WaterLogic P2 Classe User manual

Waterlogic Commercial Products, LLC
3175 Bass Pro Drive
Grapevine, TX 76051
[phone] www.waterlogicdealers.com
Tech Portal Website: canteen-portal.waterlogic.com
Waterlogic International, LTD – Global Headquarters Grenfell Road, Maidenhead, Berkshire, SL6 1HN, United
Kingdom
P2 Classe
MANUAL

P2 Classe Manual Page 2 – Revision: 3-2-2021
P2 CLASSE MANUAL
Congratulations on your choice of the Waterlogic P2 Classe Sparkling and Still Water
Dispenser. The P2 Classe model dispenses cold still water and cold sparkling water. Every P2
Classe includes:
Bio-Cote Anti-Microbial Protection
Firewall Advanced Purification
External Filter configuration can be optimized for all water conditions
The P2 Classe provides exceptional quality and great tasting water with every use.
INTRODUCTION
Carefully read and follow all instructions to ensure proper and efficient operation of your P2
Classe Sparkling and Still Water Dispenser. Contact your Authorized Waterlogic Dealer if you
have any questions.
Waterlogic and Authorized Waterlogic Dealers employ trained service personnel who are
experienced in the installation, function and repair of this equipment. This publication is
written for use by these qualified individuals. Waterlogic encourages users to learn about
products, however, we believe that product knowledge and service is best obtained by
consulting your Authorized Waterlogic Dealer.
The P2 Classe Sparkling and Still Water Dispenser should be combined with selected water
treatment components to create a system specifically tailored for each application by trained
and qualified personnel.
Products manufactured and marketed by Waterlogic and its affiliates are protected by patents
issued or pending in the United States and other countries.
Waterlogic reserves the right to change the specifications referred to in this literature at any
time, without prior notice. Changes or modifications not expressly approved by Waterlogic
could void the warranty and user’s authority to operate the equipment.

P2 Classe Manual Page 3 – Revision: 3-2-2021
TABLE OF CONTENTS
USER GUIDE
•Safety Alert Symbols ................................................................ 4
•Safety Precautions ................................................................... 4
•Features and Benefits .............................................................. 6
•Certifications............................................................................ 7
•Model Designations and General Specifications ..................... 8
•Electrical and Shipping Specifications...................................... 9
•Operating Instructions ........................................................... 10
•Volumetric Dispense Programming…………………………………… 11
•Warranty ............................................................................... 12
SERVICE GUIDE
•Service Requirements ............................................................ 13
•Replacement Components (Consumables) ........................... 14
•Drawings and Parts List…………………….................................... 15
•Flow Diagram ......................................................................... 30
•Electrical Schematic ............................................................... 31
INSTALLATION GUIDE
•Pre-Installation Procedures ................................................... 32
•Installation and Flushing Instructions.................................... 33
•Draining Procedure ................................................................ 36
•Adjusting the Gas Blend......................................................... 37

P2 Classe Manual Page 4 – Revision: 3-2-2021
SAFETY ALERT SYMBOLS
Read and follow all safety information carefully. The signal words used in this manual are
selected as shown below and based on an assessment of the degree of potential injury or
damage (severe or minor) and the occurrence of injury (definitely occurs or has the potential to
occur) when the warning is ignored:
DANGER!
Indicates a situation which, when not avoided, results in death or severe injury.
WARNING!
Indicates a situation which, when not avoided, has the potential to result in death or
severe injury; and/or severe property damage.
CAUTION!
Indicates a situation which, when not avoided, results or has the potential to result in
minor injury; and/or minor property damage.
SAFETY PRECAUTIONS
Basic safety precautions should be followed, including the following:
Ensure all Local, State, and Federal Laws and Codes including health and safety guidelines are
met when installing Waterlogic Equipment. Only qualified service technicians should attempt
installation and service of Waterlogic Equipment. Always read the entire operating instructions
before using the appliance and save these instructions for future use.
DANGER! This product can cause death or severe injury if incorrectly operated, installed or
maintained. The installation, maintenance, sanitizing and any repair must be performed by
qualified persons trained by Waterlogic International or their approved distributors only. Do
not remove any panel or cover to protect against electrical shock and exposure to UV
radiation.
DANGER! ELECTRICAL SHOCK HAZARD. Always use a dedicated and properly grounded
outlet. Unit should be protected by ground-fault circuit interrupter (GFCI) or residual current
device (RCD) having a rated residual operating current not exceeding 30mA. Use only
Waterlogic supplied power cord. Never use extension cords or power strips to connect unit.
Do not use if the power supply cord is damaged. Always unplug from power supply prior to
servicing.
WARNING! AUTHORIZED USE ONLY. This appliance is to be used for its intended purpose as
described in this manual. Untrained individuals who use this manual assume the risk of any
resulting property damage or personal injury. This appliance can’t be used by children and
persons with reduced physical, sensory or mental capabilities or lack of experience.
WARNING! UV-C EMITTER (UV LAMP).This appliance contains a UV-C emitter (UV Lamp).
UV-C radiation may, even in small doses, cause harm to the eyes and skin. Unintended use or
damage to the housing may result in the escape of dangerous UV-C radiation. Never operate
the UV-C emitter if damaged or removed from enclosure. Do not touch or look directly into
the faucet.

