WaterLogic WL100 User manual

WL100
USER GUIDE
Waterlogic Trading LTD,
WLI Trading Limited, Second Floor, Suite 4, Beacon Court, Sandyford, Co. Dublin, Ireland
Tel: + 353 (0) 1293 1960
Fax: + 353 (0) 1293 1052
For Technical Support Email: [email protected]
WLI (UK) LTD –Global Headquarters Grenfell Road, Maidenhead, Berkshire, SL6 1HN, United Kingdom

WL100 User Guide
Page 2 - Revision:EU-2020-10-13
WL100 OPERATING, INSTALLATION, AND SERVICE MANUAL
Congratulations on your choice of the Waterlogic WL100 Water Treatment System. The WL100
Water Treatment System dispenses cold, and hot. Every WL100 Water Treatment System includes:
Bio-Cote Anti-Microbial Protection
Filter configuration can be optimized for all waterconditions
The Waterlogic WL100 Water Treatment System provides exceptional quality and great tasting
water with every use.
INTRODUCTION
Carefully read and follow all instructions to ensure proper and efficient operation of your WL100
Water Treatment System. Contact Waterlogic or an Authorized Waterlogic Dealer if you have any
questions.
Waterlogic and Authorized Waterlogic Dealers employ trained service personnel who are
experienced in the installation, function and repair of Waterlogic equipment. This publication is
written for use by these qualified individuals. Waterlogic encourages users to learn about products,
however, we believe that product knowledge and service is best obtained by consulting Waterlogic
or an Authorized Waterlogic Dealer.
Waterlogic water treatment systems should be combined with selected water treatment
components to create a system specifically tailored for each application by trained and qualified
personnel.
Products manufactured and marketed by Waterlogic and its affiliates are protected by patents
issued or pending in the United States and other countries.
Waterlogic reserves the right to change the specifications referred to in this literature at any time,
without prior notice. Changes or modifications not expressly approved by Waterlogic could void the
warranty and user’s authority to operate the equipment.
Waterlogic technical manuals cover voltages of both 120v and 220v for all our markets. Please
ensure that you carefully read the information in this manual and for any parts specific to any
market, refer to your technical agreement or specific part listing.

WL100 User Guide
Page 3 - Revision:EU-2020-10-13
TABLE OF CONTENTS
USER GUIDE
•Safety Alert Symbols ................................................................ 4
•Safety Precautions ...................................................................4
•Features and Benefits ..............................................................6
•Certifications............................................................................7
•Model Designations and General Specifications ..................... 8
•Electrical and Shipping Specifications......................................9
•Operating Instructions...........................................................10

WL100 User Guide
Page 4 - Revision:EU-2020-10-13
SAFETY ALERT SYMBOLS
Read and follow all safety information carefully. The signal words used in this manual are selected as
shown below and based on an assessment of the degree of potential injury or damage (severe or
minor) and the occurrence of injury (definitely occurs or has the potential to occur) when the
warning is ignored:
DANGER!
Indicates a situation which, when not avoided, results in death or severe injury.
WARNING!
Indicates a situation which, when not avoided, has the potential to result in death or severe
injury; and/or severe property damage.
CAUTION!
Indicates a situation which, when not avoided, results or has the potential to result in minor
injury; and/or minor property damage.
SAFETY PRECAUTIONS
Basic safety precautions should be followed, including the following:
Ensure all local laws and codes including health and safety guidelines are met when installing
Waterlogic Equipment. Only qualified service technicians should attempt installation and service of
Waterlogic Equipment. Always read the entire operating instructions before usingthe appliance
and save these instructions for future use.
DANGER! ELECTRICAL SHOCK HAZARD. Always use a dedicated and properly earthed outlet. Unit
should be protected by residual current device (RCD) having a rated residual operating current not
exceeding 30mA. Use only Waterlogic supplied power cord. Never use extension cords or power
strips to connect unit. Do not use if the power supply cord is damaged. Always unplug from power
supply prior to servicing.
WARNING! AUTHORIZED USE ONLY. This appliance is to be used for its intended purpose as
described in this manual, and untrained individuals who use this manual assume the risk of any
resulting property damage or personal injury. This appliance can be used by children aged from 8
years and above and persons with reduced physical, sensory or mental capabilities or lack of
experience and knowledge if they have been given supervision or instruction concerning use of the
appliance in a safe way and understand the hazardsinvolved.
WARNING! SUPERVISE CHILDREN. Keep appliance and cord out of reach of children under the
age of 8years. Children under the age of 8 years must not use or play with theappliance.
WARNING! DO NOT OPERATE IF DAMAGED. Unplug for safety. Contact Waterlogic or authorized
dealer for repair, service, and installation to avoid hazards.
WARNING! HOT WATER. Unit produces Hot Water in excess of 87oC (188oF). Water above 52oC
(125oF) can cause severe burns or scalding. Keep unauthorized people and children away from the
unit to avoid accidental dispensing of hot water.

