displays “Change Filter” after 9 months
None
Timer for Filter Life is turned off. Default is None
Filter Life
00 DAYS
Indicates amount of water flowed(gal/liters) or days elapsed since last reset
Ensure Filter Timer is enabled and Filter Life indicates DAYS
Sleep Mode
On
Shuts heater down (hot water) if not used in 3 hours. –Default Sleep is ON
Off
Hot water remains powered indefinitely.
Default Set
Cold
Defaults Display & Dispense Selection to Cold after 3 seconds. Default is Cold
Sparkling
Defaults Display & Dispense Selection to Sparkling after 3 seconds.
Reset
OK?
Resets the Filter Life to zero. Confirm by selecting Button 3 (Hot) to Save and
Exit. This resets the timer.

Revision 1.1 Page 16
PROGRAMMING INSTRUCTIONS
Access the programming menu by depressing Buttons No. 1 and No. 2 simultaneously for three
seconds until the Password Message appears on the display: Password * * * *
PASSWORD IS: 1 1 1 1
Press Button No. 1 until the number 1 is displayed
Press Button No. 2 to move to next field
Press Button No. 1 until the number 1 is displayed
Press Button No. 2 to move to next field and continue…until all 4 fields display 1 1 1 1
Press Button No. 3 to enter the password and access the programming mode.
Note: Unit will exit programming mode if no buttons are pressed within 5 seconds and return
to display mode.
Programming Example: Change Language
1. Press Buttons No. 1 and No. 2 for three seconds until “Password ****” appears
on the display. Enter 1 1 1 1 Password as shown above.
2. Press Button No. 2 repeatedly to scroll through the menu until the option
“Language” appears on the display.
3. Press Button No. 3 to select the Language option.
4. Press Button No. 2 repeatedly to scroll down through the languages until Spanish
is displayed).
5. Press Button No. 3 to select “Spanish.” This saves the selection.
6. Press Button No. 4 to exit programming mode.
Programming Example: Change Language and Lower Cold Temp
1. Press Buttons No. 1 and No. 2 for three seconds until “Password ****” appears on
the display. Enter 1 1 1 1 Password as shown above.
2. Press Button No. 2 repeatedly until the menu scrolls to the option “Language” on
the display.
3. Press Button No. 3 to select the Language option.
4. Press Button No. 1 repeatedly to scroll up through the language. (Spanish, French,
English, and others).
5. Press Button No. 3 to select “English.”
6. Press Button No. 1 repeatedly until the menu scrolls up to the option “Cold Temp
Set” on the display.
7. Press Button No. 3 to select the “Cold Temp Set” option.
8. Press Button No. 1 repeatedly until “39F” is displayed.
9. Press Button No. 3 to select “39F.”
10. Press Button No. 4 to exit Programming mode.

Revision 1.1 Page 17
WL500 QUICK START GUIDE
Critical Requirements
Establish Food Grade CO2Supply and regulate to 35-45 psi.This will produce optimum
sparkling water and CO2 concentration when combined with 46 F degree or cooler water.
Regulate the Water Supply to 40–60 psi.ALWAYS use a pressure regulator.
1) Prior to setting the WL500 machine, open the knock-out on the back panel of the base
cabinet to allow running the CO2 pipe from the base cabinet to the WL500 machine.
2) Unpack the WL500 and set on top of base cabinet so that the side panels of the machine
align with the side panels of the base cabinet.
3) Secure the WL500 to the base cabinet using the bolt provided in
the base cabinet. Note that the connection point is accessed
from the underside of the base cabinet. The bolt threads into
the WL500 base plate and locks the unit together.
4) Install a regulator onto a 5lb or 10lb food grade CO2bottle and
purge some gas from the bottle. Regulate output to 35-45 psi.
Close the regulator outlet valve, and secure in the base cabinet.
5) Route a ¼-inch pipe from the outlet fitting of the CO2 regulator through the knock-out up to
the CO2IN bulkhead fitting on the back of the WL500.
6) Slowly open and supply CO2 to the WL500 prior to establishing water supply and power.
7) Remove the filters and flush (5-gallons recommended). Reinstall filters. Note that the filters
are a reverse-thread. Ensure proper filtration for local water conditions.
8) Establish 40–60 psi 0.5 gal/min or greater potable water supply. Leak Protection is
recommended.
9) Supply power to the WL500, and turn on the RED power switch (GREEN power switch MUST
remain OFF until the WL500 tanks are filled or hot tank overload will trip).
10) Fill the hot, cold, and sparkling tanks by dispensing until water flows from each. The
sparkling tank will self-fill after the cold tank is filled. Once tanks are full, turn on the green
power switch to allow the heating and chilling systems to function.
11) Regenerate the sparkling tank by dispensing the initial batch of 1 liter from the chamber.
Remember that the water in the cold tank needs to be cold (below 46 F) to make premium
tasting sparkling water.