P2 Classe Manual Page 5 – Revision: 3-2-2021
WARNING! DO NOT OPERATE IF DAMAGED. Unplug and isolate water supply if abnormal
conditions exist. Contact Waterlogic or authorized dealer for repair, service, and installation
to avoid hazards.
WARNING! CONNECT TO POTABLE WATER SUPPLY. This system is to be used for water only
and is not intended for use where water is microbiologically unsafe or with water of unknown
quality without adequate disinfection before or after the system.
WARNING! TIP HAZARD. Dispenser could tip or fall causing serious injury. Always install
unit on a firm, flat, and level surface and secure unit to cabinet, wall, or floor if needed.
Never place heavy items on top of unit and never climb, stand, or hang on unit or storage
cabinet to prevent injury and damage.
WARNING! UNIT IS HEAVY. TWO PERSON LIFT REQUIRED. Transport unit empty and
always use material handling equipment or two people with proper lifting technique to
reduce injury risk.
WARNING! STORE AND TRANSPORT UNIT EMPTY. ALWAYS SANITIZE BEFORE USE.
The unit must be completely drained before storing to avoid stagnation and reduce
microbiological contamination (potential bacterial growth). Always sanitize before use to
eliminate any potential microbiological contaminates.
CAUTION! INDOOR USE ONLY. Intended for Household Use. Never expose to direct
sunlight, heat sources, or ambient air temperature above 37°C (100°F) or below 2°C (35°F).
Install indoors and keep unit away from excessive humidity. Never expose to freezing
temperatures. Ensure there is adequate clearance around the unit to allow refrigeration
system condenser to dissipate heat. Warmer environments require more clearance around
the unit. Minimum clearance around all surfaces of the machine is 2-inches. Installs where
the ambient temperature exceeds 27°C (80°F), require a minimum of 4-inches clearance for
proper heat dissipation and efficient operation.
CAUTION! USE A WATER PRESSURE REGULATOR. Waterlogic will not be responsible for
injury or damage caused by excessive water pressure. Input or feed pressure must be 40 psi
to 60 psi. Be aware of any potential pressure surges caused by building/municipal pumping
stations.
CAUTION! USE UV STABILIZED SUPPLY LINES. Feed the unit with a potable ambient or cold
water supply only. Feed water over 37°C (100°F) can damage the treatment components.
Water block devices and external leak detectors are strongly recommended. Locate the unit
as close to the water supply and the electrical connections as possible. Locate the unit as
close to the water supply and the electrical connections as possible. Immediately isolate or
close water supply valve and contact service representative if leak is noticed.
Contact Waterlogic for assistance or help finding an Authorized Service Representative.

P2 Classe Manual Page 6 – Revision: 3-2-2021
P2 CLASSE FEATURES AND BENEFITS
Sparkling and Still Cold Water
Counter Top and Cabinet Models come standard with Sparkling and Still Cold Water Selections
to meet a wide range of customer demands. Cold Water Temperature is not adjustable.
Programmable Volumetric Dispense Settings
The P2 Classe is equipped with programmable volumetric dispense settings. Using the dispense
buttons, preset volumes of water dispensed can be configured for each of the 4 dispense
buttons.
Large Dispense Area with Adjustable (and Removeable) Drip Tray
12.25” from Faucet to drip tray allow for a wide range of water containers. The Drip Tray height
can also be adjusted to accommodate for filling of standardized containers. The Drip Tray is also
removeable to easily dump any water that has overflowed or spilled during dispense.
Firewall Advanced Purification
Firewall is a proprietary technology that places the UV lamp at the point of dispense. This point
of dispense purification keeps the dispense nozzle free from external contamination as well as
purifying the water, making the freshest water possible.
Ice Bath Drain Port
The P2 Classe is equipped with a drain port to the ice bath. This makes for easier maintenance
as well to ease transport if needed.
Energy Saver
The P2 Classe comes from the factory with Energy Saver active. For the Classe to comply with
Energy Star, the energy saver must come activated (ON) from the factory. When no buttons are
pressed on the front user interface panel, the machine will automatically enter energy saver
mode after 3 hours of inactivity, and the compressor cycle will be set to a 20 hour cycle. When
any one of the front buttons are pressed while the system is in energy saver mode, the Classe
will exit energy saver mode, and the compressor will enter its normal operation mode. Energy
saver can be disabled/enabled by using the small black button on the back of the machine
labeled “sleep mode”. While sleep mode is inactive, the 4th LED (crescent moon) will NOT be lit.
When it has entered energy saving mode, the 4th LED (crescent moon) will be lit.

