Wave Central AXIS TX PICO User manual

AXIS TX PICO
Mini RF Transmitter
Menu Guide
Wave Central LLC
99 Garden Parkway, Suite C., Carlisle, PA 17013
[phone] www.wavecentralrf.com
VER.3OCTOBER 2017

WARNING
The HD/SDI Video input
connector is 75 Ohms. Make
sure that the video cable(s) are
fitted with 75 Ohm connectors.
The illustration on the right is
the correct BNC connector.
Failure to do so will damage the
BNC connector on the Pico and
Pico Plus transmitters. The
customer is liable for any
damages for not adhering to this
practice.
VER.3OCTOBER 2017

AXIS PICO TRANSMITTER
USER CONTROL INTERFACE
CANCEL/BACK DISPLAY SCREEN SCROLL/
BUTTON CONFIRM BUTTON
Apply power to the unit; power up sequence will then start.
VER.3 OCTOBER 2017
1

To select a menu header, you press the button on the left of the LED display
and then using the joystick controller on the right side of the LED display,
you can scroll through the menu headings: STATUS / CONFIGURATION /
PRESET / UNIT
By selecting the “Status” menu, you can use the right joystick to scroll down
and see the parameters the Pico unit is set up for (Channel & Preset / RF
Modulation / Video / Audio)
VER.3 OCTOBER 2017
2

CONFIGURATION
There are four menus heading under the CONFIGURATION menu: RF /
VIDEO / AUDIO / DATA By pressing the joystick and scrolling down, you can
select which menu you want to see. By pressing the joystick again, you will
enter that menu.
RF
RF Output: (Should be set to On)
RF Power: (Should be set to 100mW)
VER.3 OCTOBER 2017
3

RF Frequency: (Should be set to desired channel e.g. 5900.0000 MHz)
RF Bandwidth: (Should be set to 8 MHz)
RF Modulation: (Should be set to 16-QAM)
RF FEC: (Should be set to 2/3)
VER.3 OCTOBER 2017
4

RF GUARD INT. (Should be set to 1/32)
VIDEO
VIDEO Format: (Should be set to AUTO)
VIDEO Mode: (Should be set to Ultra Low Delay)
VER.3 OCTOBER 2017
5

By pressing the little button on the left of the LED display, will get you to the
top menu level. Scroll down once click and you will see the next menu
heading.
AUDIO
AUDIO Source: (Should be set to Embedded)
AUDIO Mode: (Should be set to Stereo)
VER.3 OCTOBER 2017
6

AUDIO Encoder: (Should be set to MPEG-1 Layer2)
AUDIO Bitrate: (Should be set to 192 kbps)
AUDIO Mic P48: (Should be set to Off)
VER.3 OCTOBER 2017
7

DATA
DATA Input: (Set to Off)
DATA Baud Rate: (Set to 4800 Baud)
DATA Format: (Set to 8 Bit – None)
By pressing the little button on the left of the LED display, will get you to the
top menu level. Scroll down once click and you will see the next menu
heading.
PRESET
VER.3 OCTOBER 2017
8

There are 16 different preset files. This enables the user to change
parameters and save the changes to different files (if wanted). Normally, we
would have all the preset parameters match from one to sixteen,
the only change from one file to the other would be the frequency. Then by
changing from one preset to another, it becomes very easy to only change
the unit’s channel……. By selecting a different “PRESET” (channel). By
pressing the little button on the left of the LED display, will get you to the top
menu level. Using the right button, scroll down once click and you will see
the preset number highlighted.
UNIT
VER.3 OCTOBER 2017
9

By scrolling down, you can see the unit’s internal temperature, software
version and serial number.
By pressing the little button on the left of the LED display, will get you to the
top menu level.
VER.3 OCTOBER 2017
10

DOCUMENT DISCLAIMER
SPECIFICATIONS ARE SUBJECT TO CHANGE WITHOUT
NOTICE.
WAVE CENTRAL LLC, IS NOT LIABLE FOR DAMAGES TO
THIS OR ASSOCIATED EQUIPMENT CAUSED BY ANY
ERRORS OR OMMISSIONS CONTAINED HEREIN.
FIMIULARIZATION OF THESE MENUS IS ENCOURAGED.