WL100 User Guide
Page 5 - Revision:EU-2020-10-13
WARNING! CONNECT TO POTABLE WATER SUPPLY. This system is to be used for water only and
is not intended for use where water is microbiologically unsafe or with water of unknown quality
without adequate disinfection. System is designed for the supplemental bactericidal treatment of
public drinking water, or other drinking water, which has been tested and deemed acceptable for
human consumption by the water provider. The system is designed to reduce normally occurring
non-pathogenic or nuisance microorganisms only. System is not intended for treatment of
contaminated water.
WARNING! TIP HAZARD. Dispenser could tip or fall causing serious injury. Always install unit on a
firm, flat, and level surface and secure the WL100 Water Treatment System to the base cabinet
with the screw provided to lock the components together. Secure unit to cabinet, wall, or floor if
needed. Never place heavy items on top of unit and never climb, stand, or hang on unit or storage
cabinet to prevent injury and damage.
WARNING! UNIT IS HEAVY. TWO PERSON LIFT REQUIRED. Transport unit empty and always use
material handling equipment or two people with proper lifting technique to reduce injury risk.
WARNING! STORE AND TRANSPORT UNIT EMPTY. ALWAYS SANITISE BEFORE USE.
The unit must be completely drained and sealed before storing to avoid stagnation and reduce
microbiological contamination (potential bacterial growth). Sanitise before use to eliminate any
potential microbiological contaminates
CAUTION! INDOOR USE ONLY. Intended for household use only. Never expose to direct sunlight,
heat sources, or ambient air temperature above 37°C (100°F) or below 2°C (35°F). Install indoors
and keep unit away from excessive humidity. Never expose to freezing temperatures. Ensure
there is adequate clearance around the unit (50mm minimum) to allow refrigeration system
condenser to dissipate heat. Warmer environments require more clearance around the unit.
Installs where the ambient temperature exceeds 27°C (80°F), require a minimum of 100mm
clearance for proper heat dissipation and efficient operation.
CAUTION! USE A WATER PRESSURE REGULATOR. Waterlogic will not be responsible for injury or
damage caused by excessive water pressure. Input or feed pressure must be 2.7Bar to 4Bar. Be
aware of any potential pressure surges caused by building/municipal pumping stations. Water
block devices and external leak detectors are strongly recommended. Locate the unit as close to
the water supply and the electrical connections aspossible to minimize risk.
CAUTION! USE PROPER SUPPLY LINES AND FEED WITH POTABLE AMBIENT WATER ONLY.
Feed water over 37°C (100°F) may damage the treatment components. Always use supply lines
with adequate pressure rating and UV resistance. Close water supply valve and contact service
representative if a leak is noticed.
Contact Waterlogic for assistance or help finding an Authorized Service Representative.

WL100 User Guide
Page 6 - Revision:EU-2020-10-13
WL100 FEATURES AND BENEFITS
Ambient, Cold and Hot Water
Ambient, Cold and Hot Water Selections to meet a wide range of customer demands.
High Volume Storage and Water Capacity
WL100 Water Treatment Systems have 2 Litre (0.44 Gallon) Cold Tank and 1.5 Litre (0.33 Gallon) Hot
Tank.
BioCote®Anti-Microbial Protection
Certain plastic, silicon, and painted surfaces surrounding the dispensing areas and
drip tray are infused with an exclusive additive called BioCote®. BioCote® provides
an effective barrier against microbes like bacteria and mould, which may cause
odour or staining.
Recessed Faucet
BioCote® Faucet (Spigot) is recessed into unit to protect from cross contamination.
Large Dispense Area
22 cm (8.5 inch) dispense height to accommodate most cup and bottle sizes.
Child Safeguard
The WL100 Water Treatment System requires user to select and hold
both Red Buttons to prevent accidental dispensing of hot water.
Energy Saving Sleep Mode
Energy Saving Sleep Mode can be programmed to turn off Heater after 3
hours of inactivity.
Stainless Steel Tanks
Peace of mind drinking from high quality, sealed stainless steel
reservoirs.
Advanced Filtration
The WL100 Water Treatment System Free Standing equipped with easy
access filter mounting tray that allows dealers to optimize filter
configuration for all water conditions.
High Capacity Removable Drip Tray
High Capacity Removable Drip Tray with BioCote® protection. Drip tray
is two-piece for easy cleaning and comes configured with optional drain
port.