P2 Classe Manual Page 7 – Revision: 3-2-2021
CERTIFICATIONS
P2 Classeshave been tested and certified to rigorous NSF and UL Standards. We believe that
performance testing and certifications validate Waterlogic as a world-leader in water
treatment systems.
Waterlogic P2 Classe Certifications Include
UL399 – Certified Drinking Water Cooler
Intertek Labs (ETL) Certified the P2 Classe to ANSI/UL 399 Standard for Drinking
Water Coolers.
CSA C22.2 No. 120 CSA Standard for Refrigeration
BPA Free - Waterlogic tests for BPA and declares that all of its products are
Bisphenol-A FREE and contain no harmful BPA plastics.
NSF/ANSI-55 Class A – Ultraviolet Microbiological Water Treatment System
NSF / ANSI 372 – Drinking Water System Components – Lead Content
This Firewall System conforms to NSF/ANSI-55 Class A – Certified Drinking Water
System Components, NSF / ANSI 372 – Drinking Water System Components for
low Lead Content.
Waterlogic is certified to ISO 9001:2015 – Quality Management Systems (certified
by Intertek). ISO 9001 is the internationally accepted standard for well managed
organizations that have adopted the key quality management principles to its
operations to bring consistent quality products and a culture of continuous
improvement.
Safe Drinking Water Act
Waterlogic Water Treatment Systems conform to the Safe Drinking Water Act (SWDA) “lead-
free” amendment effective January 4, 2014.

P2 Classe Manual Page 8 – Revision: 3-2-2021
MODEL/PART DESIGNATIONS
BRAND NAME DESCRIPTION
MODEL -
PART NUMBER
P2 Classe
P2 Classe
–
Cold, Cold Sparkling
CLASSE P2F-P2FX-M-CS-IB-SB-WLU
Serial Number: TP2C425SBXXX
SPECIFICATIONS
ITEM P2 CLASSE
Water Connection 1/4” Quick Connect
Cold Water Temperature Cold Water Temperature – Factory Set Point 5°C (41°F)
Sparkling Tank Capacity 1 Liter
Ice Bath Capacity 21 Liters
Recommended Service
Pressure
43-60 psi (275-414 kPa) – Use Pressure Regulator
Recommended CO
2
Service
Pressure
50-60 psi (345-414 kPa) – Use Pressure Regulator
Rated Service Flow - Cold 2.0-3.0 Liters per Minute (0.5-0.8 Gallons per minute)
Rated Service Flow -
Sparkling
2.5-3.5 Liters per Minute (0.6-0.9 Gallons per minute)
Environmental Temperature 16° - 32°C (60° - 90°F)
UV Lamp (per Firewall) 15 W
Refrigerant Gas R134a, 110g, 3.88 ounces
R134a Pressures High (230 psi), Low (90 psi)

P2 Classe Manual Page 9 – Revision: 3-2-2021
15.75”
23.25”
22.6”
SHIPPING SPECIFICATIONS
ITEM
WHL2 Classe
Width/Depth/Height 401mm(W) x 590mm(D) x 550mm(H)
15.79” x 23.25” x 21.65”
Width/Depth/Height w/ Wheels 401mm(W) x 590mm(D) x 607mm(H)
15.79” x 23.25” x 23.9”
Weight (dry) 48 kg (106 pounds)
ELECTRICAL SPECIFICATIONS
ELECTRICAL SUPPLY 120V/60Hz 15 Amp Service
COMPONENT
POWER (approximate)
AMP DRAW (approximate)
Pump 267w 2A
Fan
45w
0.5A
Mixing Motor 25w 0.3A
Control Power
30w
0.2A
Compressor 220w 2A
UV Lamp System 15w 0.6A
P2 Classe TOTAL 617w 5.6A