Revision 1.1 Page 18
PRE-INSTALLATION PROCEDURES
DANGER! ELECTRICAL SHOCK HAZARD.
Only qualified personnel who have read and understand this entire manual should attempt to
install, or service this unit, failure to do so could result in death or serious injury. DO NOT plug
into an electrical supply until specifically instructed.
WARNING! ALWAYS SANITIZE BEFORE USE.
Sanitize before use to eliminate any potential microbiological contaminates.
Materials Needed:
Personal Protective Equipment. Rubber or Nitrile Safety Gloves and Protective Eyewear
Phillips Screwdriver. Temperature Gauge.
Water Pitcher or Container to collect water from the faucet
5 gallon container or drain basin
Sanitizer - Household Bleach (5.25% Sodium Hypochlorite) or Citric Acid Based Cleaner
¼” Plastic Tubing, at least 4 feet in length, and assorted ¼” quick connect fittings.
TDS Meter and Test Strips for measuring chlorine. - Optional
1/8 NPT Female Thread to ¼” Compression Fitting (Used to connect hose to drain fittings)
Beverage Head to flush Waterlogic Filters (Q Series –LH thread). - Optional
1. Unpack the Waterlogic WL500 and check exterior for damage.
WARNING! WL500 IS HEAVY.
Use proper lifting aids and handling techniques to avoid injury. Use assistance as single
person lift could cause injury. Always drain before handling and transporting and handling
to reduce the weight of the unit.
2. Remove the Retaining Screw that is located directly in
front of the faucet nipple. Refer to Figure 1. Removing
this screw will allow access to the inside serviceable
components (filters and UV lamp).
3. Open the front hatch cover by lifting up and hinging
outward. Front hatch cover can be removed by carefully
squeezing panel base and pulling over hinge pins.
Flush Filters
CAUTION! FILTER FLUSH REQUIRED.
WL500 contains 2 Carbon Filters that must be flushed or removed before use to avoid
contaminating WL500 with carbon fines. Never rinse filters through solenoids or tanks.
4. Remove the 2 filters that are inside the front hatch cover. Remember that these filters are
reverse-threaded into beverage heads, and you must turn them clockwise to remove.
5. Utilizing extra beverage head, rinse the carbon filters. Alternatively, filters can be flushed in
unit by removing the right side panel to access the beverage head outlet hose and flush to
drain using an extra piece of ¼ line.