WL100 User Guide
Page 7 - Revision:EU-2020-10-13
WL100 CERTIFICATIONS
Waterlogic Water Treatment Systems have been tested, and certified to rigorous CE, NSF and UL
Standards. We believe that performance testing and certifications validate Waterlogic as a world-
leader in water treatment systems.
WL100 Water Treatment System Certifications Include
UL399 –Certified Drinking Water Cooler
Intertek Labs (ETL) Certified the WL100 Water Treatment System to ANSI/UL 399
Standard for Drinking Water Coolers.
BPA Free - Waterlogic tests for BPA and declares that all of its products are Bisphenol-A
FREE and contain no harmful BPA plastics.
This system is certified by IAPMO R&T according to NSF/ANSI-61 –Certified Drinking Water
System Components, NSF / ANSI 372 –Drinking Water System Components for low Lead Content,
and CSA B483.1 - Drinking Water Treatment Systems.
Waterlogic is certified to ISO 9001:2015 –Quality Management Systems
(certified by Intertek). ISO 9001 is the internationally accepted standard
for well managed organizations that have adopted the key quality
management principles to its operations to bring consistent quality
products and a culture of continuous improvement.

WL100 User Guide
Page 8 - Revision:EU-2020-10-13
MODEL/PART DESIGNATIONS
BRAND NAME
DESCRIPTION
MODEL -
PART NUMBER
WL100 Mini
Waterlogic WL100 Mini
100-M
F-100-M-HC-TT-CS-WLT –Hot and Cold
F-100-M-CA-TT-CS-WLT –Cold and Ambient
WL100 Free Standing
Waterlogic WL100 Free Standing
100-FS
F-100-FS-HC-TT-CS-WLT –Hot and Cold
F-100-FS-CA-TT-CS-WLT –Cold and Ambient
SPECIFICATIONS
ITEM
WL100 Mini
WL100 Free Standing
Power Supply
220V/50Hz or 120V/60Hz
Water Connection
¼” Quick Connect
Cold Water Temperature
Cold Water Temperature –Factory Set Point 5°C (41°F)
Adjustable to 1.1° - 12.2°C (34° - 54° F)
Cold Tank Size
2 Litre (.44 Gallons)
Hot Water Temperature
85°C (185° F)
Hot Water Manual Reset
Overload
105°C (221° F)
Hot Tank Size
1.5 Litre (.33 Gallons)
Drip tray size
1.3 Litre (0.28 Gallons)
Recommended Service
Pressure
2.5-3.5 Bar –Always Use Pressure Regulator
Maximum Service Pressure
4 bar –Use Pressure Regulator
Rated Service Flow
1.89 Litres per minutes (0.5 gallons per minute)
Environmental Temperature
2° - 37°C (35° - 100°F)
Heater
500 W
Refrigerant Gas
R600a: 20 g|R134a: 40 g
R600a: 21 g |R134a: 45 g

WL100 User Guide
Page 9 - Revision:EU-2020-10-13
ELECTRICAL SPECIFICATIONS
ELECTRICAL SUPPLY
220V/50Hz or 120V/60Hz
120V/60Hz
COMPONENT
POWER (approximate)
Amperage (approximate)
Heater
500 Watts
4.2
Compressor
90 Watts
1.4
Control Unit
10 Watts
0.15
WL100 TOTAL
600 Watts
5.75
PRODUCT DIMMENSIONS
ITEM
WL100 Mini
WL100 Free Standing
Width/Depth/Height
345 mm x 367 mm x 450 mm
(13.58” x 14.45” x 17.74”)
345 mm x 367 mm x 1022 mm
(13.58” x 14.45” x 40.24”)
Weight (dry)
18 kg (40 pounds)
23 kg (50 pounds)

WL100 User Guide
Page 10 - Revision:EU-2020-10-13
OPERATING INSTRUCTIONS