P2 Classe Manual Page 10 – Revision: 3-2-2021
OPERATING INSTRUCTIONS
The P2 Classe utilizes a very simple user interface. 4 main buttons across the front user panel.
The first two buttons (red/yellow) can be used to dispense cold Sparkling water and the last
two (green/blue) are used to dispense cold Still water. Each of the buttons are programmed to
dispense a preset volume of water and can be reprogrammed if desired.
•One quick push: Initiates dispensing of the preset volume of water. Will automatically
shut off once preset volume is dispensed
•Push and hold: Initiates continuous dispensing of water until the button is released.
•Factory presets for the small and large dispense buttons are 750ml and 1000ml
respectively.
The diagram below details the meaning and operational conditions of the LED panel located on
the right side of the face of the machine.
(Flashes during initial fill.)

P2 Classe Manual Page 11 – Revision: 3-2-2021
VOLUMETRIC DISPENSE PROGRAMMING
The P2 Firewall incorporates volumetric dispensing control. This allows a specific auto-
dispensed volume of water to be preset for any of the 4 dispense buttons. The below steps
explain how to program dispense of both cold and sparkling options. IMPORTANT: Water must
be dispensed to calibrate the preset, so have a container ready in the dispense area to catch
this dispensed water.
•Pre-set Sparkling or Still water volume: Press both dispense buttons simultaneously
of either the sparkling or still buttons together for 5 seconds.
•Once programming mode is initiated, both sparkling button LED backlights will be
flashing.
•With a container in the dispense ready to contain the water dispensed, give a short
press and release of the dispense button you wish to preset. Water will begin to be
dispensed.
•Once the desired amount of water has been dispensed, give the same button
another short press and release to end dispensing.
•That button has now been preset to that specific volume of water.
•The two buttons for sparkling should still be flashing. At this time, the other button
can now be preset for a different volume of water if desired using the same method,
or the programming mode can be exited.
•To exit the setting mode, press both dispense buttons simultaneously for either
sparkling or still water again for 5 seconds and the LEDs will return to solid light.
(Maximum dispensing is 3liters.)
NOTE: Factory presets for the small and large dispense buttons are 750ml and 1000ml
respectively.
OR

P2 Classe Manual Page 12 – Revision: 3-2-2021
WATERLOGIC MANUFACTURED WATER TREATMENT SYSTEM LIMITED WARRANTY
UNITED STATES AND CANADA ONLY
Waterlogic water treatment systems are guaranteed to the original purchaser to be free of defects
in materials and workmanship for a period of three (3) years from the date of purchase, but in no
event longer than forty-eight (48) months from the date of manufacture. Waterlogic Commercial
Products, LLC (“Waterlogic”) based in the U.S.A. and its affiliated companies are not liable for any
cost of removal, installation, transportation, or any other charges which may arise in connection
with a warranty claim.
This warranty does not cover damage or wear to products caused by abnormal operating conditions,
accident, abuse, misuse, unauthorized or improper alteration or repair, damage caused by or
resulting from shipping or accident, damage caused by hot water, freezing, flood, fire, or acts of
God. The effects from chlorine corrosion, scaling and normal wear are specifically excluded from this
warranty. This warranty does not cover products used outside the countries where the unit was
purchased and does not cover products that were not installed in accordance with Waterlogic
printed installation and operating instructions obtained in training or from www.waterlogic.us.
Failure to follow all instructions for operation and maintenance voids the warranty. This warranty is
not transferable.
To obtain warranty repairs or replacement, you must obtain a Return Authorization from
Waterlogic. To obtain a Return Authorization, you must submit a Return Authorization form with
supporting documentation to Waterlogic for evaluation. The form is available at
www.waterlogic.us. Supporting documentation must include, but is not limited to; proof of
purchase, installation date, failure date, and supporting installation and maintenance data. After
you submit a Return Authorization form and supporting documentation, Waterlogic will determine
whether a reasonably apparent defect in materials or workmanship covered by this limited warranty
exists. If Waterlogic determines the claimed defect is covered by this warranty, Waterlogic will, at its
sole discretion, determine whether to correct the defect or replace the unit, free of charge to you. If
Waterlogic determines that the unit should be returned for warranty service, Waterlogic will
approve of return in writing and will issue a Return Authorization which you must obtain prior to
shipping the product. You are responsible for the cost of freight in to Waterlogic.
Waterlogic and its affiliated companies hereby limit the duration of any and all implied warranties
to a maximum period of three (3) years from the date of purchase including, but not limited to, the
implied warranties of merchantability and fitness for a particular purpose. Some states do not allow
limitations on how long an implied warranty lasts, so the above limitation may not apply to you.
Consequential and incidental damages are not recoverable under this warranty. Some states do not
allow the exclusion or limitation of incidental or consequential damages, so the above limitation or
exclusion may not apply to you.
This warranty gives you specific legal rights and you may also have other rights which may vary
from state to state.
New Warranty Policy issued by Waterlogic Commercial Products LLC, USA - January 10, 2014
Waterlogic Commercials Products LLC Tel: [phone]
3175 Bass Pro Drive Website: waterlogic.us
Grapevine, TX 76051