Revision 1.1 Page 19
6. Flush thoroughly (at least 5 gallons) with fresh water to clear carbon fines. Test outlet water
with TDS (Total Dissolved Solids) Meter to determine exact flushing volume required.
7. Once rinsed, reinstall the filters. The PU-4029 (CBC) filter should be installed in the filter
port that is on the left side of the faucet and the PU-4076 (GAC) should be installed in the
filter port on the right side of the faucet (as you face the front of the machine).
Internal Filter Bypass Instructions
The WL500 has a CBC Filter and GAC Filter installed behind the front access panel. These filters
are reverse thread and the first filter head has an internal shut-off valve that requires a filter to
be engaged to allow water to pass through it. Alternative filtration may be required to best
meet your local water and business needs. The WL500 internal filter heads can be bypassed
internally by removing side panels and running a new ¼” JG tube from the inlet bulkhead to the
inlet solenoid tee. Always check for leaks after installing and ensure the tubing is routed away
any moving or hot parts to avoid potential damage.
Sanitizing
Sanitize using a household bleach solution or other approved cleaner throughout the cold and
sparkling water circuits. Follow all instructions on the sanitizer and flush with fresh water
through the faucet until odor and taste is acceptable.
WARNING! USE PROPER PERSONAL PROTECTIVE EQUIPMENT
Always ensure proper ventilation and use proper personal protective equipment such as gloves
and eye protection when using chemicals. Refer to Material Safety Data Sheet for specific
requirements of each chemical product. Take all necessary precautions to prevent sanitizer from
contacting eyes, clothing, and any other surfaces in could damage (carpets).
8. Remove the UV Cover Plate and set aside –2 Screws.
9. Disconnect the UV Lamp harness and carefully remove the UV Lamp from the quartz sleeve.
CAUTION! UV SYSTEM IS FRAGILE. Never handle the UV System with bare hands. UV
Lamp and quartz sleeve must be free of oils and contaminants to ensure proper operation.
10. Remove UV Sensor from the side of the cold tank/quartz sleeve retaining cap.
11. Unscrew cold tank/quartz sleeve retaining cap and remove the quartz sleeve. This may
require top cover to be removed to access properly and facilitate removal.
12. Mix ½ gallon of sanitizer per directions or use Bleach Solution (1 teaspoon = 1/6 oz. = 5 ml =
½ cap full) of household bleach (Sodium Hypochlorite 5 - 10% Concentration) with 1/2
gallon of water. Always ensure sanitizer is compatible with stainless steel and acetal plastic.
13. Pour sanitizer solution into cold tank thru funnel or spout. You may add concentrated
sanitizer (½ cap bleach) directly into empty cold tank instead of premixing.
14. Inspect and clean quartz sleeve and O-ring. Reinstall the quartz sleeve and quartz sleeve
retaining nut. Tighten firmly to ensure proper seal. Over-tightening can cause damage.
15. Reinstall the UV Lamp and UV Sensor. Take care not to touch with fingers.

Revision 1.1 Page 20
16. Connect 40-60 psi regulated, potable water supply to the water inlet bulkhead fitting
located on the back of the unit. Turn on water supply and check for leaks.
17. Connect CO2gas line to WL500 bulkhead inlet fitting. Regulate to 35-45 psi. Turn on CO2.
WARNING! HIGH PRESSURE CO2GAS. Use/Handle in accordance with all safety standards.
DANGER! ELECTRICAL SHOCK HAZARD.
Do not plug in unit unless qualified. Only qualified personnel who have read and understand
this entire manual should attempt to install or service this unit.
18. Connect WL500 to power, and turn I=ON the Red Power Switch.
CAUTION! NEVER TURN ON HEATER BEFORE FILLING HOT TANK.
Green Compressor/Heater Switch must be in the O=OFF position while the hot tank is empty.
Damage could occur within one minute and the overload (high limit) will require manual
reset if heater is turned on with an empty hot tank.
Fill the Cold Circuit with Sanitizer
19. Wait 10 seconds for the unit to perform its diagnostics checks, depress the main dispensing
button on the front control panel until cold water/sanitizing solution comes out the faucet.
NOTE: Container and drain basin will be required to catch the water from the faucet.
WARNING! Use Personal Protective Equipment. Gloves and Eye Protection Required.
The first 2 or 3 gallons of water will contain concentrated sanitizer. Use extreme care!
Fill the Sparkling Chamber with Sanitizer
20. The sanitizer solution will be injected into the sparkling tank by the booster pump once unit
is turned on and the cold tank is full. Dispense 1 liter of sparkling water into container and
let sparkling chamber regenerate to ensure the sparkling tank is full of sanitizer.
CAUTION! USE SANITIZER COMPATIBLE WITH STAINLESS STEEL AND ACETAL PLASTIC.
Do not allow the sanitizer solution to remain in the system for more then 10-15 minutes
unless otherwise directed by the sanitizer manufacturer.
Flushing the Sanitizer from the Machine
21. Place a pitcher, catch basin, or other container under the faucet of the WL500.
22. Flush the Cold Tank. Run several gallons of water through the faucet by dispensing cold
water to dilute and remove the sanitizer from the cold circuit. You can use chlorine test
strips to evaluate the water. Once the sanitizer odor/taste has been flushed out of the cold
side of the machine, move to the sparkling circuit.
23. Flush the Sparkling Chamber. Dispense sparkling water until only gas comes out. Let the
sparkling tank regenerate. This should take approximately 1 minute, 20 seconds. Listen for
the booster pump to turn off. Repeat the sparkling water regeneration until the sanitizer
odor/taste has been flushed out.
24. The sanitization process for the Cold and Sparkling Circuits is now complete.