P2 Classe Manual Page 13 – Revision: 3-2-2021
SERVICE REQUIREMENTS
WARNING! Read and understand the contents of this manual before attempting to
service the P2 Classe. Failure to follow the instructions in this manual could result in
death, serious personal injury, or severe property damage. Only trained and qualified
technicians should attempt to install, maintain, or service Waterlogic Equipment.
1. Visually inspect all electrical and water connections for signs of wear or damage.
DANGER! HIGH VOLTAGE ELECTRICAL HAZARD. Unplug before inspection and service.
2. Waterlogic recommends changing the UV Lamp every 12 months.
NOTE: When replacing the UV Lamp Assembly, the UV Lamp
wiring harness must also be replaced.
WARNING! ULTRAVIOLET RADIATION. Protect your skin and eyes against ultraviolet
rays. Never look directly at an operating UV light. Disconnect before removing UV Lamp.
CAUTION! UV LAMPS ARE HAZARDOUS. Lamps are considered Hazardous Waste and
must be disposed of accordingly. Refer to Product MSDS sheet for details.
CAUTION! UV SYSTEM IS FRAGILE. Never handle the UV lamp or Quartz Sleeve with
bare hands. UV Lamp and quartz sleeve must be free of oils and contaminants to ensure
proper operation. Use a soft non-abrasive cloth to clean.
3. Ensure there is adequate (minimum of 2”) clearance around the P2 Classe and clean the
condenser fins and compressor fan to provide efficient cooling system operation.
4. Sanitize the cold tank per instructions in the pre-installation procedures.
WARNING! SANITIZER MAY CONTAIN HAZARDOUS CHEMICALS. Use of proper personal
protective equipment such as rubber gloves and eye protection is required.
5. Clean and sanitize external surfaces of the P2 Classe. Use soap and water or chemicals that
are compatible with ABS plastic and will not damage or degrade the product surfaces.
UV Lamp Assembly Part #:
15-Watt Bulb 12-8310 (CT-2085)
UV Lamp Connectors

P2 Classe Manual Page 14 – Revision: 3-2-2021
REPLACEMENT COMPONENTS (CONSUMABLES)
Component
WLCP Part
No.
Frequency of Replacement
UV Bulb, 15 Watts Assembly 12-2350 Every 12 months, or as required CT-2030-I00-
00
CAUTION! Use only Waterlogic Replacement parts that can be obtained from Waterlogic
or an Authorized Waterlogic Dealer, failure to do so will void the Warranty.
See Installation and Service Manual for additional information.
Surface Cleaning
Clean on a regular basis with damp lint free cloth. Never use harsh chemicals (alcohol or acid
based) or abrasive agents on any part of the product to avoid damage. A mild cleaner such as
Simple Green or equivalent is recommended.
DISPOSAL
End of Life
At the end of this product’s life, ensure that it is disposed of in an environmentally friendly
manner which is fully compliant with all Federal/State/Local Requirements and Guidelines.
Do not dispose of this appliance with normal household or business waste.

P2 Classe Manual Page 15 – Revision: 3-2-2021
P2 CLASSE DRAWING AND PARTS LIST
Wetted Drawing

P2 Classe Manual Page 16 – Revision: 3-2-2021
No WLCP Part No. Description Picture
1 ST-0240-L00-00 Classe Top Cover
2 EN-0098-L00-00 Metal Push Button
3 ST-0239-L00-00 Classe Aluminum UI Panel with Purezza Logo
4 ST-0241-L00-00 Classe UI Case
5 EL-0174-L00-00 Micro Switch w/ Lever
6 ST-0272-L00-00 Classe Micro Switch Cover
7 ST-0267-L00-00 Classe UI Hinge Stopper
8 PU-0027-L00-00 ODL Compensator
9 PL-0243-L00-00 Classe Front Panel
10 EN-0008-LA1-00 13W/15W 120V/60Hz Electronic FX Ballast
11 N/A HoReCa Firewall
12 ST-0238-L00-00 Classe Front Panel
13 ST-0260-L00-00 Classe LED PCB Bracket

P2 Classe Manual Page 17 – Revision: 3-2-2021
14 EN-0093-L00-00 Classe LED PCB Indicator
15 PL-0267-L00-00 Classe LED PCB Shading Plate
16 EN-0097-L00-00 Classe Back Light
17 ST-0237-L00-00 Classe Back Panel
18 PL-1293 Rubber O-ring for GF Side Panel Drain Hole
19 ST-0326-L00-00 Classe Back Hole Cover
20 ST-0246-L00-00 Classe Electric Cover
21
EL-0206-L00-00 Classe Reset Filter Timer/Sleep Wire
22
23 EL-5004 Switch - Power (Red)
24 EL-0021-L00-00 WL Cube Fuse 120V 15A with wire
25 EL-5029 Socket for Plug Connection
26 PU-4028 JG Bulkhead Connector Union 1/4" x 1/4"
27 ST-0333-L00-00 Classe Back Electric Fixing Panel (USA)

P2 Classe Manual Page 18 – Revision: 3-2-2021
28 ST-0304-L00-00 Classe Louvered Side Window with SUS304-Right
29 CS-0073-I00-00 Classe Air Filter
30 ST-0235-L00-00 Classe Side Panel - Right - Purezza logo
31 ST-0285-L00-00 Classe Side Panel Lock Knob – Right
32 ST-0283-L00-00 Classe Rail Bracket Sample Short – Right
33 ST-0281-L00-00 Classe Rail Bracket Sample Long
34 ST-0280-L00-00 Classe Drip Tray Body Rail
35 ST-0244-L00-00 Classe Ice Bath Bracket
36
CO-0035-L00-00 Classe Micro Channel Condenser
ST-0302-L00-00 Classe Micro Channel Condenser Metal Case
37 EN-0091-L00-00 Fan Motor and Blade 120V- M4Q045 -172/34
38 EN-0092-L00-00 Classe Main Control PCB
39 ST-0251-L00-00 Classe PCB Case

P2 Classe Manual Page 19 – Revision: 3-2-2021
40 ST-0259-L00-00 Classe Adaptor Bracket
41 EL-0126-L00-00 GF MAX Adaptor
42 CS-0089-L00-00 Lockable Wheel
43 ST-0250-L00-00 Classe Fan Bracket 2
44 ST-0249-L00-00 Classe Fan Bracket 1
45 ST-0236-L00-00 Classe Base Plate
46 ST-0262-L00-00 Classe Pump Bracket
47 EN-0095-L00-00 Brass Vane Pump P201 and Pump Motor 120VAC
48 PU-0024-I00-00 JG Straight Adaptor 8mm x 3/8” BSP
49 PU-4089KR Equal Elbow 5/16" x 5/16"
50 CS-0093-L00-00 Classe Bottom Air Filter
51 CO-0042-L00-00 LG Compressor 120V -CMA062LHCM
52 ST-0248-L00-00 Classe Back Bracket – Right

P2 Classe Manual Page 20 – Revision: 3-2-2021
53 PU-4086 JG 1/4" Plug
54 PU-4028 JG Bulkhead Connector Union 1/4" x 1/4"
55 CO-9025 Domestic Filter Dryer (WL3000, WL950)
15.88*6.35*2.1(10g)
56 ST-0247-L00-00 Classe Back Bracket – Left
57 PU-0028-I00-00 Sparkling Safety Valve Kit
58 CT-0040-I00-00 Classe Sparkling Tank
59 CT-0028-L00-00 WL7 Ice Thickness Detection Probe
60 PL-0245-L00-00 Classe Bracket for Ice Probe
61 ST-0252-L00-00 Classe Ice Probe Bracket
62 PL-0257-L00-00 Classe Bracket for Ice Probe Down
63 ST-0255-L00-00 Classe Ice Bath Top Bracket
64 PL-0244-L00-00 Classe Separating Plate for Cooling/Water Pipe
65 ST-0268-L00-00 Classe water Float Bracket
